Hisense RT417N4DC1 Montageanleitung

Safety and warning information_ ______2

Control panel ________________

Using your appliance ____ ________

Helpful and hints and tips _________

Installing your new appliance________

Description of the appliance ________

Cleaning and care

Disposal of the appliance

Troubleshooting______________

___ ______22

Safety for children and others

who are vulnerable people

For your safety and correct

usage before installing and

first using the appliance,

read this user manual

carefully, including its hints

and warnings.

To avoid unnecessary

mistakes and accidents, it is

important to make sure that

all people using the

appliance are thoroughly

familiar with its

operation and safety

features.

Save these instructions and

be sure that they remain

with the appliance if it is

moved or sold, so that

anyone, using it

its life, will be properly

informed on usage and

safety notices.

For the safety of life and

property, keep the

precautions of these user's

throughout

instructions as the

manufacturer is not

responsible for damages

caused by omission.

This appliance can be used

by children aged from 8

years and above and

persons with reduced

physical, sensory or mental

capabilities or lack of

experience and knowledge

if they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not

play with the appliance.

Cleaning and user

maintenance shall not be

made by children without

supervision.

Keep all packaging away

This appliance is in accordance with the following EU guidelines:2006/95/EC

and 2004/108/EC and 2009/125/EC and EC.643/2009 and 2002/96/EC

Hisense Refrigerator

from children as there is risk

of suffocation.

If you are discarding the

appliance, pull the plug out

of the socket, cut the

connection cable (as close

to the appliance as you can)

and remove the door to

prevent children playing

from suffering an electric

shock or from closing

themselves inside it.

If this appliance, featuring a

magnetic door seals, is to

replace an older appliance

having a spring lock (latch)

on the door or lid, be sure to

make the spring lock

unusable before you

discard the old appliance.

This will prevent it from

becoming a death trap for a

child.

General safety

WARNING —This

appliance is intended

to be used in household

and similar applications

such as

-staff kitchen areas in

shops, offices and other

working environments;

-farm houses and by

clients in hotels, motels

and other residential type

environments;

-bed and breakfast type

environments;

-catering and similar non-

retail applications

WARNING — Do not

store explosive

substances such as

aerosol cans with a

flammable propellant in

this appliance.

WARNING — If the

supply cord is damaged,

it must be replaced by the

manufacturer, its service

agent or similarly

qualified persons in order

to avoid a hazard.

WARNING — Keep

ventilation openings, in

the appliance enclosure

or in the built-in structure,

clear of obstruction.

WARNING — Do not use

mechanical devices or

other means to

accelerate the defrosting

process, other than those

recommended by the

manufacturer.

WARNING — Do not

damage the refrigerant

circuit.

WARNING — Do not use

electrical appliances

inside the food storage

compartments of the

appliance, unless they

are of the type

recommended by the

manufacturer.

Hisense Refrigerator

2. Make sure that the power

plug is not or

damaged. A or

damaged power plug may

overheat and cause a fire.

3. Make sure that you can

plug of the

appliance.

4. Do not pull the main

cable.

5. If the power plug socket

is loose, do not insert the

power plug. There is a risk

of electric shock or fire.

6.You must not operate the

appliance without the

interior lighting lamp cover.

7.The fridge is only applied

with power supply of single

phase alternating current of

220~240V/50Hz. If

fluctuation of voltage in the

district of user is so large

that the voltage exceeds the

above scope, for safety

sake, be sure to apply A.C.

Automatic voltage regulator

of more than 350W to the

fridge. The fridge must

The power cord must not

be lengthened.

crushed

access the main

Electrical safety

WARNING — The

refrigerant and insulation

blowing gas are

flammable.

When disposing of the

appliance, do so only at

an authorized waste

disposal centre. Do not

expose to flame.

The refrigerant isobutene

(R600a) is contained

within the refrigerant

circuit of the appliance, a

natural gas with a high

level of environmental

compatibility, which is

nevertheless flammable.

During transportation and

installation of the

appliance, ensure that

none of the components

of the refrigerant circuit

becomes damaged.

The refrigerant (R600a) is

flammable.

Refrigerant

Any damage to the cord

may cause a shortcircuit,

fire, and/or electric

shock.

If the refrigerant circuit

should be damaged:

-Avoid opening flames

and sources of ignition.

-Thoroughly ventilate the

room in which the

appliance is situated.

It is dangerous to alter the

specifications or modify

this product in any way.

Caution:risk of fire

Hisense Refrigerator

employ a special power

socket instead of common

one with other electric

appliances. Its plug must

match the socket with

ground wire.

Do not store flammable

gass or liquids in the

appliance,There is a risk

of an explosion.

Do not operate any

electrical appliances in

the appliance(e.g.electric

ice cream makers,mixers

etc.).

When unplugging always

pull the plug from the

mains socket,do not pull

on the cable.

Do not place hot items

near the plastic

components of this

appliance.

Do not place food

products directly against

the air outlet on the rear

wall.

Store pre-packed frozen

food in accordance with

the frozen food

manufacture’s

instructions.

The appliances

manufactures storage

recommendations should

be strictly adhered

to.Refer to relrelevant

Daily use

instructions for

Do not place carbonated

or fizzy drinks in the

freeze compartment as it

creates pressure on the

container,which may

cause it to

explode,resulting in

damage to the appliance.

Keep buring

candles,lamps and other

items with naked flames

away from the appliance

so that do not set the

appliance on fire.

The appliance is intended

for keeping food stuff

and/or beverages in

normal household as

explained in this

instruction booklet The

appliance is heavy.Care

should be taken when

moving it.

Do not remove nor touch

items from the freezer

compartment if your

hands are damp/wet,as

this could cause skin

abrasions or frost/freezer

burns.

Never use the base,

storage.

Frozen food can cause

frost burns if consumed

straight from the freezer

compartment.

Do not place the

appliance in direct

sunlight.

Hisense Refrigerator

Unpack the appliance and

check if there are damages

on it. Do not connect the

appliance if it is damaged.

Report possible damages

immediately to the place

you bought it. In this case

retain packing.

It is advisable to wait at

least four hours before

connecting the appliance to

allow the oil to flow back in

the compressor.

Adequate air circulation

should be around the

appliance, lacking this leads

to overheating. To achieve

sufficient ventilation, follow

the instructions relevant to

installation.

Wherever possible the back

of the product should not be

close to a wall to avoid

touching or catching warm

parts (compressor,

condenser) to prevent the

risk of a fire, follow the

instructions relevant to

installation.

The appliance must not be

locate close to radiators or

cookers.

Make sure that the mains

plug is accessible after the

installation of the appliance.

For electrical connection

carefully, follow the

instructions given in this

manual.

drawers, doors etc. to

stand on or as supports.

Frozen food must not be

refrozen once it has been

thawed out.

Do not consume ice

popsicles or ice cubes

straight from the freezer

as this can cause freezer

burn to the mouth

and lips.

To avoid items falling and

causing injury or damage

to the appliance, do not

overload the door racks

or put too much food in

the crisper drawers.

Installation Important!

caution!

Care and cleaning

Before maintenance, switch

off the appliance and

disconnect the mains plug

from the mains socket.

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils,

organic solvents or abrasive

cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

Hisense Refrigerator

Stand your appliance in a

dry place to avoid high

moisture.

For sufficient leveling and

air circulating in the lower

rea r secti o n o f t h e

appliance, the bottom feet

may need to be adjusted.

You can adjust them

manually by hand or by

using a suitable spanner.

To allow the doors to self-

close, tilt the top backwards

by about 10mm.

Keep the appliance out of

direct sunlight rain or frost.

Stand the appliance away

from heat sources such as

stoves, fires or heaters.

Leveling of appliance

●

Reversing the door

The side at which the door

opens can be changed,

from the right side (as

supplied) to the left side, if

the installation site requires.

Note: Before you start lay

the refrigerator

the base you should rest

it on soft foam packaging

or similar material to avoid

damaging the backboard

of the refrigerator. To

reverse the door the

following steps are

generally recommended

1. Stand the refrigerator

upright Open the upper

door to take out all door

racks (to avoid rack

sdamaged) and then close

the door

on its back

in order to gain access to

≤10mm

Hisense Refrigerator

Tools you will need

Warning! When reversing

the door, the appliance

must not be connected to

the mains. Ensure that the

plug is removed from the

mains socket.

8mm socket wrench Cross-shaped screwdriver

Monkey wrench 8mm wrench

Thin-blade screwdriver

3.Unscrew the flange

screws which are used

for fixing the right upper

hinge part . Lift the upper

door and place it on a

padded surface to prevent it

from scratching.

①

②

4. Remove the upper door

and place it on a smooth

surface with its panel

upwards. Loose screws ,

detach part , then install

part to the left side with

screws

②

①

②.

Note: Please hold the upper

door by hand during step 3

to prevent door dropping.

Hisense Refrigerator

②right upper hinge part

①flange screws

③Upper hinge cover (right)

②screw

①Screw cover

④Screw hole cover

2. Stand the refrigerator

upright, first remove the

screw cover and loose

the screw and unscrew

the upper hinge cover

which is at the top right

corner of the refrigerator,

and use a putty knife or

thin-blade screwdriver to

prize the screw hole cover

which is at the top left

corner of the refrigerator.

①

②

③

④

Door racks

②self-tapping screws

①Door holder

①

②

5. Loose screws used to fix

the middle hinge and

remove middle hinge. Then

remove the lower door.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hisense Kühlschrank Handbücher

Hisense

Hisense HRTF504 Montageanleitung

Hisense

Hisense RS694N4TB1 Montageanleitung

Hisense

Hisense RF26N6AFE Bedienungsanleitung

Hisense

Hisense HR6WC36D Montageanleitung

Hisense

Hisense RS695N4IS2 Bedienungsanleitung

Hisense

Hisense MTZ60235FF Montageanleitung

Hisense

Hisense RF750N4ISF Montageanleitung

Hisense

Hisense RD-60WC4SIB Montageanleitung

Hisense

Hisense RF528N4AC1 Montageanleitung

Hisense

Hisense FMN486W20S Montageanleitung

Hisense

Hisense H420BMEI-WD Montageanleitung

Hisense

Hisense HR6BMFF320 Montageanleitung

Hisense

Hisense RQ758N4SWFE Montageanleitung

Hisense

Hisense HRBF179B Bedienungsanleitung

Hisense

Hisense HAF240A Bedienungsanleitung

Hisense

Hisense RB14N1ASD Montageanleitung

Hisense

Hisense HRFD560SW Montageanleitung

Hisense

Hisense BCD-543WPAZR/HC1(E) Bedienungsanleitung

Hisense

Hisense RS694N4TC1 Montageanleitung

Hisense

Hisense FV181N4AW1 Montageanleitung

Hisense

Hisense HTFF525AW Montageanleitung

Hisense

Hisense FSN515W20C Montageanleitung

Hisense

Hisense H700SMI-IDL Montageanleitung

Hisense

Hisense RS-11DC4SB Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
