Home Theater Master MX-500 Bedienungsanleitung

MX-500ª

Operating

Manual

Home Theater Master

LCD Screen

Preprogrammed and Learning

Remote Control

1. Introduction

2. Batteries

A. Battery Installation

B. Battery Life

3. Summary of Operations

A. Description of Devices

B. Preprogrammed Codes

C. Learning From Other Remote Controls

D. Macro Operations

E. Favorite Channel Buttons

F. Punch Through Operations

G. Editing LCD Text

H. Cloning The MX-500TM

I. All Other Operations

J. LCD Screen And Button Layout

K. System Settings

4. Programming the MX-500TM to Control Your

Components

A. Using Preprogrammed Codes

1. Three-Digit Code Number

2. Auto Scan With Three-Digit Number

B. Learning Method

1. Programming The Function Buttons

2. Programming The Ten Device Buttons

5. Programming Favorite Channels

6. Programming Macro Buttons

A. Programming Macro Functions To M1, M2, M3,

POWER and SYSTEM OFF Buttons

B. Programming Macro Functions To The Ten Device

Buttons

7. Programming Punch Through Functions

8. Erasing Existing Programming

A. Erasing Learned Buttons

B. Erasing Favorite Channel Buttons

C. Erasing Macro Functions

1. Erase M1, M2, M3, POWER and SYSTEM OFF

Buttons

2. Erase Macro Functions In The Ten Device Buttons

D. Erasing Punch Through Functions

9. LCD Button Editing

A. To Create or Edit Text on Function and Device Buttons

B. To Create or Edit Text for Favorite Channel Buttons

10. Recalling the Preprogrammed

Three-Digit Number

11. Setting Backlight

12. Cloning MX-500TM

13. Adjustment of LCD contrast

14. Caution On Handling LCD Screen

15. Low Battery Message

16. Memory Lock

17. Glossary

18. Warranty

19. Specifications

20. Appendix

A. List of Preprogrammed LCD Text by Device

B. Three-Digit Preprogrammed Code Tables

Table of Contents Table of Contents

1 2

Congratulations! You have purchased one of the most

sophisticated remote controls on the market.

The MX-500TM has been designed to provide a new

standard in remote control technology offering a very

powerful and flexible preprogrammed and learning

product.

Setting up your MX-500TM to operate your components is

easy. Please follow the instructions in the manual and retain

the manual for future reference. If any words used are

unfamiliar to you, please refer to page 46 for a Glossary of

terms used in this manual.

Your MX-500TM can operate up to ten home entertainment

and home automation components by using the

preprogrammed code library in the remote control, by

teaching up to 530 commands into the MX-500TM from

your original remote controls, or a combination of both.

The MX-500TM has many additional operating features to

add convenience and enjoyment to the operation of your

home entertainment system. You can create your own

labels of the buttons on the LCD screen; program 50

favorite channel buttons; operate the volume, channel and

transport buttons from one device when you are in another

device; and have multiple things done with one press of a

button!

1. Introduction

There is also a list of Frequently Asked Questions (FAQ)

for the MX-500TM on the website that may prove to be

helpful. Visit www.hometheatermaster.com for FAQs.

For any questions or comments about the MX-500TM,

please visit our website, www.hometheatermaster.com or

Universal Remote Control, Inc.

500 Mamaroneck Avenue

Harrison, NY 10528

Tel: 914-835-4484

You can also e-mail us at [email protected].

Regular customer service hours are 9:00 AM to 6:00 PM

EST, Monday Ð Friday.

2. Batteries

A. Battery Installation

Before the remote control can be used, the batteries need to

be installed. First, remove the battery cover on the back of

the unit and install the four AAA batteries inside the

battery compartment as shown. Make sure the batteries line

up with the (+) and (-) markings. Improper installation

could damage the remote control. When you're done, slide

the battery cover back on. The remote control starts up

automatically and the default devices will appear on the

LCD screen.

B. Battery Life

Under normal operating conditions, the batteries will last

approximately six months. If the batteries are running low,

you will notice reduced range from the remote, commands

that are not sent properly, or are not sent at all. You may

also notice the backlighting of the LCD screen and the

buttons is diminished. Should any of these occur, replace

the batteries immediately. To ensure proper performance of

the unit, use 4 new AAA alkaline batteries.

The remote control will retain the commands and settings

in memory even after the batteries are low or become

discharged. See Memory Lock on page 46. However, you

should replace the worn batteries with a fresh set as soon as

possible. Do not mix new and used batteries.

3. Summary of Operations

A. Description of Devices

The MX-500TM is designed to operate up to ten components

including Audio Receivers, Cable and Satellite Boxes,

TV, DVD (LD), VCR1, VCR2, CD, Tape and AUX.

However, each of the device buttons and corresponding

functions can be changed to meet your individual

requirements. Almost any device that uses infrared

commands can be controlled by the MX-500TM, including

Home Automation, Personal computers and more.

Tip: The auxiliary function (AUX) could be used to operate

lighting controls; or the second VCR (VCR2) could be

changed to operate a second TV, etc.

Each device button on the main screen contains two sub-

pages of commands and you can change the name of any

LCD button using up to five alphabet characters, numbers

and symbols to customize the unit to fit your audio/video

devices. Please refer to ÒLCD Button EditingÓ on page 39

for additional details.

B. Preprogrammed Codes

The MX-500TM comes with extensive preprogrammed IR

codes for practically all major audio and video equipment.

You can set up and operate all of your components with the

MX-500TM by simply entering a three-digit code number

assigned to your brand of component. The code numbers

for the various brands of components are listed in the back

of this instruction manual. Please refer to the programming

instructions shown on page 13 for details.

3. Summary of Operations

C. Learning From Other Remote Controls

The MX-500TM can learn codes from your original remote

controls. There are 26 LCD screens in the MX-500TM. Each

screen (page) has ten function buttons, including the ten

device buttons on the main menu screen that can be taught.

In addition, there are 31 buttons and a joystick (thumbpad)

that can be taught for each of the ten devices. You can

teach up to 530 new functions into the remote control.

Please refer to page 19 in this instruction manual for

details.

D. Macro Operations

A ÒmacroÓ is a series of commands that you choose to be

sent out with the push of one button. Any function

available on your original remote control or in the

preprogrammed database can be added to a macro to

completely automate what you would normally do by

pushing buttons one at a time. It can be as simple as

turning on your TV and Cable Box, turning the TV to the

appropriate channel for operation with the Cable Box, and

changing the Cable Box channel to your favorite morning

news. A macro can be configured to Power On your TV,

DVD player and receiver, change to the appropriate inputs

and outputs, dim your lights and start a movie. It can be as

simple or as comprehensive as you want.

There are two types of macro buttons you can use for

macro operations:

M1, M2, M3, POWER and SYSTEM OFF Buttons

The M1, M2, and M3 are called Òsystem-wideÓ buttons

because they send out the same signal no matter what

device you are currently controlling. The POWER and

3. Summary of Operations

SYSTEM OFF buttons can be made Òsystem-wideÓ if they

are programmed with macros.

(Note: Programming the POWER or SYSTEM OFF buttons

with a macro overrides the preprogrammed or learned

code on the button.)

See page 26 of this manual for further information. Each of

these five buttons is designed to be able to send out a series

of up to 20 commands you program into the buttons. One

common use is to turn on and turn off all of your A/V

components with one button press, but the buttons can be

programmed with whatever macro you desire.

Ten Device Buttons

There are ten device buttons and each of these device

buttons can send out a series of up to 20 programmed

commands when pressed for more than one second. These

buttons are commonly used in sending audio input codes

when you press the button to go to a device. The audio

receiver would make an automatic input switch according

to the device button you pressed. However, these buttons

can be programmed with whatever macro you desire.

E. Favorite Channel Buttons

You can create up to 50 favorite channel buttons in the

MX-500TM by programming the most frequently watched

channel numbers into these buttons. Each of these buttons

can send out up to 10 commands. Please refer to page 24 of

the manual for Favorite Channel Programming.

F. Punch Through Operations

The MX-500TM can be set up to operate your audio component

volume control buttons (VOLUME UP and DOWN and

3. Summary of Operations

J. LCD Screen And Button Layout

Displays the name of the device selected.

System off (Power off)

Displays page number.

Displays the device and function names.

LIGHT button.

MACRO buttons.

MAIN DEVICE menu button.

LCD Page change button.

POWER

MUTE

VOLUME

CHANNEL

Previous channel button.

TRANSPORT functions(PLAY, STOP, REWIND and FF)

for VCR, CD and DVD etc.

JOYSTICK button(UP, DOWN, LEFT, RIGHT and ENTER)

to move the cursor and enter the selection by pushing down

the joystick in the center. Also called THUMBPAD.

ENTER

DISPLAY

1717

1111

1010

1515

1616

1212

1313

1414

OSDOSD

MENUMENU

GUIDE

EXITEXITINFOINFO

DISDIS

PREVPREV

CHCH

HOME THEATER MASTERHOME THEATER MASTER

LEARNING REMOTE CONTROLLEARNING REMOTE CONTROL

MUTE) while all the other buttons control other equipment.

You can also set up the remote to operate channel control and

transport functions (PLAY, STOP, REWIND, FAST

FORWARD, SKIP-, SKIP+, PAUSE and RECORD buttons)

from VCR, DVD, LD, CD or any other mode while all other

buttons in the remote control are controlling other

components. Please refer to page 32 in the manual for details.

G. Editing LCD Text

You can write your own text on each of the twenty-six

LCD screens. Please refer to page 39 in the manual for

details.

H. Cloning The MX-500TM

The MX-500TM is capable of sending all the programmed

codes and operations from one MX-500TM to another

MX-500TM. Please refer to page 43 in the manual for

details.

I. All Other Operations

You can set the duration of the backlight on time and

change the LCD screen contrast. Please refer to pages 42

and 44 in the manual for additional details.

Note: The last Device selected will remain active when you

are on the MAIN page and will be shown at the bottom of

the LCD screen. For example, if you are using ÒTVÓ and

then return to the MAIN page, the hard buttons remain in

TV mode. The LCD buttons only change when you select

another device.

3. Summary of Operations

K. System Settings

All programming is done by first entering the SETUP

mode in the remote control. Press both the MAIN and

ENTER buttons simultaneously for three seconds to enter

the SETUP mode. SETUP will be shown at the top of the

LCD screen.

You exit the SETUP mode by simply pressing the MAIN

button.

Important: When using the Preprogramming method

starting on page 13, always use the appropriate button as

shown in the illustration above when asked ÒFROM

TABLEÓ. You may have already changed the labels of the

buttons, but the code tables are in the positions as shown.

For example, the AUDIO Code Table (refer to pages

starting at 58) will ALWAYS be the top-left button. The

SAT Code Table will always be the 4th button down on the

right side of the LCD screen, etc.

WHERE DO I START?

First of all, get all of your original remote controls together.

Find out what brands of components you have. You may

have one or more components that do not have original

remote controls, but can still be controlled by the

MX-500TM. You must use the preprogrammed method for

those devices. For the rest, you can program the MX-500TM

to make it compatible with your components by following

the preprogrammed method instructions, by using your

original remote controls to teach the MX-500TM, or both

methods.

Next, it is a good idea to decide whether you want a

ÒDevice-basedÓ configuration, or if you want an

ÒActivity-basedÓ configuration.

A Ò Device-basedÓ configuration centers on each Device

with its two LCD pages controlling one component. All of

the functions that your original remote control has on it

would be put on to one device. The MX-500TM comes with

the labels and preprogrammed codes in a ÒDevice-basedÓ

setup.

If you go to the ÒList of Preprogrammed LCD Text by

DeviceÓ on page 53, you will see diagrams of how the

MX-500TM is set up at the factory. When you choose a

preprogrammed code for a component from the ÒSetup

Code TablesÓ in the Appendix of this manual, that code

will be applied to one device only.

An ÒActivity-basedÓ configuration centers on what you are

doing at the time. If you are watching a DVD on your TV,

and are using your Home Theater receiver to control the

3. Summary of Operations

4. Programming the MX-500

to Control Your Components

DISDIS

PREVPREV

CHCH

sound, you may want to start by setting up the DVD

Device using the preprogrammed method described below,

and then add functions from the other devices you will be

using while watching your DVD video to the DVD device.

For example, while playing a DVD, you will want to adjust

the volume of your receiver. So, you would use the ÒPunch

ThroughÓ method described on page 32 to put the

Receiver's Volume control into your DVD Device. You

may then want to adjust other functions of your Receiver

while staying in the DVD device, so you would use the

learning method described on page 19 to add those

functions to your DVD device, such as surround sound

controls, the receiver's DVD input code, the TV's power

code, etc. Everything that you need for watching a DVD on

your TV without having to jump back and forth from

Device to Device.

You can decide where on the MX-500TM you want your

functions to reside, relabeling the LCD screen buttons

(explained on page 39) for those functions, and choosing

preprogramming, learning, or a combination of both to

fully customize your MX-500TM will give you a remote

totally customized to your needs.

So, let's start with learning how to Preprogram the

MX-500TM.

A. Using Preprogrammed Codes

1. Three-Digit Code Number

You can program the MX-500TM to make it compatible with

your components by using the preprogrammed method:

1. Manually turn on the device you wish to operate.

2. Go to the SETUP mode by pressing both the MAIN and

ENTER buttons simultaneously for three seconds until

SETUP appears at the top of the LCD screen.

3. Press the P-PRO button next to the LCD screen.

4. The remote will be flashing ÒSELECT BUTTONÓ.

Press the button for the device you wish to program. (For

example, to program TV, press the TV button.)

5. The remote will be flashing ÒFROM TABLEÓ. Select the

device from which you want to access the code table.

Important: If you have already relabeled your device

keys, your LCD screen will not look like the illustration

above. Select the appropriate LCD button for the ÒFROM

TABLEÓ using the labels as shown in the illustration on

page 11 of this manual. For example, if you have relabeled

AUX as LIGHTS, you would still push the bottom-left

button to access the AUX Code Table.

Note: Use VCR1, not VCR2, to access the VCR code

library.

6. The remote will be flashing ÒENTER NUMBERÓ. Refer

to the tables starting on page 58 in the back of this manual

and find the manufacturer of your device. (If you are

programming the remote for the TV device, find the TV

device code table.)

7. Point the remote control toward the device and enter the

4. Programming the MX-500

to Control Your Components

4. Programming the MX-500

to Control Your Components

4. Programming the MX-500

to Control Your Components 4. Programming the MX-500

to Control Your Components

first three-digit code number you selected for your device.

There is no way of knowing which code is the one that will

have the functions that more closely match your device

than the others, so it is wise to try them all. See step #9

below.

(Please enter the code number within 20 seconds of

beginning programming, otherwise the remote will revert

to the SETUP menu, and then after a period of time, it will

go back to the MAIN device page.)

If there is more than one code number assigned to your

brand, try one code number at a time until you find the

right code number (the number that turns off your device.)

If the device turns off when you enter the three-digit code,

make note of the code. It will have at least some of the

functions in it that are needed to control your device.

8. Confirm that it is the right code by pressing the Power

button. The device should turn on. After you have

confirmed that the right code is entered, save the code by

pressing the SAVE button on the LCD.

9. At this point try ALL of the buttons on the remote, and

see which ones work with your device. The majority of the

buttons should work with your device. Make note of the

code if it seems to be the right one, and try the next one.

You are trying to find the one that has the most functions to

operate your equipment. If there are any functions missing,

you will learn them from your original remote in the

ÒLearning MethodÓ section on page 19.

10. Continue to program other components by repeating

from Step 1 above.

11. You can press EXIT at any time if you do not wish to

proceed.

12. When you are finished programming your remote, exit

from the preprogramming mode by pressing the MAIN

button and then exit from the SETUP mode by pressing the

MAIN button once again.

Tip: You can change the preprogrammed code for each

device at any time by following the steps above. The new

code will override the old code. For example, this would be

done if you replaced your old TV with a new one.

Tip: Please note that you use the code table from VCR1 for

VCR2 setup. The code table for Laser Disc is stored under

DVD. The code table for Tuner is stored under Audio.

2. Auto Scan With Three-Digit Number

You can also program your remote control by sending out a

series of Power Off commands for different brands stored

in the library by using the following steps. This is similar

to the first method, except it is easier to move through all

of the device codes for your device and make note of each

one that turns your device OFF.

1. Manually turn on the device you plan to operate.

2. Go to the SETUP mode by pressing both the MAIN and

ENT buttons simultaneously for three seconds.

3. Press the P-PRO button next to the LCD screen.

1817

the device back on, and reverse your UP or DOWN one

press at a time, until the unit turns off. There is no way of

knowing which code is the one that will have the functions

that more closely match your device than the others, so it is

wise to try them all. See #9 below.

(Please press the UP or DOWN button within 20 seconds

of beginning programming, otherwise the remote will

revert to the SETUP menu, and then after a period of time,

it will go back to the MAIN device page.)

If there is more than one code number assigned to your

brand, try one code number at a time until you find the

right code number (the number that turns off your device.)

If the device turns off when you enter the three-digit code,

make note of the code. It will have at least some of the

functions in it that are needed to control your device.

8. Confirm that it is the right code by pressing the Power

button. After you have confirmed that the right code is

entered, save the code by pressing the SAVE button on the

LCD.

9. Confirm that you entered the right code number that

matches your component by pressing other functional

buttons. If any of the buttons do not operate, as they

should, please repeat from Step 1.

10. Continue to program other components by repeating

from step 1 above.

11. You can press EXIT at any time if you do not wish to

proceed.

12. Exit from Preprogrammed mode by pressing the MAIN

button and then exit from the SETUP mode by pressing the

MAIN button once again.

4. Programming the MX-500

to Control Your Components 4. Programming the MX-500

to Control Your Components

4. The remote will be flashing ÒSELECT BUTTONÓ.

Press the device you wish to program. (For example, to

program TV, press the TV button.)

5. The remote will be flashing ÒFROM TABLEÓ. Select the

device from which the scanned code will be selected.

(Important: If you have already relabeled your device

keys, your LCD screen will not look like the illustration

above. Select the appropriate LCD button for the ÒFROM

TABLEÓ using the labels as shown in the illustration on

page 11 of this manual. For example, if you have relabeled

AUX as LIGHTS, you would still push the bottom-left

button to access the AUX Code Table.

Note: Use VCR1, not VCR2, to access the VCR code

library.)

6. Point the remote control toward the component and press

either the UP or DOWN button on the LCD. (It will send

out a series of Power Off codes when the button is kept

pressed and the code numbers that are being sent are shown

on the LCD.) If the right code number is sent, the

component will turn off right after the code number is

transmitted.

7. Release the UP or DOWN button you were pressing as

soon as the device is turned off. If you should happen to go

past the one that turned off you device, just manually turn

Andere Handbücher für MX-500

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Home Theater Master Fernbedienung Handbücher

Home Theater Master

Home Theater Master MX-1000 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-200 Bedienungsanleitung

Home Theater Master

Home Theater Master MRf-250C Bedienungsanleitung

Home Theater Master

Home Theater Master MX-500 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-3000 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-800 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-600 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-1000 Bedienungsanleitung

Home Theater Master

Home Theater Master MX700TM Bedienungsanleitung

Home Theater Master

Home Theater Master MX-500 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-700 Bedienungsanleitung

Home Theater Master

Home Theater Master MRF-200 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-1000 Bedienungsanleitung

Home Theater Master

Home Theater Master MX-500 Bedienungsanleitung

Home Theater Master

Home Theater Master SL-8000 Bedienungsanleitung

Home Theater Master

Home Theater Master MRF-250 Bedienungsanleitung

Home Theater Master

Home Theater Master MRF-250 Bedienungsanleitung

Beliebte Fernbedienung Handbücher anderer Marken

Panasonic

Panasonic EUR7622KB0 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen Beo4 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung

Multiplex

Multiplex PROFI TX 9 Bedienungsanleitung

One Remote

One Remote RMB4 Bedienungsanleitung

FUTABA

FUTABA 9ZAP - PART2 Bedienungsanleitung

HR Matic

HR Matic HR MULTI 3 Bedienungsanleitung

Yamaha

Yamaha ACC-GNRST-30-20 Bedienungsanleitung

EisSound

EisSound KBSOUND Bedienungsanleitung

Marantz

Marantz RC101 Bedienungsanleitung

Conrad

Conrad FS20 TC6 Bedienungsanleitung

Anritsu

Anritsu MP1777A Bedienungsanleitung

Niles

Niles WVC100 Fehlerbehebungshandbuch

RCA

RCA RCU1300 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen BEO6 Bedienungsanleitung

GE 94901 Bedienungsanleitung

Onbon

Onbon YQ1-75 Bedienungsanleitung

FUTABA

FUTABA R7108SB Montageanleitung
