Installation Instructions for Furnace Humidifier

Plastic Models - Standard and Self-cleaning

Please read the instructions carefully before starting the installation.

Version 3 - June 2001

400 D / 800 D

M-300 / M-400

For future use, please copy the free help line number into the space below.

Free help line for technical assistance:

1-800-879-0123

WARNINGS AND DISCLAIMER

Installation Precautions

1) This humidifier will be connected to and used under water pressure and it must be installed in such a way that if a leak

occurs, the water could not cause any damage to the property. Make sure all water connections are properly installed or water

spill could occur.

2) This humidifier is intended for use on forced warm air circulation furnaces, as well as multi-fuel furnaces where temperature

does not exceed 180°F (82ºC). Higher temperatures will damage your humidifier and possibly cause overflow condition and

water damage to your home.

3) Do not install a humidifier where surrounding temperatures may be 32°F (0ºC) or colder. Freezing water will damage the

humidifier and burst the supply pipe, resulting in home damage.

4) Do not install the humidifier or the bypass connection directly on the furnace housing.

5) Do not install the humidifier or the bypass connection on a plenum side where a cooling coil could restrict or inhibit the

airflow through the humidifier.

6) Always check that you are not about to cut or drill into any air conditioning or electrical accessory during installation.

7) Do not install a humidifier on the supply duct where the static pressure exceeds 0.4” Water Column.

8) Do not install a humidifier if the city water pressure exceeds 90 psi. Check the local codes related to pressure reduction.

9) The installation, wiring and plumbing of the humidifier must comply with national and local electrical, plumbing and building

codes.

10) Electrical wiring and water tubing must not come into contact with sharp edges or hot surfaces. For the drainable models,

please make certain the drain tube has no bends, its end placed in a floor drain and there is no resistance to the flow of the

discharged water.

11) The transformer supplied is rated for 120 V power supply. Do not connect it to an installation supplied with another voltage.

12) Do not set the humidity level higher than normally recommended, or condensation damage could occur.

Safety Warnings

1) Please beware of sharp edges when you cut into a metal duct.

2) Always shut the power off before starting the installation. An electric shock from 120 volts could cause serious injury.

1. Required tooling

Tin snips, 3/32” drill, pliers, screwdrivers, electric drill, hammer, centre punch, medium sandpaper.

IMPORTANT NOTE: This humidifier is supplied with RECEX ® screws that allow the use of either a Robertson or Phillips

head screwdriver.

2. Typical installations (Please see Fig. 1)

There are two frequently encountered types of installations: LOWBOY furnace (1.1) and HI-BOY furnace (1.2).

3. Principles of operation

•This humidifier uses a motor driven evaporator pad. Warm air is by-passed from the warm air plenum and forced through

the evaporator pad while it turns in the water pan. Humid air is drawn back into the return duct.

BEFORE YOU START - GENERAL SAFETY AND INSTALLATION PRECAUTIONS

Please read and understand these instructions fully before you begin this installation and save them for future reference.

The manufacturer will assume no responsibility and the warranty will be void if the user does not adhere to the following precautions.

Self-cleaning model:

All instructions pertinent only to the self-cleaning model are shaded in the following text.

The drum contains all the small parts and installation hardware. It is closed by a round metal damper (10.B) that will be used

later in the installation process. Open the drum to remove all the parts, then re-assemble the drum without the damper.

4. Humidifier location (Please see Fig. 1, 2 and 3)

•This humidifier should be installed on the return duct (cold air). If for any reason you must install it on the supply duct, the

air pressure may lift the cover and you will have to attach it.

•Identify the return duct and choose the duct side, which offers the best access for installation and maintenance.

•The humidifier must be installed in such a way that if a leak occurs, the water could not cause any damage to the

property.

5. Preparing the humidifier

This humidifier is factory assembled with the air inlet located at the left side, thus the motor will be installed on the right side.

Everything is reversible, if necessary. However, if it is suitable as supplied, please go directly to Step 6 (Installing the

humidifier).

If humidifier reversal is necessary, do the following (please see Fig. 12)

Lift the front of the water pan to disengage it from the sides of the humidifier and slide it out of the unit.

•Remove the two screws (12.1) located at the top of the humidifier body.

•Open the two sides (12.2) of the humidifier.

•Bend the two sides in the opposite direction and finish with the top.

•Put the two screws (12.1) back in place, taking care to not strip the plastic material.

6. Installing the humidifier (Please see Fig. 2, 3 and 4)

•Please refer to the general view of a typical installation.

•Shut off the furnace power.

•Kit No. 1 contains all the material you need to install the humidifier body.

•Choose the location of the template and make sure that a distance of approximately 14” between the furthest left vertical

line of the humidifier opening and the centre of the air take-off collar can be obtained. (Please see Fig.2).

•This 14” dimension is given for a typical installation. Some installations may differ.

•Apply the humidifier template (#1) on the return duct, level it and then attach it to the duct.

•Starting from the vertical line of the opening (the one closest to the warm air duct), measure 14” and mark the centre of

the air take-off opening.

Warning: Always check that you are not about to cut or drill into any air conditioning or electrical accessory during

installation.

•Center punch the four screw holes and the four corner holes through the template and pierce the duct with a 3/32” drill.

•Remove the template. Join the four corner holes with a marker line. Make a starting hole and cut a rectangular opening

that will correspond to the back opening of the humidifier (7-3/4” x 6-1/2”).

•Install the humidifier in the opening and attach it with the four screws #8 x 3/4”. The ribs around the humidifier back

opening must fit into the rectangular opening in the duct. Check that the humidifier body is level from side to side and from

back to front. Then fasten the humidifier to the duct.

•Fasten the motor (4.1) to the opposite side of the air intake. Kit No. 5 contains the motor (4.1) and two screws (4.2).

7. Installing the air take-off collar (Please see Fig. 2 and 10)

•Center the air take-off collar on the point previously marked on the warm air duct.

•Hold the collar (2.3) on the duct and mark the four fastening holes and the inside zone of the collar.

WARNING: Always check that you are not about to cut or drill into any air conditioning or electrical accessory during

installation.

•Drill the four fastening holes (3/32” dia).

•Make a starting hole and cut a round opening for the air take-off collar.

•Fasten the air take-off collar to the duct with screw #1 while making sure that the air damper is installed between the collar

and the air duct. The hole on the outer edge of the air damper should line up with hole #1 of the take-off collar, and the

finger pull protrudes outward (Fig. 10A).

•Install screws #2 and #3.

•Close the opening to approximately 50%.

•Install screw #4 by piercing the damper, which will hold it in position.

Self-cleaning model:

Normally, when the warm air of the furnace flows through the humidifier, it evaporates the water contained in the foam pad, leaving

behind mineral deposits.

In the self-cleaning humidifier, the principle is to eliminate a small quantity of water containing a high level of minerals before filling

the unit with fresh water. The concentration of dissolved minerals will remain low, thus leaving few or no deposits on the parts that

contact the water. Environmentally, when compared to flow-through models, this unit is extremely friendly (as low as a few pans per

day) and the only thing you will have to do is to clean the water pan and the float with hot water every three months.

In one of the front corners of the pan will be the drain mechanism. Actuated by a paddle wheel, it opens a valve every eight turns of

the drum for one minute each time, thus allowing a very controlled water discharge.

NOTE: The quantity of minerals dissolved in the water may vary from town to town, thus providing variable results.

•OPTIONAL: If the damper is snugly in place and can remain in a fixed position, screw #4 may be left out. This will allow

for easier opening and closing of the air damper.

8. Installing the flexible duct (Please see the general view Fig. 2)

•Measure the required flexible duct length necessary to connect the humidifier to the air take-off collar (2.3), so it does not

sag.

•Cut the excess portion.

•Slide the flexible duct (2.1) on the air take-off collar (2.3) and secure it by inserting the plastic pins (2.2) through the vinyl

in between two reinforcement wires.

•Repeat this operation at the humidifier side.

9. Installing the automatic valve (Please see Fig. 4, 5 and 7)

•Kit No. 2 contains all the material you need to install the automatic valve.

•Remove the oblong knock-out to open a hole where the valve has to be installed.

•Install the valve (7.1) inside the casing and fasten it with the hexagonal plastic nut (7.4). The valve body is held in a

vertical position by two ribs (4.4) of the humidifier body.

•Take the float (7.3) and install it behind the valve lever (7.2) with the pivot pin (7.5) fitted in the round hole.

•Insert the screw (7.6) in the kidney-shaped opening through the valve lever (7.2) and the float arm (7.3) and screw it into

the nut (5.1) installed in the hexagonal housing of the float arm.

•Partially tighten the screw (7.6).

10. Preparing the water pan (and the draining system if necessary) Please see Fig. 15

If this humidifier is a non-self cleaning model, no special preparation is necessary and the water pan is ready to install as is.

Please go directly to step 11.

11. Installing the pan into the humidifier

•Slide the water pan into the humidifier, between the two plastic rails located at the sides of the unit.

•Slightly open the sides of the humidifier and insert the two side tabs of the water pan into the two rectangular holes (4.5)

in the sides of the humidifier.

•Push the front of the water pan down to snap the two tabs in the sides of the humidifier.

SELF-CLEANING MODEL: The automatic valve must be installed on the same side as the air intake.

SELF-CLEANING MODEL:

The water pan and the draining system have to be assembled.

•The draining system must be installed on the same side as the motor.

•The water pan has two round knockouts on the bottom of the pan, located at the front left and right side.

•Locate the knockout that is closest to the motor and mark it on the bottom of the pan.

•Carefully make the appropriate round opening by knocking it with a flat screwdriver and a hammer.

•The drain mechanism is factory-assembled to be installed on the right side of the pan. If the motor is on the right side, then no

change is necessary.

•If the knockout hole is not big enough to receive the drain mechanism, enlarge it a little bit with a small cutter.

•Install the drain box in the water pan, the two screws of the cover towards the back of the pan. The box (15.2) has to sit between

the ribs (15.6) in the water pan. The paddle wheel (15.7) is on the right side.

•Make sure the rubber “O” ring (15.3) is between the drain box housing (15.2) and the bottom of the water pan (15.1).

•Secure the drain box (15.2) to the water pan (15.1) with the plastic nut (15.4), without stripping.

•If the motor is on the left side of the humidifier, the draining system must be reversed. Please do the following:

•After having opened the left knockout hole, install the draining system in hole of the water pan as described above.

•The paddle wheel (17.5) is still on the right side.

•Remove the two screws (16.3) retaining the cover (16.4) and open the draining mechanism.

•Carefully lift the inside plunger (16.1) and the spring (16.2) and remove them from the box.

•Observe how the shaft is positioned. Please note that the two ribs (17.3) on the shaft (17.2) are sitting on the right wall of the box

•(17.1). Take the shaft and flip it so the paddle wheel (17.5) is on the left side, the two ribs (17.3) on the shaft sitting now on the left

wall of the box (17.4).

•Put the plunger (16.1) back in its original position, then reinstall the spring (16.2) in the middle of the plunger.

•Hook the plastic cover (16.4) in the front wall of the box, making sure that the spring (16.2) sits around a plastic protrusion (16.5) in

the center of the cover (16.4).

•Carefully put the two screws (16.3) back in place to hold the cover, without stripping.

•The draining system is now reversed. Turn the paddle wheel by hand to make sure it turns freely and that it stops positively every

1/8 of a turn.

SELF CLEANING MODEL:

•Push one end of the drain hose (11.3) onto the draining system connector (11.2). The other end must be connected to a drain.

•Please install the tubing as vertical as possible and do not leave bends where water could accumulate between draining periods,

thus allowing minerals to build-up deposits in the tubing.

•The housing of the draining system is designed to protect against failure. Any overflow would be drained immediately.

12. Connecting the supply tubing to the humidifier (Please see Fig. 7)

Please ensure that operations 12, 13 and 14 are completed in sequence.

The plastic tubing MUST be kept away from hot surfaces (e.g. the warm air duct or the exhaust vent). Please measure

carefully before cutting.

IMPORTANT: Rough up both ends of the plastic tubing (approx. 1 inch long) with sandpaper in a rotating action

(7.11).

•Slip the plastic compression nut (7.9) onto the tubing, then the rubber sleeve (7.8), and finally fit one of the brass inserts

•(7.7,1/2” long, supplied with the brass valve) into the end of tubing.

•Push the tubing fully into the automatic valve, tighten the plastic compression nut (7.9) securely by hand, then add 1/2

turn with a small wrench, without stripping.

13. Installing the supply valve on a copper pipe (Please see Fig. 13)

A plastic bag contains a brass valve and all the material required to install the water supply valve. Water is taken from the

nearest cold water pipe suitable for the supply valve installation. Shut off the main water valve.

CAUTION: Please make sure that the piercing needle is completely recessed into the valve body by turning the handle

counter clockwise.

•Assemble one side of top clamp (13.1) to bottom clamp (13.2) with a screw (13.3) and a nut (13.4).

•Make sure that the rubber gasket (13.5) is in place over the piercing needle and position the valve assembly on the

copper water line.

•Assemble the other side of the top clamp (13.1) to the bottom clamp (13.2) with the remaining screw and nut.

•Tighten the two screws so that the valve is firmly attached to the water pipe. The two sides of the clamp must be parallel.

•Turn the valve handle completely clockwise until it stops. This will pierce the copper pipe and close the valve.

•This saddle valve is designed to be fully open or closed. Do not use it to regulate the water flow.

14. Connecting the water supply tubing to the supply valve (Please see Fig. 13)

• Slip the brass compression nut (13.9) onto the plastic tubing, then the nylon sleeve (13.7) with its most tapered end towards

the end of tubing.

Fit the second brass insert (13.8, 1/2” long, supplied with the brass valve) into the end of tubing.

Push the tubing fully into the supply valve. Then tighten the brass compression nut with a small wrench.

NOTE: The brass sleeve (13.6) supplied with the brass valve is to be used only if copper tubing (optional) replaces

the plastic tubing.

15. Installing the drum

The drum shaft has a flat end (14.6) that fits into the motor. The opposite end of the shaft snaps into position in the centre of

the air collar.

16. Adjusting the water level (Please see Fig. 7)

•The water level is adjusted by altering the height of the float.

•The optimal water level in the pan is at 3/4” from the top of the water pan.

•Open the main water valve then the supply valve installed on the water pipe.

•Loosen the screw (7.6) and adjust the float in such a way that it closes the automatic valve when the water level reaches

3/4” from the top of the water pan.

•Tighten the screw (7.6) when achieved.

•Wait until the automatic valve completely closes and check all fittings. If necessary, tighten the compression nuts a little

more without stripping.

17. Installing the humidistat and the transformer (Please see Fig. 1, 2, 8 and 9)

•This humidifier is supplied with a transformer that can be plugged in to any electric outlet. The humidistat is a duct

mounted type.

•The RETURN duct mounting method allows a better “sensing” of all the air returned to the furnace without being

disturbed by a sudden increase in moisture level (kitchen or bathroom), thus offering superior humidity control.

•Kit No. 4 contains all the material you need to install the humidistat.

•The humidistat should be installed on a flat and vertical surface of the RETURN duct at 6 inches minimum from the

humidifier top (Fig. 2).

•Attach the humidistat template (#2) on the duct.

SELF-CLEANING MODEL: The peg (14.7) located at the end of the drum comes in contact with the paddle wheel at every turn.

This movement allows draining at regular intervals.

WARNING: Always check that you are not about to cut or drill into any air conditioning or electrical accessory during

installation.

•Mark and drill the mounting holes and cut an opening for the humidistat.

•Push the two quick connectors (9.5) on the humidistat (9.3) terminals identified #2 (or COM) and #3 (or NO).

•Split the wire coming from the transformer (9.1) in two on a suitable distance to connect one end to one of the motor (9.2)

wires and the other end to the humidistat terminal identified #2 (or COM).

•Use the separate piece of wire (9.4) to connect the other wire of the motor to the second humidistat terminal identified #3

(or NO).

•Run the control wires through an opening located at the bottom of the front panel of the humidistat.

•Hold the wires while you install the humidistat in the opening. Check that the metal of the duct neither touches the

connections nor cuts the wire insulation. Then fasten the humidistat to the duct. The humidistat mechanism is exposed in

the duct.

•Temporarily install the control knob (8.4) on the humidistat. (Finalize after the humidifier start-up).

18. Humidifier start-up

•Plug the transformer (9.1) and slowly turn the humidistat control knob (8.4) to the maximum setting. You should hear a

click and the humidifier drum should start turning slowly (approximately 1 revolution per minute).

•THE DRUM CAN ROTATE IN EITHER DIRECTION.

•Carefully check that both ends of the water supply tubing are firmly held in place by their respective compression fitting.

•Check that the water level in the pan is at the right level and that the float closes the automatic valve completely.

•After peeling off the backing, affix the faceplate to the cover of the humidistat and re-install the control knob.

•Set the humidistat to a median value (40 %).

•Make sure that there is no leak before leaving the installation unattended.

19. Controlling the humidity level

•A relative humidity environment of 40% is recommended. However, you should take the outside temperature in

consideration before setting the humidity level in order to avoid condensation on the windows. Please refer to the table on

the humidistat to help determine the proper level.

•Each adjustment of the humidistat should be followed by a period of 24 hours to allow the general humidity level to

stabilize in the house.

•If your house remains unoccupied during the winter season, adjust the humidistat to a lower set point to prevent

condensation.

20. Humidifier maintenance tips

•Do not stop nor rotate the drum manually. Do not remove the drum when it is rotating as it may cause permanent damage

to the motor.

•Check the evaporator pad yearly and replace it if required.

•Depending on the water quality, the water pan and the float should be cleaned once a month.

21. Summer season

•If the system is used in air conditioning during the summer, reduce the air volume going through the humidifier by closing

the air damper.

•It is advisable to simply shut off the humidifier system :

1. Close the water supply valve (13.1).

2. Turn the humidistat knob (8.4) to the “OFF” position.

3. Unplug the transformer (9.1).

4. Empty and clean the water pan.

SELF-CLEANING MODEL:

Make sure that the peg (14.7) located at the end of the drum comes in contact with the paddle wheel at every turn.

Make sure that the drain tube has no bends or kinks and that the drained water flows easily to the floor drain without

accumulating in the tube.

SELF-CLEANING MODEL:

The draining system should also be cleaned once a year. Remove the screws (16.3) at the top of the plastic box and

carefully pull

the little plunger (16.1). Wash the plunger and the inside of the box with a little brush. Then re-assemble the draining unit in

the reverse order. Please refer to

Fig 16

and

instruction # 10

for a more detailed description.

WARRANTY:

This humidifier is guaranteed against any defects in material and workmanship, under normal use, for

one (1) year from the date of purchase.

The frame and door are guaranteed for life against defects in material and workmanship, under normal use.

This warranty applies only if the unit is properly installed and operated according to the instructions provided with this

product. This warranty will not cover defects due to misuse or faulty installation. The manufacturer will not be held

responsible for any damage caused by water leaking from this installation. If warranty service is required during the

warranty period, the distributor will, at its sole discretion, repair or replace the product, without charge, upon delivery

of the product to the store where it was purchased, with proof of purchase.

Spare parts for this flow-thru model are available in kits only.

Fig. Description Quantity per kit

2.1

4.1

4.2

7.1

7.2

7.3

7.4

7.5

7.6

7.7 & 13.8

7.8

7.9

7.1 & 5.1

15.2

15.3

15.4

11.3

16.1

16.2

16.6

13.1

13.2

13.3

13.4

13.5

13.6

13.7

13.8

13.9

9.1

8.1

8.2

8.3

8.4

9.5

14.5

15.1

Flexible duct

Motor

Metal screw #6 x 1/2” 2

Float & Valve

Automatic valve

Valve arm

Float

Plastic hexagonal nut 7/16-24

Pivot point of the float

Stainless steel screw 10-32 x 1/2”

Brass insert (in the supply valve kit)

Rubber ferrule

Plastic compression nut

Stainless steel hex nut 10-32

Drain kit

Drain mechanism

Rubber “O” Ring 0.375” ID x 0.500” OD x 0.070”

Plastic hexagonal nut 7/16 – 24

Drain plastic tube 3/16” ID x 5/16” OD

Plunger

Spring

Rubber “O” Ring 0.250” ID x 0.437” OD x 0.103”

Supply valve

Needle valve body & top bracket

Valve bottom bracket

Machine screw 1/4-20 x 1-3/4”

Hexagonal nut 1/4-20

Rubber gasket

Brass sleeve for copper tubing

Nylon sleeve for plastic tubing

Brass insert

Brass compression nut

Water supply tube 1/4 OD”

Plug-in transformer 120/24 VAC

Humidistat

Humidistat assembly

Flat head metal screw #6 x 1”

Self-sticking label

Adjustment knob

Quick wire connector

Evaporator pad

Self-cleaning water pan

Kit #5

Kit #2

Kit #4

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hamilton Luftbefeuchter Handbücher

Hamilton

Hamilton 10HF Handbuch

Beliebte Luftbefeuchter Handbücher anderer Marken

Boneco

Boneco H300 Bedienungsanleitung

Bionaire

Bionaire CM1 Handbuch

Air-O-Swiss

Air-O-Swiss AOS 7131 Handbuch

KING

KING K 5002 Rainbow Bedienungsanleitung

Crane

Crane EE-6902 Bedienungsanleitung

Glaziar

Glaziar Ness Bedienungsanleitung

Philips

Philips DreamStation Go Abmessungen

Honeywell

Honeywell MISTMATE HUL520BC Bedienungsanleitung

Stadler Form

Stadler Form Hera Bedienungsanleitung

Hunter

Hunter 31206 Bedienungsanleitung

TaoTronics

TaoTronics TT-AH004 Bedienungsanleitung

adorini

adorini Cigar Heaven Bedienungsanleitung

Lanaform

Lanaform Aroma Bedienungsanleitung

Aprilaire

Aprilaire 800 Series Bedienungsanleitung

Pyle

Pyle SereneLife PHUMDIF8 Bedienungsanleitung

Trotec

Trotec B 200 Bedienungsanleitung

Pure Humidifier

Pure Humidifier EC Series Bedienungsanleitung

Crane

Crane EE-864 Bedienungsanleitung
