Microsoft Cluster Installation Documentation

for

HP NetServer LXr 8000 with HP A3661B Model 30/FC

High Availability Disk Array

To assist you in installing your HP NetServer Microsoft Cluster, this file contains the documents

listed below in one pdf file.

•Installation Overview - This page provides an overview of the installation steps provided in

the Installation Guide.

•Configuration Guide - This guide provides configuration information specific to your cluster

configuration that you will need during installation of your cluster.

•HP NetServer Microsoft Cluster Installation Guide - This is the first of two documents used

to install the cluster. It covers the installation of all cluster supported HP NetServers and the

cluster software, and references the Shared Storage Supplement for installation and setup of the

shared storage.

•Shared Storage Supplement - This supplement is specific to the shared storage device you are

using and must be used with the installation guide. It provides instructions for installing and

setting up your shared storage devices.

13 September 1999

(See next page)

Version History

13 September 1999 Revised the Configuration Guide to add a description of the cluster’s SPOFs. See

the Configuration Guide for details.

9 August 1999 Revised pdf to add 30/FC Install Guide Supplement.

21 April 1999 Revised Configuration Guide to limit the HP NetServer CPU speeds to

400 or 450 MHz.

11 January 1999 Package released

Installing a Cluster

“The Big Picture”

Gathering Hardware,

Software, etc. ➮

Gather:

Hardware

Software (Windows NT, NIC drivers, etc.)

IP Addresses, subnet mask, etc.

User names, password, and domain

Tools

What’s Needed

Setting Up Hardware ➮

Install components:

into NetServers (i.e., LAN adapters)

into Shared Storage (i.e., drives)

Configure NetServer and Shared Storage:

Cabling

Switches

Etc.

Setup and cable the cluster:

Stack as standalone or racked solution

Connect device cabling

NetServers

Shared Storage

Cluster

Installing Software ➮

NetServers:

Configure NetServer Hardware and BIOS

Install Windows NT

Install Service Pack

Shared Storage:

Create disk partitions

Assign Drive Letters

Format logical drives

Cluster:

Install MSCS

Reinstall Service Pack

Install HotFix (Service Pack 3 only)

NetServers

Shared Storage

Cluster

Testing ➮Run:

Hardware Verification and Labeling Utility

Cluster Installation Test (CIT)

Test the Cluster

The Overall Tasks

How to do it!

(See the referenced

part in the Installation

Guide)

What you will be

doing!

This page intentionally left blank.

HP NetServer LXr 8000

with

HP A3661B High Availability Disk Array Model 30 / FC

Cluster Configuration Guide

13 September 1999

Introduction

This document defines the supported HP NetServer LXr 8000 and A3661B High Availability Disk Array

Model 30/FC (LXr 8000 / Model 30-FC) configurations for Microsoft Cluster Server. These configurations

minimize single points of failure (SPOF), provide maximum availability, and have been certified by

Hewlett-Packard and Microsoft. This guide is prescriptive; it describes the configurations supported by HP.

Any deviance to these configurations can result in an inoperative cluster or an operating cluster with

degraded performance, hidden SPOFs, etc., and therefore will not be supported by HP.

What’s Defined in a Racked Cluster

Cluster

SPUs

Local and Shared Storage

Intra-cluster and Client LANs

Shared Storage Cabling

Cluster

Type of SPUs HP NetServer LXr 8000

Each node must be the same model SPU, but may have different clocks

speeds, main memory sizes, cache sizes, and number of CPUs (2, 3, or 4).

Number of nodes 2

Shared Storage See Shared Storage below.

LANs:

Client LAN Any NIC that is HP and Microsoft approved. See Client LAN below.

Intra-cluster

(Heartbeat) LAN HP D5013A only with crossover cable. See Intra-cluster LAN below.

Power source Direct from power mains, power conditioner or uninterruptible power

supply (UPS) using any power conditioner or UPS.

System software:

Navigator version L.14.00 or later

Operating System Microsoft Windows NT Server 4.0, Enterprise Edition or later

Service pack SP3 with hotfix “clusfixi” or later

Single Points of Failure

(SPOF) The Model 30/FC Disk Array virtually does not have single points of

failure. However, care should be taken to bind LUNs as described in the

Model 30/FC Disk Array manual. The manual addresses topics such as;

spreading LUNs equally across internal buses and using RAID modes. In a

cluster configuration, single points of failure arise due to the method used

to connect the disk array to the server. These single points of failure are as

follows:

•Due to Windows NT inability to allow for dual data paths, a total

fibre-channel hub failure (removal of power from the hub, catastrophic

failure of multiple hub ports) will result in the loss of the cluster. It is

possible to power the hub using an UPS to remove part of the issue,

however an unforeseen total hub failure would still be a single point of

failure. Current data on the fibre channel hub indicates that risk in this

area is minimal.

•If the data connection between the hub and Model 30/FC Disk Array

is broken the cluster will go down. The fibre channel cables are

generally known to be robust with an insignificant possibility of

failure.

•A failure in the storage processor of the Model 30/FC Disk Array will

result in a loss of the cluster. The possibility of the storage processor

failing is small. Current configurations do not allow for failover to

another storage processor in the Windows NT environment.

SPU

Model HP NetServer LXr 8000

Clock speed 400 MHz. or higher

No. of CPUs 2 – 4

BIOS version Release 1 or later

CPU cache Any size

RAM 256 MB minimum. Must be HP.

No. of power supplies 3

Local storage Internal or external, using any controller except NetRAID 1 or 3. Must use

HP disks. See

Local Storage below.

I/O slots: P3 – P4 Shared storage controller

P1 – NetRAID local storage

P5 – Intra-cluster (Heartbeat) LAN

P6 – Client LAN

All others – Any other plug-in cards.

Storage

Local

Physical drive location SPU internal drive bays or HP external drive cabinet (e.g., HP Rack

Storage/8 or /12)

Disk drives Must be HP

Controller SPU embedded controller or any controller, any number, manufacturer or

driver in I/O slot P1 for NetRAID local storage (except NetRAID 1 or 3).

See SPU I/O slots above.

SCSI bus Any HP cables that meet SCSI specifications and any SCSI bus speed

Shared Storage

Host Bus Adapter:

Model A5246A HP Fibre Channel Adapter Kit for NT

No. of HBA 1 – 2. (See Shared Storage Configurations.)

Driver 2.xx

SPU I/O slot P3 (1st HBA) and P4 (2nd HBA)

Disk Array Controller:

Model SP630/FC Storage Processor (ordered with A3661B or A3662B)

No. of controllers 1 – 2. (See Shared Storage Configurations.)

Microcode 9.45.03 or greater

Disk Array Storage:

Model A3661B HP High Availability Disk Array Model 30/FC.

No. of cabinets See Shared Storage Configurations.

Controller 1 – 2. (See Shared Storage Configurations.)

Disk capacities: 4 GB, 8.8 GB, 17.8 GB

ArrayGUIde Version 1.7.0 or greater

RAID levels 1, 1/0, 3 and 5

Logical units Logical units within each array must be numbered from 0 – 7.

Hot spares Recommend assigning logical unit numbers 8 or greater

Power Supply 3

RAID arrays Different size or speed disks are allowed in the same RAID array but

are not recommended in the same logical unit.

Shared Storage Cables (Fiber Optics)

Cables for the Short Wave

Port of either a Short or

Long Wave Hub

A3583A 2 meter FC cable,

A3531A 16 meter FC cable,

A3735A 50 meter FC cable,

A3736A 100 meter FC cable,

Any cable ≤500 meters per segment that conforms to ANSI X3.230-

1994 Fibre Channel Standards Specification (FC-PH) rev 4.3.

Cables for the Long Wave

Port of a Long Wave Hub Any cable ≤2 kilometers that meets ANSI X3.230-1994 Fibre Channel

Standards Specification (FC-PH) rev 4.3.

Shared Storage Configurations

Configurations:

Basic See "Basic Configuration Cabling Diagrams with Single or Cascaded

Hubs."

Redundant See "Redundant Configuration Cabling Diagrams with Single or

Cascaded Hubs."

Fibre Channel Hubs:

Model A3724A HP 10-port Short Wave Fibre Channel (FC) Hub

A4839A HP 10-port Long Wave FC Hub

No. of Hubs Basic Configuration: 1 or 2

Redundant Configuration: 2 or 4 with 1 min. or 2. max. per FC

Arbitrated Loop.

Disk Arrays (See Shared

Storage.):

No. of Disk Arrays 1-8

No. of Controllers 1 per Disk Array for Basic Configuration.

2 per Disk Array for Redundant Configuration.

LANs

Intra-cluster (Heartbeat) LAN Client LAN

LAN connection HP D5954A crossover cable or any

equivalent Any LAN

The intra-cluster LAN may only be used for

cluster node communication via a crossover

cable. It may not be used for client

communication.

NIC:

Model HP D5013A (10/100TX PCI) Any that is on both the HP

Tested Products List and the

Microsoft Hardware

Compatibility List.

Driver 3.27.00.0001 or later (Do not enable FEC

Features.) Any driver

NOTE: If the NIC used is the

same as the Intra-cluster LAN,

then the Client LAN must use the

same driver as the Intra-cluster

LAN.

No. of NICs 1 1 minimum

SPU I\O slot P5 P6

Shared Storage Cabling

This part of the guide defines the allowable cabling configurations for clusters using the HP NetServer

LXr 8000 and High Availability Disk Array Model 30/FC. Only these cabling configurations and cables

are supported.

Basic Configuration with Single Fibre Channel Arbitrated Loop Hub

Port connections to this

hub are for example

only. You can use any

port, except for port 10

on Long Wave Hubs.

The remaining ports can

be used for connection

of additional Disk Arrays.

See Shared

Storage Cables for

a list of cables that

can be connected

to the Short Wave

Ports of the hub.

Basic Configuration with Cascaded Fibre Channel Arbitrated Loop

Hubs

See Shared

Storage Cables for

a list of cables that

can be connected

to the Short Wave

Ports of the hub.

Port connections to

these hubs are for

example only. You can

use any port, except for

port 10 on Long Wave

Hubs. The remaining

ports can be used for

connection of additional

Disk Arrays.

See Shared Storage

Cables for a list of

cables that can be

connected between

hubs. Port 10 is used

exclusively in Long

Wave hubs for hub-to-

hub connection.

Andere Handbücher für D5970A - NetServer - LCII

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HP Server Handbücher

HP DL120 - ProLiant - G5 Bedienungsanleitung

HP T5735 - Compaq Thin Client Service-Handbuch

HP ProLiant DL38 Bedienungs- und Sicherheitshinweise

HP ProLiant DL360 Generation 3 Bedienungsanleitung

HP D7171A - NetServer - LPr Bedienungsanleitung

HP ProLiant BL490c Bedienungsanleitung

HP Tc2120 - Server - 256 MB RAM Betriebsanleitung

HP 9000 V-Class Handbuch

HP 9000 Integrity rp8440 Bedienungsanleitung

HP SC20 Gebrauchsanweisung

HP ProLiant BL490c Generation 7 (G7) Gebrauchsanweisung

HP BL30p - ProLiant - 1 GB RAM Bedienungsanleitung

HP Integrity rx4610 Bedienungsanleitung

HP D5970A - NetServer - LCII Bedienungsanleitung

HP ProLiant DL585 Bedienungsanleitung

HP D7171A - NetServer - LPr Bedienungsanleitung

HP vc4820T - Thin Client Bedienungsanleitung

HP 117755-003 - ProSignia - 740 Gebrauchs- und Pflegehandbuch

HP D7171A - NetServer - LPr Bedienungsanleitung

HP Integrity rx2620 Bedienungsanleitung

HP ProLiant MicroServer Generation 8 Bedienungsanleitung

HP ProLiant DL180 Gen9 Bedienungsanleitung

HP D7171A - NetServer - LPr Bedienungsanleitung

HP ProLiant DL380 G6 Server Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

Planet

Planet NAS-7410 Bedienungsanleitung

Lenovo

Lenovo ThinkSystem SR635 V3 Bedienungsanleitung

Dell

Dell PowerEdge HS5610 Handbuch
