R
POWER PACK 320
User’s Manual & Installation Guide
Index V1.1
1
Connection Diagram
Products Table
Accessories
Technical Drawing
Back Cover
5
6
7
8
9
Safety Information
Warranty
Marking
2
Explanation
Details
Ordering Information
3
Block Diagram
4
Cover & Index
www.heraled.com 2
20
POWER PACK 320
R
Safety Information
Warranty
Caution – unplug the power supply from the main power before connecting any cables as this can damage the products.
Caution – avoid looking directly into the led light source at close range for your own safety.
Any people installing this product should comply with local standards and regulations and must be qualifed for the handling of
electrical equipment.
• Do not attempt to install or use the product until installation instructions and safety labels are fully understood.
This product is designed for indoor and outdoor usage.
• Ensure product operates within the specifed temperature range.
• Do not attempt to open the product.
• Do not use the product if the power cables are damaged.
• Only use product for specifed voltage.
• Always maintain connection to ensure waterproofing.
• If the product has been subjected to drastic temperature variances, for example, following transportation,
do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric
shock and product damages.
• When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat
(and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies..
• Any non-compliance of the Installation Guide will void the Hera warranty.
Hera warrants the products for a period of three (3) years from date of purchase, provided that
the purchased items are used under the conditions stated in this user manual.
Marking
Please study this Installation Guide thougly and check the lates Tecnical Specification Sheets available from the
Our website www.heraled.com before setup.
Details
Hera Power Pack® 320; consists of power supply unit and full isolated DMX splitter. DMX isolates the signal independently from each
other and delivers it with 5 Pin Push-Lock type Connector to power and DMX output. Furthermore, it is delivered to the standard DMX
output by isolating it. It has 90~264VAC 50/60Hz Universal operating voltage and 320 Watt power. It has active PFC. It is manufactured at
two different types as 24V and 48V. It has been shaped from plate, having aluminum body. It is produced RAL9004 black as a standard. It
can be assembled to the walls with the lobes at the sides.
Legendary solution in long distance DMX transmission
• DMX input and output with standard Neutrik® DMX connectors
• Power output with 5 Pin Push-Lock connectors
• It is cooled down with adjustable speed fan
• Safe use in interior spaces with IP20 protection
Explanation
Power Supply : Internal Power Supply 320 Watt With Active PFC
Input : 90~264VAC 50/60Hz Universal AC input / Full range
AC Input 3-Pin VDE Male Socket
Output : 5-Pin IP67 Waterproof Connector (Power + DMX)
DMX Signal Input and Output 3 Pin XLR
Housing : Aluminium Sheet Metal With Powder Finishing
Screw and Mounting Accessories : Black Iron
Temperature :Operating : -40°C - 50°C - (-40° - 122° F)
Storage : -40°C - 85°C - (-40°C - 185° F)
Dimensions (H x W x D) : 55x250x200 mm (2,16x9,84x7,87 in)
Weight : 1,7 kg (3,7 lb)
Certification : EU safety: EN 60950
EU EMC: EN 55103-1, EN 55103-2, EN 55022, EN 55024, EN 61000-3-2, EN 61000-3-3
US safety: ANSI/UL 60950-1
POWER PACK 320
R
Ordering Information
Power Pack® 320-48 1x320W Power Supply P08002
Power Pack® 320-24 1x320W Power Supply P08010
www.heraled.com 3
*Standart product codes that we provided is above. Please contact us for special orders.
POWER PACK 320
R
Indoor Zone
Block Diagram
POWERDMX OUTDMX INUSB
DMX Signal
8
Any device which supports Art-Net to DMX 512 or USB Interface
Please Check MADRIX Web Site
Minimum Computer System Requirements
Art-Net
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
www.heraled.com 4
Outdoor Zone
White
DMX (+)
Blue
DMX (-)
Black
GND
POWER PACK 320
R
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
DMX 512
Connection DiagramConnection Diagram
Connection Diagram
White
DMX (+)
Blue
DMX (-)
(+)48VDC
DMX(+) DMX(-)
GND
www.heraled.com 5
Black
GND
*Please check 6. page for numbers of product connection
POWER PACK 320
R
Sword® 25x1Series 30cm
32 pcs. PD®60S Dome Pixel Dot Series
32 pcs.
12 pcs.
Sword® 25x1Series 50cm
Sword® 25x1Series 100cm
Sword® 25x1Series 150cm
Sword® 50x1 Series 30cm
Sword® 50x1 Series 50cm
Sword® 50x1 Series 100cm
Sword® 50x1 Series 150cm
Sword® 100x1 Series 30cm
Sword® 101x1 Series 50cm
Sword® 101x1 Series 100cm
Sword® 101x1 Series 150cm
Sword® 100x4 Series 30cm
Sword® 101x4 Series 50cm
Sword® 101x4 Series 100cm
Sword® 101x4 Series 150cm
Vertical Tube® Series 50cm
Vertical Tube® Series 100cm
Vertical Tube® Series 150cm
Vertical Tube® Series 200cm
Pd®60 Dome Pixel Dot Series
PD®60S Pixel Dot Series
Pd®60 Pixel Dot Series
6 pcs.
4 pcs.
3 pcs.
14 pcs.
8 pcs.
4 pcs.
2 pcs.
32 pcs.
32 pcs.
17 pcs.
11 pcs.
32 pcs.
32 pcs.
17 pcs.
11 pcs.
28 pcs.
17 pcs.
8 pcs.
5 pcs.
www.heraled.com 6
Products Table
POWER PACK 320
R
A01020
5 Pole Female IP67 Push-lock Connector
Optional
A01022
AC Male Connector
Standard
A01014
NC3FXX 3 Pole Female XLR Connector
Optional
27mm
1.06"
Accessories
56mm / 2.2"
73mm / 2.8"
19.2mm
0,75"
A01015
NC3MXX 3 Pole Male XLR Connector
Optional
70mm / 2.68"
19.2mm
0,75"
*Standart product codes that we provided is above. Please contact us for special orders.
www.heraled.com 7
280 mm / 11.0"
55 mm
2.16"
200 mm
250 mm / 9,84"
7.82"
POWER PACK 320
R
Technical Drawing
www.heraled.com 8
