Haier AC142ACNAC Bedienungsanleitung

HCFU-14CL03/R1 (AC142ACNAC+AU142ABNAC)

HCFU-18CL03/R1 (AC182ACNAC+AU182ABNAC)

HCFU-24CL03/R1 (AC242ACNAC+AU242ABNAC)

HCFU-28CM03/R1 (AC28NACNAC+AU28NABNAC)

HCFU-36CM03/R1 (AC36NACNAC+AU36NABNAC)

HCFU-42CM03/R1 (AC42NACNAC+AU42NABNAC)

MANUAL CODE: SYJS-006 EDITION:2002.12.31.

Haier Group

Super low outdoor ambient cooling at -15

Auto-restart function

Group control(with a group controller)

Auto-changeover

Compact design of indoor unit

Weekly timing(with a weekly timer)

With new environment friendly refrigerant R407C

Features

Service Manual

Commercial Air Conditioning

Convertible Type Low Ambient Cooling Series

CONTENTS

1. Description of Products & Features…………………...…….1

2. Specifications…………………………. ………………...……3

3. Safety precaution…………………………..………………….9

4. Net dimensions of indoor and outdoor unit………………...11

5. Installation instructions ……………………. ………………..17

6. Parts and functions …………………………..…… ..……….28

7. Remote controller functions………………………….………31

8. Refrigerant diagram…………………………..……………....43

9. Electrical control functions……………………………………44

10. Diagnostic information(trouble shooting)…………….……51

11. Electrical data.........................................…………….……56

12. Exploded views and parts lists...............……………. ……67

13. Perdormance curves……………............................... ……87

14. Noise level charts.....……………............................... ……93

15. Air velocity distribution …………............................... ……94

CONTENTS

Contents……..............................................…...………...…….1

- 1 -

1 DESCRIPTION OF PRODUCTS & FEATURES

1.1 Products coding direction

Old code

H CFU – 42 CM 03 /R1

Refersto HFC refrigerant

Power: 03(230V/50Hz).04(240V/50Hz).12(115V/60Hz).13(230v/60Hz)

Low ambient cooling

“H” refer to cooling and heating, ”C” refer to cooling only

Nominal cooling capacity (BTU/h), 42=42000BTU/h

Indoor and outdoor unit code: "CF" Convertible type; "U" Outdoor unit

“H” means “Haier”

New code

A C42 NA C NAC

Climate type: T1(see table 1), and -15 degree cooling

Design number (Astands for fix speed type)

Product type: A stands for heat pump type, refrigerant is R22

B stands for heat pump type, refrigerant is R407

M stands for cool only type, refrigerant is R22

N stands for cool only type, refrigerant is R407

Appearance character

Product series: one by one type

Applicable voltage: 2 stands for 220-240V/50Hz,4 stands for 220v/60Hz

N stand for 380V/50Hz

Cooling / Heating capacity,42=42000BTU/h

Product type : “B” stands for cassette type, “C” stands for convertible

type, ”D” stands for duct, “S” stands for split type, ”Q” stands for chiller

system, "E" stands for ceiling concealed type, “U” stands for outdoor unit

Air conditioner

1.2 Brief Introduction to T1 T2 T3 working condition

Table1

Climate type

Type of Air Conditioner T1 T2 T3

Cool only 18 43 10 35 21 52

Heat pump -7 43 -7 35 -7 52

Electricity heating 43 35 52

1.3 Operating Range of air conditioners

Low ambient cooling

Operation Operation Range Outside / Inside

Cooling -150C – 43oC

Dehumidifying -150C – 43oC

DESCRIPTION OF PRODUCTS & FEATURES

- 2-

1.4Products characteristic

(2).HFC refrigerant technology

To protect the environment, we have adopted the HFC refrigerant. The HFC R407C is of zero ODP

for the purpose of environmental protection.

(3).Ceiling/console convertible,flexible installation,convenient maintenance,saving

the users' expenditures

(4).Adopting single-phase or three-phase power supply,applicable for household

and commercial usage

(5).Dual air outlet design,floor air blowing,accelerating the indoor air circulation,

quick temperature adjustment

(6).Long-distance air blowing,large power,large cooling/heating ratio

(7).Intelligent remote control,convenient and flexible control

(8).Super-slim indoor unit design,luxury and nice-looking,saving space,harmonious

and unitive with the indoor environment

(9).Adopting screw-fastening for the air inlet grill,firmly fixed;adopting slipway

insert-lock fastening method for the filter screen,convenient cleaning or replacing

the filter screen without opening the air inlet grill.

The system can run the cooling operation at the low ambient temperature -15

(1).Low ambient temperature cooling technology

(10).Group control,units up to 128 sets can be controlled

DESCRIPTION OF PRODUCTS & FEATURES

- 3-

Function

Cooling Heating

Capacity BTU/h

14000 /

W2000 /

EER or COP BTU/W 7.00 /

Dehumidifying capacity 10‐³×m³/h

Power source PH-V-Hz

Running current/Starting current A

Power cable

Unit model (color)

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Control type (wireless/wired)

Fresh air hole dimension mm

Noise level (H-M-L) dB(A)

External mm×mm×mm

Package mm×mm×mm

Unit model (color)

Compressor Model / Manufacture

Type

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Refrigerant control method

Noise level H-M-L dB(A)

Refrigerant Type

Charge kg

Pipe Liquid mm

Gas mm

Connect method

Drop m

Piping length m

Item Model HCFU-14CL03/R1

1PH, 220V-230V,50HZ

Indoor unit

AC142ACNAC /WHITE

CENTRIFUGAL×2

1070/1000/940

900

TP2M/9.52

2/2

0.199

2-7

Dimension

L×W×H

900×655×199

1150×750×300

PVC 18/20

wired

48/44/38

Weight (net / gross) 30/39

Panel

Dimension

L×W×H

Weight (net / gross) /

Outdoor unit

AU142ABNAC / WHITE

ZR34K3E-TFJ-522 / COPELAND

scroll

Axial-flow×1

820

700/-/-

TP2M/9.52

2/2

0.225

43-60

Dimension

L×W×H

810×288×680

960×406×760

PVC,18/20

Capillary

Defrosting

Auto

15.88

FLARED

52/-/

Four way valve

Between

I.U. & O.U.

MAX :5

MAX :15

Total power input

Weight (net / gross) 59/66

Piping

R407C

1.8

6.35

2 SPECIFICATIONS

9.4/40.7

SPECIFICATIONS

- 4-

Function

Cooling Heating

Capacity BTU/h

18000 /

W2000 /

EER or COP BTU/W 9.00 /

Dehumidifying capacity 10‐³×m³/h

Power source PH-V-Hz

Running current/Starting current A

Power cable

Unit model (color)

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Control type (wireless/wired)

Fresh air hole dimension mm

Noise level (H-M-L) dB(A)

External mm×mm×mm

Package mm×mm×mm

Unit model (color)

Compressor Model / Manufacture

Type

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Refrigerant control method

Noise level H-M-L dB(A)

Refrigerant Type

Charge kg

Pipe Liquid mm

Gas mm

Connect method

Drop m

Piping length m

Item Model HCFU-18CL03/R1

1PH, 220V-230V,50HZ

Indoor unit

AC182ABNAC /WHITE

CENTRIFUGAL×2

500/450/380

1050

TP2M/9.52

2/2

0.199

2-7

Dimension

L×W×H

990×655×199

1160×760×310

PVC 18/20

wired

43/42/40

Weight (net / gross) 29/39

Panel

Dimension

L×W×H

Weight (net / gross) /

Outdoor unit

AU182ABNAC / WHITE

ZR34K3E-TFJ-522 / COPELAND

scroll

Axial-flow×1

820

700/-/-

TP2M/9.52

2/2

0.225

43-60

Dimension

L×W×H

810×288×680

960×406×760

PVC,18/20

Capillary

Defrosting

Auto

15.88

FLARED

52/-/46

Four way valve

Between

I.U. & O.U.

MAX :5

MAX :15

Total power input

Weight (net / gross) 58/66

Piping

R407C

1.80

6.35

9.3/46.0

SPECIFICATIONS

- 6-

Function

Cooling Heating

Capacity BTU/h

24000 /

W2800 /

EER or COP BTU/W 8.57 /

Dehumidifying capacity 10‐³×m³/h

Power source PH-V-Hz

Running current/Starting current A

Power cable

Unit model (color)

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Control type (wireless/wired)

Fresh air hole dimension mm

Noise level (H-M-L) dB(A)

External mm×mm×mm

Package mm×mm×mm

Unit model (color)

Compressor Model / Manufacture

Type

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Refrigerant control method

Noise level H-M-L dB(A)

Refrigerant Type

Charge kg

Pipe Liquid mm

Gas mm

Connect method

Drop m

Piping length m

Item Model HCFU-24CL03/R1

1PH,220V~230V,50Hz

Indoor unit

AC242ACNAC /WHITE

CENTRIFUGAL×2

1300/1200/1000

1300

TP2M/9.52

2/2

0.221

2-7

Dimension

L×W×H

1320×715×235

1380×770×300

PVC 18/20

wired

35/32/29

Weight (net / gross) 40/57

Panel

Dimension

L×W×H

Weight (net / gross) /

Outdoor unit

AU242ABNAC / WHITE

ZR34K3E-TFJ-522 / Copeland

scroll

Axial-flow×1

840/-/-

3240

TP2M/9.52

3/3

0.62

43-60

Dimension

L×W×H

948×830×340

1050×979×440

PVC,18/20

Capillary

Defrosting Auto

15.88

FLARED

58/-/50

Four way valve

Between

I.U. & O.U.

MAX :15

MAX : 30

Total power input

Weight (net / gross) 70/85

Piping

R407C

1.85

9.52

12.5/60.1 /

SPECIFICATIONS

Function

Cooling Heating

Capacity BTU/h

28000 /

W2800 /

EER or COP BTU/W 10.0 /

Dehumidifying capacity 10‐³×m³/h

Power source PH-V-Hz

Running current/Starting current A

Power cable

Unit model (color)

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Control type (wireless/wired)

Fresh air hole dimension mm

Noise level (H-M-L) dB(A)

External mm×mm×mm

Package mm×mm×mm

Unit model (color)

Compressor Model / Manufacture

Type

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Refrigerant control method

Noise level H-M-L dB(A)

Refrigerant Type

Charge kg

Pipe Liquid mm

Gas mm

Connect method

Drop m

Piping length m

Item Model HCFU-28CM03/R1

3N,380V~400V,50Hz

Indoor unit

AC28NACNAC /WHITE

CENTRIFUGAL×2

1300/1200/1000

1300

TP2M/9.52

2/2

0.221

2-7

Dimension

L×W×H

1320×715×235

1380×770×300

PVC 18/20

wired

35/32/29

Weight (net / gross) 40/57

Panel

Dimension

L×W×H

Weight (net / gross) /

Outdoor unit

AU28NABNAC / WHITE

ZR34K3E-TFJ-522 / Copeland

scroll

Axial-flow×1

840/-/-

3240

TP2M/9.52

3/3

0.62

43-60

Dimension

L×W×H

948×830×340

1050×979×440

PVC,18/20

Capillary

Defrosting Auto

15.88

FLARED

58/-/50

Four way valve

Between

I.U. & O.U.

MAX :15

MAX : 30

Total power input

Weight (net / gross) 74/89

Piping

R407C

1.85

9.52

12.5/60.1 /

SPECIFICATIONS

Function

Cooling Heating

Capacity BTU/h

36000 /

W3600 /

EER or COP BTU/W 10.0 /

Dehumidifying capacity 10‐³×m³/h

Power source PH-V-Hz

Running current/Starting current A

Power cable

Unit model (color)

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Control type (wireless/wired)

Fresh air hole dimension mm

Noise level (H-M-L) dB(A)

External mm×mm×mm

Package mm×mm×mm

Unit model (color)

Compressor Model / Manufacture

Type

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Refrigerant control method

Noise level H-M-L dB(A)

Refrigerant Type

Charge kg

Pipe Liquid mm

Gas mm

Connect method

Drop m

Piping length m

Item Model HCFU-36CM03/R1

3N, 380V-400V,50HZ

Indoor unit

AC36NACNAC /WHITE

CENTRIFUGAL×3

1300/1200/1000

1600

TP2M/9.52

3/3

0.338

2-7

Dimension

L×W×H

1920×715×235

1980×761×295

PVC 18/20

wired

56/54/52

Weight (net / gross) 46/52

Panel

Dimension

L×W×H

Weight (net / gross) /

Outdoor unit

AU36NABNAC / WHITE

ZR34K3E-TFJ-522 / COPELAND

scroll

Axial-flow×2

840/-/-

6000

TP2M/9.52

5/5

0.92

43-60

Dimension

L×W×H

948×1225×340

1050×1375×440

PVC,18/20

Capillary

Defrosting Auto

19.05

FLARED

52/-/46

Four way valve

Between

I.U. & O.U.

MAX :30

MAX : 50

Total power input

Weight (net / gross) 85/111

Piping

R407C

3.1

9.52

6.4/32 /

SPECIFICATIONS

Function

Cooling Heating

Capacity BTU/h

42000 /

W4600 /

EER or COP BTU/W 9.1

Dehumidifying capacity

10‐³×m³/h

Power source PH-V-Hz

Running current/Starting current A

Power cable

Unit model (color)

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Control type (wireless/wired)

Fresh air hole dimension mm

Noise level (H-M-L) dB(A)

External mm×mm×mm

Package mm×mm×mm

Unit model (color)

Compressor Model / Manufacture

Type

Fan Type × Number

Speed r/min

Air-flow(H-M-L) m³/h

Heat exchanger Type / Diameter

Flow

Total area m²

Temp. scope

External mm×mm×mm

Package mm×mm×mm

Drainage pipe (material , I.D./O.D.)

Refrigerant control method

Noise level H-M-L dB(A)

Refrigerant Type

Charge kg

Pipe Liquid mm

Gas mm

Connect method

Drop m

Piping length m

Item Model HCFU-42CM03/R1

3N, 380V-400V,50HZ

Indoor unit

AB42NACNAC /WHITE

CENTRIFUGAL×3

980/880/820

2040

TP2M/9.52

3/3

0.199

2-7

Dimension

L×W×H

1920×715×235

1980×761×295

PVC 18/20

wireless

43/41/39

Weight (net / gross) 46/53

Panel

Dimension

L×W×H

Weight (net / gross) /

Outdoor unit

AU42NAANAC / WHITE

ZR34K3E-TFJ-522 / COPELAND

scroll

Axial-flow×2

840/-/-

6000

TP2M/9.52

5/5

0.92

43-60

Dimension

L×W×H

948×1225×340

1050×1375×440

PVC,18/20

Capillary

Defrosting Auto

19.05

FLARED

64/-/-

Four way valve

Between

I.U. & O.U.

MAX :30

MAX : 50

Total power input

Weight (net / gross)

85/111

Piping

R407C

3.2

9.52

9.3/32

SPECIFICATIONS

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Haier Klimaanlage Handbücher

Haier

Haier AS09PBAHRA Bedienungsanleitung

Haier

Haier HSU-24HEA03(T3) Bedienungsanleitung

Haier

Haier HSU-09C03 Bedienungsanleitung

Haier

Haier 3P19 Series Bedienungsanleitung

Haier

Haier HWR05XC7 - 5,200 BTU Window Air Conditioner Bedienungsanleitung

Haier

Haier HSU-12CG03 Bedienungsanleitung

Haier

Haier HU062WAMNA Bedienungsanleitung

Haier

Haier HSU-18CR03-Y Bedienungsanleitung

Haier

Haier 10530627 Bedienungsanleitung

Haier

Haier inosens 1U35S2SM1FA-2 Bedienungsanleitung

Haier

Haier ESA4089 Bedienungsanleitung

Haier

Haier AD90S2SM3FA Montage- und Bedienungsanleitung

Haier

Haier HWR10XC6 - annexe 1 Bedienungsanleitung

Haier

Haier HSU-18HVE03 Bedienungsanleitung

Haier

Haier ESA3109 Bedienungsanleitung

Haier

Haier HSU-18HEK03-R2 Bedienungsanleitung

Haier

Haier HWR06XC6 - Window Air Conditioner Bedienungsanleitung

Haier

Haier HSU-18LEK03-Y2 Bedienungsanleitung

Haier

Haier AMA05JF Bedienungsanleitung

Haier

Haier HSU18XH7-G - Ductless Split Indoor Wall Mount Unit Heat... Bedienungsanleitung

Haier

Haier ESA4089 Bedienungsanleitung

Haier

Haier 1U09MACFRA Bedienungsanleitung

Haier

Haier HSM09HRA03 Bedienungsanleitung

Haier

Haier AC282AFERA Administratorhandbuch

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung
