Hamilton Beach 19801 Betriebsanleitung

READ BEFORE USE

LIRE AVANT UTILISATION

LEA ANTES DE USAR

Questions?

Please call us – our friendly

associates are ready to help.

USA: 1.800.851.8900

¿Preguntas?

Por favor llámenos – nuestros

amables representantes están

listos para ayudar.

MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente

este instructivo antes de usar su

aparato.

Visit www.hamiltonbeach.com for our

complete line of products and Use and

Care Guides –as well as

delicious recipes, tips, and

to register your product online!

Rendez-vous sur www.hamiltonbeach.ca

pour notre liste complète de produits et de

nos manuels utilisateur – ainsi que nos

délicieuses recettes, nos conseils et pour

enregistrer votre produit en ligne !

¡Visite www.hamiltonbeach.com.mx para

obtener nuestra línea completa de productos

y las Guías de Uso y Cuidado, además de

deliciosas recetas, consejos y para registrar

su producto en línea!

Questions ?

N’hésitez pas à nous appeler –

nos associés s’empresseront

de vous aider.

CAN : 1.800.267.2826

DurathonTM Iron

Fer à repasser

Plancha

English ...................... 2

Français .................. 15

Español .................. 31

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 1

SAVE THESE INSTRUCTIONS!

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING

1. Only use an iron for its intended use.

2. To avoid the risk of electric shock, do not immerse the iron

in water or other liquids.

3. Always turn the iron to OFF before plugging or unplugging

the iron from the electrical outlet. Never pull on the cord to

disconnect the iron from the electrical outlet; instead, grasp

the plug and pull on the plug to disconnect the iron.

4. Do not let the cord touch hot surfaces. Let the iron cool

completely before putting the iron away. Coil the cord

loosely around the iron for storing.

5. Always disconnect the iron from the electrical outlet before

filling the iron with water, emptying the water from the iron,

and when the iron is not in use.

6. Do not operate the iron with a damaged cord or in the event

the iron has been dropped or damaged or there are visible signs

of damage or it is leaking. To avoid the risk of electric shock,

do not disassemble the iron. Take it to a qualified serviceman

for examination and repair. Incorrect assembly might result in

a risk of electric shock when the iron is used after reassembly.

7. The iron must be used and rested on a stable surface.

8. When placing the iron on its stand, ensure that the surface

on which the stand is placed is stable.

9. Close supervision is required for any appliance used by or

near children. Do not leave the iron unattended while the iron

is connected or on an ironing board.

10. Burns can occur from touching hot metal parts, hot water, or

steam. Use caution when you turn a steam iron upside down—

there might be hot water in the reservoir.

11. To avoid a circuit overload, do not operate an iron on the same

circuit with another high-wattage appliance.

12. If an extension cord is absolutely necessary, a cord with an

ampere rating equal to or greater than the maximum rating of the

iron shall be used. A cord rated for less amperage can result in a

risk of fire or electric shock due to overheating. Care shall be

taken to arrange the cord so that it cannot be pulled or be tripped

over.

When using your flatiron, basic safety precautions should always be followed, including the following:

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 2

OTHER CONSUMER SAFETY INFORMATION

This product is intended for household use only.

WARNING! Shock Hazard: This appliance has a polarized plug (one

wide blade) that reduces the risk of electric shock. The plug fits only

one way into a polarized outlet. Do not defeat the safety purpose of

the plug by modifying the plug in any way or by using an adapter.

If the plug does not fit fully into the outlet, reverse the plug. If it still

does not fit, have an electrician replace the outlet.

• Use the iron on an ironing board. Ironing on any other surface

may damage that surface.

• Do not iron or vertical-steam clothes that are being worn.

• Do not use vertical steam in the direction of people or pets.

• During first use of the iron, it may appear to smoke. This will stop

and does not indicate a defect or hazard.

• Many irons spit or sputter during the first few uses with tap water.

This happens as the steam chamber becomes conditioned. This

will stop after a few uses.

• To clean steam vents before first use, prepare iron for steam ironing

and then iron over an old cloth for a few minutes while letting the

iron steam. Press the Steam Burst button several times to clean the

vents. Then follow the self-cleaning instructions on page 12.

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 3

Parts and Features

Heel Rest

Water Tank

Cover

Cord

Self-Clean

Button

Durathon™ Nonstick Soleplate

Spray

Nozzle

Spray and Steam

Burst Buttons

Adjustable

Steam Switch

Temperature Settings/

Auto Shutoff Indicator

Temperature

Settings Button

Hot Dot Indicator

(refer to page 9 for more information)

Soft Touch Grip

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 4

How to Dry Iron

1 2 3 4

Set the Adjustable Steam Switch

to (Dry Iron). Press Temperature Settings Button

to select desired temperature.

Allow 2 minutes for iron to reach

maximum temperature. The light

will blink while preheating.

To turn iron off, press Temperature

Settings Button until OFF is

illuminated. The light will stay

on until iron is unplugged.

IRON POSITION

Resting on soleplate

Resting on either side

Resting on heel

POSITION SENSING/AUTO SHUTOFF

The iron will turn off automatically when left in the following positions.

The Auto Shutoff time varies based on the iron’s position.

MOTIONLESS TIME

30 seconds

15 minutes

NOTE: Moving the iron will reset the Auto Shutoff sensor.

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 5

How to Steam Iron

Set the Adjustable Steam Switch

to (Dry Iron). Press Temperature Settings

Button to select desired fabric

setting in the steam range.

Allow 2 minutes for iron to reach

maximum temperature. The light

will blink while preheating.

WARNING! Burn Hazard:

Attempting to steam iron on

a lower temperature setting or

failing to allow the iron to preheat

for 2 minutes can result in hot

water dripping from the soleplate.

Set Adjustable Steam Switch to

the desired steam level.

6 6

For vertical steaming, hold iron 6 inches (15 cm) from garment and do

not allow hot soleplate to touch delicate garments. Press and release

the Steam Burst Button to steam out wrinkles. Wait at least 5 seconds

before pressing Steam Burst Button again.

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 6

How to Steam Iron (cont.)

To turn iron off, set Adjustable

Steam Switch to (Dry Iron).

7 8

Press Temperature Settings

Button until OFF is illuminated.

The light will stay on until iron is

unplugged.

IRON POSITION

Resting on soleplate

Resting on either side

Resting on heel

POSITION SENSING/AUTO SHUTOFF

The iron will turn off automatically when left in the following positions.

The Auto Shutoff time varies based on the iron’s position.

MOTIONLESS TIME

30 seconds

15 minutes

NOTE: Moving the iron will reset the Auto Shutoff sensor.

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 7

Fabric Setting Chart

NOTICE: To avoid garment damage, check garment label for

fabric composition and ironing instructions.

Garment Label Symbols

Fabric care labels on garments have symbols that show ironing

instructions and recommended temperature settings. These symbols

are shown below along with an explanation of their meaning.

Temperature

Setting

OFF

Synthetics

Silk, Wool

Cotton, Linen

Steam

Setting

Dry

Iron

Steam

Range

Ironing

Instructions

OFF

Dry iron using spray

if necessary.

Iron silk on wrong

side.

For cotton, iron while

still damp or use

spray.

For linen, iron fabric

on wrong side.

•

Low

••

Medium

•••

High

Iron High Temp

Setting Medium

Temp

Setting

Low Temp

Setting

Do not iron Do not use

steam

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 8

Hot Dot Indicator

After the iron has been preheated (approximately 2 minutes after turning on the iron), the Hot Dot Indicator will gradually change from

all black to red, and the word “HOT” will appear in the center of the dot in white letters. When the word “HOT” is no longer visible

(approximately 35 minutes after turning off the iron) and the dot is all black again, the iron is cool enough to put away.

WARNING! Burn Hazard: The Hot Dot Indicator is a guideline only. Always avoid contact with the soleplate of the iron.

Due to usage conditions, the Hot Dot Indicator may stop working before the end of the iron’s useful life. If may start to remain red after the

iron cools down. Replacement Hot Dot Indicators are available by calling 1.800.851.8900.

Iron is cool enough to store. Iron is too hot to store.

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 9

Tips for Best Ironing Results

PREPARE TO IRON:

1. Cover your ironing board with a padded, heat-resistant cover. Brush or wipe off any dust, dirt, or debris so it doesn’t end up on your clothes.

2. To set the height of the ironing board, stand with your elbows bent at right angles; then drop your hands slightly so that your arms are in a

comfortable position. Set the height of your ironing board to this height.

3. Check the soleplate (the surface of the iron that meets the fabric) for mineral deposits or scorched material before you begin ironing. If these

deposits or minerals are left on the soleplate, they may end up on your clothes. Unsure? Test-glide the iron on a rag or old towel first.

TEST KITCHEN TIP: To clean an iron’s soleplate, preheat the iron to the highest temperature setting and iron over a damp, 100% cotton cloth.

This creates heavy steam that transfers grime from the soleplate to the cloth. Many irons have a Self-Clean Button. This will clean the steam

holes, but it will not remove grime from the flat surface of the soleplate. NOTE: Care should be used while cleaning; steam can burn.

FAST FACTS:

• Don’t iron in a circular motion as this can stretch fabric. Instead, iron lengthwise.

• Natural fibers such as cotton and linen should be ironed slightly damp for faster, easier ironing. If they are completely dry, use maximum steam

while ironing or mist them with water prior to ironing.

• Any portion of a garment that has 2 layers of fabric such as pockets, seams, collars, and cuffs should be ironed inside out first.

• To press a collar, iron from the points in using small strokes of the iron. After wrinkles are pressed out, crease the collar into place by hand—not

with the iron. Treat French cuffs similarly, gently creasing by hand after ironing.

IRONING VERSUS PRESSING:

• You may have heard the terms “ironing” and “pressing” used interchangeably, but they are actually quite different. When ironing, you slide the

iron back and forth over fabric. When pressing, the iron is placed and held on the fabric in one spot, lifted up, and this process is repeated until

the areas that need attention are smooth. A “pressing” technique is helpful to avoid stretching fabrics.

• A pressing cloth can help reduce unwanted “shine” on fabrics. You can purchase a pressing cloth in the laundry care section, or a clean white

dishtowel or 100% cotton pillowcase works equally well. You do not need to increase the recommended iron temperature when using a

pressing cloth.

FABRIC FACTS AND LABELS:

Every fabric is different and should be treated accordingly. The label inside clothing or linens should recommend fabric care instructions that

include ironing treatment. As a general rule, these instructions should be followed. If the fabric is a blend, use a low temperature setting. If you

do not know what the content of the fabric is, use the lowest temperature first and test on an inside seam.

840202100 ENv02.qxd:Layout 1 5/6/11 3:31 PM Page 10

Andere Handbücher für 19801

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Hamilton Beach Eisen Handbücher

Hamilton Beach

Hamilton Beach Pro SteamMax HB608WB Bedienungsanleitung

Hamilton Beach

Hamilton Beach 840087000 Bedienungsanleitung

Hamilton Beach

Hamilton Beach HIR400 - Hospitality Iron 1 EA Bedienungsanleitung

Hamilton Beach

Hamilton Beach Durathon 19901 Betriebsanleitung

Hamilton Beach

Hamilton Beach 14431 - Smart Grip Iron Betriebsanleitung

Hamilton Beach

Hamilton Beach DURATHON Betriebsanleitung

Hamilton Beach

Hamilton Beach 840104900 Bedienungsanleitung

Hamilton Beach

Hamilton Beach 840159500 Bedienungsanleitung

Hamilton Beach

Hamilton Beach 14525 Bedienungsanleitung

Hamilton Beach

Hamilton Beach 14975 - Professional Iron Bedienungsanleitung

Hamilton Beach

Hamilton Beach 840124900 Bedienungsanleitung

Hamilton Beach

Hamilton Beach ProCare HB268SGBG Bedienungsanleitung

Hamilton Beach

Hamilton Beach 840066300 Montageanleitung

Hamilton Beach

Hamilton Beach 14880C Bedienungsanleitung

Hamilton Beach

Hamilton Beach 17130 Bedienungsanleitung

Hamilton Beach

Hamilton Beach 840091300 Bedienungsanleitung

Hamilton Beach

Hamilton Beach 15410T Bedienungsanleitung

Hamilton Beach

Hamilton Beach HIR700-CE Bedienungsanleitung

Hamilton Beach

Hamilton Beach 14600 Programmierhandbuch

Hamilton Beach

Hamilton Beach 14200 - Nonstick Auto-Off Retro Steam Iron Bedienungsanleitung

Hamilton Beach

Hamilton Beach 14210 Bedienungsanleitung

Hamilton Beach

Hamilton Beach 14017 Betriebsanleitung

Hamilton Beach

Hamilton Beach Easy Touch Iron Bedienungsanleitung

Hamilton Beach

Hamilton Beach 840043400 Montageanleitung

Beliebte Eisen Handbücher anderer Marken

Clatronic

Clatronic DB 3703 Bedienungsanleitung

TEFAL

TEFAL FV4093Z0 Bedienungsanleitung

Gorenje

Gorenje SIH 2200 BS Bedienungsanleitung

Philips

Philips GC6012 Bedienungsanleitung

Bosch

Bosch 2 Series Bedienungsanleitung

Riffel

Riffel Catena KB-819 Bedienungsanleitung

Texi

Texi Hestia Bedienungsanleitung

Maxwell

Maxwell MW-3010 Bedienungsanleitung

TREVIDEA

TREVIDEA Girmi ST60 Bedienungsanleitung

Philips

Philips HI5914/30 Bedienungsanleitung

Primula

Primula Vapormat Bedienungsanleitung

Magio

Magio MG-541 Bedienungsanleitung

Scarlett

Scarlett SC-1334S Bedienungsanleitung

Bosch

Bosch Sensixx B22L Bedienungsanleitung

Philips

Philips GC651 Bedienungsanleitung

Vitek

Vitek VT-1247 VT Bedienungsanleitung

Cleanmaxx

Cleanmaxx 3397 Bedienungsanleitung

Philips

Philips GC800 Bedienungsanleitung
