Howdens HJA8900 Bedienungsanleitung
HJA8900
Quick Start Guide
Please carefully read the user Instruction Booklet before
operating the washer dryer
Selector
Temp. Spin
Speed
Options
Display
Tumble
Dry
Start
Pause
On / Off
Delay
Start
Programmes
Washing
Door Locked
Child Lock
RinsingSpinning Drying End
Programme Duration
No Water
Incoming
Warning
1. Sort laundry according to fabric type and colour fastness.
2. Turn on machine.
3. Loosely load machine (*half load if tumble dryer cycle to be used) and close door.
4. Add detergent / fabric conditioner
as desired (do not use liquid detergent
if selecting delayed start).
5. Select wash programme using rotary dial.
6. Adjust temperature / spin and select options etc. as desired.
7. Select tumble drying cycle if desired (*half load only).
8. Push start button.
The door will lock and the machine will begin the programme.
To cancel a programme:
Push and hold the start button - machine displays 3-2-1 and then stops.
(To empty the water from the machine select a spin cycle & press start button).
At the end of a programme:
The programme end indicator is displayed and an alert sounds when the door lock
opens.
(- The display and all indicators will turn off if no button is pressed within 2 mins).
Hints/Tips
Do not overload the machine with laundry (loosely fill).
Do not use too much detergent (follow instructions on packets).
Powder
Detergent
Detergent
Fabric
Conditioner
Liquid
Check filter regulary for items
(buttons, coins etc).
A blocked filter can cause the machine to
empty or spin.
Programme Charts
Washing
Drying
EN Auxiliary
functions
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Prewash
Quicker Wash
Extra Rinse
Drying
Selectable temperature
range °C
Cottons
90
8 78 2,40 1400 ••• •
90-Cold
60
8 78 1,50 1400 ••• •
90-Cold
40
8 78 1,00 1400 ••• •
90-Cold
Cottons Eco 60**
8 47 0,76 1400 •
60-Cold
Synthetics
60
3 67 1,05 1200 ••• •
60-Cold
40
3 67 0,75 1200 ••• •
60-Cold
Wool 40
1,5 45 0,45 1200 •
40-Cold
Delicates 40
3,5 48 0,50 1000 •
40-Cold
Hand Wash 30
1 35 0,30 1200
30-Cold
Rapid 30° 30
2 32 0,10 1400 ••
30-Cold
Quick
90
8 54 1,90 1400 ••
90-Cold
60
8 54 1,10 1400 ••
90-Cold
30
8 50 0,18 1400 ••
90-Cold
Shirts 60
3,5 45 0,85 800 ••• •
60-Cold
EN Auxiliary
functions Drying level
Programme (°C)
Max. Load(kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Prewash
Quicker Wash
Extra Rinse
Drying
Extra Dry
Cupboard Dry
Iron Dry
Time based drying - minutes
Selectable temperature
range °C
CottonDry - 5 35 2,75 1400
*••••
-
Synthetic Dry - 3 22 1,70 -
* •••
-
Anti Allergy Wash & Dry 60 2 120 3,80 1400
**••••
90-30
5 Kg Wash & Dry 60 5 94 5,00 1400
*••••
60-Cold
Mini Wash & Dry 30 0,5 35 0,60 1000
•* •
30-Cold
Mini Wash & Dry 30 1 44 1,00 1000
•* •
30-Cold
