NSG 9000

Universal EdgeQAM

HW and Installation User’s Guide

VERSION 1.5 & UP

NSG 9000-3G & bNSG 9000

Rev D

Disclaimer

Harmonic reserves the right to alter the equipment specifications and descriptions in this publication without prior notice. No part of

this publication shall be deemed to be part of any contract or warranty unless specifically incorporated by reference into such

contract or warranty. The information contained herein is merely descriptive in nature, and does not constitute a binding offer for

sale of the product described herein. Harmonic assumes no responsibility or liability arising from the use of the products described

herein, except as expressly agreed to in writing by Harmonic. The use and purchase of this product do not convey a license under

any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic. Nothing hereunder constitutes a

representation or warranty that using any products in the manner described herein will not infringe any patents of third parties.

Trademark Acknowledgments

Harmonic and all Harmonic product names are trademarks of Harmonic Inc. All other trademarks are the property of their respective

owners.

Conventions

NOTE: The Note symbol calls your attention to additional information that you will benefit from

heeding. It may be used to call attention to an especially important piece of information you need, or it

may provide additional information that applies in only some carefully delineated circumstances.

TIP: The Tip symbol calls your attention to parenthetical information that is not necessary for performing

a given procedure, but which, if followed, might make the procedure or its subsequent steps easier,

smoother, or more efficient.

In addition to these symbols, this manual uses the following text conventions:

Data Entry: indicates text you enter at the keyboard.

User Interface: indicates a button to click, a menu item to select, or a key or key sequence

to press.

Screen Output: shows console output or other text that is displayed to you on a

computer screen.

Bold: indicates the definition of a new term.

references in online documents.

Complimentary Documentation

Document Explanation

NSG 9000 Software Guide Describes the main features, configuration and alarms

of the NSG 9000 application.

bNSG 9000 Firmware Guide Describes the main features, initial configuration and

alarms of the bNSG 9000 application.

Revision History

Table 0-1: Revision History

Revision Date Description By

A May 2009 Creating document Tova

B October 2009 Corrections to table 1-1 Tova

C November 2009 Correction to table 1-12 Tova

D July 2011 Support of additional power supply Tova

Preface

Table of Contents

Main Features and Specifications

1.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.3 NSG 9000 Physical and Power Specifications. . . . . . . . . . . . . . . . . . . 8

1.3.1 Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3.2 NSG 9000 Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3.3 Power Supply Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3.4 Power Consumption from Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.3.5 Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.4 Stream Processing Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.5 NSG 9000 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.5.1 Front Bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.5.2 EIA-232 Serial Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.5.3 Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.5.4 Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.5.5 Air Inlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.5.6 Cooling Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.6 Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.6.1 Processing Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.6.2 Module Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

1.6.3 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

1.6.4 What’s Next... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Installation

2.1 Unpacking the NSG 9000 Platform . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2 Installing the NSG 9000 Platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2.1 Rack Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2.2 Rack Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2.3 Rack Positioning and Device Mounting . . . . . . . . . . . . . . . . . . . . . . . 20

2.2.4 Rack Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.2.5 Power Source and Wiring Specifications . . . . . . . . . . . . . . . . . . . . . . 21

2.2.6 Facility Cooling Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.2.7 Required Tools for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.3 Inserting the Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.3.1 Tools for Mounting/Replacing a Module . . . . . . . . . . . . . . . . . . . . . . 23

2.3.2 Installing a DTI Card (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Cabling

3.1 Device Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.1.1 Back Panel Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.2 Cabling the GbE Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table of Contents

3.2.1 Mirroring a GbE Input Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.3 Connecting the QAM-RF Output Cables. . . . . . . . . . . . . . . . . . . . . . . 30

3.4 Connecting the ASI Monitoring Port Cables. . . . . . . . . . . . . . . . . . . . 30

3.5 Connecting the Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.6 Cabling the DTI Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.7 Connecting Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.7.1 Grounding the Mounted Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.7.2 Connecting the AC Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.7.3 Connecting the –48 VDC Power Supply . . . . . . . . . . . . . . . . . . . . . . 31

3.8 Establishing Ethernet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

3.8.1 What’s Next... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Maintenance

4.1 Cooling Fans Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.1.1 Removing and Replacing the Cooling Fans Unit . . . . . . . . . . . . . . . . 33

4.2 Hot Swapping Power Supply Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Chapter 1

Main Features and Specifications

1.1 Introduction

This platform may operate as NSG 9000, a powerful Network Services GatewayTM or as

bNSG 9000, an augmented Broadcasting Network GatewayTM.

NOTE: NSG 9000 comes with either an AC power supply or –48 VDC power supply. All types of the NSG

9000 platform are intended to be installed in restricted access locations.

1.2 Main Features

The following table describes the main features of the NSG 9000 platform:

Table 1-1: Main Specifications

Component Feature Description

Chassis Chassis 2-RU, mounts in Electronic Industries

Association (EIA) standard rack

Chassis Hot-swappable

Front Panel

The front panel module includes four cooling

fans, LCD display panel and a keypad, and

indication LEDs. The module may be removed

for maintenance purposes while the system is

operational.

Chassis Indication LEDs 2 power, alarm and 9 output status LEDs.

Processing

module

6 x GbE input

ports (3 active & 3

backup)

Provides three independent ports receiving

simultaneously different feeds

Only three ports are simultaneously active,

see, 1.6.1.5 GbE Input Ports on page 15.

Input rate of up to 1000 Mbps per port

Processing

module

1 x ASI monitoring

port

ASI monitoring port can be configured to

output the same data as a selected QAM-RF

output TS. The ASI Port can be configured to

monitor any output TS.

Processing

module

Back panel LEDs Activity and alarm LED pair for each GbE port

(12 LEDs in all).

Processing

module

10Base-T/

100Base-T

Ethernet ports

Two independent Ethernet ports, typically used

for management (ETH1) and scrambling

(ETH2).

Processing

module

2xDTI ports

(optional)

Two DTI ports, typically used for M-CMTS

applications.

Chapter 1 Main Features and Specifications Main Features

QAM-RF

module

Hot-swappable Up to 9 QAM-RF modules may be mounted in

the chassis. Modules may be added or

removed while the system is operational.

QAM-RF

modules

Up to nine QAM-

RF modules, with

2x QAM-RF ports

per module.

Overall, the

system includes

up to 18 QAM-RF

ports, capable of

carrying up to 72

QAM-RF channels

Each port carries up to four QAM channels

combined and upconverted. For further

information, refer to page 17.

QAM Mode:

ITU-T J.83 Annex-A (DVB): 8 MHz

ITU-T J.83 Annex-B: 6 MHz

ITU-T J.83 Annex-C (Japan): 6 MHz

QAM Constellations:

ITU-T J.83 Annex-A:16, 32, 64, 128, 256

ITU-T J.83 Annex-B: 64, 256

ITU-T J.83 Annex-C:16, 32, 64, 128, 256

For further QAM-RF specifications, see

product specification sheet.

QAM-RF

module

Maximum output

bit rate

ITU-T J.83 Annex-A

Up to 3xQAM channels per physical port

(Triple QAM)

Up to 6xQAM channels per module

Max output bitrate per QAM channel -

51.287 Mbps

ITU-T J.83 Annex-B:

Up to 4xQAM channels per physical port

(Quad QAM)

Up to 8xQAM channels per module

Max output bitrate per QAM channel -

38.811 Mbps

ITU-T J.83 Annex-C:

Up to 4xQAM channels per physical port

(Quad QAM)

Up to 8xQAM channels per module

Max output bitrate per QAM channel -

39.171 Mbps

Power Supply AC/DC Power

Supply Options

Two distinct types of Power Supply are

available: AC and DC. See 1.3.3 Power Supply

Specifications on page 8.

Power Supply Hot Swappable

redundant power

supply

Two independent Power Supply units may be

mounted in the chassis. The units can be

removed or inserted while the system is

operational.

Power Supply Current and load

sharing

When operating with two Power Supplies, load

is shared and balanced between the two

modules.

Table 1-1: Main Specifications

Component Feature Description

Chapter 1 Main Features and Specifications NSG 9000 Physical and Power Specifications

1.3 NSG 9000 Physical and Power Specifications

1.3.1 Physical Dimensions

1.3.2 NSG 9000 Weight

1.3.3 Power Supply Specifications

Harmonic sells power supply units that have been thoroughly qualified to operate with the

NSG 9000-3G device. Tab le 1 –4 lists power specifications of a fully populated unit toghether

with the Harmonic part numbers for the qualified power supply modules. Use these part

numbers for ordering your power supply modules.

bNSG firmware version 1.2.1 and NSG9000-3G firmware version 1.6.6 and up, supports also

power supply units with the following part number: NSG-PS-AC-03, NSG-PS-DC-03, NSG-PS-

AC-03, NSG-PS-DC-03.

Table 1-2: Physical Dimensions

Dimension Inches mm

Height 3.47 88.1

Width 19.00 482.6

Total Length (front to back) 22.88 581.2

Depth (From rack mount fixture to

back of device)

21.78 553.4

Table 1-3: NSG 9000 Weight

Configuration Weight (lb.) Weight (kg)

Chassis 33.97 15.44

Power Supply (AC/DC) 3.95 1.80

QAM-RF blade 2.29 1.04

Full platform (chassis + 2xPS +

9xQRF)

62.48 28.4

Full platform, single PS

(chassis + 1xPS + 9xQRF)

58.53 26.6

Chapter 1 Main Features and Specifications NSG 9000 Physical and Power Specifications

CAUTION: Both power supply units should be of the same part number. Power supply units with

different part numbers, may adversely affect the performance of the QAM-RF output signal.

1.3.4 Power Consumption from Grid

The following table lists the power consumtion from grid of a fully populated device and of a

single QAM-RF module. Use the consumption figure of a single module in order to calculate

the consumption of a partly-populated chassis:

For more details, see 2.2.5.2 Overcurrent protection on page 21.

Table 1–4: Power Supply Units Specifications

Harmonic Part

Number

Type

Input Voltage

Range

Input Line

Frequency Comments

NSG-PS-AC-01 AC 85 to 264 VAC 47 to 63 Hz Supports up to 24 QAM channels per RF port

NSG-PS-DC-01 DC -36 to -72 VDC N/A Supports up to 24 QAM channels per RF port

NSG-PS-AC-02 AC 100 to240 VAC 47 to 63 Hz Supports up to 24 QAM channels per RF port

NSG-PS-DC-02 DC -40 to -60 VDC N/A Supports up to 24 QAM channels per RF port

NSG-PS-AC-03 AC 100 to240 VAC 47 to 63 Hz Supports up to 36 QAM channels per RF port

NSG-PS-DC-03 DC -40 to -60 VDC N/A Supports up to 36 QAM channels per RF port

Table 1-5: Power Consumption

Max Power Consumption from Grid(Watts)

Input

Voltage

Fully Populated

Chassis

Single QAM-RF

Module

110V AC 490 36

220V AC 480

48V DC 450

Chapter 1 Main Features and Specifications Stream Processing Overview

1.3.5 Environmental Specifications

The following table lists the environmental specifications for the NSG 9000 (NSG-9K-CS-01):

1.4 Stream Processing Overview

The NSG 9000 accepts a GbE input, and outputs MPEG data over

QAM-RF signal. The following diagram shows the flow of data through the GbE channel.

NOTE: The diagram shows the flow of data via a single Quadruple

QAM-RF module. NSG 9000 may include up to 9 Quadruple QAM modules.

Table 1-6: Environmental Specifications

Parameter Description

Operating temperature 0 to 50 °C (32 to 122 °F)

Storage temperature –20 to 80 °C (–4 to 176 °F)

Relative humidity Maximum 95% non-condensing

Ventilation If units are installed in a closed rack, the rack must be

ventilated to ensure proper cooling of the units. Ventilation

rate must be:

At least 1.0 cubic meter per minute (35 cubic feet per

minute) per NSG 9000 unit.

Ventilation rate must be at least 2.2 M3/min (78 CFM) per

NSG 9000 unit. This is the air flow through the unit while fans

operate at full speed.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Harmonic Tor Handbücher

Harmonic

Harmonic NSG 9116 Handbuch

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

Huawei

Huawei EchoLife HG620 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung
