Home Zone Security ELI0993V Bedienungsanleitung

Model No. ELI0993V

(888) 782-5618

IMPORTANT SAFETY OPERATING INSTRUCTIONS

1. Please read all warning and instruction labels which are included in the box and ﬁxture to avoid personal injury, property damage

caused by ﬁre, cuts, bruises, death and other dangers.

2. Please follow these general precautions before installing, maintaining, or ﬁxing

1. It is important to select an outdoor location with full, direct sunlight where the solar panel can receive at least 8 hours of sunlight

each day.

2. It is important to avoid placing the solar light by light sources, such as street lights or porch lights, which may cause the solar light

to turn off automatically.

3. To avoid explosion and corrosion, please keep the solar light away from ﬁre and humid environment

4. No striking to avoid any damages to solar cell

1. The packing contains small parts that could be swallowed by children

2. Keep the packaging material away from children and pets

3. The solar light is not a toy

4. We do not take responsibility if the instruction manual is not followed correctly or if the product is handled

improperly resulting in damage to person or property

PRECAUTION

1. Dimension: approx.W 7.08"(18 cm) x D 7.08"(18 cm) x H 65"(165 cm)

2. Light source: 3 pcs 2700-3300K LED

3. Brightness: 30 / 60 lumens

REF. PARTS

PARAMETER:

Solar Unit

securit y

www.homezonesecurity.com

Solar Lamp Post

1 pc Lamp head 4 pcs pole 1 pc base 3 pcs connector 2 pcs screws 2 pcs Anchor

(888) 782-5618

1. Use a damp cloth to clean the solar panel

2. To avoid any damage to this light, please do not use any chemical or abrasive cleaner

HOW TO OPERATE AND INSTALL

HOW IT WORKS

CLEANING AND MAINTENANCE

Figure 1

This product contains (2) 1.2V AA 1800mAH Ni-MH rechargeable batteries. When

the batteiesy expire, these must be recycled or disposed of properly. Please

contact your local waste disposal authority for correct procedure.

Do not put battery into ﬁre

Do not mix old and new batteries.

Do not mix Alkaline and Carbon batteries

1. Remove the Solar Panel Unit from Plastic lens.

2. Open the battery chamber covers.

3. Replace the old batteries with new batteries making sure the polarity is correct.

4. Place back the battery chamber covers.

Battery replacement

RECHARGEABLE BATTERY

• Remove the Solar Panel Unit (Part A) from Plastic lens (Part B)

• Slide on the switch to your desired position which is on the bottom of the Solar

Panel Unit (Part A )

- High: 60lumens brightness

- Low: 30lumens brightness

• Replace the Solar Panel Unit accordingly.

Figure 2

• Put the Lamp head (Part A & B), Poles (Part D), and Connectors (Part C) together.

• Choose desired ground location. Drill two holes on the ground. Insert the Plastic

Anchors (Part G) and put the Base (Part E) to align the holes. Screw the Screws

(Part F) to ﬁx the base.

• Put the assembly part onto the base.

Note: Install light in location where it can receive a full 8 hours of sunlight to allow

the rechargeable battery to reach maximum capacity

Note: Lights with solar panel may have a protective film over the solar panel. This

must be removed prior to use.

securit y

www.homezonesecurity.com

Model No. ELI0993V

Solar Lamp Post

Figure 1 Figure 2

Solar panel collects sunlight to

charge the battery (included)

during the day

Automatically turns on at dusk for

up to 8 hours of nighttime

illumination
