rp7400 Hardware Manual

Notice

Hewlett-Packard makes no warranty of any kind with regard to this material,

including but not limited to, the implied warranties of merchantability and fitness

for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or

for incidental or consequential damages in connection with the furnishing, performance, or

use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on

equipment that is not furnished by Hewlett-Packard.

All rights are reserved. No part of this document may be photographed, reproduced, or

translated to another language without prior written consent of Hewlett-Packard Company.

The information contained in this document is subject to change without notice.

HP welcomes your feedback. To make comments and suggestions about product documentation,

send a message to [email protected].

Include the document title and manufacturing part number. All submissions become the property of HP.

What’s New?

Visit this page to find out what new information has been released since the last web site publish (August,

2001) and CD-ROM on August, 2001. The additions and modifications to the web site listed here are effective

as of March, 2010.

New Sections On the Web Site:

• System upgrade instructions for the PA8700 upgrade.

Modified Sections On the Web Site:

• Identified changes to all sections as applicable to HP e3000.

The current version of the Customer CD-ROM was released August, 2002.

The web site will be identical to the CD-ROM on September, 2002.

NOTE All references to rp74xx are equally applicable to the HP e3000.

What’s New?

System Overview

The following sections provide or point to an overview of the rp7400 server hardware and software.

Hardware overview

For an overview of the Enterprise Server Family hardware go to http://www.hp.com/go/hp9000_servers-docs

For an overview of the HP-9000 or HP e3000 rp7400 Server hardware go to http://www.hp.com/go/hp9000_servers-docs

Software Overview

The HP-9000 rp7400 server is designed to operate using HP-UX version 11.0 or newer.

The HP e3000 rp7400 is designed to operate using MPE/iX release 7.0 (uni-processor support) and MPE/iX

release 7.0 express (multi-processor support).

NOTE All references to rp7400 are equally applicable to the HP e3000 and n4000.

KEY:

X - Supported with MPE/iX 7.0

X* - Supported with MPE/iX 7.0 Express 1 Release

X1 - Supported with MPE/iX 7.5 or later

NOTE 1 and 2 way 550 MHz and 750MHz servers are not supported.

Table 1

Processor

Speed Number of Processors Supported

220MHz1234567

330MHz X

380MHz X

440MHz X1 X1

500MHz X* X* X* X*

550MHz X* X*

750MHz X1 X1

System Overview

rp7400 Enterprise Server System Safety and Regulatory Information

Overview

Regulatory Compliance statements are required by some countries for international importation of rp7400

Enterprise Servers. The following information is provided:

Regulatory Information

Electrical Safety

— Electrostatic Discharge (ESD) Precautions

— Battery Notice

Cabinet Safety Precautions

Declaration of Conformity

FCC Statement (USA Only)

Canada RFI Statement

European Union RFI Statement

Korean RFI Statement

Taiwan RFI Statement

Japan Safety and Regulatory Statements

Acoustics (Germany)

Australian C-Tick Label

Laser Safety

Product Information

For detailed information on the rp7400 Enterprise Server product, see the following web site:

http://www.hp.com/go/hp9000_servers-docs (in the Systems Hardware selection).

rp7400 Enterprise Server System Safety and Regulatory Information

Regulatory Information

For your protection, this product has been tested for conformance to various national and international

regulations and standards. The scope of this regulatory testing includes electrical and mechanical safety,

electromagnetic emissions, immunity, acoustics and hazardous materials.

When required, approvals are obtained from third party test agencies. Approval marks appear on the product

label. In addition, various regulatory bodies require some information under the headings listed in this

section.

Electrical Safety

This product has not been evaluated for connection to an “IT” power system (AC distribution system having

no direct connection to earth according to IEC 950).

Locate the AC outlet near the computer! The AC power cords are this product's main AC disconnect devices

and must be easily accessible at all times.

Electrostatic Discharge (ESD) Precautions

When handling any electronic component or assembly (such as, a PCI card or Memory SIMM), you must

observe the following antistatic precautions to prevent damage. An ESD kit (HP P/N A3024-80004) is

available (or supplied with Memory additions). This kit contains one wrist strap, one conductive sheet, and

one anti-static foam pad.

• Always wear a grounded wrist strap when working around the system, and when handling printed circuit

boards.

• Treat all assemblies, components and interface connections as static-sensitive.

• Avoid working in carpeted areas, and keep body movement to a minimum while removing or installing

boards, to minimize buildup of static charge.

Battery Notice

This product contains a Lithium battery.

This battery is not to be removed or replaced by the user. If the battery needs to be replaced, contact your

Hewlett-Packard authorized service personnel.

CAUTION Lithium batteries may explode if mistreated.

Do not recharge, disassemble, or dispose of in a fire.

Please properly recycle all used batteries.

rp7400 Enterprise Server System Safety and Regulatory Information

Cabinet Safety Precautions

WARNING Cabinets are heavy even when empty. Exercise caution when moving cabinets

whether equipment is installed in the cabinet or not. Avoid rolling cabinets on rough

or uneven surfaces or inclines greater than 10 degrees. Unloading cabinets from the

pallet and movement of cabinets should be performed by at least two people.

WARNING Slideable products are not to be extended from the cabinet while the equipment is

on the shipping pallet. The cabinet must be unloaded from the pallet and both front

and rear anti-tip feet properly installed prior to extending any slideable product.

WARNING Once installed, both the front and rear anti-tip feet must remain in place to maintain

stability. Only one slideable product must be extended at a time.

Sicherheitsvorkehrungen für Einbaugehäuse

WARNING Einbaugehäuse haben auch ohne Inhalt ein hohes Gewicht. Seien Sie also vorsichtig,

wenn Sie ein Gehäuse hin und her bewegen, sei es mit oder ohne installierten

Innenteilen. Rollen Sie das Gehäuse nach Möglichkeit nicht über rauhe oder

unebene Oberflächen bzw. Oberflächen mit mehr als 10 Grad Neigung. Das Abladen

von der Palette und Positionieren muß von mindestens zwei Personen durchgeführt

werden.

WARNING Ziehen Sie keine beweglichen Teile heraus, solange sich das Einbaugehäuse auf der

Palette befindet. Laden Sie es zunächst von der Palette ab, und stellen Sie es mit den

kippsicheren Vorder-und Hinterfüßen ordnungsgemäß auf, um bewegliche Teile

sicher herausziehen zu können.

WARNING Nach deren Installation dürfen die kippsicheren Füße nicht wieder entfernt werden,

um sicheren Stand zu gewährleisten. Ziehen Sie jeweils nur ein bewegliches Teil

heraus.

rp7400 Enterprise Server System Safety and Regulatory Information

Consignes de sécurité relatives aux armoires

WARNING Une armoire est lourde même lorsqu’elle est vide. Faites preuve de prudence lorsque

vous en déplacer une, peu importe si des éléments y sont installés ou non. Évitez de

faire rouler l’armoire sur un sol irrégulier ou incliné à plus de 10 degrés. Il faut au

moins deux personnes pour décharger une armoire de la palette d’expédition et la

déplacer.

WARNING Ne faites pas glisser les éléments coulissants hors de l’armoire alors qu’elle se trouve

sur la palette d’expédition. Vous devez d’abord décharger l’armoire de la palette et

installer correctement les pieds antibasculement, en avant et en arrière, avant de

faire glisser les éléments coulissants.

WARNING Lorsqu’ils sont installés, les pieds antibasculement situés à l’avant et à l’arrière

doivent tous deux rester en place pour assurer la stabilité de l'armoire. Vous ne

devez faire glisser hors de l’armoire qu’un seul élément coulissant à la fois.

Medidas de seguridad para armarios

WARNING Los armarios son pesados aun cuando estén vacíos. Tenga cuidado cuando mueva los

armarios independientemente de que haya equipo instalado en el armario o no.

Evite desplazar los armarios sobre superficies rugosas o disparejas o pendientes de

más de 10 grados. Dos personas, como mínimo, tienen que realizar la descarga de los

armarios de la plataforma de carga y mover los armarios.

WARNING Los productos deslizables no deben extenderse del armario cuando el equipo se

encuentre en la plataforma de carga. Se debe descargar el armario de la plataforma

e instalar bien las punteras delanteras y traseras de protección antes de extender

cualquier producto deslizable.

WARNING Una vez instalado, se deberán dejar puestas las punteras de protección, delanteras y

traseras, para mantener la estabilidad. Se deberá extender un solo producto

deslizable cada vez.
