Highland MC-DY3020Power101 Bedienungsanleitung
1300W Electric Griddle
MODEL #MC-DY3020Power101
ITEM #3846377
888-251-1024
HIGHLAND and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
TM
TM
SM21473
11
1300W
3
4
6
9
9
9
Package Contents ...........................................................................................................................
Safety Information ...........................................................................................................................
Operating Instructions ......................................................................................................................
8
Technical data of the product ...........................................................................................................
6
Ingredients Cook Menu ....................................................................................................................
Troubleshooting ...............................................................................................................................
Cleaning and Maintenance ..............................................................................................................
Warranty ..........................................................................................................................................
A
B
C
Handle
Glass Cover
Base
1
1
1
PART DESCRIPTION QUANTITY
D
Bottom Plate 1
E
Baking Tray 1
F
Working Indicator Light 1
G
Adjusting Knob 1
H
Pancake Pan 1
I
Casserole Pan 1
J
Tokoyaki Pan 1
A
C
E
F
G
B
D
H
J
I
When using your electrical appliances, basic safety precautions should always be
followed to reduce the risk of fire, electric hazard and injury to persons, including the
following.
1. Read all instructions.
2. Do not touch hot surface. Use handles or buttons of control panel. The unit body will
become very hot during long-time using, handle it carefully.
3. Close supervision is necessary when any appliance is used by or near children.
4. To protect against electrical shock, do not immerse cord, plug, or cooker body in water
or other liquid.
5. Unplug from outlet when not being used and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair, or adjustment.
7. The use of accessory attachment not recommended by the appliance manufacturer
may cause injuries.
8. Intended for countertop use only.
9. Do not use the appliance for other than intended use.
10. Do not use outdoors.
11. Extreme caution must be used when moving an appliance containing hot oil or other
hot liquids.
12. Do not let cord hang over edge of table and counter, or touch hot surface.
13. Prior to first use, please make sure that the electric rating of the appliance is in
conformity with the current electric rating.
14. To disconnect, the any control to "off", then remove plug from wall outlet.
15. DO NOT place unit on or near a hot gas or electric burner, or in a heated oven.
16. Only carry the electric griddle from the side handles on the cooking base.
17. a) A short power-supply cord (or detachable power-supply cord) is provided to reduce
the risk resulting from becoming entangled in or tripping over a longer cord.
b) Longer detachable power-supply cords or extension cords are available and may be
used if care is exercised in their use.
c) If a longer detachable power-supply cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least
as great as the electrical rating of the appliance;
2) The cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally;
3) If the appliance is of the grounded type, the cord set or extension cord should be
a grounding-type 3-wire cord.
18. HOUSEHOLD USE ONLY.
19. This appliance is not intended for deep frying foods
SAVE THESE INSTRUCTIONS
5
20. This appliance is not intended for use by people (including children) with reduced
physical, sensory, or mental capabilities or lack of experience and knowledge, unless
they have been provided with supervision or instruction concerning use of the
appliance by a person responsible for their safety.
21. Children should be supervised to ensure that they do not play with the appliance.
22. The appliance shall be installed in accordance with national wiring regulations.
6
OPERATING INSTRUCTIONS
1. Insert the power plug and make sure it is plugged
in.
2. Turn the adjusting knob in the front to the high
temperature position.
3. Apply cooking oil on the surface of the baking
tray(E).
C
C
C
E
7
4. Put the food into the baking tray (E) after the oil is
hot.
5. Put on the glass cover, start cooking, open the
glass cover and stir the food at the right time to
ensure uniform heating.
6. After cooking, unplug the power cord and wipe
the baking tray (E) with a wet towel after cooling
down.
C
C
C
E
E
8
INGREDIENTS COOK MENU
Takoyaki Pan
Pancake Pan
Takoyaki Balls
Beef
hamburger
Octopus
Low-gluten
flour
Eggs
Salt
Water
Beef
Casserole Pan Fried Chicken
Wings
Chicken
wings
Salt
Ginger
Onion
Soy sauce
1、Chop up the cooked octopus. Most recipes call
for 1⁄2 inch (1.3 cm) cubes of octopus.
2、Combine and whisk the dry ingredients of the
recipe. These include: 2 eggs, 1 cup of Low gluten
powder and 1 tsp baking powder. Add some salt or
sugar as you like.
3、If the batter appears too thin, add a small
amount of flour and whisk thoroughly. If the batter
appears too thick, add a small amount of water and
mix.
4、Turn on the machine, Pre-heat for 3 mins and
then heat the takoyaki on high level for 3 mins or
more. Add the octopus to the takoyaki.
5、Turn each piece 180 degrees so that the cooked
portion on the bottom of the each ball faces
upwards until cooked.
1、Chop up the beef,add some salt or whatever
you like.
2、Turn on the machine, Pre-heat for 3 mins and
then heat the hamburger on high level for 3 mins or
more.
3、Turn each piece 180 degrees so that the cooked
portion on the bottom of the each hamburger faces
upwards until cooked.
1、Brine the wings. Stir chicken wings with ginger,
green onion and soy sauce for half an hour.
2、Turn on the machine. Pre-heat for 3 mins and
then heat the chicken wings on high level for 3 mins
or more.
3、Turn each piece 180 degrees so that the cooked
portion on the bottom of the each wings faces
upwards until cooked.
Accessories Menu Ingredients Steps
TECHNICAL DATA OF THE PRODUCT
HIGH：200-230℃(392- 446 ℉)
MED：150-180℃(302- 356 ℉)
LOW：100-130℃(212-266℉)
WARM：50-80℃(122-176℉)
(Just for reference)
TROUBLESHOOTING
9
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Working
light is
always
off
The
working
light is
always
on and
never
off
The heating
plate stops
functioning
1. The power supply is not
connected
2. Internal wire is disconnected
3. Fuse is burnt out
4. The temperature controller is
damaged
1. Check whether the switches,
plugs, sockets, power leads are
intact or not, and ensure that the
plugs and sockets are in right place.
2, 3, 4 send to the designated
maintenance department for
maintenance
The heating
plate starts
functioning
The temperature controller is
damaged
Send to the designated
maintenance department for
maintenance
The heating
plate starts
functioning
Indicator light is damaged Send to the designated
maintenance department for
maintenance
The heating
plate stops
functioning
1. The electric heating pipe is
damaged
2. Internal wire is disconnected
Send to the designated
maintenance department for
maintenance
CLEANING AND MAINTENANCE
• Please be sure to unplug the power cord plug after each use, wait for a few minutes
after power has been turned off, and then wipe it with a damp cloth. If it is stored for a
long time, it should be cleaned with detergent.
• Do not use abrasive cleaning products or solvents for cleaning.
• After use, the oil in the product baking tray should be poured out, and it should be
replaced with clean oil when cooking each time.
• Do not put the product in water for cleaning in case of electric shock and malfunction.
• Dry all components before storage and put the product in a safe and dry place.
• Any other servicing should be performed by an authorized service representative.
WARRANTY
10
ONE YEAR LIMITED WARRANTY. The manufacturer warrants this product to be free
from manufacturing defects in material and workmanship. This one year warranty does not
cover transit damages.
This warranty does not apply to the finish on any portion of the product. Serving performed
by unauthorized persons shall render the warranty invalid. For warranty service, contact
Customer Service at 888-251-1024, 8 a.m.-8 p.m., EST, Monday – Sunday.Some states
do not allow the limitation or exclusion of certain damages. Therefore, these limitations
and exclusions may not apply to you. This warranty gives the consumer specific legal
rights. You may have other rights that vary from state to state.
Printed in China
