HDTV Supply HDMI Matrix Bedienungsanleitung

HDTV Supply, Inc.

Operating Instructions

Thanks for purchasing our product.

Please be sure to read this instruction

manual Carefully before using our product.

Quick Start Guide

Page 2

User Manual

Table of Contents

Quick Start Guide

Page 3

Contents

Introduction 4

HDMI Matrix 5

Product Overview 5

Features 5

Package Contents 7

Specifications 7

Panel Descriptions 8

Front Panel 8

Rear Panel 8

Side Panel 9

Installation 9

Operation 10

Maintenance 17

Product Service 17

Provided Service 17

Mail-In Service 17

Warranty 18

Warranty Limits and Exclusions 18

Quick Start Guide

Page 4

Introduction

This is a 4-by-2 HDMI true matrix. It allows any source

(Blue-Ray player, HD DVD player, satellite receiver, game

system, etc.) to be shown on the any of the two displays

simultaneously, no matter the source is HDCP or not.

Extra infrared receiver extension and IR emitter can

control HDMI source and HDMI MATRIX.

This 4X2 HDMI Matrix Switch has the ability of

equalization and amplification to ensure HDMI signal's

transmission through long cable without quality loss.

This 4X2 HDMI Matrix Switch offers solutions for digital

entertainment center, HDTV retail and show site, HDTV,

STB, DVD and projector factory, noise, space and security

concerns, data center control, information distribution,

conference room presentation, school and corporate

training environments.

Quick Start Guide

Page 5

HDMI Matrix

Product Overview ( Model Number: MX0402-321 )

Features

Easy to use: install in seconds, no need for setting.

Allows up to four HDMI source devices to be independently switched to two

HDMI monitors, HDTVs, or projectors.

The two outputs could show the same or different source at the same time no

matter the source is HDCP or not.

Support high definition resolutions 1080P, 1080i, 720P and standard video

format.

Three switching modes：panel buttons, local IR, IR extension.

With extra infrared receiver extension and IR emitter extension for IR call back

function to control the HDMI source or HDMI MATRIX from remote rooms.

HDCP compliant.

HDMI 1.3 version.

Notice

Quick Start Guide

Page 6

HDTV Supply Inc. reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

Warning

To reduce the risk of fire, electric shock or product damage:

Quick Start Guide

Page 7

Package Contents

1.Main unit. P/N_MX0402-321.

Quick Start Guide

Page 8

2.5VDC Power Supply. P/N_VDC0502.

3.1x Remote.

4.2x IR_RX (IR receiver) extension cable.

5.4x IR_TX (IR emitter) extension cable.

6.2x IR_RX cable extender jack pair.

7.Operating Instructions. P/N_INS MX0402-321.

8.2x Mounting Ear.

NOTE: PART NUMBER (Abbreviation as P/N).

Specifications

Operating Temperature

Range

-5 to +35°C(-41 to +95 °F)

Operating Humidity Range

5 to 90 % RH (no condensation)

Input Video Signal

0.5-1.0 volts p-p

Input DDC Signal

5 volts p-p (TTL)

Signaling Rate

2.25Gbit/s

Video Format Supported

DTV/HDTV:

1080P/1080i/720P/576P/480P/576i/480i

Output Video

HDMI1.2 and HDMI 1.3

Audio Format Supported

DTS-HD、Dolby trueHD

Maximum Transmission

Distance

<15m (If needed, HDMI extender is

optional)

Power Consumption

10wtts (Max.)

Dimensions

204mmL×95mmW×29mmH/8.0''L×3.7''

W×1.1''H

Mass (Main Unit)

0.45kg

Note: Specifications are subject to change without notice. Mass and dimensions are

approximate.

Panel Descriptions

Front Panel

Quick Start Guide

Page 9

1. IR receiver.

2. Indicator of inputs (2 color LED, RED for Output1, BLUE for Output 2).

3. Input select button for Output 1.

4. Input select button for Output 2.

5. IR extension transmitter sockets.

6. Power switch.

Rear Panel

1. Mini USB for firmware update.

2. Power input.

3. IR extension receiver sockets.

4. HDMI output 1.

5. HDMI inputs.

6. HDMI output 2.

Side Panel

Quick Start Guide

Page 10

Installation

1. Connect the HDMI input sources ( such as HD-DVD, PS3, STB

etc) into the matrix switch.

2. Connect the HDMI outputs ( such as HD-LCD, HD-DLP) into the

matrix switch.

3. Power on the input source you want to show. ( Keep the unused

input power off, otherwise it may interfere the normal display.)

4. Connect the power supply into the matrix switch and turn on the

display you want to watch.

5. Use remote or push the button to choose input source. Extra

infrared receiver extension and IR emitter are supplied for

remote control.

6. IR call back from remote rooms to control the HDMI Matrix

function.

Attention: Insert / Extract cables gently.
