Grundig TORREON 32 Bedienungsanleitung

COLOR TELEVISION

TORREON 32

LXW 82-8790 REF

CONTENTS____________________________________________

3-4 Set-up and safety

5 Connection and Preparation

5 Connecting the antenna and power cord

5 Putting batteries in the remote control

6-9 Overview

6 Connections on the television set

7 Controls on the television set

8-9 The remote control

10-15 Settings

10 Tuning television channels automatically

10-11 Changing stored channels

12-13 Picture settings

14-15 Audio settings

16-19 TV mode

16-17 Basic functions

17 Switching from the current station to the previous one

17 Entering the switch-off time (sleep timer)

18-19 PIP mode

20-21 Teletext mode

20 TOP text or FLOF text mode

20 Normal text mode

20-21 Additional functions

22-23 Convenience functions

22 Channel scan

23 Convenience functions with the »Settings« menu

24-28 Using external devices

24-26 DVD player, DVD recorder, video recorder or set-top box

27 Decoder or satellite receiver

28 Camcorder

28 Digital amplifier/AV receiver

29-30 Operation as a PC monitor

29 Connecting a PC

29 Selecting a preset for the PC

29-30 Settings for the PC

31-32 Special settings

31-32 Tuning television channels

33-35 Information

33 Technical data

33 Service information for dealers

33 Environmental note

34 Troubleshooting

35 Additional Information for units sold in the UK.

ENGLISH

SET-UP AND SAFETY___________________________

Please note the following instructions when setting up the television

set:

This television is designed to receive and display video and audio signals.

Any other use is expressly prohibited.

The ideal viewing distance is five times the diagonal screen size.

Light falling on the screen impairs picture quality.

To assure sufficient ventilation make sure there is enough space around

it in the wall unit.

The television is designed for use in dry rooms. If you do use it outdoors,

make sure it is protected from moisture such as rain or splashing water.

Never expose the television set to moisture.

Do not place any vessels such as vases on the television, as they may

spill liquid, thus presenting a safety risk.

Place the television on a hard, level surface. Do not place any objects

such as newspapers on the television or put cloth or similar items under it.

Do not place the televison close to heating units or in direct sunlight, as

this will impair cooling.

Heat build-up can be dangerous and shortens the service life of the tele-

vision. For reasons of safety, have a repairman remove any dirt in the

set from time to time.

Never open the television under any circumstances. No warranty claims

are accepted for damage caused by incorrect handling.

Make sure the power cord or the power supply unit (if provided) are not

damaged.

Only operate the television with the power supply / power cord provided.

Thunderstorms are a danger to all electrical devices. Even when the tele-

vision is switched off, it can be damaged by a lightning strike to the

mains or the antenna. Always disconnect the mains and antenna plugs

during a storm.

Use a damp, soft cloth to clean the screen. Do not use water with soap

or detergent.

Note:

Do not connect any other equipment while the device is switched on.

Switch off the other devices as well before connecting them.

Do not plug in the power cord of your device until you have connected

the external equipment and the antenna.

TV/AV

5 x

20 cm

AUDIOINPUT

RGBINPUT

HDMIINPUT

AUDIOINPUT

YPb Pr

COMPONENTINPUT

(480i/480p//720p/1080i

AV1 AV2 OPTICAL ANT.IN ACINPUT

S-VIDEOVIDEOAUDIO

AV4COMPONENT2INPUTAUDIOINPUT

PrPbY

! SERVICE !! SERVICE !

! SERVICE !

AUDIOINPUT

RGBINPUT

HDMIINPUT

AUDIOINPUT

YPb Pr

COMPONENTINPUT

(480i/480p//720p/1080i

AV1 AV2 OPTICAL ANT.IN ACINPUT

S-VIDEOVIDEOAUDIO

AV4COMPONENT2INPUTAUDIOINPUT

PrPbY

TV R

When deciding where to put the device, remember that furniture is often

coated with various types of varnish and plastic. Many of these contain

chemicals which can corrode the feet of the device, leaving marks on the

surface of the furniture which can be difficult or impossible to remove.

The screen of your LCD television meets the highest quality standards

and has been checked for pixel faults.

Despite the great care taken in manufacturing, technological reasons

make it impossible to completely discount the possibility that some pixels

may be faulty.

Provided they are within the thresholds specified by the DIN norm,

pixel faults of this kind cannot be regarded as a defect as defined by the

warranty.

SET-UP AND SAFETY___________________________

ENGLISH

Connecting the antenna and power cord

1Plug the roof antenna cable into the »ANT. IN Ä75Ω« socket on the

television.

2Plug the power cord supplied into the power socket »AC INPUT« on the

television.

3Plug the power cord into a wall socket.

Note:

Do not plug in the power cord of your device until you have connected

the external equipment and the antenna.

Putting batteries in the remote control

1Open the battery compartment by removing the lid.

2Put in the batteries (AA, 2 x 1.5 V).

Make sure the polarity is correct (as shown on the base

of the battery compartment).

3Close the battery compartment.

Note:

If the television no longer reacts properly to remote con-

trol commands, the batteries may be flat. Always remove

used batteries.

The manufacturer accepts no liability for damage caused

by leaking batteries.

Environmental note

Batteries, including those which contain no heavy metal,

should not be disposed of with household waste. Please

dispose of used batteries in an environmentally sound

manner. Find out about the legal regulations which apply

in your area.

CONNECTION AND PREPARATION_

OPTICAL ANT. IN AC

PTICAL ANT. IN AC INPUT

AUDIOINPUT

RGBINPUT

HDMIINPUT

AUDIOINPUT

YPb Pr

COMPONENTINPUT

(480i/480p//720p/1080i AV1 AV2 OPTICAL ANT.IN ACINPUT

S-VIDEOVIDEOAUDIO

AV4COMPONENT2INPUTAUDIOINPUT

PrPbY

TV R

SAT

OVERVIEW____________________________________________

Connections on the television set

HDMI INPUT HDMI socket, audio/video input (HDMI).

RGB INPUT VGA socket, video input for PC.

AUDIO INPUT Audio input for PC.

COMPONENT INPUT

AUDIO INPUT R L Audio input (YUV signal).

Y Pb Pr Video input (YUV signal).

AV 1 SCART socket (FBAS signal, RGB signal).

AV 2 SCART socket (FBAS signal).

OPTICAL Audio signal input (PCM/Dolby digital/DTS

signal, optical) for digital multi-channel

audio/video amplifier or AV receiver.

ANT. IN Ä75 ΩAntenna socket.

AC INPUT Power cord socket.

AUDIO INPUT

RGB INPUT

HDMI INPUT

AUDIOINPUT

YPb Pr

COMPONENTINPUT

(480i/480p//720p/1080i AV1 AV2 OPTICAL ANT. IN AC INPUT

S-VIDEOVIDEOAUDIO

AV4COMPONENT2INPUTAUDIOINPUT

PrPbY

AUDIO INPUT

RGB INPUT

HDMI INPUT

AUDIO INPUT

YPb Pr

COMPONENT INPUT

(480i/480p//720p/1080i) AV1 AV2 OPTICAL ANT. IN AC INPUT

ENGLISH

Controls on the television set

O/I Power switch, switches the device in and out

of standby mode.

The device is not completely disconnected

from the mains when it is switched off.

COMPONENT 2 INPUT

AUDIO INPUT R L Audio input (YUV signal).

Y Pb Pr Video input (YUV signal).

AV 3

R AUDIO L Audio input for camcorder.

Video Video input for camcorder.

S-VIDEO Video output for S-Video camcorder.

Ǽ/I Switches the television in and out of standby.

INPUT SELECT Opens the pre-selection for AV channels.

Select in the menu using »ŃPR Ľ«,

confirm with »INPUT SELECT«.

MENU Opens the »MAIN MENU« menu.

Press »ŃPR Ľ« to select an item.

Press »INPUT SELECT« to activate a function.

Press »ŃVOL Ľ« to set a function.

Press »MENU« to close the menu.

ŃVOL ĽAdjust the volume.

Select menu functions.

ŃPR ĽSwitch the television on from standby.

Channel selection.

Select a function in the menu.

OVERVIEW____________________________________________

S-VIDEOVIDEOAUDIO

AV3COMPONENT 2 INPUTAUDIO INPUT

PrPbY

TV/AV

OVERVIEW____________________________________________

The remote control

ǼSwitches the television off (standby).

Switches the television on from standby mode.

1…0 Switches the television on from standby mode.

Selects channels directly.

?Entering the switch-off time (Sleep Timer).

Selects sub-pages in teletext mode.

ESwitches between picture formats.

Page stop in teletext mode.

PIP Selects the PIP function.

AV Opens the pre-selection for AV channels. Then selec-

tion with P+ or P-.

dSound on/off (mute).

iOpens and closes the »MAIN MENU« menu.

ZSwitches to the previously selected television channel

and then back again.

P+, P- Switch the television on from standby.

Select stations step by step.

Move the cursor in the menus up and down.

ǸǷ Adjust the volume.

Move the cursor left/right.

OK Opens the channel list.

Activates various functions.

TXT Switches between teletext and TV modes.

TV-G This button has no function.

zSelects various picture settings.

Scrolls back a page in teletext mode.

ȄDisplays the time.

Selects a page in teletext mode.

ǷǷFreeze-frame.

Selects the chapter in teletext mode.

FSelects various sound settings.

Selects the topic in teletext mode.

PIP

TV-G

Tele Pilot 170 C

SCAN

PAT SP

DVD

AUX

TOP

PIP

TV-G

Tele Pilot 170 C

SCAN

PAT SP

DVD

AUX

TOP

ENGLISH

OVERVIEW____________________________________________

SCAN Selects the channel scan function.

Reveals answers in teletext mode.

PAT Selects the double window function.

Shows the TC picture and teletext simultaneously in

teletext mode.

SSwitches to double character size in teletext mode.

Changes the size of the inset picture.

PChanges the position of the inset picture.

DR, DVD Switches to operation of a GRUNDIG digital receiver,

GRUNDIG digital receiver with hard disk (PDR),

GRUNDIG DVD player or GRUNDIG DVD recorder.

Keep the appropriate button (»DR«, »DVD«) pressed

down. Then press the appropriate button.

Note:

The »DR« button has been programmed for operating

a GRUNDIG digital receiver (remote control level 1).

The »DVD« button has been programmed for opera-

ting a GRUNDIG DVD player.

You can change this programming, see »AUX« button.

The functions available depend on the model of the

device you are using.

Just try it out.

AUX Programming the remote control for the operation of

external devices.

Press »AUX« and hold it down and press three num-

ber buttons to enter the code:

»1«, »2«, »3« for a GRUNDIG DVD player.

»4«, »5«, »6« for a GRUNDIG DVD recorder.

»1«, »4«, »7« for a GRUNDIG digital receiver (remote

control level 1).

»2«, »5«, »8« for a GRUNDIG digital receiver (remote

control level 2).

»3«, »6«, »9« for a GRUNDIG digital receiver with

hard disk (PDR).

PIP

TV-G

Tele Pilot 170 C

SCAN

PAT SP

DVD

AUX

TOP

PIP

TV-G

Tele Pilot 170 C

SCAN

PAT SP

DVD

AUX

TOP

SETTINGS ______________________________________________

Tuning television channels automatically

The television is equipped with automatic tuning.

You start the search and can then sort the television stations into

your order of preference.

There are 99 presets, to which you can assign television stations

from the antenna or from the cable connection.

1Switch on the television with »O/I« on the television set, then

press »P+« on the remote control.

– The »Sprache« (Language) menu appears when the device is

first switched on.

Hint:

If the »Language« menu does not appear on the screen, follow

the instructions on retuning all television channels on page 32.

2Select language with »P+«, »P-«, »Ǹ« or »Ƿ« and press

»OK« to confirm.

– The »Country« menu appears.

3Select the country with »P+« or »P-« and press »OK« to confirm.

Note:

If your country is not displayed, select ». . . . . .«..

– The automatic search may last a few minutes, depending on

the number of television stations found.

– After the search the television switches to preset 1 and the

»Preset list« menu appears.

Changing stored channels

If channels were stored with the automatic channel search during the

tuning of the television channels, you can delete them. You can also

store stations in a different preset, change or enter the name of a

station, as well as skip channels.

Deleting stations

1In the »Preset list« menu, select the station to be deleted by pres-

sing »P+«, »P-«, »Ǹ« or »Ƿ«.

2Highlight the channel with »z« (red).

3Delete the channel with »z« (red).

Note:

To delete other television stations, repeat steps 1to 3.

Sprache

English Svenska

Deutsch Suomi

Français Nederlands

Italiano о усск

Español Norsk

Português Polski

Dansk âe‰tina

Auswählen Zurück

u. bestätigen Ende

●

Preset list

Delete Back

Select

Skip Exit

and edit Move

1 ARD

2 ZDF

3 BR

4 RTL

5 SAT 1

6 PRO 7

7 BR

8 TEL5

11 S

12 ---- S

13 ---- S

14 ---- S

15 ---- S

16 ---- S

17 ---- S

18 ---- S

19 ---- S

20 ---- S

21 ---- S

22 ---- S

23 ---- S

24 ---- S

●

Country

Select Back

and confirm Exit

Germany

France

Espana

Portugal

Switzerland

Sweden

......

●

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Grundig Fernseher Handbücher

Grundig

Grundig Davio 14 P 37-4501 FR/Text Bedienungsanleitung

Grundig

Grundig 55 GUB 8678 Bedienungs- und Wartungshandbuch

Grundig

Grundig Xentia LXW 102-8625 REF Bedienungsanleitung

Grundig

Grundig 55 VLE 7630 WP Bedienungsanleitung

Grundig

Grundig CUC 6331 Bedienungsanleitung

Grundig

Grundig VISION 7 32-7851 T Bedienungsanleitung

Grundig

Grundig 02 GBH 4719 Bedienungsanleitung

Grundig

Grundig 32 VLE 4500 BM Bedienungsanleitung

Grundig

Grundig DAVIO 37 P 37-2201 Bedienungsanleitung

Grundig

Grundig 43GFB6626 Bedienungsanleitung

Grundig

Grundig Fire TV 32 VLE 6010 Bedienungsanleitung

Grundig

Grundig 43 GFB 6827 Bedienungsanleitung

Grundig

Grundig 48 VLX 8582 SP Bedienungsanleitung

Grundig

Grundig 49GFB6626 Bedienungsanleitung

Grundig

Grundig CUC 1836 Bedienungsanleitung

Grundig

Grundig 43 GHU 7910 B Bedienungsanleitung

Grundig

Grundig XEPHIA 42 PW 110-5501 TOP Bedienungsanleitung

Grundig

Grundig CUC 2032 Bedienungsanleitung

Grundig

Grundig T 51-830 Multi/ICN Bedienungsanleitung

Grundig

Grundig APOLLO 42 PW 110-7505 TOP Bedienungsanleitung

Grundig

Grundig 65 GHU 8000 Bedienungsanleitung

Grundig

Grundig 22 VLE 525 BG Bedienungsanleitung

Grundig

Grundig 55 GUB 8688 A Bedienungs- und Wartungshandbuch

Grundig

Grundig M 70-281/8 IDTV/LOG Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
