Grundig CDS 5000 DEC Bedienungsanleitung

HIFI MICRO SYSTEM

CDS 5000 DEC

CONTENTS____________________________________________

3 Set-up and safety

4 Overview

The hi-fi system controls

LEDs on the hi-fi system

The back of the hi-fi system

The remote control

13 Connection and preparation

17 Settings

Setting the time

Setting and storing radio stations

20 General functions

21 Tuner mode

Selecting the TUNER input source

Selecting a preset

Stereo/mono reception

RDS information

23 CD mode

Selecting the CD input source

Inserting a CD

Playing back a CD

Displaying other information

Selecting another track

Searching for a passage within a track

Selecting albums and tracks (MP3 only)

Viewing the name of the album or tracks (MP3 only)

MP3 search functions

Repeating a track (Repeat One)

Repeating all the tracks on an album (MP3 only)

Playing back tracks in random order

Playing the start of each track (Intro)

29 SD/MMC and USB mode

Playing the contents of a memory card

Playing the contents of an MP3 player

30 Timer mode

Switch-on timer

Sleep timer

33 Information

Cleaning the CD unit

Technical data

General instructions on laser devices

Troubleshooting

Environmental note

ENGLISH

Please note the following instructions when setting up the system:

The hi-fi system is designed for the playback of audio signals. Any other use

is expressly prohibited.

If you want to set up the hi-fi system on wall shelves or in cupboards, please

ensure that it is adequately ventilated. There must be at least 10 cm of space

at the side, above and behind the hi-fi system.

When setting up the hi-fi, remember that furniture is often coated with

various types of varnish and plastic, which often contain chemical additives.

These additives may cause corrosion to the feet of the unit. This may leave

stains on the surface of the furniture which can be difficult or impossible to

remove.

If the hi-fi system is exposed to sudden changes in temperature, for example

when taken from the cold into a warm room, wait at least two hours before

using it.

The hi-fi system is designed for use in dry rooms. If you do use it outdoors,

make sure it is protected from moisture such as dripping or splashing water.

Do not place the hi-fi system close to heating units or in direct sunlight, as

this will impair cooling.

Do not place any vessels containing liquids, such as vases, on the hi-fi

system. Do not insert any foreign objects in the CD compartment. Do not

place any objects such as burning candles on the hi-fi system.

Do not open the hi-fi system casing under any circumstances. Warranty

claims are excluded for damage resulting from improper handling.

Thunderstorms are a danger to all electrical devices. Even if the hi-fi system

is switched off, it can be damaged by a lightning strike to the mains or the

antenna cable. Always disconnect the mains and antenna plugs during a

storm.

SET-UP AND SAFETY___________________________

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CDINFO SEARCH INTRO ALBUM

CDMODE REPEAT

1234

5678 JOG POWER

OPEN

°C2h

°C

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CDINFO SEARCH INTRO ALBUM

CDMODE REPEAT

1234

5678 JOG POWER

OPEN

EO MONO

POWER

OPEN

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CDINFO SEARCH INTRO ALBUM

CDMODE REPEAT

1234

5678 JOG POWER

OPEN

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CDINFO SEARCH INTRO ALBUM

CDMODE REPEAT

1234

5678 JOG POWER

OPEN

! SERVICE !! SERVICE !

! SERVICE !

TV R

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CDINFO SEARCH INTRO ALBUM

CDMODE REPEAT

1234

5678 JOG POWER

OPEN

The hi-fi system controls

General information

ǼPOWER Switches the hi-fi system to and from standby mode.

The only way to completely disconnect the hi-fi system

from the mains supply is to pull out the plug.

SOURCE Switches between the TUNER, CD, USB/CARD and

AUX input sources.

SNOOZE/MUTE Switches the hi-fi speakers to and from mute mode.

– z+Adjusts the volume and the settings in the jog menu.

JOG Opens the settings in the jog menu for bass, treble,

audio format, snooze in alarm mode, ticker and static

text in MP3 and RDS modes and 12/24 hour clock

format.

Ȅ+Changes the time forwards.

Ȅ–Changes the time backwards.

OVERVIEW____________________________________________

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CD INFO SEARCH INTRO ALBUM

CD MODE REPEAT

1234

5678 JOG POWER

OPEN

ENGLISH

Infrared sensor for remote control signals.

,Auto dimmer sensor. Automatically adjusts the

brightness of the backlight display to the brightness

of the surroundings.

OPEN SOpens the front flap.

yHeadphone jack for connecting a headphone set with

a jack plug (3.5 mm) under the front flap.

The loudspeakers of the hi-fi system are automatically

switched off.

AUX Audio input for connecting an external device with a

jack plug (3.5 mm) under the front flap.

Tuner mode

BAND Selects the frequency band »FM 1«, »FM 2« or »AM«

(medium wave).

89 Press and hold down to start the station search.

Press briefly to change the frequency in small steps.

1 ... 8 Stores radio stations. Selects stored radio stations.

OVERVIEW____________________________________________

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CD INFO SEARCH INTRO ALBUM

CD MODE REPEAT

1234

5678 JOG POWER

SD/MMC

USB

AUX

CD mode

CD compartmentSlot for inserting CDs.

Ejects the CD.

ıII Starts and pauses CD playback.

s6 In MP3 and CD-DA mode: press briefly to select the

next track, press and hold down to search forwards

for a particular passage.

5a In MP3 and CD-DA mode: press briefly to select the

previous track, press and hold down to search back-

wards for a particular passage.

7Ends CD playback.

CD INFO In MP3 and CD-DA mode: the elapsed playing time

of the track appears.

SEARCH In MP3 and CD-DA mode: switches between the

various search functions.

In USB and SD/MMC mode: switches between the

USB and CARD input sources.

INTRO In MP3 and CD-DA mode: for playing brief introduc-

tions to tracks.

OVERVIEW____________________________________________

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CD INFO SEARCH INTRO ALBUM

CD MODE REPEAT

1234

5678 JOG POWER

OPEN

ENGLISH

ALBUM In MP3 mode: press once to view the name of the

album, press twice to view the name of the track.

CD MODE In MP3 and CD-DA mode: plays back tracks in

random order.

REPEAT In MP3 mode: repeats a track, all the tracks on the

CD or all the tracks on the current album.

In CD-DA mode: repeats a track or the entire CD.

AS In MP3 mode: forward or reverse album selection.

USB and SD/MMC mode

USB USB interface for connecting an MP3 player using a

USB cable (under the front flap). Not suitable for

connecting to a PC.

SD/MMC Card slot for inserting a memory card (SD or MMC)

(under the front flap).

(

OVERVIEW____________________________________________

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CD INFO SEARCH INTRO ALBUM

CD MODE REPEAT

1234

5678 JOG POWER

SD/MMC

USB

AUX

Timer mode

e1Press and hold down to activate the setting for

alarm time 1.

Briefly press to switch the alarm standby for

alarm time 1 on or off.

e2Press and hold down to activate the setting for

alarm time 2.

Briefly press to switch the alarm standby for

alarm time 2 on or off.

Ȅ+Sets the alarm time forwards.

Ȅ–Sets the alarm time backwards.

SLEEP Sets the sleep timer.

SNOOZE/MUTE Depending on the setting in the jog menu, the alarm

function comes on in intervals of between 5 and 22

minutes.

OVERVIEW____________________________________________

BAND

SOURCE

SLEEP

SNOOZE/

MUTE

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

CD INFO SEARCH INTRO ALBUM

CD MODE REPEAT

1234

5678 JOG POWER

OPEN

ENGLISH

LEDs on the hi-fi system

ZALARM 2 Lights up red if the alarm is switched to

TONE signal tone for alarm time 2.

ZALARM 2 Lights up red if the alarm is switched to

MUSIC radio station, CD or USB for alarm time 2.

ZALARM 1 Lights up red if the alarm is switched to

TONE signal tone for alarm time 1.

ZALARM 1 Lights up red if the alarm is switched to

MUSIC radio station, CD or USB for alarm time 1.

ZWIDE Lights up red if the audio format »WIDE« has

been set in the jog menu.

ZSTEREO Lights up red if the audio format »STEREO« has

been set in the jog menu.

ZMONO Lights up red if the audio format »MONO« has

been set in the jog menu.

OVERVIEW____________________________________________

ALARM2

TONE ALARM2

MUSIC ALARM1

MUSIC

ALARM1

TONE WIDE STEREO MONO

ALBUM

The back of the hi-fi system

AC ~ Power cord.

The only way to completely disconnect the hi-fi

system from the mains supply is to pull out the

plug.

EXT. INT. Switches between external and internal (built-in)

FM antenna.

FM ANTENNA Antenna socket for the roof antenna or the wire

antenna supplied.

AM ANTENNA Antenna socket for connecting the MW antenna

supplied.

AUX INPUT Audio input for connecting an external device.

AUX OUTPUT Audio output for connecting an external device.

OVERVIEW____________________________________________

FM ANTENNA

ANTENNA AUX AUX

INPUTINPUT OUTPUT

75 OHMS

EXT

INT

Inhaltsverzeichnis

Andere Grundig Stereoanlage Handbücher

Grundig

Grundig Varixx UMS 4401 SPCD Bedienungsanleitung

Grundig

Grundig M25/00 Bedienungsanleitung

Grundig

Grundig K-RCD 110 Bedienungsanleitung

Grundig

Grundig UMS 2010 Bedienungsanleitung

Grundig

Grundig 01M-GHF1080-1421-01 Bedienungsanleitung

Grundig

Grundig M 37-DC Bedienungsanleitung

Grundig

Grundig M 4050 Bedienungsanleitung

Grundig

Grundig PA 6-I Bedienungsanleitung

Grundig

Grundig CDM 700 Bedienungsanleitung

Grundig

Grundig M 19-C Bedienungsanleitung

Grundig

Grundig CIRFLEXX UMS 4101 Bedienungsanleitung

Grundig

Grundig FREAXX 30 RRCD 4203 PLL Bedienungsanleitung

Grundig

Grundig VERTIGA UMS 5100 Bedienungsanleitung

Grundig

Grundig CIRFLEXX UMS 4100 Bedienungsanleitung

Grundig

Grundig RR 430 CD Bedienungsanleitung

Grundig

Grundig Ovation 3 Bedienungsanleitung

Grundig

Grundig K-RCD 120 Bedienungsanleitung

Grundig

Grundig Satellit 2400 Bedienungsanleitung

Grundig

Grundig CDM5000 Bedienungsanleitung

Grundig

Grundig Cirflexx UMS 5400 DEC Bedienungsanleitung

Grundig

Grundig DMS600B Bedienungsanleitung

Grundig

Grundig UMS 2 Bedienungsanleitung

Grundig

Grundig M 2300 DAB+ Bedienungsanleitung

Grundig

Grundig Vertiga UMS 4600 DEC Bedienungsanleitung

Beliebte Stereoanlage Handbücher anderer Marken

LG CM3330B Bedienungsanleitung

Sony

Sony SS-CEP50 Bedienungsanleitung

Cetacea Sound

Cetacea Sound CVS-II Bedienungsanleitung

Aiwa

Aiwa XR-H66MD Bedienungsanleitung

Denon

Denon UCD-250 Bedienungsanleitung

Sanyo

Sanyo DC-MX41i Bedienungsanleitung

Sharp

Sharp CD-ES600V Bedienungsanleitung

Exibel

Exibel BDX600-UK Bedienungsanleitung

Sanyo

Sanyo DC-F320 Bedienungsanleitung

Philips

Philips FWM583X Bedienungsanleitung

Sharp

Sharp CD-C462 Bedienungsanleitung

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Bedienungsanleitung

Aiwa

Aiwa XR-EM70 Bedienungsanleitung

Cyrus

Cyrus Lyric Bedienungsanleitung

Philips

Philips MCM159/98 Bedienungsanleitung

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Bedienungsanleitung

RCA

RCA RS3965SB Bedienungsanleitung

Sharp

Sharp XL-UH240 Bedienungsanleitung
