Smart Wireless
Door Sensor and
Security Alarm Kit
securit y
TM
Say hello to Alarm.
Siren Base Station
The gateway of the Alarm system. Bridges all
of your Alarm devices to the Home Zone Smart App,
so you can manage your alarm system remotely.
Connects to the USB power cable (included)
Contact Sensor
Alerts you when a door or a window is opened.
A contact sensor works using a sensor and a
magnet. Once the contact sensor is triggered,
it will send an alert to the user via the gateway.
2
Double-sided tape x 5sets
Round Double-sided tape x 1pc
User manualx1
Sirenx1 Contact sensorsx5
Adapterx1 USB cablex1
What’s in the box
3
The siren gateway can allow users to update and manage the alarm system via internet and Home Zone Smart APP.
• Know which contact sensor is triggered
• Manage and monitor the alarm system remotely
• Built-in 120dB siren. Sound volume can be managed by APP.
• Supports up to 20 sensors.
• Setup schedules to arm and disarm.
General Information
Main Features
How does it work？
Siren
4
System Overview
Power on/off switch
Charging port
Reset button
LED indicator flashes quickly (2 times per second): Siren is in Wi-Fi configuration mode
LED indicator flashes slowly (once every 2 seconds): Siren is in AP pairing mode
Note: Pressing and holding the Reset button will reset the Wi-Fi configuration.
5
LED indicator
Connect
Download
Set up Router
Home Zone Smart App is available for both iOS and Android OS. Search the name 'Home Zone Smart' in the App Store
or Android Market.
This device only supports 2.4GHz frequency and does not support 5GHz. Please ensure router is set for 2.4GHz band before
connecting your device to router.
Placing your mobile device and Siren close to the router during setup can speed up the configuration process.
6
Registration process
Step 1 : Open the Home Zone Smart APP, click "Register", read the "Privacy Policy" and click "Agree".
Step 2 : Input a valid Email address and click "Continue". Input Verification Code, then log in the App
securit y
TM
7
Set up your Siren Base Station.
The Siren Base Station can bridge all of your contact sensors and Send alert notice through the APP to your mobile device
if you have activated the alarm kit.
Place your Siren Base Station in a central location in your house. DO NOT install it on the floor.
Use the included USB power cable and adapter to connect the Siren base station to power outlet.
8
1. Launch the app and tap the Plus ( + ) in the upper right 2. Select Security Alarm.
Add Siren Base Station to Home Zone Smart App.
9
3. Choose your Wi-Fi network and Enter the password. Make sure that upper right shows “EZ mode” and then
press “Next”. Once the adding process is completed, press “Done”.
