This guide describes the requirements and procedures for connecting and conﬁguring the XP family of

disk arrays to work with the Tru64 UNIX operating system.

Part number: A5951-96064

Sixth edition: December, 2005

Legal and notice information

Conﬁdential computer software. Valid license from HP required for possession, use or copying. Consistent with

FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical

Data for Commercial Items are licensed to the U.S. Government under vendor’s standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP products

and services are set forth in the express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical

or editorial errors or omissions contained herein.

Microsoft, Windows, Windows XP, and Windows NT are U.S. registered trademarks of Microsoft Corporation.

Disk Array XP operating system conﬁguration guide: Tru64 UNIX

Contents

Preface ......................... 5

Aboutthisguide................................ 5

Intendedaudience............................... 5

Diskarrays.................................. 5

Relateddocumentation............................. 5

Documentconventionsandsymbols ....................... 6

HPtechnicalsupport.............................. 7

Subscriptionservice .............................. 7

OtherHPwebsites .............................. 7

1Installation....................... 9

Featuresandrequirements ........................... 9

FibreChannelinterface.......................... 10

Deviceemulationtypes.......................... 10

Failover ................................ 11

SNMP conﬁguration........................... 11

RAIDManagercommanddevices ..................... 11

Installationprocedures ............................ 12

Install and conﬁgurethediskarray....................... 13

Settingthehostmodeforthediskarrayports ................ 14

SettingtheSystemOptionModes ..................... 16

ConﬁguringtheFibreChannelports .................... 16

FibreAddress............................ 16

FabricandConnectionparametersettings................ 17

Install and conﬁgurethehost ......................... 18

LoadingtheOSandsoftware ....................... 18

Installing and conﬁguringtheHBAs..................... 18

SetHBAlooporfabricmode ..................... 18

Conﬁguring system ﬁles........................ 19

Settingupclusteringandfabriczoning ................... 20

Setting up fabric zoning and LUN security for multiple operating systems . . . . . 21

Connectthediskarray............................ 22

Deﬁningthepaths............................ 22

Verifyinghostrecognitionofdiskarraydevices................ 24

Conﬁgurediskdevices............................ 25

Writingthepartitionlabels ........................ 26

Towritethepartitionlabel: ...................... 26

Creating the ﬁlesystems ......................... 27

Disk Array XP operating system conﬁguration guide: Tru64 UNIX 3

To create a ﬁlesystemforeachdevice: ................. 27

To create an advanced ﬁlesystem:................... 27

Creatingmountdirectories ........................ 28

Mounting the ﬁlesystems......................... 29

To mount a Tru64 ﬁlesystem: ..................... 29

Verifying the ﬁlesystems ......................... 31

Settingandverifyingautomaticmountingatbootup.............. 33

Checkingpathfailover.......................... 34

2Troubleshooting.................... 35

Errorconditions............................... 35

CallingtheHPsupportcenter ......................... 38

ContactInformation ........................... 38

Beforeyoucall ........................... 38

APathWorksheet.................... 39

BDiskarraysupportedemulations............. 41

Supportedemulations ............................ 41

Emulation speciﬁcations ........................... 42

Glossary........................ 45

Index ......................... 49

Preface

About this guide

This guide provides information about:

•Requirements and procedures for connecting an XP disk array to a host system

•Conﬁguring the disk array for use with the Tru64 UNIX operating system

Intended audience

This guide is intended for system administrators with knowledge of:

•The host hardware

•Tru64 operating system

•XP disk arrays

Disk arrays

Unless otherwise noted, the term “disk array” refers to these disk arrays:

•HP StorageWorks Disk Array XP128

•HP StorageWorks Disk Array XP1024

•HP StorageWorks XP10000 Disk Array

•HP StorageWorks XP12000 Disk Array

Related documentation

The following documents provide related information:

•HP StorageWorks Disk Array XP128: Owner’s Guide

•HP StorageWorks Disk Array XP1024: Owner’s Guide

•HP StorageWorks XP10000 Disk Array: Owner’s Guide

•HP StorageWorks XP12000 Disk Array: Owner’s Guide

You can ﬁnd these documents on the storage web site:

http://h18006.www1.hp.com/storage/xparrays.html

Disk Array XP operating system conﬁguration guide: Tru64 UNIX 5

Document conventions and symbols

Convention Element

Blue text Cross-reference links and email addresses

Bold •Keys that are pressed

•Text typed into a GUI element, such as a box

•GUI elements that are clicked or selected, such as

menu and list items, buttons, tabs, and check boxes

•Literalvaluestypedexactlyasshown

Italics

Text emphasis and book titles

Blue, underlined:

www.hp.com

Web site addresses

Monospace font •File and directory names

•System output

•Code

•Commands, their arguments, and argument values

Monospace, italic

font •Code variables

•Command variables

Monospace, bold

font Emphasized monospace text

WARNING!

Indicates that failure to follow directions could result in bodily harm or death.

CAUTION:

Indicates that failure to follow directions could result in damage to equipment or data.

NOTE:

Provides additional information.

6Preface

HP technical support

In North America, call technical support at 1-800-633-3600, available 24 hours a

day, 7 days a week.

Outside North America, call technical support at the location nearest you. Telephone

numbers for worldwide technical support are listed on the HP support web site:

http://www.hp.com/support. From this web site, select your country.

Collect the following information before calling:

•Technical support registration number (if applicable)

•Product serial numbers

•Product model names and numbers

•Applicable error messages

•Operating system type and revision level

•Detailed questions

For continuous quality improvement, calls may be recorded or monitored.

Subscription service

HP strongly recommends that customers register online using the Subscriber’s Choice

web site: http://www.hp.com/go/e-updates.

Subscribing to this service provides you with e-mail updates about the latest product

enhancements, driver versions, and ﬁrmware documents, plus instant access to many

other product resources.

After subscribing, locate your products by selecting Business support and then Storage

under Product Category.

Other HP web sites

For additional information, see the following HP web sites:

•h

ttp://www.hp.com/go/storage

•http://www.hp.com/support/

•http://www.hp.com/service_locator

•http://www.docs.hp.com

Disk Array XP operating system conﬁguration guide: Tru64 UNIX 7

8Preface

1 Installation

You and your HP service representative each play a role in installation. Your HP service

representative is responsible for installing the disk array and formatting the disk devices.

You are responsible for conﬁguring the host server for the new devices with assistance

from your HP service representative.

Features and requirements

Ask your HP service representative about the latest supported hardware and software.

The disk array has the following features:

•Storage capacity. The storage capacity for each model is listed below:

XP128: From8to128drivesforupto36TB,48FCports

XP1024: From8to1024drivesforupto149TB,64FCports

XP10000: Up to 240drivesforupto69.2TB,48FCports

XP12000: Up to 1152 drives for up to 332 TB, 128 FC ports

•Server support. PCI-based AlphaStation or AlphaServer

•Operating system support. Tru64 UNIX, versions 4.0F/G or 5.1A/B with latest

supported patches

Conform the environment to these requirements before installing the array:

•Host Bus Adapters (HBAs) Install HBAs and all utilities and drivers. Refer to the

adapter documentation for installation details

•(Recommended) HP StorageWorks Remote Web Console XP, Command View

XP Advanced Edition or Command View XP with LUN management feature for

conﬁguring disk array ports and paths

•(Recommended) HP StorageWorks LUN Conﬁguration and Security Manager XP

•(Optional) OtheravailableXPsoftware(somemaynotbesupportedbyyour

system):

HP StorageWorks Business Copy XP

HP StorageWorks Continuous Access XP

HP StorageWorks Continuous Access Extension XP

HP StorageWorks Auto LUN XP

HP StorageWorks Data Exchange XP

HP StorageWorks Resource Manager XP

HP StorageWorks RAID Manager XP

Disk Array XP operating system conﬁguration guide: Tru64 UNIX 9

HP StorageWorks Cache LUN XP

HP StorageWorks Auto Path XP

HP StorageWorks Cluster Extension XP

HP StorageWorks Performance Advisor XP

Fibre Channel interface

The XP family of disk arrays supports these Fibre Channel elements:

•Connection speed of 1 Gbps and 2 Gbps

•Short-wave non-OFC (open ﬁber control) optical interface

•Multimode optical cables with SC or LC connectors

•Public or private arbitrated loop (FC-AL) or direct fabric attach

•Fibre Channel switches

Even though the interface is Fibre Channel, this guide uses the term “SCSI disk” because

disk array devices are deﬁned to the host as SCSI disks.

Device emulation types

The XP family of disk arrays supports these device emulation types:

•OPEN-x devices: OPEN-x logical units represent disk devices. Except for

OPEN-V, these devices are based on ﬁxed sizes. OPEN-V is a user-deﬁned size.

Supported emulations include OPEN-3, OPEN-8, OPEN-9, OPEN-E, OPEN-L,

and OPEN-V devices.

•LUSE devices (OPEN-

): Logical Unit Size Expansion (LUSE) devices combine 2

to 36 OPEN-x devices to create expanded LDEVs larger than standard OPEN-x

disk devices. For example, an OPEN-x LUSE volume created from ten OPEN-x

volumesisdesignatedasOPEN-x*10.

•CVS devices (OPEN-x CVS): Volume Size Conﬁguration (VSC) deﬁnes custom

volumes (CVS) that are smaller than normal ﬁxed-sized logical disk devices

(volumes). (OPEN-V is a CVS-based custom disk size that you determine. OPEN-L

does not support CVS.)

•LUSE (expanded) CVS devices (OPEN-x*n CVS): LUSE CVS combines CVS devices

to create an expanded device. This is done by ﬁrst creating CVS custom-sized

devices and then using LUSE to combine from 2 to 36 CVS devices. For example,

if three OPEN-9 CVS volumes are combined to create an expanded device, this

device is designated as OPEN-9*3-CVS.

10 Installation

Andere Handbücher für StorageWorks XP1024

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HP Disk-Array-System Handbücher

HP StorageWorks XP12000 Bedienungsanleitung

HP StorageWorks Series Bedienungsanleitung

HP STORAGEWORKS XP20000 Bedienungsanleitung

HP STORAGEWORKS XP24000 Bedienungsanleitung

HP StorageWorks 2000sa Bedienungsanleitung

HP StorageWorks MSA 1000 Bedienungsanleitung

HP XP20000/XP24000 Bedienungsanleitung

HP StorageWorks 2000fc - G2 Modular Smart Array Bedienungsanleitung

HP StorageWorks MSA 1000 Kurzanleitung

HP XP20000/XP24000 Bedienungsanleitung

HP 4400 Enterprise Bedienungsanleitung

HP 2354 Bedienungsanleitung

HP StorageWorks XP10000 - Disk Array Betriebsanleitung

HP StorageWorks P2000 Bedienungsanleitung

HP XP20000/XP24000 Bedienungsanleitung

HP StorageWorks EVA6400 Bedienungsanleitung

HP XP20000/XP24000 Bedienungsanleitung

HP StorageWorks 2000i Bedienungsanleitung

HP StorageWorks XP12000 Bedienungsanleitung

HP StorageWorks MSA 1000 Gebrauchsanweisung

HP XP20000/XP24000 Bedienungsanleitung

HP StorageWorks XP12000 Betriebsanleitung

HP A3550A - High Availability Disk Arrays Model 20 Storage... Bedienungsanleitung

Beliebte Disk-Array-System Handbücher anderer Marken

Fujitsu

Fujitsu ETERNUS DX60 S2 Bedienungsanleitung

Accom

Accom WSD/2XTREME Bedienungsanleitung

ATTO Technology

ATTO Technology Diamond Storage Array V-Class Bedienungsanleitung

National Instruments

National Instruments RMX-8268 Bedienungsanleitung

Overland Tandberg

Overland Tandberg SnapServer DX1 Bedienungsanleitung

easyRAID

easyRAID Q08QA-2GR2 Bedienungsanleitung

NEC

NEC NF2300-SR412E Bedienungsanleitung

EMC

EMC iomega StorCenter px12-350r Bedienungsanleitung

Infortrend

Infortrend EonStor A08U-C2411 Bedienungsanleitung

SE Audiotechnik

SE Audiotechnik M-F3 Bedienungsanleitung

Buffalo

Buffalo HD-QHU3R5 Bedienungsanleitung

Addonics Technologies

Addonics Technologies Z4SN25NML Bedienungsanleitung

G-Technology

G-Technology G-RAID2 Bedienungsanleitung

Bosch

Bosch DVA-16K SCSI Bedienungsanleitung

easyRAID

easyRAID ERQ12+U4R2 Gebrauchsanweisung

easyRAID

easyRAID X6P U3R2 Bedienungsanleitung

CRU

CRU DataPort 25 USB-to-Dual SATA Bedienungsanleitung

Seagate

Seagate Lyve Mobile Array Bedienungsanleitung
