Quick Reference Guide
Compaq Evo Thin Client T20 and
Compaq Thin Client T1010 NT
Embedded Terminals
Document Part Number: 243495-001
June 2001
© 2001 Compaq Computer Corporation
Compaq, the Compaq logo, Armada, Deskpro Registered in U. S. Patent and
Trademark Office. Evo is a trademark of Compaq Information Technologies
Group, L.P. in the United States and other countries.
ICA is a registered trademark and MetaFrame is a trademark of Citrix
Systems, Inc.
Microsoft, MS-DOS, Windows, Windows NT are trademarks of Microsoft
Corporation in the United States and other countries.
All other product names mentioned herein may be trademarks of their respective
companies.
Compaq shall not be liable for technical or editorial errors or omissions
contained herein. The information in this document is provided “as is” without
warranty of any kind and is subject to change without notice. The warranties for
Compaq products are set forth in the express limited warranty statements
accompanying such products. Nothing herein should be construed as
constituting an additional warranty.
Compaq service tool software, including associated documentation, is the
property of and contains confidential technology of Compaq Computer
Corporation. Service customer is hereby licensed to use the software only for
activities directly relating to the delivery of, and only during the term of, the
applicable services delivered by Compaq or its authorized service provider.
Customer may not modify or reverse engineer, remove, or transfer the software
or make the software or any resultant diagnosis or system management data
available to other parties without Compaq’s or its authorized service provider’s
consent. Upon termination of the services, customer will, at Compaq’s or its
service provider’s option, destroy or return the software and associated
documentation in its possession.
ÄCAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of
information.
ÅWARNING: Text set off in this manner indicates that failure to follow
directions could result in bodily harm or loss of life.
Printed in the U.S.A.
Quick Reference Guide
First Edition (June 2001)
Document Part Number: 243495-001
Quick Reference Guide iii
Contents
1 Introduction
Introducing the Compaq Evo Thin Client T20 and Compaq
Thin Client T1010 Terminals. . . . . . . . . . . . . . . . . . . . . . 1–1
About This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
2 Evo Thin Client T20
Evo Thin Client T20 Features . . . . . . . . . . . . . . . . . . . . . 2–2
3 Thin Client T1010
Thin Client T1010 Features . . . . . . . . . . . . . . . . . . . . . . . 3–2
4 Extended Windows NT Embedded Features
Extended Control Panel Features . . . . . . . . . . . . . . . . . . . 4–1
Extended Program Features . . . . . . . . . . . . . . . . . . . . . . . 4–3
5 Using Your System
Logging On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
Time Synchronization . . . . . . . . . . . . . . . . . . . . . . . . 5–2
Joining A Domain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
Shutting Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
6 The Windows NT Embedded Desktop
Users Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1
Administrators Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . 6–2
iv Quick Reference Guide
7 About Dialog Box
8 Application Notes
Drive Z: RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–1
Drive C: Flash ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–1
Saving Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–1
Upgrading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–2
Mapping Network Drives. . . . . . . . . . . . . . . . . . . . . . . . . 8–4
Domain Participation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–5
Setting Keyboard Languages . . . . . . . . . . . . . . . . . . . . . . 8–5
Remote Administrator Support . . . . . . . . . . . . . . . . . . . . 8–6
Shadowing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–6
Quick Reference Guide 1–1
1
Introduction
Introducing the Compaq
Evo
Thin
Client T20 and Compaq Thin Client T1010
Terminals
Compaq Evo Thin Client T20 and Compaq Thin Client T1010
terminals use the Windows NT® Embedded operating system to
display windows rather than the classic text-based display. These
computers are designed to connect to Windows Terminal Server
(WTS) and Windows 2000 servers via Remote Desktop Protocol
(RDP) and Independent Computing Architecture (ICA). RDP is
the Microsoft presentation service protocol for connecting to
Windows terminal servers. ICA is the Citrix presentation service
protocol for Windows NT servers. Both allow an application’s
user interface to execute on a NT Embedded-based terminal while
the application’s logic executes on the server.
About This Book
This publication is a supplement to the standard Windows NT
Embedded documentation supplied by Microsoft Corporation,
which is also available on the Microsoft web site at
http://www.microsoft.com/windows/embedded/nt/. This document
explains the differences, enhancements, and additional features
provided by Compaq with the thin client. No attempt has been
made in this publication to document the standard NT features
found in this product.
Quick Reference Guide 2–1
2
Evo
Thin Client T20
The Compaq Evo Thin Client T20 terminal is a small footprint,
low profile, modular NT Embedded-based terminal. The
connections for monitor, network and USB I/O devices are on the
back panel of the terminal. Figure 1 shows the Evo Thin Client
T20 terminal. The Evo Thin Client T20 supports only USB
devices. Keyboard and mouse connections are accomplished
using the USB ports on the back of the terminal.
Figure 1: Evo Thin Client T20
2–2 Quick Reference Guide
Evo Thin Client T20
Evo
Thin Client T20 Features
The following list outlines the key features of the Evo Thin Client
T20 terminal:
■Windows 3.1, Windows 95, Windows 98, and Windows NT
applications via Windows 2000 or Windows Terminal Server
■RDP and ICA application compliant
■10/100 Base-T network communications
■Four USB ports
■Extended color support up to 16 bits
■Support for monochrome or color monitor
The following items are provided with Evo Thin Client T20
terminals:
■Power cord and power supply
■Keyboard and mouse
■Installation and user information
Evo Thin Client T20
Quick Reference Guide 2–3
Use Figure 2 to connect power supply/power cord, monitor,
keyboard, mouse, ethernet, and other external devices such as
headphones to your terminal.
Figure 2: Evo Thin Client T20 Back Panel
Quick Reference Guide 3–1
3
Thin Client T1010
The Compaq Thin Client T1010 terminal is a modular-type NT
Embedded-based terminal. The connections for its peripherals
such as the monitor, keyboard, and mouse are on the back panel
of the thin client. Figure 1 shows the Thin Client T1010.
Figure 1: Thin Client T1010
3–2 Quick Reference Guide
Thin Client T1010
Thin Client T1010 Features
The following list outlines the key features of the Thin Client
T1010 terminal:
■Windows 3.1, Windows 95, Windows 98, and Windows NT
applications via Windows 2000 or Windows Terminal Server
■RDP and ICA application compliant
■10/100 Base-T network communications
■Dual high-speed serial ports
■Parallel printer port
■USB port (See Note)
■Extended color support up to 16 bits
■Support for monochrome or color monitor
■Desktop housing
✎A variety of PC cards are supported via the option card slot. USB
will be supported in future releases.
The following items are provided with the Thin ClientT1010:
■Power cord and power supply
■Keyboard and mouse
■Installation and user information
