Homeworks HQP7-RF-2 Bedienungsanleitung
P/N 043554 Rev. A
07/2021
Wireless Processor
HQP7-RF-2
48 V-100 mA
English
Installation Instructions
Please Read Before Installing
Product Overview
Status LED
Green = Normal operation
Blue = Firmware upgrade in process
Red = Error
Program Button
Used to factory reset processor
and to associate into a system
This HomeWorks wireless processor is compatible with Sunnata dimmers/switches/keypads,
Maestro dimmers/switches/fan controls, Pico controls, Radio Powr Savr sensors, Triathlon
and Sivoia QS wireless shades, seeTouch keypads, HomeWorks plug-in dimmers and
switches, HomeWorks RF dimmer and switch modules, and Ketra wireless fixtures and lamps.
Other products may also be compatible; see individual product spec sheets for details on
system compatibility.
This HomeWorks wireless processor must be powered by an IEEE 802.3af 2003 or 802.3at
2009 compliant LPS/SELV PoE or PoE+ power supply.
2
Additional Components
Junction box
mount adapter
(included)
Shelf-mount adapter
P/N: L-SMNT-WH
(sold separately)
Recess-mount
adapter
(included)
Ladder
Drill
Pencil
Philips head screwdriver
Tools You May Need
Components
(not included)
Mud ring
22in
(70 mm)
Hole saw
31in to 3`in
(83 mm to 89 mm)
3
Reliability of Clear Connect wireless communication requires that the wireless processor
be centrally-located and within a maximum distance of the specific wireless devices
in the system. A maximum of 16 total wired and wireless processors can be on
one system. Wireless processors must be mounted 5 ft (1.5 m) away from wireless
interference sources like microwaves, Wireless Access Points (WAPs), etc. PoE wiring
must be kept internal to the building. Do not run PoE wiring outdoors or install the
processor in metallic enclosures.
Step 1—Choose a Location to Install
Distances for Wireless Devices
• Each device must be within 30 ft (9 m) of a repeater or wireless processor.
• Repeaters can be spanned up to 60 ft (18 m) apart from other repeaters to create
the network.
For myLutron users, please see Application Note 745 for additional information on
Clear Connect - Type X Best Practices on www.lutron.com.
• All devices associated with the wireless processor must be within a 75 ft (23 m) radius
of the processor.
• There must be a minimum of two devices within 25 ft (7.6 m) of the wireless processor.
• Each Clear Connect – Type X device should have two or more non-battery powered
Type X devices within 25 ft (7.6 m) of another compatible Clear Connect – Type X
device. Using more than two devices is ideal for creating an ultra high-performance
mesh network.
Clear Connect – Type A Devices (seeTouch keypads, Maestro dimmers,
Pico wireless controls, Sivoia QS wireless shades, etc.)
Clear Connect – Type X Devices
4
0.30 in to 1.20 in
(8 mm to 30 mm)
Each wireless processor comes with a recess-mount adapter and a junction box
mount adapter. NOTE: To utilize the shelf-mount adapter (P/N: L-SMNT-WH, sold
separately), please see the instructions included with that product.
Step 3—Select the Mounting Adapter for your Installation
31in to 3`in
(83 mm to 89 mm)
Step 2—Provide Opening for Adapter
Recess-mount
adapter
Recess-mount adapter
RJ45 Connector (Ethernet Jack)
Ceiling installation Wall installation
Step 4a—Installation using the Recess-Mount Adapter
Ceiling
Recess-mount
adapter
Wall
OR
Plug in Ethernet cable and attach processor to PoE-enabled network switch or PoE injector
5
Step 4b— Installation using the Junction Box Mount Adapter
Junction box
Junction box
Mud ring
RJ45 Connector (Ethernet Jack)
Junction box
mount adapter Junction box
mount adapter
Junction box
Plug in Ethernet cable and attach processor to PoE-enabled network switch or PoE injector
OR
Junction box mount adapter
Ceiling installation Wall installation
6
IN
OUT
Step 4c— Installation using the Shelf-Mount Adapter
(P/N: L-SMNT-WH, sold separately)
WiFi router
PoE injector or switch Wireless processor
Internet
VerticalHorizontal
Wall
Level
Surface
#6 (M3) screw
recommended
(2 included)
• Hold the adapter to the wall in
the desired location
• Using a pencil, mark the location
of the screw holes
• If using drywall, prep for anchors
• Partially drive two (2) screws
at least 1/4 in (6.3 mm) into the
wall or the drywall anchors
• Feed right-angle connector of
the 6 ft (1.8 m) Ethernet cable
through the adapter BEFORE
tightening screws
• Tighten screws
• Plug in Ethernet cable and attach
processor to PoE-enabled
network switch or PoE injector
• Attach processor to adapter
7
Add the processor into the HomeWorks Designer software.
Note: Ensure you are using the latest version of the HomeWorks Designer software.
For additional troubleshooting information, please see www.lutron.com/support
Step 5—System Setup
Symptom Probable Cause
Unit does not
power on
A PoE switch is not being used or is not configured as a PoE switch
The other end of the Ethernet cable is not connected to a PoE switch
Unit cannot be
found in software
The Ethernet cable is not connected to the same LAN as the wired processor
Model is not supported (Athena/myRoom vs. HomeWorks)
Ethernet run is longer than the supported 328 ft (100 m) and a PoE extender
is needed
Unit does not
control
surrounding lights
Lights are out of range of the wireless processor
Processor lost power/Ethernet wire run too long and PoE booster is required
Troubleshooting
Mode / Error LED Pattern Description
Normal Operation Status LED blinks green every 10 seconds
Software Update Status LED blinks blue
Error Status LED remains solid red
Processor Identify Status LED blinks green rapidly
LED Diagnostics
Customer Assistance
For questions concerning the installation
or operation of this product, please visit
www.lutron.com/HWsupport
Limited Warranty
For limited warranty information,
please scan the code below with
a smartphone.
FCC/IC/IFT Information
This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation. Modifications not expressly
approved by Lutron Electronics Co., Inc. could void the user’s authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
This equipment complies with FCC/ISED radiation exposure limits set for an uncontrolled environment. The user should avoid prolonged
exposure within 7.9 in (20 cm) of the antenna, which may exceed the FCC/ISED radio frequency exposure limits.
Controlling this HomeKit®-enabled accessory automatically and away from home requires a
HomePod®, Apple®TV, or iPad®set up as a home hub. It is recommended that you update to the
latest software and operating system.
Communication between iPhone®, iPad®, Apple Watch®, HomePod®, or Mac®and the HomeKit®-
enabled HomeWorks processor is secured by HomeKit®technology. Use of the Works with Apple®
badge means that an accessory has been designed to work specifically with the technology identified in the badge and has been certified
by the developer to meet Apple®performance standards. Apple®is not responsible for the operation of this device or its compliance with
safety and regulatory standards.
)Lutron, Lutron, Athena, HomeWorks, Sunnata, Ketra, Maestro, myRoom, Pico, Radio Powr Savr, Triathlon, Sivoia, seeTouch, and Clear
Connect are trademarks or registered trademarks of Lutron Electronics Co., Inc. in the US and/or other countries. Apple, Apple Watch,
HomeKit, HomePod. iPad, iPhone, and Mac are trademarks of Apple Inc., registered in the U.S. and other countries. All other product
names, logos, and brands are property of their respective owners. ©2021 Lutron Electronics Co., Inc.
Instructions d’installation
Veuillez lire avant l’installation
Présentation du produit
LED d’état
Verte = Fonctionnement normal
Bleue = Mise à jour du micrologiciel en cours
Rouge = Erreur
Bouton de programmation
Utilisé pour réinitialiser le processeur aux réglages
d’usine et pour l’associer à un système
Ce processeur HomeWorks sans fil est compatible avec les gradateurs/interrupteurs/claviers
Sunnata, les gradateurs/interrupteurs/commandes de ventilateurs Maestro, les commandes
Pico, les détecteurs Radio Powr Savr, les stores sans fil Triathlon et Sivoia QS, les claviers
seeTouch, les gradateurs et interrupteurs enfichables HomeWorks, les modules de gradateurs
et interrupteurs RF HomeWorks et les luminaires et lampes sans fil Ketra. D’autres produits
peuvent également être compatibles; voir les fiches techniques individuelles des produits
pour plus de détails sur la compatibilité du système.
Ce processeur sans fil HomeWorks doit être alimenté par une alimentation LPS/SELV PoE ou
PoE+ certifiée IEEE 802.3af 2003 ou 802.3at 2009.
Français
Processeur sans fil
HQP7-RF-2
48 V-100 mA
2
Composants supplémentaires
Adaptateur pour
montage de boîtier de
raccordement (inclus)
Adaptateur pour
étagère n° de pièce:
L-SMNT-WH
(vendu séparément)
Adaptateur pour
montage encastré
(inclus)
Échelle
Perceuse
Crayon
Tournevis cruciforme
Outils dont vous pourriez avoir besoin
Composants
(non inclus)
Cadre de montage
70 mm
(22 po)
Scie cloche
83 mm à 89 mm
(31/po à 3`po)
