RVM1625SJ – Hotpoint Counter Saver Plus™ Microwave Oven

Specification Created 1/04

440017

Listed by

Underwriters

Laboratories

Dimensions (in inches)

21-3/4"

Door open

16-13/32

66" MIN.

Mounting

height

from

floor

30"

MIN.

width

required

12"

MIN.

Exhaust outlet

connects to

3-1/4" X 10" duct

15-1/4

29-7/8

Important Information: When installing the Counter Saver Plus

microwave oven over a range, allow minimum of 2" from bottom of

Counter Saver Plus microwave oven to top of range backguard to allow for

removal of light covers.

Installation Information: This information is not intended to be used for

installing unit described. Before installing, consult installation instructions

packed with product/kit for current dimensional data.

When replacing a 36" range

hood, this kit fills in the

additional width to provide a

custom, built-in appearance. For

installation between cabinets only;

not for end-of-cabinet installation.

Each kit contains two, 3"-wide

filler panels.

JX81A–

Recirculating

Charcoal Filter Kit

To be used when the

Counter Saver Plus

microwave oven

cannot be vented to

the outside.

Optional Accessories (Available at additional cost)

JX48BL – Black Filler

Panel Kit

Ventilation Options: The Counter Saver Plus microwave oven is designed for adaptation for the

following three types of ventilation:

Outside Exhaust (Vertical)

Outside Exhaust (Horizontal)

Recirculating (Non-vented ductless–see Filter Kit Drawing)

Note: Before installing, consult installation instructions for current dimensional data on these

three types of ventilation.

Specification Created 1/04

440017

RVM1625SJ – Hotpoint Counter Saver Plus™ Microwave Oven

Features and Benefits

• 1.6 cu. ft. capacity – 1000 Watts (IEC-705 test procedure)

• Turntable – Continually rotates food to ensure even cooking

• Convenience cooking controls – Allows cooking and reheating at the touch of a button

• Auto/Time Defrost – Automatically defrosts for a specified amount of time

• Delay Start – Allows preprogramming of the oven start time, making it easy to

plan ahead

• 10 Power Levels – Offer maximum cooking flexibility, from warming and reheating,

to the full speed of microwave cooking at high power

• Timer on/off – Optional reminder signals when meals are done

• Model RVM1625SJ – Silver metallic

*IEC-705 Test Procedure

RVM1625SJ

Timer

On/Off

Defrost

Auto/Time

AM/PMClock

Time

Cook Popcorn Reheat

Reminder

display on/off

minute cook 1-6

guide behind door

scroll speed

Start

Delay

Start

Surface

Light

on-off

high-low-off

1 2 3

4 5 6

7 8 9

Clear

Off

Power

Level

Vent

Fan
