Haier HDW100SCT Bedienungsanleitung

61501-A

Parts Manual

Dishwasher

Model:

HDW100SCT HA AA

Product Code:

61501-A

61501-A - NOVEMBER 2009

Fisher & Paykel Appliances Ltd

78 Springs Road,

East Tamaki,

PO Box 58-732, Botany,

Manukau 2163,

New Zealand

Telephone: 09 273 0600

Facsimile: 09 273 0656

PRODUCT

Brand Haier

Voltage 220-240V, 50Hz

Model HDW100SCT HA AA

Product Code 61501-A

61501-A

GUIDE TO USING THIS MANUAL

The model covered by this manual is listed on the front cover.

The information detailed in this manual is subject to change without notice. The latest version is indicated by

the reprint date and replaces any earlier editions.

The front cover picture shows the type of product and may not necessarily be an exact image of the model

covered by the manual.

Kit Parts

Kit components are shown in italics. Where a part number is shown against the descriptions for these kit

components, they are also available as separate items. In addition, some parts may be supplied with these

kits that are not available as separate items, and are therefore either not listed, or a part number is not

shown against the part description in this manual.

Parts List Key

italics Kit components or parts included are shown in italics. Refer to above notes: Kit Parts.

NI As a part reference, indicates the part is not illustrated on the diagram.

NOT USED As a part number, indicates the diagram part reference is not used in this manual.

NS As a part number, indicates the part cannot be serviced or replaced and is not available

as a spare part.

CONTENTS

CHASSIS & TUB ASSEMBLY.............................................................................................6

BASKETS............................................................................................................................8

SPRAY ARM ASSEMBLY.................................................................................................10

DOOR................................................................................................................................14

61501-A

CHASSIS & TUB ASSEMBLY

61501-A

CHASSIS & TUB ASSEMBLY

REF PART DESCRIPTION

1 H0120103797 PANEL TOP 100SCT

2 H0120104772 DECORATIVE SIDE PANEL RH SS

10 H0120200967 RAIL END CAP GREY

11 H012G1020069 RAIL

12 H012G1310023 BRACKET MIDDLE REAR

13 H0120101601A BRACKET LOWER REAR

14 H012G2160204 DRAIN HOSE GROMMET

15 H0120200656 END CAP RIGHT BASE SS

16 H0120105715 BASE PANEL

17 H0120200655 END CAP LEFT BASE

18 H0120200654 FRONT PANEL BASE SS

19 H0120200065 SERVICE PANEL COVER

20 H012G1451092 ADJUSTABLE FOOT REAR

22 H012G1610002 ADJUSTABLE FOOT FRONT

23 H012G1451091 FRONT FOOT LEVELING BRACKET

24 H012G1310027 SERVICE PANEL

25 H0120104771 DECORATIVE SIDE PANEL LH SS

26 NS TUB ASSEMBLY

27 H0120200966 TUB ROLLERS GREY

28 H0120106568 REAR GUSSET LH

29 H012G1310020 UPPER REAR PANEL

30 H0120202328 LATCH

31 H0120203553 LATCH TONGUE

32 H0120300248 GASKET TUB

34 H0120106569 REAR GUSSET RH

61501-A

BASKETS

61501-A

BASKETS

REF PART DESCRIPTION

3 H0120106652 UPPER BASKET SS

4 H0120201235 FOLD DOWN

5 H0120200963 ROLLER BASKET

6 H0120200965 AXLE STUB

7 H0120801727 CUTLERY BASKET GREY

8 H0120200964 ROLLER LOWER BASKET

9 H0120106687 LOWER BASKET SS

61501-A

RETICULATION ASSEMBLY
