Harbor Freight Tools Remote Control Stunt Car Montageanleitung
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 19f
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2019 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m ay not be in cluded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 56166
Specifications
Batteries Required 3x “AA” Batteries (for Car)
2x “AA” Batteries (for Remote)
Frequency 27MHz
Important Safety Information
1. Changes or modifications not expressly
approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
2. Follow basic safety precautions to
reduce the risk of personal injury and/
or damage to the product during use.
3. Do not allow children younger than age 5
to use this Stunt Car. Children should
not operate without adult supervision.
4. Keep out of reach of children younger
than 3. Contains small parts that
may present a choking hazard.
5. Do not swing Remote Antenna near
your face or near other people.
6. Keep spectators and pets away. Spectators
should only watch from a safe distance.
7. Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium)
batteries. Position batteries in proper polarity.
Do not use swollen or leaking batteries.
8. Do not open the Stunt Car’s housing or
modify its design. Doing so may cause
damage and/or make it dangerous.
9. Do not use if parts are loose
or damaged. If the toy has been
damaged, immediately stop using it.
10. Only use outside or in large,
enclosed area. Do not drive near open
flames, pets, or delicate furniture.
11. If you lose control of the Stunt
Car, release the buttons.
12. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by
the operator that common sense and caution
are factors which cannot be built into this
product, but must be supplied by the operator.
13. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
Page 3For technical questions, please call 1-888-866-5797.Item 56166
Assembly
Unpacking
1. Carefully slide the cardboard support
containing the Stunt Car out of the packaging.
2. Remove the Remote.
3. Remove the Stunt Car from the cardboard. If
any part does not slide out easily, stop and
clear the obstruction before proceeding.
Installing Batteries
Remote
1. Unscrew and remove the battery
cover on the back of the Remote.
2. Insert 2 AA batteries (not included) into battery
compartment, following indicated polarity.
3. Replace the Remote battery cover.
Stunt Car
1. Unscrew and remove the battery cover from
the bottom of the Stunt Car. See below.
Battery
Cover
Battery
Compartment
2. Insert three “AA” batteries (not
included) into the battery compartment,
following the indicated polarity.
CAUTION! Replace all batteries at
one time. All batteries must be of
the same type and charge level.
3. Replace the battery compartment
on bottom side of the Stunt Car.
4. Screw cover on securely.
Page 4 For technical questions, please call 1-888-866-5797. Item 56166
Operation
CAUTION! Keep spectators a safe distance away during use.
Note: Read through this section completely and get familiar with the controls BEFORE using Stunt Car.
1. Turn Car Switch on.
2. Place Stunt Car on floor with wheels down.
Note: Each Remote control stick corresponds
to one set of wheels on the Stunt Car.
3. To move Stunt Car forward, push Left control
stick up. To move Stunt Car backward,
push Left control stick down. See below.
4. To flip the front wheels to the left, push
the Right control stick to the left. To
flip the front wheels to the right, push
the Right control stick to the right.
Note; Flipping the wheels in either direction
continuously will turn the Car in a complete circle.
5. To make the Car do a front flip to the
left, push Left control stick up and Right
control stick to the right. See below.
6. To make the Car do a front flip to the
right, push Left control stick up and
Right control stick to the left.
7. To stop the Stunt Car, release the buttons.
Note: If the Stunt Car rolls onto its back, the small
trick wheels will allow it to continue moving.
8. To make the front wheels spin in this
position, push Right control stick to
the left or right. See below.
9. After use, turn Car Switch off. Store indoors,
away from water, out of the reach of children.
Page 5For technical questions, please call 1-888-866-5797.Item 56166
Maintenance
1. Keep the Stunt Car clean and dry.
2. Store the Stunt Car out of
the reach of children.
3. Properly recycle all used batteries.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available.
Page 6 For technical questions, please call 1-888-866-5797. Item 56166
FCC NOTICE:
Caution: The user is cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try and correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Page 7For technical questions, please call 1-888-866-5797.Item 56166
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
