HH Electronics Tensor-SOLO Bedienungsanleitung

USER MANUAL


Page 1

CONTENTS
TENSOR-SOLO OVERVIEW .............................................................................................................................. 2
FEATURES ......................................................................................................................................................2
WHAT’S INCLUDED ...................................................................................................................................... 2
SETUP .................................................................................................................................................................. 3
CONTROLS......................................................................................................................................................... 3
CHANNELS 1/2.............................................................................................................................................. 4
CHANNELS 3/4.............................................................................................................................................. 4
MASTER CONTROLS .................................................................................................................................... 5
MAINS INLET .................................................................................................................................................6
SPECIFICATIONS ............................................................................................................................................... 7
BLACK............................................................................................................................................................. 7
WHITE............................................................................................................................................................. 8
DIMENSIONS.................................................................................................................................................9
SAFETY AND WARNINGS...............................................................................................................................10




Page 2

TENSOR-SOLO OVERVIEW

The Tensor-SOLO all-in-one column PA delivers a superior audio experience from an ultra portable

system. The 8" subwoofer and six 2.75”drivers allow for crystal clear audio coverage for 100+ people.

With its simple 4-piece ‘slot together’ design, the Tensor-SOLO can be set up swiftly and effortlessly.

Microphones or line level devices such as keyboards can connect to the Tensor-SOLO simultaneously

via the 4-channel mixer. Bluetooth enabled devices can also connect for wireless audio streaming and

with integrated True Wireless Stereo technology (TWS), two Tensor-SOLO systems can be linked for

stereo audio transmission wirelessly. The on-board DSP provides 4 EQ presets for different voicings

as well as comprehensive audio protection to prevent the system being overloaded. Carry bag and

slip cover are included, and its super-lightweight –weighing just 13Kg, 29lbs; the Tensor-SOLO is the

ultimate wireless audio solution.

FEATURES

•Ultra-lightweight 4 piece design weighing only 13Kg

•Impressive audio performance –perfect for 100+ people

•High power ensuring impressive coverage without compression

•4-channel mic/line mixer with built-in reverb

•Bluetooth connectivity including TWS system linking

•4x DSP presets for swift and effortless setup

•Available in black (Tensor-SOLO-BK) or white (Tensor-SOLO-WH)

WHAT’S INCLUDED

•Main Subwoofer unit

•1x top column loudspeaker

•2x top column spacers

•Padded slip cover for subwoofer

•Padded 3 piece column carry bag

•IEC power cable

Page 3

SETUP

The Tensor-SOLO may be used with either one or two spacer units depending on the unit’s position

and your chosen usage. For floor mounted operation, two spacers are recommended.

Position the subwoofer on a stable surface in the desired location, then proceed to fit the spacer

columns by firmly pressing them into position. Finally insert the column loudspeaker, ensuring all

joints are firmly pushed into position.

Care must be taken to position the unit to avoid causing a hazard, ensuring it cannot be knocked or

tripped over. If in doubt the unit should be secured in place.

A. Tensor-SOLO Subwoofer and amplifier

B. Two identical spacer pillars

C. Column loudspeaker

Page 4

CONTROLS

CHANNELS 1/2

1. LEVEL CONTROL

Controls the input level individually for channels 1

and 2. Set to minimum when first setting up your

inputs and gradually increase to a suitable volume.

2. LINE/MIC SWITCH

Switch to adjust gain for each channel. 40dB

added in the MIC setting for lower level inputs.

0dB added in LINE mode.

3. REVERB SWITCH

Toggle the internal reverb for each channel

individually. Reverb level is controlled separately.

4. XLR/6.3mm COMBI JACKS

Channel 1 and 2 inputs take either XLR or 6.3mm

jack. Can connect balanced or unbalanced signals.

CHANNELS 3/4

5. LEVEL CONTROL

Set the input level for both line level channels 3 & 4. Set to

minimum when first setting up your inputs and gradually

increase to a suitable volume.

6. BLUETOOTH INDICATOR

The blue LED indicates the Bluetooth status. Flashing indicates

attempting to connect and a solid blue light indicates a

connection. Short press the button to connect to your device –

it will show as ‘HH-Tensor’.

To connect a second system, hold the TWS button with a

device already connected. Then hold the TWS button on your

second system that will then auto pair.

7. AUX AND RCA INPUTS

A pair of RCA phono sockets and a single 3.5mm stereo

socket for auxiliary audio. Intended for line level audio use.

Both inputs may be used simultaneously.

Page 5

MASTER CONTROLS

8. MASTER VOLUME

Control the overall volume of all 4

channels. Set to minimum when setting

up inputs and gradually turn up to a

suitable volume.

Power LED will light green when the

system is powered on. The same LED

will turn red when the signal is being

limited by the onboard limiters.

Occasional flashing of red is ok

however avoid continuous illumination

of red limit light. Turn the master

volume down if so.

9. REVERB LEVEL

Set the reverb level for channel 1/2

reverbs. Will only work if the reverb

switches (3) are on.

10. DSP PRESET SELECT

4 EQ presets are loaded onto the Tensor-SOLO to enhance your sound depending on the use case.

Use the button to cycle through each preset. The 4 green LEDs will light one at a time to signal the

corresponding preset that is currently selected. The 4 green LEDs indicate which preset is currently

active.

MUSIC –Bass and treble lift with flat mids

BAND –Bass lift, flat mids and a slight treble cut off

NATURAL –Mostly flat with a slight bass and treble cut off

SPEECH –Large bass roll off and otherwise flat –intended for use with microphones

11. MIX OUT

Line level output that includes all 4 channels and is pre master volume.

Page 6

MAINS INLET

12.VOLTAGE SELECT SWITCH

The Tensor-SOLO is a dual voltage device, capable of being used around the world.

This switch should be correctly set for your country already. Although every effort has been made to

select the correct voltage for the region of use, it is advised that this is checked before first powering

on. Damage could occur if the voltage is incorrectly set.

Only change this setting with the mains cord unplugged and ensure it is set correctly before

powering on. Fuse change (14) will be required if the voltage is switched.

13. POWER SWITCH

Turns the system on and off. It is good practice to keep the master volume at minimum when

switching on and off.

14. MAINS INLET SOCKET

IEC input to connect the provided mains lead.

The safety fuse is included in the pull out drawer. Only replace the fuse with the type and value

indicated on the rear panel.

Page 7

SPECIFICATIONS

BLACK

Model

Tensor-SOLO:BK

Colour

Black

System Type

Ultra Portable Column PA System

Frequency response

50-20kHz

Max SPL (1M)

(Peak)

123 dB SPL

Power Rating

300W RMS, 1200W Peak

Amplifier Type

Class D

Power Supply

Universal SMPS 100-240V~

Protection

Short circuit, Thermal overload, multi band limiter

Inputs

2x Combo (XLR/Jack) balanced/unbalanced input with Mic/Line preset switch.

3.5mm Stereo Aux in, 2x RCA, Bluetooth V5.0 Audio Receiver

Outputs

Balanced XLR mix out.

Controls

CH1-3 Level, CH1-2 Reverb on/off switch, Master Volume, Bluetooth Pairing, EQ

preset

LF Driver

8" HH Long Throw Woofer

Hi/Mid Drivers

6x 2.75"

Cabinet

Robust Polypropylene Enclosure (Sub), ABS (Sat)

Accessories

1x Padded Subwoofer Slip Cover, 1x Padded 3 Piece Column Carry Bag included

Other

Illuminating HH Logo

Dimensions

Overall Height

(assembled)

1975mm, (77.8")

Overall Weight

(assembled)

14.1Kg, 31.1 lbs

Top Unit

dimensions (HWD)

560 x 105 x 105mm, 22" x 4.1" x 4.1" (560 x 105 x 105mm, 22" x 4.1" x 4.1"

Spacers)

Top Unit Weight

1.7Kg, 3.7 lbs (1.1Kg, 2.4 lbs Spacers)

Sub Unit

dimensions (HWD)

403 x 320 x 300mm, 15.9" x 12.6" x 11.8"

Sub Unit Weight

9Kg, 19.8 lbs

Carton dimensions

(HWD)

660 x 510 x 420mm, 26" x 20.1" x 16.5" (0.142 M3)

Packed Weight (Inc

Accessories)

17.1Kg, 37.7 lbs

EAN13

5060109458626

Page 8

WHITE

Model

Tensor-SOLO:WH

Colour

White

System Type

Ultra Portable Column PA System

Frequency response

50-20kHz

Max SPL (1M) (Peak)

123 dB SPL

Power Rating

300W RMS, 1200W Peak

Amplifier Type

Class D

Power Supply

Universal SMPS 100-240V~

Protection

Short circuit, Thermal overload, multi band limiter

Inputs

2x Combo (XLR/Jack) balanced/unbalanced input with Mic/Line preset switch.

3.5mm Stereo Aux in, 2x RCA, Bluetooth V5.0 Audio Receiver

Outputs

Balanced XLR mix out.

Controls

CH1-3 Level, CH1-2 Reverb on/off switch, Master Volume, Bluetooth Pairing, EQ

preset

LF Driver

8" HH Long Throw Woofer

Hi/Mid Drivers

6x 2.75"

Cabinet

Robust Polypropylene Enclosure (Sub), ABS (Sat)

Accessories

1x Padded Subwoofer Slip Cover, 1x Padded 3 Piece Column Carry Bag included

Other

Illuminating HH Logo

Dimensions

Overall Height

(assembled)

1975mm, (77.8")

Overall Weight

(assembled)

14.1Kg, 31.1 lbs

Top Unit dimensions

(HWD)

560 x 105 x 105mm, 22" x 4.1" x 4.1" (560 x 105 x 105mm, 22" x 4.1" x 4.1"

Spacers)

Top Unit Weight

1.7Kg, 3.7 lbs (1.1Kg, 2.4 lbs Spacers)

Sub Unit dimensions

(HWD)

403 x 320 x 300mm, 15.9" x 12.6" x 11.8"

Sub Unit Weight

9Kg, 19.8 lbs

Carton dimensions

(HWD)

660 x 510 x 420mm, 26" x 20.1" x 16.5" (0.142 M3)

Packed Weight (Inc

Accessories)

17.31Kg, 38.2 lbs

EAN13

5060109458633

Page 9

DIMENSIONS
