HP X360 310 G1 PC Montageanleitung

Product End-of-Life Disassembly Instructions

Product Category: Notebooks and Tablet PCs

Marketing Name / Model

[List multiple models if applicable.]

HP x360 310 G1

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU

directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE

1.0 Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description

Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA)

With a surface greater than 10 sq cm

Mother board

Batteries

All types including standard alkaline and lithium coin

or button style batteries battery and RTC battery

Mercury-containing components

For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries

Liquid Crystal Displays (LCD) with a surface greater

than 100 sq cm

Includes background illuminated displays with gas

discharge lamps LCD

Cathode Ray Tubes (CRT)

Capacitors / condensers (Containing PCB/PCT)

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height

External electrical cables and cords

Power cords,Adapter

Gas Discharge Lamps

Plastics containing Brominated Flame Retardants

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations.

Components and waste containing asbestos

Components, parts and materials containing

refractory ceramic fibers

Components, parts and materials containing

radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description

Tool Size (if

applicable)

Description #1 Screw Driver

No.0

Description #2

Description #3

Description #4

Description #5

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. remove Rubber Foot

2. remove low door

3. remove Battery module

4. remove HDD module

5. remove LCD module

6. remove MB

7. remove speaker module

8. remove K/B module

9. remove T/P module

10. remove I/O board

11. divide Display assy (remove hinge cap TOP)

12. divide Display assy ( remove hinge cap BTN )

13. divide Display assy ( remove LCD cover )

14. divide Display assy (remove Hinge)

15. divide Display assy (remove LVDS Cable)

16. divide Display assy (Antenna cble )

17. divide Display assy ( sensor board )

18. divide Display assy (remove Camera)

19. divide Display assy (remove Panel)

20. divide Display assy ( remove LCD brkt )

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

EL-MF877-00 Page 3

Template Revision A

Step 1 Remove rubber foot Step 2 Remove log low

Step 5 Remove LCD module Step 6 Remove M/B

Step 3 Remove Battery module Step 4 Remove Hdd module

EL-MF877-00 Page 4

Template Revision A

Step 7 Remove speaker module. Step 8 Remove K/B

Step 9 Remove T/P module Step 10 Remove I/O board

Step 11 Remove Hinge cap top Step12 Remove Hinge cap BTN

EL-MF877-00 Page 5

Template Revision A

Step 13 Remove LCD Cover Step14 Remove Hinge

Step 15 Remove LVDS & sensor cable Step16 Remove Antenna cable

Step 17 Remove sensor board Step 18 Remove camera module

EL-MF877-00 Page 6

Template Revision A

Step 19 Remove Panel Step 20 Remove LCD Brkt
