Hanna Instruments Primo Series Bedienungsanleitung

Instruction Manual

Primo Series

EC and TDS Testers with

Automatic Temperature

Compensation

ISTPRIMOR1 05/05

www.hannainst.com

WARRANTY

The Primo series is warranted for one year against

defects in workmanship and materials when used for their

intended purpose and maintained according to instructions.

This warranty is limited to repair or replacement free of

charge. Damages due to accident, misuse, tampering or lack

of prescribed maintenance are not covered.

If service is required, contact the dealer from whom you

purchased the instrument. If under warranty, report the

model number, date of purchase, serial number and the

nature of the failure. If the repair is not covered by the

warranty, you will be notified of the charges incurred. If the

instrument is to be returned to Hanna Instruments, first

obtain a Returned Goods Authorization number from the

Customer Service department and then send it with shipping

costs prepaid. When shipping any instrument, make sure it is

properly packaged for complete protection.

Dear Customer,

Thank you for choosing a Hanna product.

Please read carefully this instruction manual before using the

meter. If you need additional technical information, do not

hesitate to e-mail us at [email protected].

These instruments are in compliance with the directives.

PRELIMINARY EXAMINATION

Remove the instrument from the packing material and exam-

ine it carefully. If any damage has occurred during shipment,

immediately notify your Dealer or the nearest Hanna Customer

Service Center.

Each meter is supplied with batteries and instructions.

Note: Conserve all packing material until the instrument has

been observed to function correctly. Any defective item

must be returned in its original packing.

FUNCTIONAL DESCRIPTION

ACCESSORIES

HI 70031P 1413 µS/cm solution, 20 mL sachet, 25 pcs

HI 70032P 1382 ppm solution, 20 mL sachet, 25 pcs

HI 70039P 5.00 mS/cm solution, 20 mL sachet, 25 pcs

HI 7031L 1413 µS/cm solution, 500 mL bottle

HI 7032L 1382 ppm solution, 500 mL bottle

HI 7039L 5.00 mS/cm solution, 500 mL bottle

Hanna Instruments reserves the right to modify the design,

construction and appearance of its products without advance notice.

Primo 1, Primo 3, Primo 4

Range

Primo 1 1999 ppm (mg/L)

Primo 3 1999 ppm (mg/L) / 0.0 to 60°C

Primo 4 10.00 mS/cm

Resolution

Primo 1 1 ppm (mg/L)

Primo 3 1 ppm (mg/L) / 0.1°C

Primo 4 0.01 mS/cm

Accuracy (@20°C/68°F)

Primo 1 ±2 % F.S.

Primo 3 ±2 % F.S. / ±0.5°C

Primo 4 ±2 % F.S.

Calibration solution

Primo 1 HI 70032 (1382 ppm)

Primo 3 HI 70032 (1382 ppm)

Primo 4 HI 70039 (5.00 mS/cm)

Calibration

Primo 1 Automatic, at 1382 ppm

Primo 3 Automatic, at 1382 ppm

Primo 4 Automatic, at 5.00 mS/cm

Temperature Compensation

Automatic, 0 to 60°C (32 to 122°F); ß = 2%/°C

Probe

Fixed, with 1 m (3.3’) cable

Environment

0 to 50°C (32 to 122°F); RH max 95%

Battery Type / Life

2 x 1.5V / approx. 200 hours of continuous use

auto-off after 5 minutes of non-use

Dimensioni/Peso

66 x 50 x 25 mm/ 50 g

Primo, Primo 2, Primo 5

Range

Primo 1999 ppm (mg/L)

Primo 2 1999 ppm (mg/L) / 0.0 to 60°C

Primo 5 1999 µS/cm

Resolution

Primo 1 ppm (mg/L)

Primo 2 1 ppm (mg/L) / 0.1°C

Primo 5 1 µS/cm

Accuracy (@20°C/68°F)

Primo ±2 % F.S.

Primo 2 ±2 % F.S. / ±0.5°C

Primo 5 ±2 % F.S.

Calibration solution

Primo HI 70032 (1382 ppm)

Primo 2 HI 70032 (1382 ppm)

Primo 5 HI 70031 (1413 µS/cm)

Calibration

Primo Automatic, at 1382 ppm

Primo 2 Automatic, at 1382 ppm

Primo 5 Automatic, at 1413 µS/cm

Temperature Compensation

Automatic, 0 to 60°C (32 to 122°F); ß = 2%/°C

Probe

Direct, fixed

Environment

0 to 50°C (32 to 122°F); RH max 95%

Battery Type / Life

2 x 1.5V / approx. 200 hours of continuous use

auto-off after 5 minutes of non-use

Dimensions / Weight

180 x 50 x 25 mm (7.1x2.0x1.0”) / 50 g (1.8 oz.)

SPECIFICATIONS OPERATION

• Turn the meter on by pressing the ON/OFF button.

• Immerse the probe in the sample to be measured, without

exceeding the maximum immersion level.

• Stir gently and wait for stable reading. The meter auto-

matically compensates for temperature variations.

• To extend the batteries life, after 5 minutes of non-use the

meter provides for auto-off.

CALIBRATION

• Switch the meter on.

• Press and hold the ON/OFF button for about 3 seconds.

The required calibration solution value will start blinking

on the display to indicate that the calibration mode has

been entered.

“1382” for Primo, Primo 1, Primo2, Primo3

“5.00” for Primo 4, and “1413” for Primo 5

• Immerse the probe in the proper calibration solution

without exceeding the maximum immersion level.

• Stir gently and wait for about 20 seconds.

• Once the display stops blinking, the meter is calibrated

and ready for use.

BATTERIES REPLACEMENT

The "Eb" message on the LCD warns

the user when the batteries have

to be replaced.

Open the bettery compartment and

replace the both 1.5 V batteries,

while paying attention to the cor-

rect polarity.

Batteries should be replaced only in a non hazardous area

using the battery type specified in this instruction sheet.

Important note: Once the batteries have been replaced, turn

the meter OFF and then ON again. Wait for about

30 seconds to allow a complete self-test, and then

perform a new calibration.

ERROR CODES

Error in calibration, wrong calibration solu-

tion or damaged probe.

Over range.

Low battery indication.

CE DECLARATION OF CONFORMITY

Recommendations for Users

Before using these products, make sure that they are entirely

suitable for the environment in which they are used.

Operation of this instrument in residential areas could cause

interference to radio and TV equipment. Any variation intro-

duced by the user to the supplied equipment may degrade

the instrument EMC performance.

To avoid electrical shocks, do not use this instrument when

voltage at the measurement surface exceeds 24Vac or 60Vdc.

To avoid damage or burns, do not perform any measurement

in microwave ovens.
