HSS Hire 57481 Fehlerbehebungshandbuch
Tank and
Compact Link
Lights
Zone 1 approved 110V lighting
systems.
Operating & Safety Guide SS782
All that now remains is to plug the lights into a
suitable power supply, switch ON and check that
they all work as they should. In case of difficulty, contact
your local HSS Safe and Sure Depot for advice.
If at any time, the light fails, DO NOT ATTEMPT TO
REPAIR IT YOURSELF. Contact your local HSS Safe and
Sure Depot for advice.
Never use the lights for anything other than their
intended purpose. If they are not suitable for what you
want, assume you have the wrong equipment for the
job. Contact your local HSS Safe and Sure Depot for
advice.
Never expose the equipment to excessive moisture,
dust or dangerous/corrosive chemicals.
Keep the equipment clean. You will find this less of a
chore if you clean it regularly, rather than wait until the
end of the hire period.
To prevent static sparks, you must only use a damp
cloth to clean the polycarbonate overtube.
Handle the equipment with care, this type of lighting
contains delicate bulbs that can be damaged by rough
treatment.
When not in use, store the equipment somewhere
clean, dry and safe from thieves and unauthorised
users.
Switch OFF the power supply and unplug each
light, then neatly coil the power supply cable.
Give the unit a final clean, ready for return to your
local HSS Safe and Sure Depot.
Cleaning
The operator has a duty of care to ensure the
equipment is returned clean of any potentially
harmful contaminants. Equipment that has not
been cleaned will not be accepted back by HSS.
FINISHING OFF
EQUIPMENT CARE
Code 57481/57483
©HSS Hire Service Group Plc 2002 No. SS782/01
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Web Site: http://www.hss.com/safeandsure
Contact your local
0845 608 8811
…any comments?
If you have any suggestions to enable us to improve
the information within this guide please fax your
comments or write to the Product Manager at the
address below
Fax: 020 8687 5001
SS782/01
Electric Light Specification
Tank Light
Description Explosion Proof Luminaire Electrically Powered.
Code EEx em II T3.
Area of Classification “Zone 1”
Certification EN50014, EN50019, EN50028. VTT No,
Ex-99.E.029X
Voltage 110 Volt.
Watts 72 Watts Total.
Output 5800Lm Total.
Weight 12kg
Conditions of certification Only EEx certified electrical equipment and
accessories to be attached to the unit.
Compact Link Light
Description Explosion Proof Luminaire Electrically Powered.
Code EEx em II T3.
Area of Classification “Zone 1”
Certification EN50014, EN50019, EN50028. VTT No,
Ex-01.E.054.
Voltage 110 Volt.
Watts 120 Watts Total.
Output 10,500 Lm Total.
Weight 3.5kg
Conditions of certification Only EEx certified electrical equipment and
accessories to be attached to the unit.
For advice on the safety and suitability of this equipment
contact your local HSS Safe and Sure Depot.
There is a serious risk of personal injury if you do not
follow all instructions laid down in this guide.
The hirer has a responsibility to ensure that all
necessary risk assessments have been completed
prior to the use of this equipment.
This equipment should only be used by an operator
who has been deemed competent to do so by
his/her employer.
This equipment may be used in a workplace
subject to a permit to work. It is the hirer’s
responsibility to ensure that the equipment’s
technical specification meets the requirements of
any such permit to work prior to starting work. For
further technical information contact your local
HSS Safe and Sure Depot.
This equipment should be used by an able bodied,
competent adult who has read and understood these
instructions. Anyone with either a temporary or permanent
disability, should seek expert advice before using it.
Never use this equipment if you are ill,
feeling tired, or under the influence of
alcohol or drugs.
Keep children, animals and bystanders away from
the work area.
Wear sensible, reasonably protective clothing and
footwear plus any safety wear appropriate to the
work in progress.
Check the condition of the equipment before use.
If it shows signs of damage or excessive wear,
return it to your local HSS Safe and Sure Depot.
Never leave the equipment switched ON and
unattended.
Always switch OFF and disconnect the equipment from
its power source before making any alterations or
adjustments to it.
Lights get hot. Always leave them to cool before touching
them and never remove or interfere with any safety
guards fitted.
Never position the lights near overhead power
lines or similar hazards.
The HSS Tank and Compact Link Lights are only
available in 110V (fitted with a safety push and twist
16A round yellow plug) and must be provided with a
suitable 110V generated supply, or be powered
from the mains via a suitable 110V transformer.
The plug and socket fitted to this equipment are
the safety push and twist type, no other type of
connection can be used. If in doubt contact your local
HSS Safe and Sure Depot.
ELECTRICAL SAFETY
GENERAL SAFETY Extension leads fitted with the correct plug and
socket, should be fully unwound and loosely
coiled, away from the work area. Never run them
through water, over sharp edges or where they
could trip someone.
Keep the equipment dry. Using electrical equipment
in very damp or wet conditions can be dangerous.
To reduce the risk of electric shock, always use
a suitable RCD (Residual Current-Operated Device)
available from your local HSS Safe and Sure Depot.
If using a transformer to provide power, ensure
that the total power load is less than 75% of the
units power rating.
The lights can be linked to create a continuous
run, the chart below will help you set up the
maximum amount.
If the equipment fails, or if its plug or lead gets
damaged, return it. Never try to repair it yourself.
Never carry or pull the equipment by its power
supply cable.
Ensure the power socket is switched OFF before
plugging into the power supply.
Position the lights with care, somewhere they won’t
be knocked over and where they won’t dazzle people,
this can be as dangerous as darkness.
GETTING STARTED
Position each light before connecting plugs to sockets.
The compact model can be stood upright or lain
on the ground.
The tank model can be either lain on the ground
or suspended by its hanging strap.
Now, starting with the light furthest from the
power supply connect each unit to the next.
To make the connection, lift and hold the cover to the
power take-off socket (PTO). Insert the plug into the
PTO ensuring the lug lines up with the slot (see
illustration).
Push the plug fully home, then turn clockwise
approximately a quarter turn, ensuring the socket lid
catches onto the plug.
Coil excess lead neatly but loosely, close to the power
source and away from the work area where people
can’t trip over it.
16A 110V
PTO Ex Socket
Light
Power Supply
Cable
Push
Twist
16A 110V
Push & Twist
Ex Plug
Tank Link Light
PTO
Lights
Compact Link Light
Type Max linked Maximum linked per
in any one run 1kva of power
Tank 20 10
Compact 12 7
