GW Instek C-1200 Bedienungsanleitung

LoRa Tester

C-1200

USER MANUAL

ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by

photocopied, reproduced or translated to another language without

prior written consent of Good Will company.

The information in this manual was correct at the time of printing.

However, Good Will continues to improve products and reserves the

rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

Table of Contents

SAFETY INSTRUCTIONS .................................................. 5

Safety Symbols ..................................................... 5

Safety Guidelines .................................................. 6

GETTING STARTED.......................................................... 9

C-1200 Introduction.............................................. 10

Appearance........................................................... 12

First Use Instructions ........................................... 14

BASIC OPERATION ........................................................ 26

Frequency Settings................................................ 27

Span Settings ....................................................... 29

Amplitude Settings ............................................... 30

Bandwidth Settings............................................... 31

Sweep ................................................................... 33

Trigger .................................................................. 35

ADVANCED OPERATION ................................................ 37

Measurement........................................................ 38

Manual Calibration ............................................... 59

REMOTE CONTROL ....................................................... 60

Interface Configuration ......................................... 61

Command Syntax .................................................. 64

Status Registers .................................................... 70

Command List ...................................................... 77

PC SOFTWARE ..............................................................189

Software Installation ............................................. 190

Remote Control Interface Setting .......................... 190

C-1200 User Manual

USING C-1200 PC SOFTWARE .......................................197

Transmitter (TX) Mode .........................................198

Receiver (RX) Mode ..............................................210

MP Test................................................................. 221

Specification Pretest Mode ...................................224

IO Extension .........................................................232

APPENDIX ....................................................................233

ASCII to Binary Coded Decimal Table ....................233

C-1200 Specifications............................................236

C-1200 Dimensions...............................................246

IO Extension Dimensions .....................................247

Declaration of Conformity .....................................248

SAFETY INSTRUCTIONS

This chapter contains important safety

instructions that you must follow during

operation and storage. Read the following before

any operation to ensure your safety and to keep

the instrument in the best possible condition.

Safety Symbols

These safety symbols may appear in this manual or on the

instrument.

WARNING

Warning: Identifies conditions or practices that

could result in injury or loss of life.

CAUTION

Caution: Identifies conditions or practices that

could result in damage to the instrument or to

other properties.

DANGER High Voltage

Attention Refer to the Manual

Earth (ground) Terminal

Frame or Chassis Terminal

Do not dispose electronic equipment as unsorted

municipal waste. Please use a separate collection

facility or contact the supplier from which this

instrument was purchased.

C-1200 User Manual

Safety Guidelines

General

Guideline

CAUTION

Do not place any heavy object on the instrument.

Avoid severe impact or rough handling that leads

to damaging the instrument.

Do not discharge static electricity to the instrument.

Use only mating connectors, not bare wires, for the

terminals.

Ensure signals to the RF input do not exceed

+30dBm.

Do not block the cooling fan opening.

Do not disassemble the instrument unless you are

qualified.

(Measurement categories) EN 61010-1:2010 specifies the

measurement categories and their requirements as follows. The

instrument falls under overvoltage category II.

Overvoltage category IV is for equipment installed at or near

the origin of supply to a building, between the building

entrance and the main distribution board.

Overvoltage category III is for equipment intended to form

part of a building wiring installation.

Overvoltage category II is for equipment intended to be

supplied from the building wiring.

Overvoltage category I is not relevant to this standard.

Power Supply

WARNING

AC Input voltage range: 100V~240V (Max. 82W)

Frequency: 50 - 60Hz

To avoid electrical shock connect the protective

grounding conductor of the AC power cord to an

earth ground.

SAFETY INSTRUCTIONS

Power Cord

Requirements

The connector that plugs into the socket outlet must

be a grounding-type male plug designed for use in

your region. It must have certification marks showing

certification by an agency in your region. The

connectors that plug into the Appliance Inlets (AC

receptacle) must be an IEC 60320, sheet C13, female

connector. If the power cord supplied with the system

does not meet requirements for use in your region

discard the cord, do not use with adapters.

Cleaning

Disconnect the power cord before cleaning.

Use a soft cloth dampened in a solution of mild

detergent and water. Do not spray any liquid.

Do not use chemicals containing harsh material

such as benzene, toluene, xylene, and acetone.

Operation

Environment

Location: Indoor, no direct sunlight, dust free,

almost non-conductive pollution (Note below)

Temperature: 5°C to 45°C

Humidity: <90% (non condensing)

(Pollution Degree) EN 61010-1:2010 specifies the pollution

degrees and their requirements as follows. The instrument falls

under degree 2.

Pollution refers to “addition of foreign matter, solid, liquid, or

gaseous (ionized gases), that may produce a reduction of

dielectric strength or surface resistivity”.

Pollution degree 1: No pollution or only dry, non-conductive

pollution occurs. The pollution has no influence.

Pollution degree 2: Normally only non-conductive pollution

occurs. Occasionally, however, a temporary conductivity

caused by condensation must be expected.

Pollution degree 3: Conductive pollution occurs, or dry, non-

conductive pollution occurs which becomes conductive due

to condensation which is expected. In such conditions,

equipment is normally protected against exposure to direct

sunlight, precipitation, and full wind pressure, but neither

temperature nor humidity is controlled.

C-1200 User Manual

Storage

environment

Location: Indoor

Temperature: -20°C to 70°C

Humidity: <90% (non condensing)

Altitude:< 2,000 meters

Disposal

Do not dispose this instrument as unsorted municipal

waste. Please use a separate collection facility or

contact the supplier from which this instrument was

purchased. Please make sure discarded electrical

waste is properly recycled to reduce environmental

impact.

Lifting and

carrying

WARNING

Use safe practices as follows when lifting.

Do not place any object on top of rack- mounted

devices.

GETTING STARTED

This chapter provides a brief overview of the C-

1200, the package contents, instructions for first

time use and an introduction to the front panel,

rear panel.

C-1200 Introduction .................................................... 10

Main Features.................................................................................... 10

Accessories ........................................................................................ 11

Appearance ................................................................. 12

Front Panel......................................................................................... 12

Rear Panel .......................................................................................... 13

First Use Instructions.................................................. 14

Power Up ........................................................................................... 14

Power Down....................................................................................... 15

System status..................................................................................... 16

Firmware Update ............................................................................... 19

Method 1: Via USB flash drive...................................20

Method 2: Through TFTP ..........................................21

C-1200 User Manual

C-1200 Introduction

C-1200, a LoRa tester with 4 channels TRx

ports supporting both Sub-GHz and 2.4

GHz frequency band, is able to provide

complete parameter setting of both LoRa

and (G) FSK modulated signals.

Note

This document applies to device software version

V3.03.180424_25. The software version can be

found by the command: SYSTem: VERSion:

SOFTware?

Main Features

Performance

9kHz~3.25GHz bandwidth

1Hz resolution

Nominal RBW accuracy of ±5% <1MHz,

±8% =1MHz

Video bandwidth 1Hz~1MHz (1-3-10 steps)

Amplitude measurement range: DANL~30dBm

(frequency dependent)

Input attenuation: 0 ~ 50dB, 1dB steps

Phase noise: < -88dBc/Hz@1GHz, 10kHz,

typical

Features

1-3-10 step increments for RBW bandwidth

Built-in preamplifier

2FSK measurement

Demodulation analyzer
