Hama BRS2 Bedienungsanleitung
00004633
Bluetooth Remote Shutter BRS2
Bluetooth-Fernauslöser
D
GB
Operating Instructions
Bedienungsanleitung
ON OFF
Open Battery Cover
Change Battery Close Battery Cover
A
B
1
1
2 3
4
23
00004633
1X CR2032
00004633
1X CR2032
00004633
1X CR2032
2
GOperating instruction
Controls and Displays
1. LED indicator light
2. ON /OFF button
3. Release button
4. Battery compartment cover
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to
specichazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
•Bluetooth Remote Shutter BRS2
•1hand strap
•1battery (CR2032)
•These operating instructions
3. Safety Notes
•Protect the product from dirt, moistureand overheating, and only use it in adry
environment.
•Donot use the product in areas wherethe use of electronic devices is not permitted.
•Donot use the product in moist environments and avoid splashes.
•Donot drop the product and do not expose it to any major shocks.
•Dispose of packaging material immediately according to locally applicable
regulations.
•Donot modify the product in any way.Doing so voids the warranty.
•Use the product for its intended purpose only.
•This product is intended for private, non-commercial use only.
•Donot use the product in the immediate vicinity of heaters or other heat sources
or in direct sunlight.
•Keep this product, as all electrical products, out of the reach of children!
•Donot operate the product outside the power limits given in the specications.
3
•Donot attempt to service or repair the product yourself.Leave any and all service
work to qualied experts.
•Donot open the device or continue to operate it if it becomes damaged.
Warning –Batteries
•When inserting batteries, note the correct polarity (+ and -markings) and insert
the batteries accordingly.Failure to do so could result in the batteries leaking
or exploding.
•Only use batteries (or rechargeable batteries) that match the specied type.
•Beforeyou insert the batteries, clean the battery contacts and the polar contacts.
•Donot allow children to change batteries without supervision.
•Donot mix old and new batteries or batteries of adifferent type or make.
•Remove the batteries from products that arenot being used for an extended
period (unless these arebeing kept ready for an emergency).
•Donot short-circuit batteries.
•Donot charge batteries.
•Donot throw batteries in a re.
•Keep batteries out of the reach of children.
•Never open, damage or swallow batteries or allow them to enter the
environment. They can contain toxic, environmentally harmful heavy metals.
•Immediately remove and dispose of dead batteries from the product.
•Avoid storing, charging or using the device in extreme temperatures and
extremely low atmospheric pressure(for example, at high altitudes).
Warning –Button cells
•Donot ingest battery,risk of burns due to dangerous substances.
•This product contains button cells. If swallowed, the button cell can cause severe
internal burns within just two hours and lead to death.
•Keep new and used batteries out of the reach of children.
•Ifthe battery compartment does not close securely,stop using the product and
keep it out of the reach of children.
•Ifyou think that batteries wereswallowed or areinapart of the body,seek
medical assistance immediately.
4. System Requirements
•The Bluetooth remote release supports Bluetooth-capable terminal devices such
as smartphones and tablet PCs that run the iOS 6orAndroid 4.2.2 (or newer)
operating systems.
4
Note
•Note that support of the Bluetooth remote release depends on your terminal
device.
•Please refer to the operating instructions for the device you areusing.
5. Getting Started
•Open the battery compartment by undoing the screws on the battery cover (4) using
ascrewdriver.
•Remove the battery cover (4) and insert aCR2032 battery with the correct polarity (B).
•Close the battery compartment by putting back the battery cover and tightening the
screws using ascrewdriver (B).
6. Operation
Note
•The functions described in this section areonly available for Bluetooth-capable
terminal devices.
•Note that the maximum range for Bluetooth is 10 metres without obstacles such
as walls, people, etc.
6.1. Bluetooth pairing
Note –Pairing
•Make surethat your Bluetooth-capable terminal device is on and Bluetooth is
activated.
•Make surethat your Bluetooth-capable terminal device is visible for other
Bluetooth devices.
•For moreinformation, please refer to the operating instructions of your terminal
device.
5
•Slide the On/off switch (2) to the ON position to switch on the Bluetooth remote
release. The control light (1) begins to ash green (slowly).
•This means the Bluetooth remote release is searching for aBluetooth connection.
•Open the Bluetooth settings on your terminal device and wait until Hama BRS2
appears in the list of Bluetooth devices found.
•Select Hama BRS2 and wait until the Bluetooth remote release is listed as
connected in the Bluetooth settings on your terminal device. The control light (1)
begins to ash green (quickly).
•You can now use the Bluetooth remote release.
6.2. Automatic Bluetooth connection (after successful pairing)
Note
•Make surethat your Bluetooth-capable terminal device is on and Bluetooth is
activated.
•Make surethat your Bluetooth-capable terminal device is visible for other
Bluetooth devices.
•For moreinformation, please refer to the operating instructions of your terminal
device.
•The Bluetooth remote release remains connected to the Bluetooth device it was
last paired with.
•Slide the On/off switch (2) to the ON position to switch on the Bluetooth remote
release. The control light (1) begins to ash green (slowly).
•After 3–5 seconds, the Bluetooth remote release automatically connects to the
device.
•You can now use the Bluetooth remote release.
6
Note –Connection impaired
After the devices have been paired once, the connection is then established
automatically.Ifthe Bluetooth connection is not established automatically,check
the following:
•Check the Bluetooth settings of your terminal device to see whether Hama BRS2
is connected. If not, repeat the steps listed under 6.1. Bluetooth pairing.
•Check whether obstacles areimpairing the range. If so, move the devices closer
together.
•The performance can also be affected by aweak battery.Change the battery
if necessary.
•Only one Bluetooth device can be connected at atime. If thereisanactive
connection to another device, deactivate this connection and try again.
6.3. Replacing the batteries
The battery has been designed to last for up to 2,000 shots, although this depends on
the conditions of use.
If the Bluetooth remote release does not respond after you press the release button (3),
or does not connect to the terminal device, etc., change the battery as follows: See (B).
7. Care and Maintenance
Only clean this product with aslightly damp, lint-free cloth and do not use aggressive
cleaning agents. Make surethat water does not get into the product.
8. Warranty Disclaimer
Hama GmbH &Co. KG assumes no liability and provides no warranty for damage
resulting from improper installation/mounting, improper use of the product or from
failuretoobserve the operating instructions and/or safety notes.
7
9. Technical Data
Bluetooth Remote Shutter
Bluetooth version 3.0
Bluetooth Class Class 2
Range Max. 10 m
Dimensions (W xLxH) 35 x35x15 mm
Weight Approx. 10 g
Battery type CR2032
10. Declaration of Conformity
Hereby,Hama GmbH &CoKG declares that the radio equipment type
[00004633] is in compliance with Directive 2014/53/EU.The full text
of the EU declaration of conformity is available at the following internet
address: www.hama.com /00004633/Downloads.
Frequency band(s) 2.402 GHz ~2.480 GHz
Maximum radio-frequency
power transmitted 0.03 mW E.I.R.P.
8
Bedienungselemente und Anzeigen
1. LED-Kontrollleuchte
2. Ein-/ Ausschalter
3. Auslösetaste
4. Batteriefachabdeckung
1. Erklärung von Warnsymbolen und Hinweisen
Warnung
Wirdverwendet, um Sicherheitshinweise zu kennzeichnen oder um Aufmerksamkeit
auf besondereGefahren und Risiken zu lenken.
Hinweis
Wirdverwendet, um zusätzlich Informationen oder wichtige Hinweise zu
kennzeichnen.
2. Packungsinhalt
•Bluetooth-Fernauslöser BRS2
•1Handschlaufe
•1Batterie (CR2032)
•diese Bedienungsanleitung
3. Sicherheitshinweise
•Schützen Sie das Produkt vor Schmutz, Feuchtigkeit und Überhitzung und
verwenden Sie es nur in trockenen Umgebungen.
•Benutzen Sie das Produkt nicht in Bereichen, in denen elektronische Produkte nicht
erlaubt sind.
•Verwenden Sie das Produkt nicht in einer feuchten Umgebung und vermeiden Sie
Spritzwasser.
•Lassen Sie das Produkt nicht fallen und setzen Sie es keinen heftigen
Erschütterungen aus.
•Entsorgen Sie das Verpackungsmaterial sofort gemäß den örtlich gültigen
Entsorgungsvorschriften.
•Nehmen Sie keine Veränderungen am Produkt vor.Dadurch verlieren Sie jegliche
Gewährleistungsansprüche.
•Verwenden Sie das Produkt ausschließlich für den dazu vorgesehenen Zweck.
•Das Produkt ist für den privaten, nicht-gewerblichen Gebrauch vorgesehen.
DBedienungsanleitung
