3. Connect Mesh 2 Channel Interface
The Connect Mesh 2 Channel Interface can be connected to the existing electrical installation. This allows it to add
to your Bluetooth Mesh Network. The interface oers consumer a possibility of switching an output (ON/OFF) and
reading in 2 key signals at the inputs. As delivered, there is no connection between the output and the inputs. This
only has to be created by programming in the app, if desired.
3.1. General information
230 V Ports
Sensor Ports
[image 3.1.1]
3.2. Setup
IMPORTANT
The connection may only be carried out by a Professional electrician. For details on the connection, please
refer to the mounting instructions.
After the power supply is switched ON, the status LED will ash. Afterwards, the device can be provisioned as
described within the Connect Mesh App.
3.3. Switching a group on/o
If the Connect Mesh 2 Channel Interface is added within the Häfele Connect Mesh App, there will appear two
dierent devices in your device list. One light (the light you connected to the Output port) and one switch device
(which represents the switches you connected to the sensor ports). Both switches can be added to an individual
group to toggle the group on and o. In addition, scenes within groups can be triggered.
3.4. Dimming
If the inputs of the Connect Mesh 2 Channel Interface are added to a device group, you can use it to dim the brightness
of the light. By keeping the switch pressed, the light will start getting brighter. Release the switch press at a certain level of
light brightness to set it. The lights will lower their brightness until they switched o completely.
IMPORTANT
The light which is connected to the Interface output cannot be dimmed, but only switched ON and OFF.
732.28.427
732.28.427
HDE 25.06.20
HDE 25.06.20
5/5
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
3.5. Update Mode
Option 1: Update Mode by App
• In case the rmware is outdated, the user will be notied inside the Connect Mesh App. There the user can start and
perform the update of the mesh device (more information in the specic Häfele Connect Mesh App).
Option 2: Manual Update by Power On/O
• Start the device (red status LED ashes).
• Switch ON/OFF your Connect Mesh 2 Channel Interface 4 times at consistent intervals of 2 seconds each.
(Attention: Wait until the red status led is o, before switching ON again.)
• The status LED will light constantly to signify the device is in Update Mode and can be updated in the Häfele Connect
Mesh App.
3.6. Reset
Option 1: Reset by App
• In case the device is provisioned and connected through the app, the user can reset the mesh device via the Connect
Mesh App (more information in the specic Häfele Connect Mesh App).
Option 2: Manual Reset by Power On/O
• Switch ON/OFF your Connect Mesh 2 Channel Interface 8 times at consistent intervals of 2 seconds each.
(Attention: Wait until the red status led is o, before switching ON again.)
• The ashing LED will identify that the device is again in provisioning mode.
Now use the Häfele Connect Mesh App to provision the device.
3.7. Status LED
Status LED Behavior Meaning
Off The Connect Mesh 2 Channel Interface is either switched OFF or check your
connections again.
Flashing The Connect Mesh 2 Channel Interface is in provisioning mode and is ready to be
added to an existing BLE Mesh network.
On The Connect Mesh 2 Channel Interface is either in normal operation mode or in
OTA update mode.
If it is OTA update mode, it will remain in OTA update mode for 60 seconds or until
the power is uninterrupted.
