6. NOTE
○ Setting combinations of the temperature, pressure and heating time for fusing interlinings
are made according to interlining and fabric materials used.
Check carefully proper fusing condition (temperature, pressure and heating time.)
○ Although, the belt is coated with Teflon to insure heat-proof, it is breakable by cutlery
or broken pieces of metals. Be extra-careful not to put needles, ball point pens or scissors
in the belt.
○ Do not place the interlinings upside down on the belt, or the products may be caught in
the tension roller for the upper belt.
○ If there is excessive interlining, the products may be caught in the tension roller
for the lower belt even when the interlining is properly placed on the belt.
○ From time to time, remove the side cover, and check that the products are not caught
in the tension rollers. In case of the trouble, me d it immediately.
○ Replace the cloth of the cleaner with a new one before it gets dirty.
○ Clean the exfoliation device clean with a well dried floor cloth.
○ It is very hard to remove the resins adhered to the belt, but it can be cleaned up easily
with HASHIMA NEW CLEAN.
○ Lubricates the bearings and gears every one or two months.
○ Pour the accessory the HASIMA gear oil to four sites of bearing support with which the
pressure roller is provided.
○ Ensure for safety that the covers and others are normally provided with, as the interior
of the machine is under condition of very high temperature and high voltage. Don’t use
machine when the covers are open. It is dangerous.
Attention to be paid when using manual handle.
The machine is equipped with the emergency stop function in response to warping of the
belt. Moreover, it is possible to unload the finished fabric within the machine using the
accessory manual handle., when the machine has stopped due to an electric failure and so on.
But disconnect the power source from its origin, when using the manual handle as it is very
dangerous. When you resume to drive the machine, ensure the reasons why it has stopped and
make sure of safety before inputting the power source.
７． HOW TO CHANGE BELT CLEANER
※ Exchange the belt cleaner for a new one when the heat on the machine unit is cooled enough,
as it is dangerous. Set the original power source to OFF.
1. The cleaner is installed together with the strip-off device in the rear side of the machine.
2. Pull down the strip-off device.
3. The cleaner has been set at a position touching the upper/lower belts properly.
4. The cleaner can be removed easily by setting it after pulling out the lock pin.
5. The cleaner shaft is covered with left and replacement cloth covered the felt.
6. Coarse cloth such as a towel is suitable as replacement cloth, but do not use thick cloth,
which may be damage the belt.
7. Do not cover too much cloth, which may lead to an uneven separation of material or cause
the strip-off device not to return to its original position. The upper cleaner of rotary
strip-off device can be removed by pulling the left knob.
