INSTALLATION GUIDE - HIGHLIGHTER®DL
MODULAR ARCHITECTURAL DELINEATION LED LIGHTING SYSTEM
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
IG-HIGHLIGHTER-DL, 290211, 2021-04-05 | Page 2 / 14
gvalighting.com
WARNING
Do not attempt to install or use Luminaire until you read and understand this guide and safety
labels.
Luminaires must be installed by a qualified professional in accordance with all national and
local electrical and construction codes and regulations.
Ensure that main power supply is OFF before installing or wiring luminaire(s).
Do not exceed specified voltage and current input.
Do not use luminaires with a damaged lens, body, or cable.
Not heeding cautions may result in a hazardous situation which can cause equipment and
property damage, personal injury, or death.
CAUTION
Do not exceed the specified voltage and current input.
Do not exceed the maximum number of specified fixtures in a light run. Doing so will result in a
current overload.
GVA Luminaires have no serviceable parts. Do not attempt to open the units.
Do not hot swap! Ensure power supply is off before connecting or disconnecting fixtures.
Do not stare into beam or view directly with optical instruments.
Do not splice GVA Lighting provided leader cables and/or jumper cables.
Unauthorized feild repairs will void warranty.
TABLE OF CONTENTS
A. - Warnings and Cautions
1. - System Diagrams
1.1. - INFINITY® Technology Typical System Diagram
1.2. - ELV/ELV48 Typical System Diagram
2. - Mechanical
2.1. - Required Hardware and Hole Pattern
2.2. - Mounting Profile
2.3. - First Luminaire & Leader Cable
2.4. - HIGLIGHTER®Module Connection
2.5. - Next / Last Luminaire & Connector Cap
2.6. - System Check
2.7. - Module Removal
2.8. - Round and Flat Diffusers
2.9. - NICHE Cover Lens
2.10. - Endcaps - Standard - Optional
2.11. - Endcaps - NICHE - Optional
