HiBoost 4K Plus Bedienungsanleitung
4K Plus
4K Plus Pro
10K Plus
10K Plus Pro
User Manual
Home Mobile Signal Booster
Boost Your Bars
3150 Premier Drive,Suite 130,
Irving, TX 75063
(972) 870-5666
www.hiboost.com
Package Content
Introduction
Pre-Installation Instructions
light pattern
APP Assisted Installation
LCD Assisted Installation
Quick Troubleshooting Guide
Technical Specifications
Authorized Accessories List
FCC and IC Statements
Return and Warranty Policies
01
03
04
11
13
28
40
43
44
45
48
CONTENTS
01
Package Content
HIBoost 4K/10K Plus
Signal Booster
Outdoor Antenna Outdoor CableOutdoor Cable
49.2 ft NM-SMAM
16.4ft SMAF-NM
Through-Window Cable
Power Supply Accessories for main parts
Waterproof tape
02
Package Content
NOTE: Available accessories can be purchased through HiBoost.com
Warning: Un-authorized antennas, cables, and/or coupling devices are prohibited
by new FCC rules. Please contact FCC for details: 1(888)-CALL-FCC
HiBoost 4K/10K Plus Pro
Power Supply Accessories for main parts
Signal Booster
Outdoor Antenna Outdoor CableOutdoor Cable
49.2 ft NM-SMAM 16.4ft SMAF-NM
Through-Window Cable
waterproof Indoor Antenna Indoor Cable
30 ft NM-SMAM
03
Introduction
Thanks again for purchasing HiBoost cell Booster. The HiBoost Plus/Pro series is a collection
of precision-engineered products that improve cellular reception inside of homes and
businesses by amplifying incoming and outgoing cell phone signals.
Both HiBoost Plus and Plus Pro have built-in antennas, so both can directly receive and
send signals through boosters. But Plus Pro has one more indoor antenna to facilitate the
need to cover more rooms.
HiBoost Plus/Pro exclusive cloud-based Signal Supervisor mobile application and LCD
display allow users to monitor the live status of HiBoost Plus/Pro cell phone signal boosters
directly from the LCD display or remotely from a mobile device anywhere at any time.
If there are any issues while installing a HiBoost Plus/Pro cell phone signal booster, please
contact the HiBoost technical support team through the following options:
Online Support: Create a ticket or chat via Signal Supervisor App
(972) 870-5666 (M-F from 9 am – 5 pm CST)
www.hiboost.com
04
We strongly recommend you to read the user guide completely before you install.
HiBoost 4K/10K Plus/Plus Pro provide 2 options of booster installation,
APP and LCD installation ways are unique methods provided by HiBoost
1. App assisted installation,
FIRST CHOICE From Page 13~27.
It’s more convenient and many work could be done by ONE
person, and the most important is that the obtained signal
can be very precise.
2. LCD assisted installation,
SECOND CHOICE From Page 28 ~39.
It can achieve the same precise effect as App guidance.
But it may need two people and the installation process is a
little cumbersome.
LCD signal meter tells how
strong the signal is
Pre-Installation Instructions
The App helps you find the
best signal outside
05
Then why has HiBoost spent extra big efforts and costs to design APP and
LCD signal meters to help you install?
Out of the various reasons, the most important reason is that we would like you, our
valuable client, to get the maximum output power from the booster system in order to get
optimal signal reception for all your mobile devices.
As it is known and a big thanks, FCC makes signal boosters legal in 2014 so that every
body can install and benefit from the signals;
But FCC regulations do limit the gain and output power of all consumer boosters to low
values in order to avoid any interference to the cell towers;
Furthermore FCC stipulates that any improper install should trigger immediately further
reduction of the booster’s already-limited gain and power to protect the towers.
Therefore, you can understand how important you need to find the perfect outside
signal from the tower and how important to squeeze every last gain and power from
the booster, even 1dB more power is so precious when you suffer from no signals.
HiBoost App & LCD signal meters will help you to fine tune the best power and get
as much cover of your spaces.
06
General Working Principle:
※Please do spend sometime to read it fully, as it is crucial to get full bars for your rooms.
Before we start any of the two ways, please allow us to spend 3 pages to make you
understand how the booster system works for you.
How HiBoost Booster works
1. Outdoor antenna receives outside
signal from the nearby cell tower and
sends it to HiBoost Booster
2. The booster amplifies the signal
and sends to indoor antenna(s);
3. Indoor antenna(s) receive amplified
signal and send it throughout your
rooms
Vice versa,booster(plus)/indoor antenna receices cellphone signal and sends to the booster
The booster then amplifies the signal and sends it to outdoor antenna
Outdoor antenna sends signal to the cell tower
Then you can make phone calls and internet streaming.
07
08
