Hisense 40H4G Bedienungsanleitung
Roku TV menu may vary and subject to change.
http://www.hisense-canada.com/support/
40H4G
43H4G Quick Setup Guide
ES-Y194299-1 B
©Hisense Company Ltd. and Roku, Inc. 2020
All material in this Quick Setup Guide is the property of Hisense Company Ltd. and Roku Inc. and its subsidiaries, and is protected
under U.S. and International copyright and/or other intellectual property laws. Reproduction or transmission of the materials, in whole
or in part, in any manner, electronic, print, or otherwise, without the prior written consent of Hisense Company Ltd. and Roku, Inc. is a
violation of the rights of Hisense Company Ltd. and Roku, Inc. rights under the aforementioned laws.
No part of this publication may be stored, reproduced, transmitted or distributed, in whole or in part, in any manner, electronic or
otherwise, whether or not for a charge or other or no consideration, without the prior written permission of Hisense Company Ltd. and
Roku, Inc.
Requests for permission to store, reproduce, transmit or distribute materials may be made to the following address:
CANADA: Hisense Canada Co., Ltd
2283 Argentia Road, Unit 16
Mississauga, ON, Canada
L5N 5Z2
Hisense, and any and all other Hisense product names, logo’s, slogans or marks are registered trademarks of Hisense Company
Ltd. and its subsidiaries. All other trademarks are the property of their respective holders. ROKU, ROKU TV and the ROKU logo are
trademarks and the property of Roku, Inc. Other channel logos, brand and product names are trademarks or registered trademarks of
their respective holders.
©2020 All rights reserved. Hisense and the Hisense logo are registered trademarks of Hisense. Other brand and product names are
registered trademarks of their respective owners.
© 2020 Roku, Inc. All rights reserved. ROKU, ROKU TV and the ROKU logo are trademarks and the property of Roku, Inc. Other
channel logos, brand and product names are trademarks or registered trademarks of their respective holders.
1
Your easy way to endless entertainment
*Payment required for some channel content. Channels can change and vary by country.
† Roku search is for movies and TV shows and does not work with all channels.
# Limitations apply to the Roku mobile app. Please see support.roku.com for device compatibility information.
2
WELCOME TO THE HISENSE FAMILY!
Congratulations on the purchase of your new Hisense Roku TV ! This Quick Setup Guide will walk you through
a few easy steps to set up your TV.
Because we value your business, we want to keep you in the know of 'all things Hisense'. Using your mobile phone, scan the Registration page QR code
to register your TV. Depending on the make and model of your phone, you may need to download a QR code scanning app.
Disclaimer: This Quick Setup Guide is intended as a general guideline to help you set up your Hisense Roku
TV. Images throughout this document are for illustrative purposes only and may differ from the actual product.
Country Customer Care Center Hisense Support Page REGISTER YOUR TV
U.S.A • Phone: 1-888-935-8880
• Hours of Operation:
Monday - Friday: 9 AM to 9 PM EST
Saturday - Sunday: 9 AM to 6 PM EST
http://www.hisense-usa.com/
support/ http://www.hisense-
usa.com/support/
register
CANADA • Phone: 1-855-344-7367
• Hours of Operation:
Monday - Friday: 8 AM to 8 PM EST
http://www.hisense-canada.
com/support/
http://www.hisense-
canada.com/support/
productReg.asp
MEXICO • Phone: 01-800-008 8880
• Hours of Operation: Monday - Friday 9:00-18:00
http://www.hisense.com.mx/
support/
*Scan to download user manual
http://www.hisense.
com.mx/support/
productReg.asp
3
· Please check foam for accessories before discarding.
· Veuillez vérifier la mousse pour qu'il n'y ait pas d'accessoires avant de la jeter.
· Antes de desechar la espuma, asegúrese de retirar todos los accesorios.
Packaged contents
Your package in which you purchased your new TV contains the following items:
TV Remote Control
2 AAA batteries Quick Setup Guide (this document)
Important Safety Information and Warranty Card leaflet 2 legs that form the TV stand
4 screws (M4×25)
IMPORTANT:
To prevent accidentally discarding items that came with your TV, be sure to check ALL of the foam in the carton box.
Required tools and devices
Wireless router (not included) for Internet connectivity
Phillips screwdriver (not included) to secure the TV stand
HDMI and other types of cables (not included) to connect external devices to the TV
Wall mount bracket (not included) if you prefer to mount the TV to the wall
4
Buttons and ports on the Hisense Roku TV
Back View of the TV TV Side View
STANDBY / INPUT
HEADPHONE
ANT/CABLE
DC 5V 0.5A(MAX)
USB
DIGITAL
AUDIO OUT
HDMI 1/ARC
HDMI 3HDMI 2
RESET
40” 43”
ANT/CABLE
DIGITAL
AUDIO OUT
VIDEOL
AV IN
RHDMI 1/ARC
HDMI 3HDMI 2
RESET
USB
DC 5V 0.5A(MAX)
5
STEP 1. Attach the TV stand or wall mount bracket (not included)
leg
Screws: M4×25
leg
Screws: M4×25
CAUTION:
Be sure to disconnect the A/C power cord before installing a stand or Wall-Mount brackets.
The LED display is very fragile and must be protected at all times when installing the legs that form the stand. Be sure to protect the
TV screen from getting scratched or damaged by any hard objects. In addition, DO NOT exert pressure on the front of the TV at any
time because it could crack.
After the installation is complete, make sure the TV is steady on a table or firmly attached to a wall mount, before removing all
protective film, if any.
To attach the left and right leg that forms the stand:
1. Carefully place your TV face down on a soft, flat surface to prevent damage to the TV or scratching to the screen.
2. Remove the 2 legs from the foam and then insert the legs into the bottom slots of the TV.
3. Use the screws that came inside the carton with your TV to secure each leg tightly.
Attach the TV Stand (For steps to attach the wall mount see page 6)
6
Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, be
sure to do the following things:
1.Place the TV face down on a flat, clean, safe and cushioned
surface.
2.Remove the TV stand if you already attached it.
3.Place the spacers (not included) in the corresponding bracket
holes.
CAUTION:
• When you attach the mount, be sure to use the spacers
(provided by the third-party manufacturer) between the TV
and the bracket.
• To prevent internal damage to the TV and ensure it is
mounted securely, be sure to use fixing screws (not
included) that are 8 - 10 mm in length when measured from
the attaching surface of the rear cover.
8 - 10 mm
Wall mount hole pattern
(mm) 100 × 200(40")
200 × 200(43")
Wall mount screw size (mm) M6
Follow instructions provided with the Wall mount bracket.
If you have additional questions, please contact the wall-mount
manufacturer or the retailer from which you purchased the TV.
The selected screws are 8 - 10 mm in length when measured
from the attaching surface of the rear cover.
NOTE: The diameter and length of the screws differ depending
on the wall mount bracket model.
Rear cover of the TV Spacer
Screw
Wall mount bracket
Screw
(not included)
Bracket
(not included)
Spacer
(not included)
7
STEP 2. Connect devices to your TV
Check to ensure that you have selected the right cables for the ports and that they are connected securely. Loose connections can
affect the quality of the picture image and color. (Cables and External Equipment not included.)
TV label Port Cable External Equipment Brief Description
ANT/CABLE
Antenna
VHF/UHF Antenna
ANT OUT
Connect an outdoor or indoor
antenna.
HDMI
DVD Player/Recorder
Set-top Box
Satellite Receiver
Satellite
antenna
cable
VCR
Video
Camera
Connect a High Speed HDMI®Cable
from an external device.
AV IN
VIDEO Yellow
Connect a composite video cable
and left-right audio cables from an
external AV device.
LWhite
RRed
DIGITALAUDIO OUT
SpeakerAudio Amplier
Connect a digital audio cable from an
external digital audio system.
8
TV label Port Cable External Equipment Brief Description
HEADPHONE Connect headphone (sold separately) for
audio out of the TV.
USB
Connect a USB memory stick to enjoy its
photos, music, and movies, or to enable
Live TV Pause. Live TV Pause is only
available on the Antenna input of your
Roku TV and requires a dedicated USB
2.0 compatible ash drive with at least
16GB of storage. Live TV Pause requires
connecting to the Roku service.
RESET Restart or factory reset your TV.
