Grundig 32 GEH 4820 E Referenzhandbuch

Television

Brief Instruction

32 GEH 4820 E

ENGLISH

CONTENTS---------------------------------------------------------------------------------------------------------------

4 SETUP AND SAFETY

7 GENERAL INFORMATION

7 Special features of your television

7 Receiving digital channels

8 Important notes on environmental

protection

8 Notes on still pictures

9 PACKAGING CONTENTS

9 Standard accessories

10 CONNECTION/

PREPARATION

10 Setting up with stand

10 Preparing for mounting on the VESA

installation kit

11 Connecting the air and the mains cable

12 Inserting batteries in the remote control

13 OVERVIEW

13 Connections of the television set

14 Buttons of the remote control

14 Turning on the television and switching it

to standby mode

15 Remote control - main functions

16 Remote control - all functions

17 SETTINGS

17 First time installation and channel search...

17 Selecting language, country and

operation mode

18 Searching television channels with

satellite signal

19 Searching terrestrial digital television

channels

19 Searching cable digital television

channels

21 Changing stored channels for digital

stations

23 PICTURE AND VOLUME SETTINGS

23 Picture settings

23 Sound settings

25 FUNCTIONING OF THE TV - BASIC

FUNCTIONS

25 Basic functions

26 Changing the picture format

27 ELECTRONIC TV GUIDE

27 Electronic TV guide

28 TELETEXT MODE

28 Text mode

28 Additional functions

29 USB MODE

29 The file formats

30 Connecting external data media

31 The file browser

31 Playback – Basic functions

32 Additional playback functions

33 LANGUAGE SETTINGS

33 Changing the menu language

33 Changing the Teletext language

33 Changing the audio language

33 Changing the subtitle language

34 TIME SETTINGS

34 Time

34 Time Zone

34 Sleep timer

34 Auto standby

34 Sleep timer for OSD menu

35 LOCK SETTINGS

35 Menu Lock

35 Changing the PIN code

35 Blocking a television channel

36 Watching a blocked television channel

36 Parental Guidance

36 Locking the control panel (parental

control)

37 OTHER SETTINGS

37 Software update (USB)

37 Resetting the television to its original state

ENGLISH

CONTENTS---------------------------------------------------------------------------------------------------------------

38 USING EXTERNAL DEVICES

38 HDMI CEC

38 HDMI CEC connection functions of the

television

39 High definition – HD ready

39 Connection options

40 Connecting an external device

40 Headphones

40 Hi-fi system

41 OPERATION WITH COMMON

INTERFACE

41 What is Common Interface?

41 Inserting the CA module

41 Access control for CA module and smart

cards

42 DETAILED CHANNEL SETTINGS

42 Searching for all digital television

channels from a satellite automatically

43 Searching for digital television channels

from a satellite manually

44 LNB Settings

45 Motorized antenna setup (DiSEqC 1.2)

46 Searching for digital television channels

through cable automatically

47 Searching for digital television channels

through cable manually

47 Searching for digital television channels

through aerial automatically

48 Manual searching for digital television

channels with aerial connection

49 Tuning analogue television channels

50 Displaying signal information

51 INFORMATION

51 Service information for dealers

51 Environmental warning

51 Cleaning the TV set

51 Disposing of the packaging

52 Troubleshooting

53 GLOSSARY

54 INDEX

ENGLISH

SETUP AND SAFETY -------------------------------------------------------------------------------------

About your TV set

7 In addition to DVB-S, DVB-T and DVB-C digital

TV programmes, you can also watch analogue

TV broadcasts with your TV set.

Intended use

7 The TV set is designed for use in dry rooms.

7 Use the TV set with the supplied stand or a

suitable VESA bracket.

7 The TV set is primarily intended for the

playback of TV programmes, streaming

content and music/video material from

external devices. Any other use is strictly

prohibited.

It is not intended as an information display or

for predominant use as a computer monitor.

If a still image or a non-full-format image is

displayed for an extended period, visible

traces may remain on the screen for some

time.

This is not a defect that can be used in

warranty request.

Moving the product

Unplug the product before moving it. Disconnect

antenna cable and other external devices

connected to the TV set. If you have kept the

original product box, use it to pack the product.

If you have not kept the original product box,

wrap the product in bubble wrap or a thick

cardboard. Pay attention to avoid damages

during moving.

Safety

WARNING

Risk of electrical accident

7 Do not dismantle the TV set. Safety risk may

arise and also the guarantee of the product

can be void if the television set is opened.

7 The TV set can only be operated with the

power cable or the AC/DC adapter supplied

with the product.

7 Do not operate the TV set with a damaged

power cable/AC/DC adaptor (if supplied).

7 If the plug on the TV set has an earthing

contact, only insert the plug into a socket with

an earthing contact.

7 Plug the TV set into the mains socket only after

you have connected the external devices and

the antenna.

7 Protect the TV set from moisture. Do not place

any vessels filled with water (such as vases)

on the TV.

Fire hazard

7 To prevent the spread of fire,

keep candles or other open

flames away from this product

at all times.

7 Do not cover the ventilation

slots on the TV set.

7 Always unplug the power plug and antenna

plug during a thunderstorm.

7 Keep candles or other open flames away from

the TV set.

7 Do not expose the batteries to extreme heat

such as sunshine, fire or the like.

7 Only use batteries of the same type (brand,

size, properties). Do not use used and new

batteries together.

ENGLISH

SETUP AND SAFETY -------------------------------------------------------------------------------------

WARNING

Injuries caused by falling TV set

Never place the TV set on an unstable surface.

The TV set may fall, causing serious injury,

possibly leading to death in isolated cases.

Observe the following precautions especially to

protect the children from such negative incidents:

Only use furniture that can safely support the

TV set.

Make sure that the TV set does not protrude

beyond the dimensions of the furniture on

which it is resting.

Do not place the TV set on tall furniture that

has the risk of tipping over such as cabinets,

sideboards or bookcases. If you have no other

choice, fix the furniture and the TV set to the

wall to prevent them from tipping over.

Do not place the TV set on fabric or other

materials located between the TV set and

furniture.

Instruct children that there is danger

associated with climbing on furniture when the

TV set is to be reached.

Consider the above mentioned warnings

whenever you change the location of the TV

set.

CAUTION

Shortened service life due to high

operating temperature

7 Do not place the TV set next to heating units

or in direct sunlight.

7 To ensure adequate ventilation, maintain

clearance of at least 10 cm around the TV set.

Disposing the packaging

7 The packaging materials are dangerous for

children. Keep the packaging materials out of

the reach of children.

7 The packaging of the product is manufactured

from recyclable materials. Dispose of

by classifying in accordance with waste

regulations. Do not dispose along with normal

household waste.

Discoloration of furniture due to

rubber feet

7 Some furniture surfaces may discolor when

they come in contact with rubber. To protect

furniture, you can place a sheet made of glass

or plastic under the stand. Do not use textile

underlays or mats such as doilies.

ENGLISH

Environmental information

7 Do not dispose of batteries in

the household waste. Used

batteries must be returned to

retail stores or public collection points. You

help protect the environment in this way.

7 Be sure to dispose of packaging materials

for your product separately according to the

guidelines of local authorities so that they

can be recycled in an environmentally safe

manner.

7 Do not dispose of the product

along with normal household

waste at the end of its service

life. Take it to a recycling center

for electrical and electronic equipment.

Tips for power saving

Switch the TV set to stand-by if you will not use

it for a while. In standby mode, the TV set uses

very little energy (≤ 0.5 W).

If you do not use the TV set for an extended

period, turn it off with the power switch or

unplug the power cord from the socket. If

you turn off the device or disconnect it from

the power supply, the switch-on timer and

programmed recordings will not work.

7 Select a location so that no direct sunlight falls

on the screen. Thus, you can select a lower

backlight and provide power saving.

SETUP AND SAFETY -------------------------------------------------------------------------------------

ENGLISH

Special features of your

television

With your TV set, you can receive and watch

digital TV programmes including the High

Resolution (HD) ones over DVB-S/S2, DVB-T

and DVB-C.

At present, reception for these digital

television channels in High Definition is only

possible in some countries in Europe.

Although this TV set meets the current DVB-S/

S2, DVB-T and DVB-C standards as of April

2013, its compatibility with future DVB-S/

S2 digital satellite broadcasts, DVB-T digital

terrestrial broadcasts and DVB-C digital cable

broadcasts is not guaranteed.

This television can receive and process all

analogue and all unencrypted digital stations.

This television set has an integrated digital

and analogue receiver. The digital receiver

unit converts the signals from digital stations to

provide outstanding audio and picture quality.

The TV guide (only for digital stations) tells

you of any schedule changes at short notice,

and provides an overview of all the channels’

schedules for the next few days.

Detailed information on the individual

channels – if it is provided by the broadcaster

– is also available in the electronic 7 Day TV

Guide.

You can connect various data media such as

an external hard disk, a USB memory stick

or a digital camera to the USB socket. Using

the file browser, you can then select and play

the file formats you want (for example, MP4,

MP3 or JPEG data).

GENERAL INFORMATION -------------------------------------------------------------------

Receiving digital channels

To receive digital satellite channels (DVB-S/

S2) you need a satellite antenna.

To receive digital channels (DVB-T) you need

a digital rooftop or indoor antenna (passive

or active indoor antenna with its own power

supply).

The antenna cable of the cable TV network

that broadcast in DVB-C must be plugged into

TV in order to receive the DVB-C broadcasts.

Unlike analogue broadcasting, not every

channel has its own transmission frequency.

Instead, several channels are grouped into

what are known as bouquets on a regional or

national level.

You can find the current transmission

information on teletext from various channels,

or look at the TV guide.

Various digital television stations from private

broadcasters are scrambled (DVB-S/S2,

DVB-T and DVB-C). Watching these stations

and the recording and playback functions are

only possible with the appropriate CI module

and a SmartCard. Ask your specialist dealer.

ENGLISH

GENERAL INFORMATION -------------------------------------------------------------------

Notes on still pictures

Watching the same picture for a long time on

the screen may cause a still image remains

feebly on the background. Feeble picture(s)

on the background is originated from LCD/

LED technology and does not require any

action under guarantee. To avoid such cases

and/or minimize the impact, you may observe

the tips below.

Do not allow the same TV channel to stay on

the screen for a very long time. Channel logos

may cause this situation.

Do not allow the images, which are not full

screen, to constantly stay on the screen; if

not streamed in full screen format by the

broadcaster, you can convert the images to

full screen by changing image formats.

Higher brightness and/or contrast values will

lead this impact to appear faster; therefore,

you are recommended to watch your TV in

the lowest brightness and contrast levels that

would satisfy you.

Important notes on

environmental protection

Those items mentioned below will help you

reduce the consumption of natural resources

as well as save your money by reducing

electricity bills.

If you will not be using the TV set for several

days, it should be disconnected from the

mains for environmental and safety reasons.

TV will not consume energy in this condition.

If the TV set has main switch, it will be enough

to turn the TV off via main switch. TV will

reduce energy consumption almost to Zero

Watt.

TV consumes less energy on stand-by mode.

However, some TV sets may have features

such as on timer, that require the TV set to be

left in standby to work correctly.

TV consumes less energy when brightness is

reduced.

ENGLISH

PACKAGING CONTENTS ----------------------------------------------------------------------

Standard accessories

1 TV

2 Stand

3 Remote control

4 Battery for remote control

5 Screws and mounting instructions for stand

6 Quick Instruction Manual

Manual

ENGLISH

CONNECTION/PREPARATION -----------------------------------------------------

Setting up or hanging

7 Select a location so that no direct sunlight falls

on the screen.

Setting up with stand

7 To mount the stand, refer to the installation

instructions included.

7 Place the TV set on a hard, level surface.

Preparing for mounting on the

VESA installation kit

Contact authorised dealer to purchase the

bracket.

You will need the following:

7 A pair of scissors,

7 A cross-tip screwdriver.

Follow the installation instructions for the VESA

installation kit.

1 Place the TV set in the film on a smooth

surface with the screen facing down.

2 Cut open the film on the back side using the

scissors.

3 Connect the required cables to the

connectors of television. Refer to

"Connections" section in this manual.

4 Tie the cables so they do not hang down

onto the floor.

5 Screw the VESA bracket onto the TV set

and mount it according to its installation

instructions. VESA

Inhaltsverzeichnis

Andere Grundig Fernseher Handbücher

Grundig

Grundig CUC 7350 Bedienungsanleitung

Grundig

Grundig 32 VLE 6020 Bedienungsanleitung

Grundig

Grundig 43 GFB 6621 Bedienungsanleitung

Grundig

Grundig B50 A 850 B Bedienungsanleitung

Grundig

Grundig DIGI 100 Bedienungsanleitung

Grundig

Grundig CUC 7305 Bedienungsanleitung

Grundig

Grundig AMIRA 15 Einrichtungshandbuch

Grundig

Grundig XEPHIA 42 PW 110-6606 TOP Bedienungsanleitung

Grundig

Grundig CUC 6360 Bedienungsanleitung

Grundig

Grundig 50 GCU 8900B Bedienungsanleitung

Grundig

Grundig 40 VLE 5429 BP Bedienungsanleitung

Grundig

Grundig PlanaVision 50 PXW 130-8620 Dolby Bedienungsanleitung

Grundig

Grundig 32 VLE 565 BG Bedienungsanleitung

Grundig

Grundig XEPHIA 42 PW 110-5510 TOP Bedienungsanleitung

Grundig

Grundig CUC 1825 Bedienungsanleitung

Grundig

Grundig 65 VLX 7730 BP Bedienungsanleitung

Grundig

Grundig M 63-105 iDTV Bedienungsanleitung

Grundig

Grundig 49GFB6624 Bedienungsanleitung

Grundig

Grundig CUC1828 Bedienungsanleitung

Grundig

Grundig 55 GEU 8950 B Bedienungsanleitung

Grundig

Grundig 32 GFS 6820 Bedienungsanleitung

Grundig

Grundig CUC 6331 Bedienungsanleitung

Grundig

Grundig 43 VLE 6625 BP Bedienungsanleitung

Grundig

Grundig M82-169 PALplus Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
