Hisense LCT43D6ASE Bedienungsanleitung

Owner’ s manual

Compact Double Door Refrigerator

Model:LCT43D6ASE

LCT43D6AVE

All material in this Owner's Manual is the property of Hisense

Company Ltd. and its subsidiaries, and is protected under US and

in any manner, electronic, print, or otherwise, without the prior

or distributed, in whole or in part, in any manner, electronic or

Requests for permission to store, reproduce, transmit or distribute

materials may be made to the following address:

PO Box 3289

Suwanee, GA 30024

Hisense, and any and all other Hisense product names, logos, slogans

or marks are registered trademarks of Hisense Company Ltd. and its

holders.

appliance, unless they are of the type recommended by the manufacturer.

21. WARNING: Do not use electrical appliances inside the food storage compartments of the

20. WARNING: Do not damage the refrigerant circuit.

clear of obstruction.

19. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure,

This appliance is not intended for use by persons (including children) with

reduced physical,sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure their do not play with the appliance

pertaining to the installation, handing, servicing

For compression-type appliances which use flammable refrigerants, instructions

shall include information

22. WARNING: Do not use electrical appliances inside the food storage compartments of the

appliance, unless they are of the type recommended by the manufacturer.

Appliances which use flammable insulation blowing gases instructions shall include

information regarding disposal of the appliance

Instructions shall contain the substance of the following;

Do not use extension cords or ungrounded (two prong) adapters

This product should not be disposed with other household wastes.

To prevent possible harm to the environment or human health from uncontrolled waste

disposal recycles it responsibly to promote the sustainable reuse of material resources.

To return and collection systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling

WARNING! Refrigerators contain refrigerant and gases in the insulation.

Refrigerant and gases must be disposed of professionally as they may cause eye

injuries or ignition Ensure that tubing of the refrigerant circuit is not

damage prior to proper disposal.

Do not use extension cords or ungrounded(two

prong) adapters.

1.Freezer Compartment

2.Freezer Shelf

3.Light Bulb(Behind Thermostat)

4.Thermostat Control Knob

5.Refrigerator Shelf

6.Refrigerator Compartment

1.Freezer Compartment

2.Freezer Shelf

3.Light Bulb(Behind Thermostat)

4.Thermostat

5.Refrigerator Control Knob

6.Refrigerator Compartment

7.Crisper Drawer

8.Freezer Door Gasket

9.Refrigerator Door Gasket

10.Upper Shelf

11.Middle Shelf

12.Down Shelf

8.Freezer Door Gasket

7.Crisper Drawer

12.Down Shelf

11.Middle Shelf

10.Upper Shelf

9.Refrigerator Door Gasket

Warning: The LED light must not be replaced by the user!

If the LED light is damaged, contact the customer helpline

for assistance. To replace the LED light, the below steps

can be followed:

1 .Unplug your appliance.

2. Remove light cover by pushing and prying.

3. Remove screw cover and unscrew the controller box.

4. Replace LED light and snap it correctly in place.

The side at which the door opens can be

changed from the right side (as supplied) to

the left side, if the installation site requires.

Tools you will need:

. 8mm socket driver

Note: Before this step, you should lay the refrigerator

on it’s back in order to gain access to the base, you

should rest it on soft foam packaging or similar

material to avoid damaging the cooling pipes at the

rear of the refrigerator.

2. open the screw hole cove and the upper

hinge cover which is at the top right corner of

the refrigerator. upper hinge

cover (right)

1. Stand the refrigerator, open the upper

door and remove the things in the door and

close it.

3.Unscrew the special ﬂange self-tapping

screws which are used for ﬁxing the right

upper hinge part by a 8mm socket driver

or a spanner(please support the upper

door with your hand when doing it ).

right upper hinge part

special ﬂange

selftapping screws

5.Remove upper door and place it on

smooth surface with panel upwards.

6. Loose screws used to ﬁx middle hinge

and remove middle hinge. Then turn middle

hinge by 180. Take washer on axis and put

it on another end. Place it well for use.

7. Remove lower door and place panel

upwards on smooth surface.

8. Change screw hole covers on middle

cover plate from left to right (as shown in

ﬁgure below).

Front foot ﬁxed board

Self tapping screws

Adjustable bottom feet part

Lower hinge paΰrt rightα

4.Remove the right upper hinge part and

, the screw hole cover place them on

smooth surface.

screw hole cover

. 7mm wrench and 6mm wrench

Caution:

To avoid to injury yourself and/or property,

we recommend someone assist you during

the door reversal process.

.Ensure the Appliance is unplugged and

empty.

.Following

steps

are

generally

recommended

Changing the door from the right side to the left.

phillips screwdrivers

Putty Knife or slotted srewdrivers

Parts you will need ,parts are from the package of manual

door stopper door stop
