PERIJA PLUS™

Smart Acoustic Water Leak Detector

USER GUIDE

User Manual Ver. 1.2

PERIJA PLUS™ Embedded Software Version: P190840008 / P2011400A

2020

Warranty Confirmation

Please send this document to the email address below within 60 days after the date of purchase

stated on the invoice to confirm your after-sales service and product warranty.

Email: [email protected]

NAME: COMPANY NAME:

ADDRESS:

POSTAL CODE: CITY: PROVINCE:

TEL: FAX:

EMAIL:

Please enter the serial number of each component below.

(You may find the serial numbers both on the labels of the components and in the packing list.)

- COMPONENT: SERIAL NO:

DATE OF PRODUCT DELIVERY:

iii

services disclaimer for HIGH SENSE SOLUTIONS Inc. products

- Please read the following terms and conditions carefully before using the equipment and

software applications of HIGH SENSE SOLUTIONS Inc.

- The provisions of the present document apply to all the hardware devices, casings, hardware

and screen designs, OS-level codes, Windows, web-based, and other software applications,

in addition to all accessories produced by HIGH SENSE SOLUTIONS Inc.

- The software applications developed by this company are for one user only. Any form of

duplication, copying, distribution, or sharing the exclusive access information publicly is illegal

and unauthorized, a direct violation of the company’s material and intellectual rights, and

prosecutable by law. (NOTE: Software applications permitted for use by more than one user

are distinguished on their packaging and the number of permitted users is specified in the

source codes.

- Any form of copying the display patterns, display icons, computing protocols and work modes

registered or patented by this company is illegal and unauthorized, a direct violation of the

company’s material and intellectual rights, and prosecutable by law.

- Opening or disassembling the hardware devices or accessories with the purpose of copying

the design or extracting data is illegal and unauthorized, a direct violation of the company’s

material and intellectual rights, and prosecutable by law. Should such tampering damage

certain sensitive parts (e.g. sensors) and lead to malfunction, the after-sales support and

warranty rights for the product will cease and become void immediately.

- The warranty provided by the company includes all the devices, their accessories, and spare

parts against potential defects caused by the designing or manufacturing processes carried

out by HIGH SENSE SOLUTIONS Inc. only. Any malfunctions caused by product breakage,

mishandling, shock, improper use or storage of the product (such as exposure to fire, direct

sunlight, acidic or alkaline conditions, etc.) as well as battery-related damages will not be

covered by the warranty and after-sales support.

- The users will be notified by the company as soon as new software versions or product

upgrades are available, and proper assistance and service will be provided to implement the

updates.

- All technical processes and services, including production, periodic services, (re)calibrations,

and software and hardware upgrades for the company’s products are carried out exclusively

at the production or after-sales support units of HIGH SENSE SOLUTIONS Inc. or the its

officially licensed and authorized representatives. No other individual or company is

authorized to conduct the abovementioned services and doing so will render the warranty

and after-sales support rights null and void.

- By reading this, you affirm that you understand and accept all the terms, conditions, and

provisions of this document and the legal rights concerning the products of HIGH SENSE

SOLUTIONS Inc.

- For further information, or in case you have questions or need consultation, please contact

our sales department or legal office at the following:

HIGH SENSE SOLUTIONS Inc.

46 Long point Dr. Richmond Hill, Ontario, L4E 3W8, Canada

www.highsensesolutions.ca

[email protected]

Tel: +1 (905) 597 2341 Tel: +1 (647) 588 6020

Important Safety Information

IMPORTANT SAFETY INFORMATION

- The hardware manufacturing machines only function properly within the ranges defined in

their technical specifications such as electrical parameters, temperature, humidity, etc.

Therefore, do not operate them outside their working range or for undefined applications.

- When connected to AC power, the device’s battery chargers must always be plugged into

grounded outlets to ensure maximum safety.

- The device is equipped with rechargeable Li-ion batteries, but the batteries are not readily

accessible.

- The device’s battery charger is only meant to be used indoors.

- Prevent any mechanical shocks to the device or its accessories.

- In case the device slows down, the buttons fail to function, or the device stops working

altogether, execute the quick RESET mode. As may be seen on the panel behind the device,

in case of emergency, you can force shut down the device by simultaneously pressing the

three keys FILTER SCAN + HP + SWAP.

- Do not operate the device in extremely cold or hot temperatures.

- Do not leave the device exposed to direct and intense sunlight.

- Devices requiring the use of headphones to operate, expose the user to potential risks as the

headphones may reduce or eliminate essential ambient sounds –such as warnings –at the

workplace. Therefore, please ensure all safety requirements and conditions are in place

before making use of such devices.

- Recharge and maintain the device’s rechargeable batteries as soon as the batteries get

exhausted.

- Remove the non-rechargeable batteries after each instance of use.

- Cleanse and dry the device and its accessories after each instance of use.

- Whenever you come across this symbol in the user manuals provided by this

company, it is meant to warn of potential danger. Therefore, always be on the lookout for

such danger signs.

Features and Specifications

FEATURES AND SPECIFICATIONS

1. Amplification

59.0dB ± 3dB

2. Filters

HPF (100 Hz, 200 Hz, 400 Hz)

LPF (600 Hz, 800 Hz, 1200 Hz)

3. filteROT™

Function

Each filter runs for 5 seconds; filter selection using the MUTE key

4. Display

5” Color TFT, Sunlight readable (1000 nuts)

Equipped with a User-Friendly GUI

2 Languages (English + French/Spanish/Japanese/Persian/Turkish/Arabic)

Simultaneously display of Minimum and Mean signal strength numerically, on Bar-

graph and Line-graph

Date and Time (Real time internal clock) / Continuous GPS, Temperature and

Humidity Data

Battery level, Memory Capacity, Headphone Status, Connectors Status

5. Audio

8-ohm Stereophonic Wired Headphones

Supports Bluetooth Headphone

Supports Aviation Headphones

6. GPS

Internal GPS / CEP 2.5m, Refresh time 1 sec

7. Sensors

Headphones Connected/Disconnected Status Sensor

Geophone Connected/Disconnected Status Sensor

Temperature Sensor

Humidity Sensor

8. Internal Data

Logger

Total capacity: 1,200,000 data frames

Internal Memory: 30 Folders,

20 Projects per Folder

2000 data frames per project

9. Data Transfer

Equipped with Bluetooth® Data Transfer Technology

10. Smart Utility

Application

HSS Water Leak Detection Android APP

11. Operation

Temperature

-10°C to +55°C

12. Geophone

Sensor

Pick-Up Sensor 900 V/g or more (at 400 Hz)

IP67 equivalent (water depth 1m, 30 minutes)

Piezoelectric type

External dimensions: φ78 × 50mm (excluding cable section)

Weight: 580g

13. Battery

Li-ion 18650 rechargeable battery pack 3 x 3.7-3500mA

Smart Battery Management System

Sleep Mode, Power Saving Mode

14. Charger

Li-ion battery pack Fast charger

15. Carrying Case

Professional Waterproof and Shockproof Hard Case, NANUK 930

16. User Manual

Includes tips and guides

17. Warranty

One Year

18. After-sales

services

Five Years

Table of Contents

vii

Table of Contents
1INTRODUCTION....................................................................................................................... 1
1 PERIJA PLUS™ FEATURES AND SPECIFICATIONS .............................................................. 1
2 PERIJA PLUS™ Standard Accessories................................................................................ 2
3 PERIJA PLUS™ Optional Accessories................................................................................. 2
4 Hardware Overview ......................................................................................................... 3
2GETTING STARTED .................................................................................................................. 5
3GRAPHICAL USER INTERFACE (GUI) ........................................................................................ 8
1 General Form of Display................................................................................................... 8
2 Acoustic Water Leak Detector ......................................................................................... 9
3 Main Menu..................................................................................................................... 12
4 Time & Date Settings...................................................................................................... 13
5 Display ............................................................................................................................ 14
5.1 Brightness ............................................................................................................... 14
5.2 Language................................................................................................................. 15
6 File Management ........................................................................................................... 15
7 Options........................................................................................................................... 17
7.1 Inside Temperature Violation Alarm ...................................................................... 17
7.2 Inside Humidity Violation Alarm............................................................................. 17
7.3 Memory Capacity Alarm ......................................................................................... 18
7.4 Poor GPS Alarm....................................................................................................... 18
7.5 Smart Power Management..................................................................................... 18
7.6 Audio Alarm ............................................................................................................ 18
8 Bluetooth®...................................................................................................................... 18
8.1 Connecting to a New Device................................................................................... 19
8.2 Connecting to the Last Paired Device..................................................................... 20
9 Global Positioning System (GPS).................................................................................... 20
10 About the PERIJA PLUS™ Acoustic Leak Detector ...................................................... 21
10.1 System Info ............................................................................................................. 21
10.2 Leak Detection ........................................................................................................ 22
10.3 Contact Us............................................................................................................... 22
10.4 User Guide .............................................................................................................. 23
4LEAK DETECTION INSTRUCTIONS.......................................................................................... 24
1 The Relationship between Water Pressure and Leak Noise.......................................... 24
2 The Relationship between Propagation Distance and Leak Noise Intensity ................. 25
3 The Relationship between Leak noise and Burial Depth of Leaking Pipe...................... 25

Table of Contents

viii

4.4 Key Facts about Water Leak Noise................................................................................. 26
4.5 Disruptive Noise Sources Generating Sounds like Leak Noises ..................................... 26
4.6Standard Procedure of Leak Detection Survey .............................................................. 26
5Transferring Data from PERIJA Plus™ to HSS-APP Application............................................. 29
5.1 Transferring Single Project............................................................................................. 30
5.2 Transferring All Projects................................................................................................. 36
5.3 Deleting Single Project ................................................................................................... 36
5.4 Deleting All Projects ....................................................................................................... 37
6TROUBLESHOOT AND MAINTENANCE.................................................................................. 38






Introduction

1INTRODUCTION

The following user manual introduces the acoustic leak detection device PERIJA Plus™ whose

current embedded software version is P2011400A.

PERIJA Plus™ is an extremely accurate and sensitive water leak detector developed based on

acoustic technology which is used to detect leaks in all types of water pipe networks under

pressure. With a boot and survey time of just under one minute, the device can detect leaks

in metallic and non-metallic water pipe networks in both the main lines and branches. The

device is moreover suitable for use in industrial, urban, and rural environments.

1.1 PERIJA PLUS™ FEATURES AND SPECIFICATIONS

•5” TFT Color display with excellent visibility in direct sunlight

•Displaying data in English and French

•Additional option (per customer request) to display data in Arabic, Chinese, Japanese,

Persian, Turkish and Spanish

•Equipped with the powerful Fuji Tecom Inc. piezo-electric sensor (U.S.A. Patent

US5959210A)

•Broadband performance frequency from 100 to 1200 Hz, along with nine band-pass

filters

•Equipped with the filteROT™ mode to help select the best available sound filter in the

workplace

•Equipped with the GPS (global positioning system)

•Equipped with dedicated memory to save leak detection, system performance,

geographic data

•Ability to display the value of received audio signals instantaneously in the form of

simple numbers or bar-graphs

•Ability to measure and display minimum and maximum received signal while holding

the MUTE key in the form of bar-graphs or line-graphs

•Supports wired and Bluetooth® stereo headphones

•Equipped with the Bluetooth® technology to transfer the information to HSS Water

Leak Detection APP (Utility Smart Assistant)

•Ability to mark the discovered leak locations on the information and the option to only

transfer the information of discovered leaks to the Android application HSS-APP

•Equipped with inside temperature and humidity sensors, smart display brightness

control, and energy-saving mode

•Equipped with the emergency shutdown function

•Equipped with the wind noise reduction system

•Equipped with rechargeable batteries and a fast charger

•Equipped with Real-time date and time display

•Equipped with a user-friendly Graphical User Interface (GUI) to control the device’s

parameters and settings

Introduction

1.2 PERIJA PLUS™ Standard Accessories

•Main Unit of PERIJA PLUS™

•Hand Switch and Pick-Up Sensor

•Stereo Headphone

•Li-ion Battery Pack Fast Charger

•Main Unit Shoulder Strap

•Hard Carrying Case NANUK 930

•HSS Water Leak Detection (Android APP)

•User Guide

1.3 PERIJA PLUS™ Optional Accessories

•Aviation Headphone

•3 Pieces Steel Contact Rods

Inhaltsverzeichnis

Andere HSS Hire Sicherheitssensor Handbücher

HSS Hire

HSS Hire Life Line Bedienungsanleitung

Beliebte Sicherheitssensor Handbücher anderer Marken

THORLABS

THORLABS PDA10JT Bedienungsanleitung

Waeco

Waeco UV-DETECT Bedienungsanleitung

Intermatic

Intermatic IOS-DSIMF Bedienungsanleitung

urmet domus

urmet domus 1083 Bedienungsanleitung

Siemens

Siemens AZL66 Series Bedienungsanleitung

BTI

BTI Profiline Multi Finder Bedienungsanleitung

Challenger

Challenger SL01 Bedienungsanleitung

DMP Electronics

DMP Electronics 1122INT Bedienungsanleitung

Rielta

Rielta Ladoga MK-RK Bedienungsanleitung

Mirion Technologies

Mirion Technologies ACCURAD PRD Bedienungsanleitung

Bosch

Bosch DS835 Bedienungsanleitung

DBI SALA

DBI SALA EZ Stop Bedienerhandbuch

Lamptime

Lamptime ST05C Bedienungsanleitung

Ubiquiti

Ubiquiti MFI-MSC Bedienungsanleitung

Subsite

Subsite 910R Montageanleitung

Satel

Satel OPAL Pro Bedienungsanleitung

Aleph

Aleph XC-1XTEU Bedienungsanleitung

Pima

Pima LARIS QUAD Bedienungsanleitung
