Grundig CDS 3000 DEC Bedienungsanleitung

HIFI MICRO SYSTEM

CDS 3000 DEC

CONTENTS____________________________________________

3 Set-up and safety

4 Overview

The hi-fi system controls

The back of the hi-fi system

Operating controls and subwoofer connections

The remote control

13 Connection and Preparation

16 Settings

Setting the time

Tuning and storing radio stations

Setting the alarm times

19 General functions

21 Tuner mode

Selecting the tuner input source

Selecting a preset

Stereo/mono reception

RDS information

23 CD mode

Selecting the CD input source

Inserting a CD

Playing back a CD

Display information (MP3 only)

Selecting another track

Searching for a passage within a track

Selecting albums and tracks (MP3 only)

Selecting playback modes

Creating a playlist

28 USB mode

Playing the content of an MP3 player

29 Timer mode

Switch-on timer

Sleep timer

31 Information

Cleaning the CD unit

Technical data

General information on laser devices

Troubleshooting

Environmental note

ENGLISH

Please note the following instructions when setting up the system:

The hi-fi system is designed for the playback of audio signals. Any other use

is expressly prohibited.

If you want to set up the hi-fi system on wall shelves or in cupboards, please

ensure that it is adequately ventilated. There must be at least 10 cm of space

at the side, above and behind the hi-fi system. Do not cover the hi-fi system

with newspapers, table cloths, curtains, etc.

When setting up the hi-fi and the subwoofer, remember that furniture is often

coated with various types of varnish and plastic, which often contain chemi-

cal additives. These additives may cause corrosion to the feet of the unit. This

may leave stains on the surface of the furniture which can be difficult or

impossible to remove.

If the hi-fi system is exposed to sudden changes in temperature, for example

when taken from the cold into a warm room, wait at least two hours before

using it.

Only use the hi-fi system in a moderate climate.

The hi-fi system is designed for use in dry rooms. If you do use it outdoors,

make sure it is protected from moisture such as dripping or splashing water.

Do not place the hi-fi system close to heating units or in direct sunlight, as

this will impair cooling.

Do not place any vessels containing liquids, such as vases, on the hi-fi

system or the subwoofer. Do not insert any foreign objects in the CD

compartment. Do not place any objects such as burning candles on the

hi-fi system or the subwoofer.

Do not open the hi-fi system and the subwoofer casing under any circum-

stances. Warranty claims are excluded for damage resulting from improper

handling.

Thunderstorms are a danger to all electrical devices. Even if the hi-fi system

is switched off, it can be damaged by a lightning strike to the mains or the

antenna cable. Always disconnect the mains and antenna plugs during a

storm.

If malfunctions occur due to brief mains overloads or static electricity

charges, reset the device. To do this, pull out the power plug and connect it

again after a few seconds or press »Reset«.

SET-UP AND SAFETY___________________________

TOMAIN UNIT POWER

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

°C2h

°C

TOMAINUNIT POWER

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

PROG

RESET

EQ ST/MO

TOMAIN UNIT POWER

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

TOMAIN UNIT POWER

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

! SERVICE !! SERVICE !

! SERVICE !

TV R

TOMAIN UNIT POWER

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

The hi-fi system controls

General information

ǼON/OFF Switches the hi-fi system to and from standby mode

(on the front).

The only way to completely disconnect the hi-fi system

from the mains supply is to pull out the plug.

CD Selects the CD input source. Switches the hi-fi system

from standby mode (on the front).

FLASH Selects the flash input source (USB). Switches the hi-fi

system from standby mode (on the front).

TUNER Selects the tuner input source. Switches the hi-fi system

from standby mode (on the front).

AUX Selects the AUX input source (external device).

Switches the hi-fi system from standby mode (on the

front).

s6 Changes the time forwards (on the front).

5a Changes the time backwards (on the front).

EQ Switches between the flat, pop, rock and jazz sound

settings (on the front).

OVERVIEW____________________________________________

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

ENGLISH

+ z–Adjust the volume (on the front).

CLOCK In standby mode: activates and confirms the clock

settings. In operation: displays the time for five

seconds (on the top).

Auto dimmer sensor. Automatically adjusts the

brightness of the backlight display to the brightness of

the surroundings (on the top).

yHeadphone jack for connecting a headphone set with

a jack plug (3.5 mm) on top of the device.

The loudspeakers of the hi-fi system are automatically

switched off.

AUX IN Audio input for connecting an external device with a

jack plug (3.5 mm) on top of the device.

Tuner mode

TUNER Selects the frequency band »FM« (FM) or »MW«

(medium wave) on front of the device.

5a s6 Press briefly to change the frequency in steps, press

and hold down to start a station search (on the front).

OVERVIEW____________________________________________

ALARM1

AUX IN

ON/OFF CHECK/SET CLOCK SNOOZE

ALARM1 ALARM2

SLEEP CHECK/SET ON/OFF

ST/MO Switches between stereo and mono reception

(on the front).

PROG Stores radio stations (on the front).

PRESET Selects the preset number and the stored radio

stations (on the front).

CD mode

CD compartment Slot for inserting the CD (on the front).

Removes the CD (on the front).

ıII Starts and pauses CD playback (on the front).

s6 In MP3 and CD-DA mode: press briefly to select the

next track, press and hold down to search forwards

for a particular passage (on the front).

5a In MP3 and CD-DA mode: press briefly to select the

previous track, press and hold down to search back-

wards for a particular passage (on the front).

7Ends CD playback (on the front).

PROG Stores the track when creating a playlist (on the front).

OVERVIEW____________________________________________

ON/OFF

CD FLASH

TUNER AUX

PROG

RESET

EQ ST/MO

ENGLISH

–In MP3 mode: selects the previous album (on the front).

ST/MO In MP3 mode: ends playback and switches to the CD

content display (on the front).

+In MP3 mode: selects the next album (on the front).

USB flash mode

USB interface for connecting an MP3 player using a

USB cable (on the top). Not suitable for connecting to

a PC.

Timer mode

ZALARM1 Lights up green if alarm time 1 is activated (on the top).

ALARM1 Activates and deactivates alarm time 1;

ON/OFF cancels Alarm 1 (on the top).

ALARM1 Press briefly: alarm time 1 appears, press and hold

CHECK/SET down: activates the setting for alarm time 1 (on the

top).

(

OVERVIEW____________________________________________

ALARM1

AUX IN

ON/OFF CHECK/SET CLOCK SNOOZE

ALARM1 ALARM2

SLEEP CHECK/SET ON/OFF

SNOOZE Stops the alarm for a maximum of nine minutes

(on the top).

ZALARM2 Lights up green if alarm time 2 is activated (on the top).

ALARM2 Activates and deactivates alarm time 2;

ON/OFF cancels Alarm 2 (on the top).

ALARM2 Press briefly: alarm time 2 appears, press and hold

CHECK/SET down: activates the setting for alarm time 2 (on the

top).

s6 Changes the alarm time forwards (on the front).

5a Changes the alarm time backwards (on the front).

SLEEP Sets the sleep timer (on the top).

OVERVIEW____________________________________________

ALARM1

AUX IN

ON/OFF CHECK/SET CLOCK SNOOZE

ALARM1 ALARM2

SLEEP CHECK/SET ON/OFF

ENGLISH

The back of the hi-fi system

FM Antenna Antenna socket for the roof antenna or the wire

(75 Ω)antenna supplied.

AM Antenna Antenna socket for connecting the MW antenna

supplied.

Reset Resets the hi-fi system.

To Subwoofer Socket for the subwoofer cable.

Aux Out Audio output for connecting an external device.

Battery Compartment for the backup battery

(1 x CR2032).

OVERVIEW____________________________________________

BatteryAux Out

To Subwoofer

Reset

FM Antenna

(75Ω)

MW Antenna

Operating controls and subwoofer connections

ON OFF Switches the subwoofer and the system on and off

(on the left side).

FUSE T 1,25 A Fuse switch (on the left side).

230 V~ 50/60 Hz Power cord (on the left side).

TO MAIN UNIT Connection socket for the hi-fi system cable

(on the right side).

ON ZMode indicator. Lights up green when the system

is switched on.

OVERVIEW____________________________________________

OFF

230V~

50/60Hz

FUSE

T 1,25 A TO MAIN UNIT ON
