1 Local Operaon

1.1 Acvate Indoor Staon

You can only congure and operate the indoor staon aer creang a password for

the device acvaon.

Steps

1. Power on the device. It will enter the acvaon page automacally.

Figure 1-1 Acvaon Page

2. Create a password and conrm it.

3. Tap OK to acvate the indoor staon.

Note

We highly recommend you to create a strong password of your own choosing

(using a minimum of 8 characters, including at least three kinds of following

categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we

recommend you change your password regularly, especially in the high security

system, changing the password monthly or weekly can beer protect your

product.

1.2 Conguraon Sengs

Network Indoor Staon Conguraon Guide

Conguraon sengs is required before starng using the indoor staon. It is

necessary to set the indoor staon network, room No., linked devices, device me

display, and so on.

1.2.1 Set Indoor Staon Network Parameters

Network connecon is mandatory for the use of the indoor staon. Set the network

parameters aer acvang the indoor staon. Only when the IP address of the

indoor staon is in the same network segment as other devices, it can work properly

in the same system.

Steps

Note

The default IP address of the indoor staon is 192.0.0.64.

Two ways are available for you to set IP address: DHCP, and set IP address manually.

1. Tap Sengs → → Conguraon , and enter admin (acvaon) password.

2. Tap to enter the network sengs page.

Figure 1-2 Network Sengs

3. Set the network parameters.

-Enable DHCP, and the system can assign an IP address of the indoor staon

automacally.

-Disable the DHCP funcon, and set the IP address manually. You should set

the device IP address, the gateway, the DNS address.

1.2.2 Set Linked Device IP

Network Indoor Staon Conguraon Guide

Linked network parameters refers to the network parameters of devices (like door

staon, doorphone, main staon, center, etc.), to which the indoor staon is linked.

Linked devices for the indoor staon refers to door staon, center, main staon, and

doorphone.

With the private SIP protocol, intercom can be realized only when all these devices

are in the same network segment with the indoor staon.

With the standard SIP protocol, intercom can be realized when all these devices

support the standard SIP protocol.

Steps

Note

•The doorphone does not support adding with the standard SIP protocol.

•Here take door staon network sengs as example.

1. Tap Sengs → → Conguraon , and enter admin (acvaon) password.

2. Tap to enter the device management page.

Figure 1-3 Device Management Page

3. Tap Indoor Extension and select a connect indoor extension.

4. Tap Main Door Staon to pop up the device informaon dialog.

Network Indoor Staon Conguraon Guide

Figure 1-4 Device Informaon

Restore the door staon via indoor staon.

Tap to restore the parameters of the door staon.

Modify the IP address of the linked door staon.

Tap to edit the IP address of door staon.

5. Select the device to link. Edit the network parameters.

1.2.3 Set Indoor Staon No.

Indoor staon No. and the indoor extension No. are numbers, which can be dialed

by other devices to call the indoor staon and the indoor extension in an intercom

system. The indoor staon No., is composed of the oor No. and the room No.

The indoor extension No. Should be a numeric from 1 to 5.

Up to 5 indoor extensions can be set for 1 indoor staon.

Steps

1. Tap Sengs → → Conguraon , and enter admin (acvaon) password.

2. Tap to enter the indoor staon sengs page.

Network Indoor Staon Conguraon Guide
