Hisense RQ689N4BD1 Montageanleitung

RQ689N4AC1

RQ689N4BD1

RQ689N4BF1

RQ689N4BI1

Contents

Safety for children and others

who are vulnerable people

For your safety and correct

usage, before installing and

first using the appliance, read

this user manual carefully,

including its hints and

warnings. To avoid

unnecessary mistakes and

accidents, it is important to

make sure that all people

using the appliance are

thoroughly familiar with its

operation and safety

features. Save these

instructions and be sure that

they remain with the

appliance if it is moved or

sold, so that anyone using it

throughout its life, will be

properly informed on its

usage and safety notices.

For the safety of life and

property, keep the

precautions of these user's

instructions as the

manufacturer is not

responsible for damages

caused by omission.

This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if

they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not

play with the appliance.

Cleaning and user

maintenance shall not be

made by children without

supervision.

Keep all packaging away

This appliance is in accordance with the following EU guidelines:

and 2014/30/EC and 2009/125/EC and EC.643/2009 and 2002/96/EC

2014/35/EC

Safety and warning information……2

Installing your new appliance………...7

Description of the appliance………….9

Display controls……………………10

Using your appliance………………….12

Helpful hints and tips……………… 14

Cleaning and care……………………15

defrosting………………………………16

Troubleshooting………………………17

Disposal of the appliance……………19

from children as there is risk

of suffocation.

If you are discarding the

appliance, pull the plug out of

the socket, cut the

connection cable (as close to

the appliance as you can)

and remove the door to

prevent children playing from

suffering an electric shock or

from closing themselves

inside it.

If this appliance, featuring a

magnetic door seals, is to

replace an older appliance

having a spring lock (latch)

on the door or lid, be sure to

make the spring lock

unusable before you discard

the old appliance. This will

prevent it from becoming a

death trap for a child

General safety

This

appliance is intended

WARNING —

to be used in

and similar applications

such as

household

-staff kitchen areas in

shops, offices and other

working environments;

-farm houses and by clients

in hotels, motels and other

residential type

environments;

-bed and breakfast type

environments;

-catering and similar non-

retail applications

WARNING — Do not store

explosive substances such

as aerosol cans with a

flammable propellant in

this appliance.

WARNING — If the supply

cord is damaged, it must be

replaced by the

manufacturer, its service

agent or similarly qualified

persons in order to avoid a

hazard.

WARNING — Keep

ventilation openings, in the

appliance enclosure or in

the built-in structure, clear

of obstruction.

WARNING — Do not use

mechanical devices or

other means to accelerate

the defrosting process,

other than those

recommended by the

manufacturer.

WARNING — Do not

damage the refrigerant

circuit.

WARNING — Do not use

electrical appliances inside

the food storage

compartments of the

appliance, unless they are

of the type recommended

by the manufacturer.

WARNING — The

refrigerant and insulation

be lengthened.

2. Make sure that the power

plug is not or

d amaged. Otherwise,it may cause

3. Make sure that you can

plug of the

appliance.

4. Do not pull the main

cable.

6. Do not use the appliance without

The power cord must not

squashed

access the main

Electrical safety

blowing gas are

flammable. When

disposing of the appliance,

do so only at an authorized

waste disposal centre. Do

not expose to flame.

The refrigerant isobutene

(R600a) is contained within

the refrigerant circuit of the

appliance, a natural gas

with a high level of

environmental

compatibility, which is

nevertheless flammable.

During transportation and

installation of the

appliance, ensure that

none of the components of

the refrigerant circuit

becomes damaged.

The refrigerant (R600a) is

flammable.

Refrigerant

It is dangerous to alter the

specifications or modify

this product in any way.

Any damage to the cord

may cause a shortcircuit,

fire, electric shock.and

Caution:risk of fire

Ensure that no parts of the

refrigerant circuit be demaged.

Avoid opening flames and

sources of ignition.

Ventilate the room thoroughly

in which the

appliance is situated.

short circuit ,electtric shock or

overheat and even cause a fire.

Do not insert the mains plugs

if the socket is loose ,there is a

risk of electric shock or fire.

the light cover of interior lighting.

7.The fridge is only applied

with power supply of single

phase alternating current of

220~240V/50Hz. If fluctuation

of voltage in the district of

user is so large that the

voltage exceeds the above

scope, for safety sake, be

sure to apply A.C. Automatic

voltage regulator of more

than 350W to the fridge. The

fridge must employ a special

power socket instead of

common one with other

electric appliances. Its plug

must match the socket with

ground wire.

Do not store flammable

gass or liquids in the

appliance,There is a risk

of an explosion.

Do not operate any

electrical appliances

inthe

appliance(e.g.electric ice

cream makers,mixers

etc.).

When unplugging always

pull the plug from the

mains socket,do not pull

on the cable.

Do not place hot items

near the plastic

components of this

appliance.

Daily use

Do not place food products

directly against the air

outlet on the rear wall.

Store pre-packed frozen

food in accordance with the

frozen food manufacture’s

instructions.

The appliances

manufactures storage

recommendations should

be strictly adhered to.Refer

to relrelevant instructions

for storage.

Do not place carbonated or

fizzy drinks in the freeze

compartment as it creates

pressure on the

container,which may cause

it to explode,resulting in

damage to the appliance.

Frozen food can cause

frost burns if consumed

straight from the freezer

compartment.

Do not place the appliance

in direct sunlight.

Keep buring candles,lamps

and other items with naked

flames away from the

appliance so that do not set

the appliance on fire.

The appliance is intended

for keeping food stuff

and/or beverages in

normal household as

explained in this

instruction booklet.

For electrical connection

carefully, follow the

instructions given in this

manual.

Unpack the appliance and

check if there are damages

on it. Do not connect the

appliance if it is damaged.

Report possible damages

immediately to the place you

bought it. In this case retain

packing.

It is advisable to wait at least

four hours before connecting

the appliance to allow the oil

to flow back in the

The appliance is

heavy.Care should be

taken when moving it.

Do not remove nor touch

items from the freezer

comartment if your hands

are damp/wet,as this could

cause skin abrasions or

frost/freezer burns.

Never use the base,

drawers, doors etc. to

stand on or as supports.

Frozen food must not be

refrozen once it has been

thawed out.

Do not consume ice

popsicles or ice cubes

straight from the freezer as

this can cause freezer burn

to the mouth

and lips.

To avoid items falling and

causing injury or damage

to the appliance, do not

overload the door racks or

put too much food in the

crisper drawers.

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils, organic

solvents or abrasive

cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

Installation Important!

caution!

Care and cleaning

Before maintenance, switch

off the appliance and

disconnect the mains plug

from the mains socket.

compressor.

Adequate air circulation

should be around the

appliance, lacking this leads

to overheating. To achieve

sufficient ventilation, follow

the instructions relevant to

installation.

Wherever possible the back

of the product should not be

too close to a wall to avoid

touching or catching warm

parts (compressor,

condenser) to prevent the

risk of a fire, follow the

instructions relevant to

installation.

The appliance must not be

locate close to radiators or

cookers.

Service

Any electrical work required

to do the servicing of the

appliance should be carried

out by qualified electrician or

competent person.

This product must be

serviced by an authorized

Service Center, and only

genuine spare parts must be

used.

1)If the appliance is Frost

Free.

2)If the appliance contains

freezer compartment.

Make sure that the mains

plug is accessible after the

installation of the appliance.

Installing your new appliance

Ventilation of appliance

Before using the appliance for the first

time, you should be informed of the

following tips.

In order to improve efficiency

of the cooling system and save

energy, it is necessary to maintain

good ventilation around the appliance

for the dissipation of heat. For this

reason, sufficient clear space should

be available around the refrigerator.

Suggest :It is advisable for there to be

50~70mm of space from the back

to the wall, at least 100mm from its

top,at least 100mm from its side to the

wall and a clear space in front to allow

the doors to open 135°.As shown in

following diagrams

100

50~70

Climate class Ambient temperature

+10°C to +32°C

+16°C to +32°C

+16°C to +38°C

+16°C to +43°C

Leveling of appliance

For sufficient leveling and air

circulating in the lower rear section of

the appliance, the bottom feet may

need to be adjusted.

●

≤10mm

To allow the doors to self-close, tilt

the top backwards by about 10mm.

Note:

the climate class showed in the table

below.

This appliance performs well within

It may not work properlyif being

left at a temperature above or below

the indicated range for a long period.

908mm

600mm

765mm

1410mm

135°

Stand your appliance in a dry place to

avoid high moisture.

Keep the appliance out of direct

sunlight，rain or frost. Stand the

appliance away from heat sources

such as stoves, fires or heaters.

●

You can adjust them manually by

hand or by using a suitable spanner.

●

Nano Triple Fresh

high-technology system

Display controls

Controlling the temperature

We recommend that when you start

your refrigerator for the first time, the

temperature for the refrigerator is set

to 5°C ,my fresh choice to -12 and

the freezer to -18°C. If you want to

change the temperature, follow the

instructions below.

Caution! When you set a temperature,

you set an average temperature for

the whole refrigerator cabinet.

Temperatures inside each

compartment may vary from the

temperature values displayed on the

panel, depending on how much food

you store and where you place them.

Ambient temperature may also affect

the actual temperature inside the

appliance.

°C

Use your appliance according to the following control regulations, your appliance

has the corresponding functions and modes as the control panels showed in the

pictures below. When the appliance is powered on for the first time, the

backlighting of the icons on display panel starts working. If no buttons have been

pressed and the doors are closed, the backlighting will turn off.

Lock

Artificial Intelligence

Holiday

Super Freeze

1. Fridge

Press "Fridge" button repeatedly to

set your desired fridge temperature

between 8 and 2, the

temperature will decrease 1

degrees with each press and the

fridge temperature indicator will

display corresponding value according

to the following sequence.

°C °C

°C

3. Freezer

Press "Freezer" button to set the freezer

temperature between -15°C and -25°C to

suit your desired temperature, and the

freezer temperature indicator will display

corresponding value according to the

following sequence.

-20°C -21°C -22°C -23°C

-24°C-25°C

-19°C

-17°C -16°C -15°C

-18°C

-5°C ...... -17°C -18°C

5°C

4°C

-4°C

-2°C 2°C 3°C

-3°C

-1°C 0°C 1°C

2. My Fresh Choice

Press "My Fresh Choice" button to set this

temperature between 5°C and -20°C to suit your

desired temperature, and the temperature indicator

will display corresponding value according to the

following sequence.

4. Super Freeze

Super Freeze can rapidly

lower frozen temperature and

freeze you food substantially

faster than usual

Refrigerator unlock key

Fridge temperature display area

My Fresh Choice temperature display area

Freezer temperature display area

Run mode icon

Fridge temperature setting key

My Fresh Choice temperature setting key

Freezer temperature setting key

Run mode setting key

Refrigerator unlock icon

NANO Fresh indicator light

Note: This compartment can be turned off

separately by set the temperature at “OF”.

Note: This compartment can be turned off

separately by set the temperature at “OF”.

-19°C -20°C

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hisense Kühlschrank Handbücher

Hisense

Hisense RIB312F4AW1 Montageanleitung

Hisense

Hisense RS694N4TBE Montageanleitung

Hisense

Hisense RD-43WR4SHD/BVA-001 Montageanleitung

Hisense

Hisense RS694N4IBF Bedienungsanleitung

Hisense

Hisense H670SG Montageanleitung

Hisense

Hisense RD-65WR4SY1 Bedienungsanleitung

Hisense

Hisense RF697N4ZS1 Montageanleitung

Hisense

Hisense H610BS RD-60WC4SZA Montageanleitung

Hisense

Hisense FV14D6CWD Montageanleitung

Hisense

Hisense FTD120AFW Montageanleitung

Hisense

Hisense FV306N4BC1 Montageanleitung

Hisense

Hisense FV105D4BW2 Montageanleitung

Hisense

Hisense RD-60WC1STA/USE-002 Bedienungsanleitung

Hisense

Hisense HRCD586TBWB Montageanleitung

Hisense

Hisense RQ560N4WBF Montageanleitung

Hisense

Hisense RS-09DC4S Series Bedienungsanleitung

Hisense

Hisense RS-47WL4SIB/CLA1-002 Montageanleitung

Hisense

Hisense RM672N4AJ1 Montageanleitung

Hisense

Hisense RD-50WC4SYS Bedienungsanleitung

Hisense

Hisense RS818N4ICE Montageanleitung

Hisense

Hisense RT18N6AWD Bedienungsanleitung

Hisense

Hisense RQ768N4ABU Montageanleitung

Hisense

Hisense RB296F4AW1 Montageanleitung

Hisense

Hisense BCD-264R Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
