The remote control is a sleepy device, after adding it will
not enter into sleepy mode immediately, and will continue
activation status for 30s and wait data interaction from the
gateway, the LED indicator will stay solid on, please be patient
to wait LED indicator to turn off.
REMOVING FROM A Z-WAVE NETWORK
There are two removing methods:
Method 1: Removing from the primary controller/gateway as
follows:
1. Set the primary controller/gateway into removing mode
(Please refer to your primary controllers manual on how to set
your controller into removing).
2. Press and hold down both buttons Iand O of Group 2 over
3 seconds, LED indicator turns on, the remote control will be
set to removing mode, and waiting to be removed, after 7s LED
indicator blinks 4 times quickly to indicate successful removing.
Method 2: Factory reset the remote control will force the
remote control to be removed from a network. (Please refer to
the part “Factory Reset”of this manual)
Note: Factory reset is not recommended for removing, please
use this procedure only if the primary controller/gateway is
missing or otherwise inoperable.
HOW TO CHECK WHETHER THE REMOTE CONTROL ALREADY
ADDED TO A NETWORK
Short press any button, if LED indicator does not turn on, the
remote control does not belong to any network, if LED indicator
turns on, it means the remote control has already been added
to a network.
If the remote control already belongs to a network, follow the
removing process before adding it in your network. Otherwise
adding of this device will fail.
FACTORY RESET
Press and hold down both buttons I and O of Group 2 together
for over 10 seconds, LED indicator turns on and then blinks 4
times quickly to indicate successful factory reset.
ASSOCIATION
Z-Wave devices control other Z-Wave devices. The relationship
between one device controlling another device is called
association. In order to control a different device, the controlling
device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups
and they are always related to certain events (e.g. button
pressed). In case the event happens all devices stored in the
respective association group will receive a common wireless
command.
ASSOCIATION GROUPS
Each group supports maximum 5 nodes for association, the
same device can be associated with multiple groups on
the remote control simultaneously, to ensure better control
experience, the remote control shall remove the associated
devices that are not under working status from association
groups in time.
ASSO-
CIATION
GROUPS
GROUP
NAME
MAX
NODES
DESCRIPTION
Group 1 Lifeline. 5 1. Send Command Class ”Device Reset Lo-
cally Notification V1”to associated devices of
this group to report factory reset information
when factory reset the remote control.
2. When remote control battery power value
changes, send Command Class ”Battery
Report V1”to associated devices of this group
to report power value information.
3. Short press or press and hold any button
to send scene activation command to the
associated devices of this group using
Command Class“Central Scene Notification
V3”
Group 2 Launch 1 5 Short press I /O button of Group 2 to send
ON/OFF command to associated devices of
this group using Command Class
”Basic Set V2”.
Press and hold down I / O button of Group 2
to send light intensity
increase/decrease command to associated
devices of this group using Command Class
”Multilevel V4”.
Group 3 Launch 2 5 Short press I /O button of Group 3 to send
ON/OFF command to associated devices
of this group using Command Class ”Basic
Set V2”.
Press and hold down I / O button of Group
3 to send light intensity increase/decrease
command to associated devices of this group
using Command Class ”Multilevel V4”.
Group 4 Launch 3 5 Short press I /O button of Group 4 to send
ON/OFF command to associated devices
of this group using Command Class ”Basic
Set V2”.
Press and hold down I / O button of Group
4 to send light intensity increase/decrease
command to associated devices of this group
using Command Class ”Multilevel V4”.
Group 5 Launch 4 5 Short press I /O button of Group 5 to send
ON/OFF command to associated devices
of this group using Command Class ”Basic
Set V2”.
Press and hold down I / O button of Group
5 to send light intensity increase/decrease
command to associated devices of this group
using Command Class ”Multilevel V4”.
SET AND UNSET ASSOCIATIONS
NOTE: ALL ASSOCIATION INFORMATION WILL BE CLEARED
AUTOMATICALLY ONCE THE REMOTE CONTROL IS EXCLUDED FROM
A NETWORK.
There are two methods to set associations:
1. Set association by operating primary controller/gateway to
send association command to the remote control:
When set association from primary controller/gateway, the
remote control shall be activated first, if it is not activated, you
should activate it manually.
The primary controller/gateway sends association command
to the remote control using“Command Class ASSOCIATION”or
“Command Class Multi Channel Association”
2. Set association by operating the remote control and devices
to be controlled:
