Instruction Manual

HI 8510 • HI 8512

HI 8710 • HI 8711

HI 8720

Panel Mounted

pH and ORP

IndicatorsandControllers

SLOPE

DOSAGE

OXID. REDUC.

ΔAL

COARSE

SET

FINE

ΔAL

MEA

SURE SET

0 mV

TEST 500 mV

TEST

HI 8720E

ORP

www.hannainst.com

2£

PRELIMINARY EXAMINATION

Remove the instrument from the packing

material and examine it carefully to make

sure that no damage has occurred during

shipping. If there is any noticeable damage,

immediately notify your dealer.

Each model is supplied complete with

transparent splash-proof front cover, mounting

brackets and instruction manual

Note: Save all packing materials until you

are sure that the instrument functions

correctly. All defective items must be

returned in the original packing materials

together with the supplied accessories.

GENERAL DESCRIPTION

HI 8510 and HI8512 pH and ORP panel-

mounted indicators, and HI 8710, HI 8711

and HI 8720 pH and ORP controllers, are

ideal for process control monitoring in a wide

range of industrial applications.

These instruments have been designed for

easy and fast installation, and are provided

with membrane keypads on the front panel,

large display and autodiagnostic functions.

All connections are made through screw ter-

minals on the rear panel.

Two versions are available for each model, to

accept either a direct input from a pH or ORP

electrode (E version) or from a transmitter

through 4-20mA input (T version).

Moreover, you can choose the output

configuration for connecting a recorder or a

PLC, between 0-20 or 4-20 mA.

DearCustomer,

ThankyouforchoosingaHANNAinstruments®

product.

Please read this instruction manual carefully

beforeusingtheinstrument.

If you need additional technical information,

do not hesitate to e-mail us at

[email protected].

These instruments are in compliance with the

directives.

PreliminaryExamination ............................. 3

GeneralDescription..................................... 3

AvailableModels ......................................... 4

MechanicalDimensions .............................. 6

FunctionalDescription HI8510.................... 7

FunctionalDescription HI8512.................. 10

FunctionalDescription HI8710.................. 13

FunctionalDescription HI8711 .................. 16

FunctionalDescription HI8720.................. 20

Specifications............................................ 24

InitialPreparation ...................................... 27

OperationalGuide ..................................... 30

pHCalibration ........................................... 34

pHValuesat VariousTemperature............. 36

pH Diagnostic Tests .................................. 37

ORP Diagnostic Tests............................... 39

LEDIndication........................................... 40

TakingRedox Measurements .................... 41

ElectrodeMaintenance.............................. 43

SuggestedInstallations ............................. 47

Accessories.............................................. 49

Warranty ................................................... 55

TABLE OF CONTENTS

4£

AVAILABLE MODELS

HI 8510E020 pH indicator with electrode

input and 0-20 mA recorder

output

HI 8510E420 pH indicator with electrode

input and 4-20 mA recorder

output

HI 8510T020 pH indicator with input from

transmitter and 0-20 mA

recorder output

HI 8510T420 pH indicator with input from

transmitter and 4-20 mA

recorder output

HI 8512E020 ORP indicator with electrode

input and 0-20 mA recorder

output

HI 8512E420 ORP indicator with electrode

input and 4-20 mA recorder

output

HI 8512T020 ORP indicator with input from

transmitter and 0-20 mA

recorder output

HI 8512T420 ORP indicator with input from

transmitter and 4-20 mA

recorder output

HI 8710E020 pH controller with electrode

input and 0-20 mA recorder

output

HI 8710E420 pH controller with electrode

input and 4-20 mA recorder

output

HI 8710T020 pH controller with input from

transmitter and 0-20 mA

recorder output

HI 8710T420 pH controller with input from

transmitter and 4-20 mA

recorder output

HI 8711E020 pH controller with 2 setpoints,

electrode input and 0-20 mA

recorder output

HI 8711E420 pH controller with 2 setpoints,

electrode input and 4-20 mA

recorder output

HI 8711T020 pH controller with 2 setpoints,

input from transmitter and 0-

20 mA recorder output

HI 8711T420 pH controller with 2 setpoints,

input from transmitter and 4-

20 mA recorder output

HI 8720E020 ORP controller with electrode

input and 0-20 mA recorder

output

HI 8720E420 ORP controller with electrode

input and 4-20 mA recorder

output

HI 8720T020 ORP controller with input from

transmitter and 0-20 mA

recorder output

HI 8720T420 ORP controller with input from

transmitter and 4-20 mA

recorder output

6£

FUNCTIONAL DESCRIPTION HI 8510

FRONTPANEL

SLOPE

SENSOR

TEST

pH 7

TEST pH 4

TEST

HI 8510E

Keypad

SENSORTEST

TodisplaythemVreadingoftheelectrodeand,

therefore,verifyitsworkingcondition

pH 7 TEST

Toverifytheinternalcircuitofthemeterinterms

ofOffsetcompensation

pH 4 TEST

Toverifytheamplifier circuitofthemeter

Trimmers

ΔΔ

ΔOForOffsetcalibration

SLOPE ForSlopecalibration

MECHANICAL DIMENSIONS

The meters are provided with a black anodized

aluminum body, front and back panels in

shockproof ABS plastic and a transparent

splash-proof front cover.

Front view of the panel-mounted unit

The dimensions show the cutout size for the

installation.

Side view of the panel-mounted unit

Adjustable location brackets (supplied with

the meter) allow the indicator to slide into the

cutout and will hold the unit securely in place.

190 mm (7.50") is the minimum space re-

quired to install the indicator with complete

wiring.

190mm MIN

7.50"

135mm

5.31"

0.25/4mm

0.01/0.160"

44mm

5.67"

ADJUSTABLE

LOCATION

BRACKET

141mm

5.55" 144m

5.67

69mm

2.71"

72mm

2.83"

8£

1.Fuseholder

2. Power supply terminals

3.Recorderoutputterminals

4. Connections to the transmitter

REARPANELHI8510T

1.Fuseholder

2. Power supply terminals

3.Recorderoutputterminals

4.ConnectionsforPt100temperaturesensor

5. BNC socket for pH electrode

FUSE

ELECTRODE

INPUT

PT100

mA OUT

220

110

REARPANELHI8510E

Unplug the instrument from the power

supplybeforereplacingthefuse. Unplug the instrument from the power

supplybeforereplacingthefuse.

10£

1.Fuseholder

2. Power supply terminals

3.Recorderoutputterminals

4. BNC socket for ORP electrode

REARPANELHI8512E

FUSE

ELECTRODE

INPUT

220

110

mA OUT

FUNCTIONAL DESCRIPTION HI 8512

Keypad

0 mV TEST To verify the instrument cali-

bration at 0 mV

500 mV TEST Toverify theslope at 500 mV

Trimmers

SLOPE Forslopecalibration

FRONTPANEL

SLOPE

0 mV

TEST 500 mV

TEST

HI 8512E

ORP

Unplug the instrument from the power

supplybeforereplacingthefuse.

12£

FUNCTIONAL DESCRIPTION HI 8710

Keypad

SET To set the pH dosage limit

MEASURE To enter measurement mode

and to enable diagnostic tests

SENSOR TEST To display electrode mV reading

and verify its working condition

ΔΔ

ΔAL To display & set alarm tolerance

pH 7 TEST To verify Offset compensation

pH 4 TEST To verify amplifier circuit

Trimmers

ΔΔ

ΔOFor Offset calibration

SLOPE For Slope calibration

ΔΔ

ΔAL To set the alarm tolerance

SET/COARSE To coarsely adjust the setpoint

SET/FINE To finely adjust the setpoint

LEDs

ACID Show that acid dosage is active

BASE Show that basic dosage is active

ΔΔ

ΔAL (blinking) Indicate an active alarm

FRONTPANEL

SLOPE

ACID BASE

ΔAL

COARSE

SET

FINE

SENSOR

TEST

MEA

SURE

ΔAL

SET

pH 7

TEST pH 4

TEST

HI 8710E

1.Fuseholder

2. Power supply terminals

3.Recorderoutputterminals

4. Connections to the transmitter

REARPANELHI8512T

Unplug the instrument from the power

supplybeforereplacingthefuse.

14£

1.Fuseholder

2. Power supply terminals

3. Acid/Basic dosage selection terminals

4.Red/ox dosage consent terminals

5.Connectionsfordosingpump

6. Alarm contacts

7.Recorder output contacts

8. Connections to the transmitter

REARPANELHI8710T

1.Fuseholder

2. Power supply terminals

3. Acid/Basic dosage selection terminals

4.Red/ox dosage consent terminals

5.Connectionsfordosingpump

6. Alarm contacts

7.Recorder output contacts

8.ConnectionsforPt100temperaturesensor

9. BNC socket for pH electrode

REARPANELHI8710E

FUSE

ELECTRODE

INPUT

PT100

mA OUT

OPEN: ACID

SHORT: BASE

SET

CONSENT

ALARM

220

110

Unplug the instrument from the power

supplybeforereplacingthefuse. Unplug the instrument from the power

supplybeforereplacingthefuse.

16£

ΔΔ

ΔAl To display and set the

alarm tolerance

pH 7 TEST To verify Offset compen-

sation

pH 4 TEST To verify amplifier circuit

Trimmers

ΔΔ

ΔOFor Offset calibration

SLOPE For Slope calibration

ΔΔ

ΔAL To set the tolerance of the

alarm

ACID SET/COARSE To coarsely adjust

acid setpoint

ACID SET/FINE To finely adjust acid

setpoint

BASE SET/COARSE To coarsely adjust

basic setpoint

BASE SET/FINE To finely adjust basic

setpoint

LEDs

ACID SET (Blinking) Show that acid dos-

age is active

BASE SET (Blinking) Show that basic

dosage is active

ΔΔ

ΔAL (Blinking) Indicate active alarm

FUNCTIONAL DESCRIPTION HI 8711

Keypad

ACID SET To set the working point

of acid dosage

BASE SET To set the working point

of basic dosage

MEASURE To enter measurement

mode and to enable

diagnostic tests

SENSOR TEST To display electrode mV

reading and, therefore,

verify its working condition

FRONT PANEL

SLOPE

ΔAL

COARSE

ACID SET

FINE

COARSE

FINE

BASE SET

HI 8711E

SENSOR

TEST

MEA

SURE

ACID

SET

ΔAL

BASE

SET

pH 7

TEST pH 4

TEST

HI 8711E

18£

1. Fuse holder

2. Power supply terminals

3. Connections for dosing pump for acid

4. Connections for dosing pump for base

5. Alarm contacts

6. Recorder output contacts

7. Connections to the transmitter

REAR PANEL HI 8711T

1. Fuse holder

2. Power supply terminals

3. Connections for dosing pump for acid

4. Connections for dosing pump for base

5. Alarm contacts

6. Recorder output contacts

7. Connections for Pt100 temperature sensor

8. BNC socket for pH electrode

REAR PANEL HI 8711E

FUSE

ELECTRODE

INPUT

PT100

mA OUT

BASE

ACID

ALARM

220

110

Unplug the instrument from the power

supplybeforereplacingthefuse. Unplug the instrument from the power

supplybeforereplacingthefuse.

Andere Handbücher für HI 8510

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hanna Instruments Controller Handbücher

Hanna Instruments

Hanna Instruments HI 504 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL100 Series Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983320-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983324-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983318-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983320-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL120 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983317-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983319-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983317-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983329-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 504 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL121 Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 24 Series Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 8410 Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 8001 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL 983322-0 Bedienungsanleitung

Hanna Instruments

Hanna Instruments BL100 Series Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 700 Series Bedienungsanleitung

Hanna Instruments

Hanna Instruments pH 500 Series Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 9910 Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 9923 Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 22 Series Bedienungsanleitung

Hanna Instruments

Hanna Instruments HI 8510 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
