Installation and User Manual
Manuel d’installation et d’utilisation
Manual de instalación y del usuario
HFC3501ACW, HF50CW20W
HF50CM23NW, HF71CW20W
HF71CM33NW, HF71CL53NW
Part # 0570000226 REV A
1
TABLE OF CONTENTS
FREEZER SAFETY................................................................................................2
PARTS AND FEATURES .......................................................................................5
INSTALLATION REQUIREMENTS ......................................................................... 6
Location Requirements................................................................................................. 6
Electrical Requirements ................................................................................................ 7
FREEZER INSTALLATION ....................................................................................8
Step 1 - Unpack Freezer ................................................................................................ 8
Step 2 - Complete the Installation ............................................................................... 9
FREEZER USE......................................................................................................9
Control ........................................................................................................................... 9
Freezer Lock and Key...................................................................................................10
Freezer Baskets ...........................................................................................................10
FREEZER CARE ................................................................................................. 11
Cleaning .......................................................................................................................11
Defrosting and Draining ..............................................................................................12
Vacation and Moving ...................................................................................................13
Reinstalling/Using Freezer Again................................................................................13
TROUBLESHOOTING........................................................................................ 14
LIMITED WARRANTY ........................................................................................ 16
RECORD KEEPING
Thank you for purchasing this Haier
product. This user manual will help you
get the best performance from your
new freezer.
For future reference, record the model
number, serial number, and the date
of purchase. The model/serial number
plate is located on a label inside the
freezer.
Staple your proof of purchase to this
manual to aid in obtaining warranty
service if needed.
___________________________________
Model number
___________________________________
Serial number
___________________________________
Date of purchase
2
FREEZER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and
on your appliance. Always read and obey all safety messages.
DANGER
WARNING
CAUTION
This is the safety alert symbol.
This symbol alerts you to potential hazards that can
kill or hurt you and others. All safety messages will
follow the safety alert symbol and either the word
“DANGER,” “WARNING” or “CAUTION.”
These words mean:
An imminently hazardous situation. You
could be killed or seriously injured if you
don’t immediately follow instructions.
A potentially hazardous situation
which, if not avoided, could result in
death or serious bodily injury.
A potentially hazardous situation
which, if not avoided, may result in
moderate or minor injury.
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
3
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: To reduce the risk of re, electrical shock, injury to persons,
or damage when using the freezer, follow basic precautions, including
the following:
• Use this appliance only for
its intended purpose as
described in this user manual.
• This freezer must be properly
installed in accordance with
the installation instructions
before it is used. See
grounding instructions in the
installation section.
• Flammable refrigerant used.
Do not use mechanical
devices to defrost freezer.
Do not puncture refrigerant
tubing.
• Flammable refrigerant used.
To be repaired only by trained
service personnel. Do not
puncture refrigerant tubing.
• Flammable refrigerant
used. Dispose of properly in
accordance with federal or
local regulations.
• Flammable refrigerant used.
Follow handling instructions
carefully. Risk of re or
explosion due to puncture of
refrigerant tubing.
• Plug into a grounded 3 prong
outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Do not repair or replace any
part of the appliance unless
specically recommended in
the manual. All other servicing
should be referred to a
qualied technician.
• Disconnect power before
servicing.
• Replace all parts and panels
before operating.
• Use nonammable cleaner.
• Keep ammable materials and
vapors, such as gasoline, away
from freezer.
• Cabinet edges along stamp/
cutout areas may be sharp.
Avoid placing hands, ngers
or other appendages near
these areas.
• This freezer should not
be recessed or built-in
an enclosed cabinet. It is
designed for freestanding
installation only.
• Before discarding or removing
from service, remove the
door. This will reduce the
possibility of danger to
children.
READ AND SAVE THESE
INSTRUCTIONS
4
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the
State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the
State of California to cause birth defects or other reproductive harm.
PROPER DISPOSAL OF YOUR OLD REFRIGERATED APPLIANCE
WARNING
Suffocation Hazard
Remove doors or lid from your old freezer or refrigerator.
Failure to do so can result in death or brain damage.
IMPORTANT: Child entrapment and suocation are not problems of the past. A
junked or abandoned freezers or refrigerators are still dangerous – even if it will sit
for “just a few days.” If you are getting rid of your old refrigerator or freezer, please
follow these instructions to help prevent accidents.
Before You Throw Away Your Old Freezer or Refrigerator:
• Remove the doors or lid.
• Leave any shelves in place so that children may not easily climb inside.
Important information to know about disposal of refrigerants:
Dispose of freezer in accordance with Federal and Local regulations.
Refrigerants must be evacuated by a licensed, EPA certied refrigerant
technician in accordance with established procedures.
5
PARTS AND FEATURES
c
b
d
a
e
f
a Lock with Key
(modelHF71CL53NW only)
b Interior Drain Plug
(not shown - see insert)
c Vinyl Coated Wire Basket
d Power Indicator - green light
(onsome models)
e Temperature Control Adjustment
f Exterior Drain Plug
6
INSTALLATION REQUIREMENTS
LOCATION REQUIREMENTS
WARNING
Explosion and Fire Hazard
Keep flammable materials and vapors, such as gasoline, away from
appliance.
Failure to do so can result in death, explosion or fire.
IMPORTANT: This freezer is designed for freestanding installation only. It should
not be recessed or built-in an enclosed cabinet. To ensure your freezer works
at optimum eciency, you should install it in a location where there is proper air
circulation, and electrical connections.
Recommended Clearances:
4"
(10.2 cm)
4"
(10.2 cm) Do Not
BlockTop
4"
(10.2 cm)
• Do not install your freezer in any location not properly insulated or heated such
as a garage. Your freezer was not designed to operate in temperature settings
below 55˚F (13°C).
• Select a suitable location for the freezer on a hard even surface away from direct
sunlight or heat source e.g. radiators, baseboard heaters, cooking appliances
etc. Any oor unevenness should be corrected.
• Place the freezer on a oor strong enough to support it fully loaded.
7
ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the power cord plug.
Do not use an adapter.
Do not use an extension cord.
Failure to do so can result in death, fire or electrical shock.
Before you move your freezer to a location, it is important to make sure you have
the proper electrical connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only, 15-amp fused, grounded electrical supply is required. It
is recommended that a separate circuit serving only your freezer be provided. Use
an outlet that cannot be turned o by a switch. Do not use an extension cord.
8
FREEZER INSTALLATION
STEP 1 - UNPACK FREEZER
WARNING
Fire or Explosion Hazard
Do not puncture refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
Failure to do so can result in death, explosion or fire.
IMPORTANT: Handle with care when moving freezer to avoid either damaging the
refrigerant tubing or increasing the risk of a leak.
IMPORTANT: When moving the freezer, never tilt it more than a 45° angle. This could
damage the compressor and the sealed system. If the freezer has been placed in
a horizontal position for any period of time, wait 24 hours before plugging in the
freezer to allow the refrigerant to settle.
1. Remove and dispose of/recycle all packing materials. This includes the foam
base and all adhesive tape. Remove all protective packaging covering the
freezer.
2. Remove user manual and other printed material before turning on the freezer.
3. Clean the exterior surface with a soft cloth.
