Haier HF71CM33NM Bedienungsanleitung
Manual Defrost
Chest Freezer
Congélateur Bahut a
Dégivrage Manuel
Congelador de Cofre
de Descongelar
Manualmente
User Manual
Guide de l’Utilisateur
Manual del Usuario
HF50CM23NW
HF71CM33NW
GENERAL SAFETY RULES
WARNING: Read all of the instructions before using this appli-
ance. When using this appliance, always exercise
basic safety precautions, including the following:
NOTE: If the freezer has been placed in a horizontal or tilted position
for any period of time wait 24 hours before plugging the unit in.
1. Use this appliance only for its intended purpose as described in this use
and care guide.
2. This freezer must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
3. Never unplug your freezer by pulling on the power cord. Always grasp
the plug firmly and pull straight out from the outlet.
4. Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector
end.
5. Unplug your freezer before cleaning or before making any repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6) DANGER - Risk of Fire or Explosion. Flammable refrigerant used. Do
not use Mechanical devices to defrost freezer. Do not puncture
refrigerant tubing.
7. If your old freezer is not being used, we recommend that you remove
the doors. This will reduce the possibility of danger to children.
8. WARNING: After your freezer is in operation, do not touch the
cold surfaces in the freezer compartment, particularly when hands
are damp or wet. Skin may adhere to these extremely cold sur-
faces.
9. Do not refreeze foods, which have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads: “…You may safely refreeze frozen foods that have thawed if
they still contain ice crystals or if they are still cold-below 40˚F”.
“…Thawed ground meats, poultry, or fish that have any off-odor or
off-color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat.”
English
1
English
“…Even partial thawing and re-freezing reduce the eating quality of
foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods.
Use refrozen foods as soon as possible, to save as much of its eating
quality as you can.
10. This freezer should not be recessed or built-in an enclosed
cabinet. It is designed for freestanding installation only.
11. Do not operate your freezer in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
CAUTION - Risk of Fire or Explosion
Dispose of property in accordance with Federal or Local
Regulations. Flammable refrigerant used.
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves
in place so that children may not easily climb inside.
2
Thank you for purchasing our Haier
product. This easy-to-use manual will
guide you in getting the best use of
your Freezer.
Remember to record the model and
serial numbers. They are on a label
inside of the Freezer.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain warranty service.
English
3
Safety Precautions ............................................................................................1
Parts And Features ............................................................................................4
Installing Your Freezer.......................................................................................5
Unpacking Your Freezer......................................................................................5
Adjusting Your Freezer........................................................................................5
Proper Air Circulation .........................................................................................5
Electrical Requirements .....................................................................................6
Use of Extension Cords ......................................................................................6
Install Limitations ...............................................................................................6
Freezer Features And Use.................................................................................7
Adjustable Temperature Dial..............................................................................7
Food Storage Baskets.........................................................................................7
Operating Your Freezer ......................................................................................8
Defrosting And Draining.....................................................................................8
Normal Operating Sounds..................................................................................8
Food Storage Information ..................................................................................9
Proper Freezer Care and Cleaning .................................................................10
Cleaning and Maintenance ...............................................................................10
Power Interruptions..........................................................................................10
Vacation and Moving Care................................................................................10
Troubleshooting...............................................................................................11
Warranty Information......................................................................................12
Table of Contents
English
Parts And Features
4
1. Temperature Control Adjustment
2. Power-On Indicator
(Green Light - HF71CM33NW
Only)
3. Vinyl Coated Wire Basket
4. Interior Drain Plug (See Insert)
5. Exterior Drain Plug
125
3
4
English
5
1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the freezer accessories inside and
outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the freezer.
CAUTION
Risk of Fire or Explosion due to puncture of refrigerant tubing.
Flammable refrigerant used. Handle with care when moving freezer to
avoid either damaging the refrigerant tubing or increasing the risk of a
leak.
• Your freezer is designed for freestanding installation only.
It should not be recessed or built-in.
• Place the freezer on a floor strong enough to support it fully loaded.
• When moving the freezer, never tilt it more than a 45-degree angle.
This could damage the compressor and the sealed system.
• If the freezer is tilted let it stand in an upright position for at least 24
hours prior to plugging. This is to allow the refrigerant to settle.
• To assure your freezer works at the maximum efficiency it
was designed for, you should install it in a location where there
is proper air circulation, plumbing and electrical connections.
• The following are recommended clearances around the freezer:
Sides……………4” (102mm)
Back..................4” (102mm)
Top....................Do not block
Unpacking Your Freezer
Adjusting Your Freezer
Proper Air Circulation
Installing Your Freezer
English
Electrical Requirement
• Make sure there is a suitable power Outlet (115 volts, 15 amps
outlet) with proper grounding to power the freezer.
• Avoid the use of three plug adapters or cutting off the third grounding
in order to accommodate a two plug outlet. This is a dangerous
practice since it provides no effective grounding for the freezer and
may result in shock hazard.
• Avoid the use of an extension cord because of potential safety haz-
ards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounding
plug and a 3-slot outlet that will accept the plug. The marked rating of
the extension cord must be equal to or greater than the electrical rat-
ing of the appliance. DO NOT USE EXTENSION CORD LONGER
THAN 12 FT.
• Do not install your freezer in any location not properly insulated or
heated e.g. garage etc. Your freezer was not designed to operate in
temperature settings below 55˚ Fahrenheit.
• Select a suitable location for the freezer on a hard even
surface away from direct sunlight or heat source e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness
should be corrected.
Install Limitations
Use of Extension Cord
WARNING: ELECTRICAL REQUIREMENT - SHOCK HAZARD
6
English
7
Freezer Features and Use
Adjustable temperature dial:
Your freezer will automatically
maintain the temperature level you
select. The temperature control dial has
7 settings plus OFF. “1” is the
warmest, “7” is the coldest. Turning the
dial to OFF stops cooling the freezer.
Set the dial to “4” and allow 24 hours
to pass before adjusting the
temperature to your needs.
(Note: If the freezer has been
placed in a horizontal or
tilted position for any period
of time wait 24 hours before
plugging the unit in.)
• Once the freezer is in its proper place, plug it in an electrical outlet
having 115 volts and 15 amps.
• Set the temperature, on the temperature control knob. “1” being the
warmest and “7” being the coldest. Initially set the temperature on
“4”. Place food inside the freezer. After using the freezer for 24 hours
set the freezer to your desired setting.
• In case you unplug your freezer or experience an electrical outage,
allow 5 minutes before plugging it back in.
Operating Your Freezer
(see fig. # 1)
OFF
1
2
3
4
5
6
7temperature control dial
fig. # 1
green power on light
(HF71CM33NW Only)
• Your freezer has a basket. Removable basket allows you
to store food more accessibly or you can remove it if not needed.
Power Run
0
1
2
3
4
5
6
7
Food Storage Basket (see fig. # 2)
fig. # 2
• Boiling water, gurgling sounds or slight vibrations that are the result
of the refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
Normal Operating Sounds You May Hear
English
• For most efficient operation and minimum energy consumption, defrost
whenever the frost becomes 1/4” thick. Use only provided plastic
scraper. Do not use boiling water as it may damage the unit.
DANGER - Risk of Fire or Explosion due to puncture
refrigerant tubing. Flammable refrigerant used. Do not
use metal instruments to defrost freezer. Do not puncture
refrigerant tubing.
• Turn the temperature control to OFF position and unplug the unit.
Defrosting usually takes a few hours. To defrost faster keep the freezer
door open.
• For draining, place a tray beneath the outer drain plug. Unscrew and
remove drain plug. (See fig #3) This will let the water flow out in the
tray. When done, screw on the drain plug in place.
Note: monitor the container under the drain to avoid overflow.
• When draining is complete, wipe the interior of the freezer with a soft
cloth. Plug in power cord back into the electrical outlet.
• Reset the temperature control to the desired setting.
• Return the food into the freezer.
Risk of Fire or Explosion. Flammable refrigerant used. Do not puncture
of refrigerant tubing. To be repaired only by trained authorized service
personnel. Consult Repair Manual before attempting to service this
product. All Safety Precautions Must be followed. Component parts
shall be replaced with like components to minimize the risk of possible
ignition due to incorrect parts or improper service.
Defrosting and Draining
8
fig. # 3
Maintenance
English
9
Frozen Food:
• Wipe containers before storing to avoid needless spills.
• Hot food should be allowed to cool before storing in the freezer.
This will prevent unnecessary energy use.
• When storing meats, keep in the original
packaging or rewrap as necessary.
• Proper freezer storage requires correct packaging. All foods must be
in packages, which do not allow the flow of air or moisture in, or out.
Improper storage will result in odor and taste transfer and will result
in the drying out of the improperly packaged food.
• Follow package or container instructions for proper storage.
• Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film
Self-sealing plastic bags
• Do not refreeze defrosted/thawed foods.
• It is recommended that the freezing date be marked on the
packaging.
These are some suggestions for safe storage:
• TV Dinners 3 - 4 Months
• Fresh Shrimp, scallops, crawfish 3 - 6 Months
• Hamburger & stew meats 3 - 4 Months
• Ground Turkey, veal, pork 3 - 4 Months
• Chops 4 - 6 Months
• Steaks 6 - 12 Months
• Chicken or turkey, whole 1 year
For detailed storage chart visit FDA website:
www.cfsan.fda.gov/~dms/fttstore.html
Food Storage Information
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Sprachen:
Andere Haier Gefrierschrank Handbücher
Haier
Haier H3F285 EH1 Series Bedienungsanleitung
Haier
Haier FR-120V Bedienungsanleitung
Haier
Haier LW-194B Bedienungs- und Wartungshandbuch
Haier
Haier LW-190B Bedienungs- und Wartungshandbuch
Haier
Haier JQ-F160B Bedienungsanleitung
Haier
Haier ESCM050EC - 5.0 Cu Ft Chest Freezer Montageanleitung
Haier
Haier BD-88DEM Bedienungsanleitung
Haier
Haier HCF-102 Bedienungsanleitung
Haier
Haier HF71CW20W Bedienungsanleitung
Haier
Haier H3F-280WSAAU1 Bedienungsanleitung
Haier
Haier HRF-368F Bedienungsanleitung
Haier
Haier ALASKA145B2 Bedienungsanleitung
Haier
Haier HUM013EA - 1.3 cu. Ft. Capacity Upright... Bedienungsanleitung
Haier
Haier Thermocool BD-100E Bedienungsanleitung
Haier
Haier Thermocool SD-332 Bedienungsanleitung
Haier
Haier BD-318A Bedienungsanleitung
Haier
Haier HMCM148PA Bedienungsanleitung
Haier
Haier HCM050EC - 5.0 cu. Ft. Capacity Freezer Bedienungsanleitung
Haier
Haier DW-86L338J Bedienungsanleitung
Haier
Haier DW-86L578S Bedienungsanleitung
