Hotpoint FFA64 Bedienungsanleitung

FRIDGE FREEZER - MODELS FFA84, FFM84, FFA76, FFM76, FFA75

FFA74, FFM74, FFA64 & FFM64

INSTRUCTIONS FOR INSTALLATION & USE

GETTING STARTED:

To ensure that your fridge freezer runs reliably and efficiently follow these steps.

SAFETY &

INSTALLATION CONTROLS USEFUL ADVICE

CLEANING &

MAINTENANCE

SERVICE &

GUARANTEE

TROUBLESHOOTING

Read the rest of these instructions to get the best from your appliance

and remember to fill in your guarantee registration.

Keep this Book in a safe place for quick reference.

Choose a location for your

fridge freezer, away from

any heat sources and

allow adequate

ventilation - 100mm

(4 inch) gap above.

Level the fridge freezer by

adjusting the front feet.

This will stop rocking or

vibration and keep the

door aligned.

Plug in and switch on.

Allow the fridge freezer

to cool before placing

food inside.

The high temperature

light will stay on until the

fridge freezer has cooled

down.

All food in the fridge

freezer should be

covered.

Move the fridge freezer

into position, using the

sides of the cabinet.

Take care to avoid

damaging the refrigerant

circuit pipe work on the

rear.

If you are freezing fresh

food, turn on fast freeze

by pressing the switch 24

hours before placing the

food inside.

Place the fresh food

inside.

Remember to turn fast freeze off

after 24 hours, however if you

forget to do so it will automatically

cancel after 48 hours.

STEP 1 STEP 2

Before plugging in and

switching on, leave the

fridge freezer in its final

location for at least 15

minutes to allow it to

settle.

STEP 4

STEP 3

STEP 5 STEP 6

Your fridge freezer is now

working.

If after 24 hours your

fridge freezer is not

operating as you want,

refer to the

Troubleshooting section.

STEP 7

NB.The spanner is for illustration

only and is not supplied with the

fridge freezer.

For Your Safety

For your safety, read the following advice:

The fridge freezer cooling system contains a small amount of gas which is

environmentally friendly but flammable. To avoid any risk :-

●Install the fridge freezer following the installation instructions and ensure

that ventilation openings are kept clear of obstruction.

●Take care when installing or moving the fridge freezer to avoid damaging

the pipes on the rear.

●If you suspect a leak, do not switch on the fridge freezer, but open the

windows and doors to ventilate the room.

●Do not use any electrical devices inside the freezer, for instance for

defrosting.

●Do not use any mechanical devices for defrosting other than any which may

have been supplied with the freezer as they may cause damage.

●Only use this fridge freezer for storing domestic foodstuffs.

When installing your fridge freezer :-

●Ensure that the mains cable is not trapped underneath or behind the fridge

freezer when you install or move it.

●Do not stack any other appliance on top of this fridge freezer as they may

damage the fridge or become unstable.

When using your fridge freezer :-

●Do not sit or stand on top of your fridge freezer.

●Do not store poisonous, flammable or dangerous substances in your fridge

freezer.

●Do not use aerosol sprays for defrosting or cleaning your fridge freezer.

If you sell the fridge freezer, pass on this booklet to the new owner.

SAFETY &

INSTALLATION

Installation

Location & Air Circulation

Locate your fridge freezer away from sources of heat e.g.

cookers, radiators, direct sunlight as extreme temperature

will affect its performance.

Allow a minimum 100mm (4 inches) between the top of

the fridge freezer and the ceiling or the underside of a

wall cupboard.

Providing you follow the recommended ventilation

requirements you will :-

●Prolong the life of the fridge freezer.

●Minimise the risk of condensation on the outside of

the fridge freezer.

●Minimise the running costs.

●Minimise operating sounds caused by vibration.

Minimum space required to open door

The fridge freezer needs a space of 600mm (24 inches) in front to allow the door

to open.

When positioning the fridge freezer next to a unit, a gap of 30mm (11/4inch) can

be left at the hinge side of the door to allow the easy removal of furniture. If

preferred the fridge freezer can be positioned so that a gap is not left.This will

restrict how far the door can be opened but the furniture can still be removed

(see diagrams below).The door hinge side can be changed to make it easier to

open (see ‘Door Reversal’ in the CLEANING & MAINTENANCE section).

SAFETY &

INSTALLATION

100mm

(4 inches)

TOP VIEW TOP VIEW

less than 30mm

30mm or more

600mm

Installation

Levelling:

Level the fridge freezer when it is in its final location by adjusting the front feet, until

firm contact is made with the floor. This will stop rocking or vibration and keep the

door aligned which helps the fridge freezer run reliably and efficiently.

Note: Before plugging in and switching on, leave the fridge freezer standing

in its final location for at least 15 minutes to allow it to settle.

SAFETY &

INSTALLATION

Bottle Retainer:

(not applicable to all models)

To fit the bottle rack retainer:

Locate the retainer groove at one end of the bottle rack

and then gradually press down along the top edge

until the retainer is fully in the home position.

Installation

Electrical Supply

WARNING: This appliance must be earthed.

The appliance must be positioned so that the plug is accessible after

installation.

Fuses

Your appliance comes fitted with a plug and a 13A fuse. If you need to replace the

fuse, only use those rated at 13A and ASTA approved to BS1362.

Changing the Plug

Cut off and dispose of the supplied plug if it does not fit your socket.

WARNING: To avoid a shock hazard do not insert the discarded plug into a socket

anywhere else.

IMPORTANT WIRES IN THE MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE

FOLLOWING CODE :

Green/Yellow - Earth

Blue - Neutral Brown - Live

If you change the plug, the colour of wires in the mains lead may not correspond with

the colour of the markings identifying terminals in the plug. You should therefore

wire it as shown above.

Changing the Mains Lead

This appliance is fitted with a special mains lead. If you need to replace the mains

lead due to damage, one can be bought from Hotpoint Service (see KEY CONTACTS,

back page).

It is strongly advised that this work is carried out by a qualified electrician.

CE Marking certifies that this appliance conforms to the following EEC

directives : Low Voltage Equipment - 72/23/EEC & 93/68 EEC

Electromagnetic Compatibility 89/336/EEC, 92/31/EEC & 93/68/EEC

SAFETY &

INSTALLATION

Controls

You can check the temperature of the fridge freezer compartments by using a Fridge

Freezer Thermometer available from Hotpoint Genuine Parts and Accessories Mail

Order Hotline (see KEY CONTACTS back page).

WARNING: Do not use a mercury filled thermometer, as breakage would cause a

health hazard.

Your fridge freezer must NOT be placed in a room where the temperature goes below

6˚C or above 38˚C for prolonged periods, as the internal fridge temperature will not

be maintained.

CONTROLS

FFA74 illustrated

Controlling the Temperature of the Fridge Compartment

The left hand control wheel on the front panel adjusts the internal fridge compartment

temperature. The internal temperature should be 5˚C or colder, although some sections

such as the salad bin will be slightly warmer.The setting of the control wheel will depend

on the location of the fridge freezer, the room temperature and how often the door is

opened. The normal set point (marked by a 3 on the dial) is usually suitable. If you

need to adjust the temperature turn the control wheel using a coin to avoid damage:

Clockwise (higher number) - Colder

Anti-clockwise (lower number) - Warmer

Controlling the Temperature of the Freezer Compartment

The right hand control wheel on the front panel adjusts the internal freezer compartment

temperature. The internal temperature should be -18˚C or colder.The setting of the

control wheel will depend on the location of the fridge freezer, the room temperature and

how often the door is opened. The normal set point (marked by a 3 on the dial) is usually

suitable. If you need to adjust the temperature turn the control wheel using a coin to

avoid damage:

Clockwise (higher number) - Colder

Anti-clockwise (lower number) - Warmer

Temperature Indicator (not applicable to all models)

The temperature indicator is located on the bottom right

hand side of the fridge compartment wall.

This indicator shows when the fridge compartment of your

fridge freezer is operating at the correct temperature.

After plugging in and switching on PLEASE WAIT 24 HOURS for the fridge compartment

temperature to stabilise. After this time the indicator should clearly show OK and that

indicates the fridge compartment is operating at the correct temperature.

If the indicator is completely black, the compartment temperature is too high and

you should adjust the left hand control wheel to a colder setting (see above).

If you have to adjust the temperature setting please WAIT A MINIMUM OF 10 HOURS,

this is time for the temperature to stabilise before checking that the indicator is

showing OK.

If large quantities of food have been added or if the fridge compartment door has

been opened frequently it is normal for the temperature indicator not to show OK.

WAIT A MINIMUM OF 10 HOURS before adjusting the temperature to a colder setting.

Controls

CONTROLS

Indicator Lights

There are two amber lights which indicate functions are selected:

●The amber fast freeze light indicates that the fast freeze button has been

pressed on. By pressing this button ON, the freezer motor will run continuously

for extra cooling.

●The amber holiday light (Models FFA84, FFM84, FFA76, FFM76, FFA75, FFA74

& FFM74 only) indicates that the holiday mode is set.

There are two red lights which warn of a rise in temperature in the freezer

compartment:

●The red high temperature warning light will come on when the fridge freezer is

first switched on or when the temperature inside the compartment rises above

the correct storage temperature. It will go out as soon as the compartment

returns to its normal storage temperature.

The red light may come on for a short period when opening the freezer door to

load or unload food, in this case storage times will not be affected.

If there has been a power cut resulting in a rise in freezer compartment

temperature, the red high temperature warning light will come on as soon as the

mains power returns. It will go out as soon as the compartment returns to its

normal storage temperature.

Avoid opening compartment doors during a power cut, the freezer insulation will

continue to protect your food. However if the power cut continues, there is a risk of your

frozen food beginning to defrost due to the rise in temperature.

●The red food defrost alert light (Models FFA84, FFM84, FFA76, FFM76, FFA75,

FFA74 & FFM74 only) will also come on when the mains power is restored to

warn there has been a power cut and the freezer compartment temperature has

risen to an unsafe level allowing partial defrosting of stored food. If this light is

ON, food should be either cooked and eaten within 24 hours, cooked and refrozen

or thrown away.

The red food defrost alert light is a particularly useful warning light if you were

out at the time of the power cut. The light will remain on until cancelled. It can

only be cancelled by pressing the button alongside it.

Check the TROUBLESHOOTING section if you have any problems with these indicator

lights.

FFA74 illustrated

Controls

CONTROLS

Fast Freeze Button - Freezing Fresh Food

The bottom compartment drawer should be used to freeze fresh food.

Transfer already frozen food to one of the upper drawers.

- Before loading 2kg or more of fresh food select fast freeze for the required

pre-freeze time (see chart below).

- If freezing up to 2kg of fresh food just select fast freeze when loading.

Once the fresh food is loaded leave fast freeze on for 24 hours to freeze the food as

quickly as possible.

Maximum freezing capacity 24 hours:

FFA76/FFM76/FFA75/FFA74/FFM74 12kg

FFA84/FFM84/FFA64/FFM64 8kg

Note : Don’t forget to turn fast freeze off after 24 hours from the introduction of

fresh food to be frozen.

However fast freeze will turn off automatically after 48 hours if you do forget.

Pre-Freeze chart when selecting Fast Freeze:

Load for freezing Pre-freeze time Load position

8 to 12kg max. 24 hours In the bottom drawer.

6 to 8kg max. 24 hours

6 to 8kg 12 hours In the bottom drawer.

2 to 6kg 12 hours In the bottom drawer.

2 to 6kg 6 hours

up to 2kg not required In the bottom drawer.

Model

FFA76

FFM76

FFA75

FFA74

FFM74

FFA64

FFM64

FFA84

FFM84

FFA76

FFM76

FFA75

FFA74

FFM74

FFA64

FFM64

FFA84

FFM84

FFA76

FFM76

FFA75

FFA74

FFM74

All

Controls

CONTROLS

Holiday Function

(Models FFA84, FFM84, FFA76, FFM76, FFA75, FFA74 & FFM74 only)

This feature allows you to set your fridge compartment to a warmer setting while you

are away on holiday, to reduce running costs without affecting the freezer.

To set up holiday mode:

1. Remove any food, from the fridge compartment, that will deteriorate while you

are away. Make sure the fridge is clean.

2. Close the door.

3. Press the holiday button and the amber holiday indicator light will show that

holiday mode is set.

To reset to normal operation:

1. Press the holiday button OR open the fridge door. The amber holiday indicator

light will go out to show holiday mode is cancelled.

2. The fridge compartment will return to the temperature set on the fridge

temperature control wheel.

Note : Opening the door or pressing the holiday button at any time after holiday

mode has been set will turn the function off. The holiday button works

independently of the fridge temperature control wheel.

Useful Advice

Note:

The Rating Plate, which lists the appliance

Model Number and Serial Number can be

found near the bottom of freezer

compartment on the interior wall.

Note:

The photographs indicate the Fast Freeze

and storage areas (see tables).The fridge

cabinet and door furniture will vary

according to each models specifications.

Fast Freeze

Models:

FFA76/FFM76/FFA75/FFA74/FFM74

Fast Freeze

Models: FFA64/FFM64

USEFUL ADVICE

Fast Freeze

Model: FFA84/FFM84

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hotpoint Kühlschrank Handbücher

Hotpoint

Hotpoint FFA90 Bedienungsanleitung

Hotpoint

Hotpoint HTR16ABSLCC - R 15.6 cu. Ft. Top-Freezer... Bedienungsanleitung

Hotpoint

Hotpoint 8215 Bedienungsanleitung

Hotpoint

Hotpoint FFUG 18xx x O3 Bedienungsanleitung

Hotpoint

Hotpoint RLS150G Bedienungsanleitung

Hotpoint

Hotpoint STM 15xx xx Bedienungsanleitung

Hotpoint

Hotpoint ENXTGH 19xxx FW O3 (TK) Series Bedienungsanleitung

Hotpoint

Hotpoint Electronic No-Frost Refrigerator Bedienungsanleitung

Hotpoint

Hotpoint ENXTYH 19 FWL Series Bedienungsanleitung

Hotpoint

Hotpoint RF187MG Bedienungsanleitung

Hotpoint

Hotpoint FFU3DG K Bedienungsanleitung

Hotpoint

Hotpoint KHM325FF.1 Bedienungsanleitung

Hotpoint

Hotpoint HMS313I Bedienungsanleitung

Hotpoint

Hotpoint FF50 Bedienungsanleitung

Hotpoint

Hotpoint RLA50 Bedienungsanleitung

Hotpoint

Hotpoint RLA80 Bedienungsanleitung

Hotpoint

Hotpoint CSX2D Bedienungsanleitung

Hotpoint

Hotpoint NMBL 19 Series Bedienungsanleitung

Hotpoint

Hotpoint HTN17BBZLWW Bedienungsanleitung

Hotpoint

Hotpoint Mistral FF1 Bedienungsanleitung

Hotpoint

Hotpoint RFA52 Bedienungsanleitung

Hotpoint

Hotpoint RLA 21 Bedienungsanleitung

Hotpoint

Hotpoint RF series Bedienungsanleitung

Hotpoint

Hotpoint HTR17BBSRWW - 16.6 cu. Ft. Top Freezer... Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
