Hanns.G JW199DPB Bedienungsanleitung
19 inch TFT LCD Monitor
JW199D
USER’S MANUAL
Congratulations!
You have just purchased a TCO'99 approved and labeled product!
Your choice has provided you with a product developed for
professional use. Your purchase has also contributed to reducing the
burden on the environment and also to the further development of
environmentally adapted electronics products.
Why do we have environmentally labeled computers?
In many countries, environmental labeling has become an established
method for encouraging the adaptation of goods and services to the
environment. The main problem, as far as computers and other
electronics equipment are concerned, is that environmentally harmful
substances are used both in the products and during their manufacture.
Since it is not so far possible to satisfactorily recycle the majority of
electronics equipment, most of these potentially damaging substances
sooner or later enter nature.
There are also other characteristics of a computer, such as energy
consumption levels, that are important from the viewpoints of both the
work (internal) and natural (external) environments. Since all methods
of electricity generation have a negative effect on the environment
(e.g. acidic and climate-influencing emissions, radioactive waste), it is
vital to save energy. Electronics equipment in offices is often left
running continuously and thereby consumes a lot of energy.
What does labeling involve?
This product meets the requirements for the TCO'99 scheme, which
provides for international and environmental labeling of personal
Page1-2 stands for
TCO’99 model only.
Please see back label
for model distinction.
computers. The labeling scheme is developed as a joint effort by the
TCO (The Swedish Confederation of Professional Employees), by
Svenska Naturskyddsforeningen (The Swedish Society for Nature
Conservation), and by Statens Energimyndighet (The Swedish
National Energy Administration).
Approval requirements cover a wide range of issues: environment,
ergonomics, usability, emission of electric and magnetic fields, energy
consumption and electrical and fire safety.
The environmental demands impose restrictions on the presence and
use of heavy metals, brominated and chlorinated flame retardants,
CFCs (freons) and chlorinated solvents, among other things. The
product must be prepared for recycling and the manufacturer is
obliged to have an environmental policy which must be adhered to in
each country where the company implements its operational policy.
The energy requirements include a demand that the computer and/or
display, after a certain period of inactivity, shall reduce its power
consumption to a lower level in one or more stages. The length of time
to reactivate the computer shall be reasonable for the user.
Labeled products must meet strict environmental demands, for
example, in respect of the reduction of electric and magnetic fields,
physical and visual ergonomics and good usability.
On the Back page of this folder, you will find a brief summary of the
environmental requirements met by this product. The complete
environmental criteria document may be ordered from:
TCO Development
SE-114 94 Stockholm, Sweden
Fax: +46 8 782 92 07
Current information regarding TCO'99 approved and labeled
products may also be obtained via the Internet, using the address:
http://www.tco-info.com/
Environmental requirements
Flame retardants
Flame retardants are present in printed circuit boards, cables, wires,
casings and housings. Their purpose is to prevent, or at least to delay
the spread of fire. Up to 30% of the plastic in a computer casing can
consist of flame retardant substances. Most flame retardants contain
bromine or chloride, and those flame retardants are chemically related
to another group of environmental toxins, PCBs. Both the flame
retardants containing bromine or chloride and the PCBs are suspected
of giving rise to severe health effects, including reproductive damage
in fish-eating birds and mammals, due to the bio-accumulative*
processes. Flame retardants have been found in human blood and
researchers fear that disturbances in foetus development may occur.
The relevant TCO'99 demand requires that plastic components
weighing more than 25 grams must not contain flame retardants with
organically bound bromine or chlorine. Flame retardants are allowed
in the printed circuit boards since no substitutes are available.
Cadmium
Cadmium is present in rechargeable batteries and in the
color-generating layers of certain computer displays. Cadmium
damages the nervous system and is toxic in high doses. The relevant
*Bio-accumulative is defined as substances which accumulate within living
organisms
TCO'99 requirement states that batteries, the color-generating layers
of display screens and the electrical or electronics components must
not contain any cadmium.
Mercury
Mercury is sometimes found in batteries, relays and switches. It
damages the nervous system and is toxic in high doses. The relevant
TCO'99 requirement states that batteries may not contain any mercury.
It also demands that mercury is not present in any of the electrical or
electronics components associated with the labeled unit.
CFCs (freons)
The relevant TCO'99 requirement states that neither CFCs nor HCFCs
may be used during the manufacture and assembly of the product.
CFCs (freons) are sometimes used for washing printed circuit boards.
CFCs break down ozone and thereby damage the ozone layer in the
stratosphere, causing increased reception on earth of ultraviolet light
with e.g. increased risks of skin cancer (malignant melanoma) as a
consequence.
Lead**
Lead can be found in picture tubes, display screens, solders and
capacitors. Lead damages the nervous system and in higher doses,
causes lead poisoning. The relevant TCO´99 requirement permits the
inclusion of lead since no replacement has yet been developed.
** Lead, Cadmium and Mercury are heavy metals which are
Bio-accumulative.
Recycling Information
We, the Hanns.G care very much about our environment protection strategy and firmly
believe that it helps us have healthier earth via appropriate treatment and recycling of
industrial technology devices at the end-of-life.
These devices contain recyclable materials, which can be re-decomposed and re-integrated
into brand-new marvels. On the contrary, other material can be classified to hazardous and
poisoned substances. We strongly encourage you to contact the provided information to
recycle this product.
For more information, please visit
www.hannsg.com
Operation Instructions
Thank you for purchasing this monitor, a high-resolution multi-scan color
monitor.
Please read this guide thoroughly before installation.
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
WARNING: (FOR FCC CERTIFIED MODELS)
This monitor has been tested and found compliant with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide proper protection against harmful interference to a
residential installation. This monitor generates, uses, and can radiate radio
frequency energy. Harmful interference to radio communication may be led
as a result if it‘s not properly installed and used. However, there is no
guarantee that interference will not occur in a particular installation. If this
monitor does cause serious interference to radio or television reception,
resetting the monitor may determine it. Moreover, users are encouraged to
correct interference by doing one or more of the following:
Reorient or relocate the receiving antenna.
Move the monitor and the receiver further away from each other.
Connect the monitor into an outlet on a circuit different from that to
which the receiver is connected.
Consult your local dealer or an qualified technician.
FCC Warning:
To assure a continued FCC compliance, a user must use a grounded
power supply cord and the provided shielded video interface cable with
bonded ferrite cores. Also, any unauthorized changes or modifications to
this monitor would void the user‘s authority to operate this device.
Note: If necessary, shielded interface cables and AC power cord must be
used to meet the emission level limits.
Content
Safety Precautions.............................................................................1
First Setup .........................................................................................2
Quick Installation................................................................................2
Front View of the Product ..................................................................3
Rear View of the Product...................................................................3
Using On Screen Display (OSD) Functions .......................................4
Supporting Timing Modes..................................................................7
Technical Information.........................................................................8
Care and Maintenance.......................................................................9
Troubleshooting .................................................................................9
Safety Precautions
This monitor is manufactured and tested on a ground principle that a user’s
safety comes first. However, improper use or installation may result danger
to the monitor as well as to the user. Carefully go over the following
WARNINGS before installation and keep this guide handy.
WARNINGS:
This monitor should be operated only at the correct power sources
indicated on the label on the rear end of the monitor. If you’re unsure of
the power supply in your residence, consult your local dealer or power
company.
Do not try to repair the monitor yourself as it contains no
user-serviceable parts. The monitor should only be repaired by a
qualified technician.
Do not remove the monitor cabinet. There is high-voltage parts inside
that may cause electric shock to human bodies, even when the power
cord is disconnected .
Stop using the monitor if the cabinet is damaged. Have it checked by a
service technician.
Put your monitor only in a clean, dry environment. Unplug the monitor
immediately if gets wet and consult your service technician.
Always unplug the monitor before cleaning it. Clean the cabinet with a
clean, dry cloth. Apply non-ammonia based cleaner onto the cloth, not
directly onto the glass screen.
Keep the monitor away from magnetic objects, motors, TV sets, and
transformer.
Do not place heavy objects on the cable or power cord.
1
For PLUG CABLE EQUIPMENT, the Socket-outlet shall be installed
near the equipment and shall be easily accessible.
First Setup
Congratulation for purchasing this monitor of high performance!
This monitor comes with the following accessories :
Quick Installation
1. Connect video cable (D-Sub cable)
Make sure both monitor and computer are powered OFF. Connect the video
cable ( D-Sub cable) to the computer.
3. Connect power cord
Connect the power cord to a properly grounded AC outlet, then to the monitor.
4. Power-ON computer and monitor
Power-ON the computer, then Power-ON the monitor.
5. Windows users: Setting the Timing Mode (Resolution and Refresh Rate)
Example: 1280 x 1024 @ 60 Hz
Resolution Right-click on the Windows desktop > Properties > Settings >
“Desktop Area”. Set the resolution.
Refresh Rate (vertical frequency) See your graphic card’s user guide for
instructions.
Example:
Power cable
2
D-Sub cable
Power cable.
D-Sub cable (15 pin)
Audio cable.
User manual.
2. Connect DVI cable
Connect the DVI cable from DVI output of computer to the DVI input of the
monitor.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Hanns.G Monitor Handbücher
Hanns.G
Hanns.G HP205 Bedienungsanleitung
Hanns.G
Hanns.G HG216DPO Bedienungsanleitung
Hanns.G
Hanns.G HW192DPB Bedienungsanleitung
Hanns.G
Hanns.G HE195 Bedienungsanleitung
Hanns.G
Hanns.G JC171DP Bedienungsanleitung
Hanns.G
Hanns.G HH221 Bedienungsanleitung
Hanns.G
Hanns.G HL221 Bedienungsanleitung
Hanns.G
Hanns.G HG171AB Bedienungsanleitung
Hanns.G
Hanns.G HW-191DPB Bedienungsanleitung
Hanns.G
Hanns.G HB-175APB Bedienungsanleitung
Hanns.G
Hanns.G Hi221AP Bedienungsanleitung
Hanns.G
Hanns.G HH-181APB Bedienungsanleitung
Hanns.G
Hanns.G HW-191APB Bedienungsanleitung
Hanns.G
Hanns.G AG172D Bedienungsanleitung
Hanns.G
Hanns.G HS191DPB Bedienungsanleitung
Hanns.G
Hanns.G HW-173ABB Bedienungsanleitung
Hanns.G
Hanns.G HW191DP (2009) Bedienungsanleitung
Hanns.G
Hanns.G HZ201 Bedienungsanleitung
Hanns.G
Hanns.G HG191RPB Bedienungsanleitung
Hanns.G
Hanns.G HB-175APB Bedienungsanleitung
