6.0 AMP HAMMER DRILL

MODEL HDHD060

ATTACH YOUR RECEIPT HERE

Serial Number _____________________ Purchase Date ______________________

Questions, problems, missing parts? Before returning to your retailer, call

our customer service department at 1-877-888-1880, 8:30 a.m. – 8:00 p.m.

EST (Monday – Friday) & 10:00 a.m. – 6:00 p.m. EST (Saturday and Sunday).

2 6.0 AMP HAMMER DRILL

TABLE OF CONTENTS

Product Speciﬁcations ....................................................2

Safety Information .......................................................3

Preparation.............................................................7

Package Contents........................................................8

Operating Instructions ....................................................9

Care and Maintenance ...................................................17

Troubleshooting ........................................................18

Warranty..............................................................18

PRODUCT SPECIFICATIONS

COMPONENT SPECIFICATIONS

Motor 120V~, 60Hz, 6.0A

No-load speed 0-2,700 RPM

Hammer speed 0-43,200 BPM

Keyed chuck 1/2" (13 mm)

Maximum drilling capacity:

In wood

In metal

In concrete

1" (25.4 mm)

1/2" (13 mm)

Tool weight 4 lbs. 14 oz. (2.2 kg)

6.0 AMP HAMMER DRILL 3

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble or operate

this product. If you have any questions regarding the product, please call Hammerhead

customer service at 1-877-888-1880, 8:30 a.m. – 8:00 p.m. EST (Monday – Friday) &

10:00 a.m. – 6:00 p.m. EST (Saturday and Sunday).

WARNING

The operation of any power tool can result in foreign objects being thrown into your eyes,

which can result in severe eye damage. Before beginning power-tool operation, always

wear safety goggles or safety glasses with side shields and a full-face shield, when

needed. We recommend using a wide vision safety mask over eyeglasses or standard

safety glasses with shields. Always use eye protection marked to comply with ANSI Z87.1.

DANGER

People with electronic devices, such as pacemakers, should consult their physician(s)

before using this product. Operation of electrical equipment in close proximity to a heart

pacemaker could cause interference or failure of the pacemaker.

WARNING

Some dust created by power sanding, sawing, grinding, drilling and other construction

activities contains chemicals known to the state of California to cause cancer, birth defects

or other reproductive harm. Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks and cement and other masonry products, and

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you do this type of work.

To reduce your exposure to these chemical: work in a well-ventilated area, and work with

approved safety equipment, such as those dust masks that are specially designed to ﬁlter

out microscopic particles.

4 6.0 AMP HAMMER DRILL

SAFETY INFORMATION

Know the Tool

To operate this tool, carefully read this manual and all labels afﬁxed to the hammer drill

before using it. Keep this manual available for future reference.

Some of the following symbols may be used on this hammer drill. Please study them and

their meaning. Proper interpretation of these symbols will allow you to operate the tool

better and more safely.

SYMBOL DEFINITION SYMBOL DEFINITION

VVolts n 0No-load Speed

AAmps /min Revolutions, Strokes, Beats or

Impacts per Minute

Hz Hertz Class II Construction

WWatts Direct Current

A danger, warning or caution.

It means ‘ATTENTION! Your

safety is involved.’

Alternating Current

IMPORTANT: This tool should only be serviced only by a qualiﬁed service technician.

IMPORANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS-This manual contains important safety and operating

instructions for hammer drill Model HDHD060.

DANGER

To reduce the risk of ﬁre or electric shock, carefully follow these operating instructions

General Power Tool Safety Warnings

WARNING

Read all safety warnings and all instructions. Failure to follow all warnings and instructions

may result in electric shock, ﬁre and/or serious injury.

Save all warnings and instructions for future reference

The term “power tool” in the warnings refers to your mains-operated (corded) power tool or

battery-operated (cordless) power tool.

6.0 AMP HAMMER DRILL 5

SAFETY INFORMATION

Work Area Safety

• Keep work area clean and well lit. Cluttered and dark areas invite accidents.

• Do not operate power tools in explosive atmospheres, such as in the presence of

ﬂammable liquids, gases or dust. Power tools create sparks which may ignite the dust

or fumes.

• Keep children and bystanders away while operating a power tool. Distractions can

cause you to lose control.

Electrical safety

• Power tool plugs must match the outlet. Never modify the plug in any way. Do not

use any adapter plugs with earthed (grounded) power tools. Unmodiﬁed plugs and

matching outlets will reduce risk of electric shock.

• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,

ranges and refrigerators. There is an increased risk of electric shock if your body is

earthed or grounded.

• Do not expose power tools to rain or wet conditions. Water entering a power tool will

increase the risk of electric shock.

• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the

power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged

or entangled cords increase the risk of electric shock.

• When operating a power tool outdoors, use an extension cord suitable for outdoor

use. Use of a cord suitable for outdoor use reduces the risk of electric shock.

• If operating a power tools in a damp location is unavoidable, use a ground-fault circuit

interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of electric shock.

Personal Safety

• Stay alert, watch what you are doing and use common sense when operating a

power tool. Do not use a power tool while you are tired or under the inﬂuence of

drugs, alcohol or medication. A moment of inattention while operating power tools may

result in serious personal injury.

• Use personal protective equipment. Always wear eye protection. Protective

equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection

used for appropriate conditions will reduce personal injuries.

• Prevent unintentional starting. Ensure the switch is in the off-position before

connecting to power source and/or battery pack, picking up or carrying the tool.

Carrying power tools with your ﬁnger on the switch or energizing power tools that have

the switch on invites accidents.

6 6.0 AMP HAMMER DRILL

SAFETY INFORMATION

• Remove any adjusting key or wrench before turning the power tool on. A wrench or

a key left attached to a rotating part of the power tool may result in personal injury.

• Do not overreach. Keep proper footing and balance at all times. This enables better

control of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and

gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in

moving parts.

• If devices are provided for the connection of dust extraction and collection

facilities, ensure these are connected and properly used. Use of dust devices can

reduce dust related hazards.

Power Tool Use and Care

• Do not force the power tool. Use the correct power tool for your application. The

correct power tool will do the job better and more safely at the rate for which it was

designed.

• Do not use the power tool if the switch does not turn it on and off. Any power tool

that cannot be controlled with the switch is dangerous and must be repaired.

• Disconnect the plug from the power source and/or the battery pack from the

power tool before making any adjustments, changing accessories, or storing

power tools. Such preventive safety measures reduce the risk of starting the power tool

accidentally.

• Store idle power tools out of the reach of children and do not allow persons

unfamiliar with the power tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained users.

• Maintain power tools. Check for misalignment or binding of moving parts,

breakage of parts and any other condition that may affect the power tool's

operation. If damaged, have the power tool repaired before use. Many accidents are

caused by poorly maintained power tools.

• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp

cutting edges are less likely to bind and are easier to control.

• Use the power tool, accessories, tool bits, etc. in accordance with these

instructions, taking into account the working conditions and the work to be

performed. Use of the power tool for operations different from those intended could

result in a hazardous situation.

Service

• Have your power tool serviced by a qualiﬁed repair person using only identical

replacement parts. This will ensure that the safety of the power tool is maintained.

6.0 AMP HAMMER DRILL 7

SAFETY INFORMATION

Speciﬁc Safety Rules for Hammer Drill

• Hold power tool by insulated gripping surfaces, when performing an operation

where the cutting accessory may contact hidden wiring or its own cord. Cutting

accessory contacting a “live” wire may make exposed metal parts of the power tool

“live” and could give the operator an electric shock.

• Wear ear protectors when impact drilling. Exposure to noise can cause hearing loss.

• Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal

injury.

• Do not use the power tool with a damaged cord. Do not touch the damaged

cord and pull the plug from the outlet when the cord is damaged while working.

Damaged cords increase the risk of an electric shock.

• Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held

more secure than by hand.

• Always wait until the power tool has come to a complete stop before placing it

down. The tool insert can jam and lead to loss of control over the power tool.

PREPARATION

Before attempting to use the hammer drill, familiarize yourself with all of its operating

features and safety requirements.

8 6.0 AMP HAMMER DRILL

PACKAGE CONTENTS

PARTS DESCRIPTION

AChuck jaws

BChuck

CChuck-key holes

DChuck sleeve

EHammer / drilling selection switch

FDepth-stop gauge

GLock-on button

HChuck key

IChuck-key strap

JVariable-speed trigger switch

KSpeed adjustment dial

LDirection-of-rotation lever

MAuxiliary handle

NPrimary handle

6.0 AMP HAMMER DRILL 9

OPERATING INSTRUCTIONS

1. Variable-Speed Trigger Switch

a. Connect the power cord of your

hammer drill to a standard

household power outlet.

b. To turn the hammer drill ON, press

the trigger switch.

c. To turn the hammer drill OFF,

release the trigger switch.

NOTICE: The variable-speed trigger

switch delivers higher speed with

increased trigger pressure and lower

speed with decreased trigger pressure.

2. Lock-On Button

This hammer drill is equipped with a

lock-on button, which is convenient

for continuous drilling for extended

periods of time.

a. To drill continuously, press and

hold the trigger switch and then

press the lock-on button. Release

the trigger switch.

b. To unlock the lock-on button and

stop continuous drilling, press the

trigger switch and the lock-on

button will release automatically.

VARIABLE-

SPEED TRIGGER

SWITCH

LOCK-ON

BUTTON

10 6.0 AMP HAMMER DRILL

OPERATING INSTRUCTIONS

3. Speed Adjustment Dial

This hammer drill is equipped with a

speed adjustment dial; the required

speed may be adjusted according to

the material and the working condi-

tions.

The speed adjustment dial can be

adjusted even if the drill is running.

Turn the variable-speed adjustment

dial counterclockwise for a higher

speed range; turn the variable-speed

adjustment dial clockwise for a lower

speed range.

4. Direction-Of-Rotation Selector

The direction of bit rotation is revers-

ible and is controlled by a selector

located above the trigger switch. With

the drill held toward you:

a. Position the direction-of-rotation

selector to the right of the tool for

forward rotation.

b. Position the direction-of-rotation

selector to the left of the tool for

reverse rotation.

NOTICE: To prevent gear damage, always

allow the hammer drill to come to a complete stop before changing the direction of rotation.

SPEED

ADJUSTMENT DIAL

DIRECTION-

OF-ROTATION

SELECTOR

REVERSE FORWARD

Inhaltsverzeichnis

Sprachen:

Andere Hammerhead Bohren Handbücher

Hammerhead

Hammerhead HAHD075 Bedienungsanleitung

Beliebte Bohren Handbücher anderer Marken

Makita

Makita BDF456 Bedienungsanleitung

Black & Decker

Black & Decker LDX220 Bedienungsanleitung

Hitachi

Hitachi DH 40MA Bedienungsanleitung

Challenge

Challenge JO Technisches Referenzhandbuch

Makita

Makita LXFD01 Bedienungsanleitung

Festool

Festool T18+3 Bedienungsanleitung

Milwaukee

Milwaukee M12 FPDX-202X Bedienungsanleitung

EINHELL

EINHELL TE-RH 32 E Bedienungsanleitung

Makita

Makita DHP484 Bedienungsanleitung

Makita

Makita FD05 Bedienungsanleitung

Bosch

Bosch PSB 530 RA Bedienungsanleitung

Maximum

Maximum 054-1359-4 Bedienungsanleitung

Makita

Makita HP332D Bedienungsanleitung

Raider

Raider RDP-HD31H Bedienungsanleitung

Bort

Bort BPM-1400x2 Bedienungsanleitung

Black & Decker

Black & Decker 7266 Bedienungsanleitung

KENT USA

KENT USA TRD1230 Bedienungsanleitung

Bosch

Bosch GSB 19-2 RE Bedienungsanleitung
