LyncTouch Installation

and User Manual

V.10.17.2019

LyncTouch is a combination touch-screen and keypad controller that can be installed before or after you

have the rest of your system set up and controllable via the HTD Lync app.

Getting started with LyncTouch when you are already controlling the system via the HTD Lync app:

1. Power off all zones. This is most easily accomplished from a single button on the app.

2. Power off the amplier(s). If your system was installed using the recommended Trigger feature,

step 1. should also put your multi-channel amplier(s) into stand-by mode. If instead, your amplier(s)

is set to always be powered on, then you will need to power off each amplier using the button on

the front. It is not necessary to press the power button on the front of the amplier if it is already in

stand-by mode.

3. Power off your central Lync controller (model Lync 6 or Lync 12) using the power button on the front.

4. Install each LyncTouch following the directions below on page 2.

5. After all LyncTouch have been installed, power on the Lync controller by pressing the button on the

front. It is at this point that the Lync controller searches for connected devices. Devices are only

recognized by the system when the Lync controller is rst powered on. If your amplier(s) was left

powered on and in stand-by mode that is all you need to do. If the power button on the front of your

amplier was previously turned off (out position), then press it back in.

Using LyncTouch with a Lync system that is being set up for the rst time:

1. Follow the instructions provided with your system to connect cables between the central Lync

controller and amplier(s) and between the amplier(s) and your speakers.

2. Make sure the amplier(s) and Lync Controller are powered off using the button on the front. It is

not necessary to press the power button on the front of the amplier if it is already in stand-by mode.

3. Install each LyncTouch following the directions below on page 2.

4. After all LyncTouch have been installed, power on the Lync controller by pressing the button on the

front. It is at this point that the Lync controller searches for connected devices. Devices are only

recognized by the system when the Lync controller is rst powered on. Similarly press the button on

the front of each amplier to turn it on.

Overview of how to install a LyncTouch:

We have made installing LyncTouch super easy with our patent-pending design. The enclosure on

the backside of the LyncTouch has been matched in size to a custom-made metal ring that you install

into a at surface, typically a wall. Once installed, you simply plug the Cat 5 or Cat 6 cable (already

terminated with an RJ45 connector) into either of the RJ45 ports on the back of the LyncTouch and push

the LyncTouch in until it is ush with the wall. Strong, neodymium magnets mounted to either side of the

LyncTouch enclosure adhere to the metal ring and keep it in place.

Installing and Connecting

Mounting into a wall using a low-voltage mounting bracket or junction box

When installing into a wall, we recommend using an OPEN BACK Junction Box or Low-Voltage Mounting

Ring. It is important that the LyncTouch be able to slide easily into the available space. This means

keeping the space clear of debris and unnecessary cables and connectors. The cable(s) that connects

to the back of the LyncTouch needs to be able to move freely in and out of the space. If your junction box

or mounting bracket includes a back that is inhibiting the free movement of your cable(s), we recommend

using a rotary (or similar) tool to cut out or widen the opening through which the cable moves. Keep

in mind that most building codes only require a closed back junction box for low voltage items such as

LyncTouch when they are installed into a wall where the adjoining space is not conditioned, such as an

attic or exterior wall.

Mounting into a Surface without a Junction Box or Low-Voltage Mounting Ring

LyncTouch can also be mounted directly into a at surface without the need for a junction box or low-

voltage mounting ring. This method is not recommended for dry-wall, but works well with hard surfaces

like wood. For this type of installation, HTD relies on the customer to determine what type of fastener

(e.g. wood screw) will work best with their surface.

Recommended Mounting Height

Unlike a light switch which is often positioned about four feet from the oor, LyncTouch is best mounted

slightly below eye level. This places LyncTouch in the most ergonomic position for the touch-screen

display. Whenever possible, avoid placing LyncTouch within the same stud space as electrical cables

operating at high voltage in order to mitigate the potential of adding electrical noise into your system.

~4 ft.

Light

switch

LyncT

ouch

Connecting a Standard Input Panel

A Standard Input Panel (SIP) offers an easy and economical

connection point for attaching an audio source component within

the same room as the LyncTouch. That source can then be

made available to every zone. The SIP connects to the back of a

LyncTouch using 5 of the 8 conductors found in a Cat cable and

a special 5-pin adapter included with the SIP. That adapter plugs

into the white connector shown in the image at right. A SIP can be

installed directly next to the LyncTouch or up to 80 feet away.

Connecting an Analog Input Panel (AIP), Digital Input Panel (DIP) or Bluetooth Input Panel (BIP)

These three active devices can be connected directly to the central Lync controller or to the back of a

LyncTouch using the available RJ45 port. When this is done, be sure to insert an RJ45 termination plug

included with every LyncTouch, AIP, DIP, and BIP into any open port to ensure proper operation.

Connecting a second LyncTouch within the same zone

In larger rooms, it is often convenient to install more than one LyncTouch. Similar to adding an AIP, DIP,

or BIP (see above), a second LyncTouch can be connected to the open port on the rst LyncTouch or

back at the central Lync controller with a special “Y” adapter (call for more info). When this is done, be

sure to insert an RJ45 termination plug included with every LyncTouch, AIP, DIP, and BIP into any open

port to ensure proper operation. Also to ensure proper operation, the “address” of the rst and second

LyncTouch need to be unique. See “Address” on page 5 for more information.

LyncTouch (Back)

LyncTouch (Back) Analog Input Panel (AIP) Digital Input Panel (DIP) Bluetooth Input Panel (BIP) RJ45 Terminator

To central

Lync Controller

RJ45 Terminator

Key Features of the LyncTouch User Interface

LyncTouch is primarily used to control the zone to which it is connected. A

handful of simple commands can also be applied across all zones at once,

including power all off and party mode.

The user interface consists of:

• a 3.5” diagonal color touchscreen display

• 3 tactile buttons:

Power Button

Quick Key (Favorite) Button

Talk Button

• 2 microphones (only active while the Talk Button is pressed)

Power Button

As its name implies, the Power Button is primarily used to turn a

zone on and off, but it can also be used to quickly mute the volume

within the zone and power off all zones.

Power On – when a zone is OFF, a quick press of the Power Button will

turn it ON

Mute – when a zone is ON, a quick press of the Power Button will mute the volume in the zone. Press the

Power Button again to un-mute.

Power Off – when a zone is ON, it can be powered OFF by pressing the Power Button for approximately 1

second. Once turned off, LyncTouch will display “OFF”. Release the Power Button.

Power Off All Zones – when a zone is ON, press and hold the Power Button for approximately 3 seconds.

The display will rst display “OFF” followed by “ALL ZONES OFF”. Release the Power Button.

Quick Key

The Quick Key is a button you can customize to allow a single button press to turn on the zone and

then activate up to two separate ACTIONS. The most common use of the Quick Key is to turn on a

zone and set it to your favorite source [ACTION 1] at your favorite volume [ACTION 2]. Alternative actions

include Power Off, All Zones Off, DND (Do Not Disturb) On, and DND Off.

Talk Button

Press and hold the talk button to talk into any single zone OR all zones that are currently powered on.

Read more under the heading: Using the Intercom.

DND – Do Not Disturb. When selected, global commands such as ALL OFF, Intercom ALL, and Party Mode

will be ignored.

Intercom – Touch this area to select a zone in which to intercom. Read more under the heading, “Using

the Intercom”

Party – Party Mode. When selected, all zones not currently in DND will be powered on and set to the

source currently selected for this zone. Prior to executing this command, a message will rst appear

requiring conrmation of this action.

Source Name/Change Source – Touch this area to select a source from a list of all available sources.

Volume Bar – Control volume dynamically by sliding your nger along the slider bar or by pressing and

holding the volume up or volume down icons. Incrementally adjust volume by tapping on the volume up or

volume down icons.

Custom Settings

***To enter setup mode, press and hold the Quick Key Button for approximately 3 seconds.***

Bass – press the “minus” and “plus” buttons to decrease/increase the

amount of bass in the zone. This adjustment can also be made within the

HTD Lync app. The default and most common setting is “0”.

Treble – press the “minus” and “plus” buttons to decrease/increase the

amount of treble in the zone. This adjustment can also be made within the

HTD Lync app. The default and most common setting is “0”.

Balance – press the “minus” and “plus” buttons to transfer the relative

volume level between Left (minus) and Right (plus). This adjustment can

also be made within the HTD Lync app. The default and most common

setting is “0”. Balance is only adjusted in rare circumstances where a

room has an odd shape and/or speakers are not evenly located.

Address – To ensure proper operation, every active device (LyncTouch,

AIP, DIP, BIP) installed within the same zone needs to be assigned a unique

Address (sometimes called ID). LyncTouch should remain at the default

of “0” unless a second LyncTouch is installed. The second LyncTouch

should be assigned to an address of 1, 2, 3, or 4 just as long as it does

not match the address used by an AIP, DIP, or BIP (which similarly are

assigned an address of 1, 2, 3, or 4) that is installed within the same zone.

Customize how the display behaves when active and in stand-by

Level on – The brightness level on a scale of 1 to 5 (brightest) of the

touchscreen display when the LyncTouch is being used. The default and

most common setting is “3”.

Level sleep – The brightness level on a scale of 1 to 5 (brightest) or

completely “Off” when the zone is turned on but the LyncTouch is not

actively being used. The default and most common setting is “Off”.

Text – The color of text that can be changed. Note that some text is

always white or gray and will not change based on this setting. The default

text color is white.

Accent – The accent color displayed throughout screen pages. The

default accent color is blue.

Auto Wake – When set to “Off” (default), the LyncTouch display will not

light up (wake up) when changes to the zone are made by the HTD Lync

app or another LyncTouch installed within the same zone. When set to

“On”, the display will wake up with any adjustments made to the zone.

Sleep Time – Determines the number of seconds the screen will stay at the “Level On” brightness level

after no interaction with the LyncTouch before returning to the “Level Sleep” setting. Available in 5 second

increments between 5 and 60. 15 is the default.

Main Settings Screen

Screen Settings

Screen

Customize the favorite (heart) button. Actions assigned here will be executed with a

single press of the Quick Key button.

Action 1 – press the rst pair of “minus” and “plus” buttons to toggle

between your options for the rst action. When “Source” is selected, use

the second pair of “minus” and “plus” buttons to select from your available

sources; when “Volume” is selected, use the second pair of “minus” and

“plus” buttons to set a volume level between 1 and 60 (max).

Action 2 – As long as an action other than “None” has been assigned to

Action 1, Action 2 will also be executed when pressing the Quick Key. The

same options found in Action 1 are available for Action 2.

Occasionally, HTD may elect to provide an update to the rmware on the LyncTouch. Use

this screen to temporarily connect to your own private WiFi network with internet access

in order to check for the availability of new rmware and to update the rmware when

available. The LyncTouch will only maintain connection to your WiFi network when you turn WiFi on and

continue to stay on this screen. Once you exit this screen, the LyncTouch will automatically disconnect from

your network.

Updating the Firmware

Step 1. Press “Wi: Off” to turn on the WiFi chip embedded in LyncTouch.

The screen will display “WiFi: Started . . .”. If you have previously connected

the LyncTouch to your WiFi network, then “Wi: Connected” should appear

and you can skip to Step 4. If your LyncTouch has never been connected

to your WiFi network or it does not detect the network to which it was

previously attached, it will display “WiFi: AP Mode”. When you see this,

proceed to Step 2.

Step 2. AP Mode. In this mode, LyncTouch is broadcasting its own WiFi

network and is ready to be connected to your existing private network.

Open a mobile device near the LyncTouch and look for a WiFi network

called “LyncTouch-X” where “X” represents the zone number in which

the LyncTouch is attached. Connect to that network. A page should

automatically appear on your mobile device titled, “LyncTouch WiFi Setup

Wizard”. [note: if this page does not automatically appear, type 192.168.4.1

into the address bar of your browser]

Step 3. Press SCAN and select your private network. Enter and save the password for this network. At

this point, LyncTouch will display “WiFi: Starting . . .” and your mobile device will be disconnected from the

LyncTouch-X network. If successful, the display will change to “WiFi: Connected” and you can proceed to

Back

Source

Patio TV

Quick Key Settings

Update Settings

Quick Key

Update

Step 4. If the LyncTouch returns to “WiFi: AP Mode”, then the LyncTouch did not successfully attach to your

network. Return to Step 2 and try again, paying close attention to the password entered.

Step 4. Once the LyncTouch is connected to your private WiFi network, it will search the HTD secure cloud

to check for the most current rmware. If your LyncTouch rmware matches the current rmware, the screen

will display “Keypad at Latest Version” and you can press the back button to return to the setup screen. At

this point, the LyncTouch WiFi chip will turn off and you are done. If instead you see the message “Update

Firmware” in red, proceed to Step 5.

Step 5. If a newer version is available than is currently installed on the LyncTouch, press “Update Firmware”

to start the process of updating the rmware from our secure cloud. This process typically takes a minute

or two but can take up to 10 minutes depending on the strength of your WiFi signal and your internet

connection speed. Once updated, the LyncTouch will automatically turn off its WiFi chip and restart to

complete the rmware update process. A message will display telling you to power cycle the central Lync

controller. At this point, it is recommended that you move to the next LyncTouch so that you only need to

power cycle the central Lync controller one time after all have been updated.

Press to temporarily disable touch on the display, allowing 30 seconds to clean the screen

using a micro-ber cloth (we include one for free with every order).

Using the Intercom

Step 1. To initiate an intercom call, touch the intercom icon at the top of the screen. A list of available zones

will appear.

Step 2. Select the zone in which you want to intercom. If that zone is currently powered off or in DND mode,

you will be asked if you would like to turn the zone on or override DND.

Step 3. Press and hold the Talk button while you speak into the zone. Any source currently playing in your

zone as well as the receiving zone will be muted while the Talk button is depressed. Your voice will be heard

over the speakers located in that zone, but not in your own.

Step 4. The screen on the LyncTouch located in the receiving zone will display the zone from which the

intercom call was initiated. Press and hold the Talk button in that zone to talk back to the initiating zone.

It is possible to start an intercom call into “All Zones”. When this option is selected, only zones

currently powered on and not in DND mode will hear the call. The rst zone to answer the call will

at that point be placed in a one-to-one intercom call with the initiating zone.

Note that the only way to listen to another zone is while the Talk button is depressed from within

that zone. In this way, it is not possible to eaves drop on a zone.

Clean

Intercom with Front/Back Door - Applies only if you have the Door Interface module (DI-21) and a Door

Station at the Front and/or Back Door.

When a visitor presses the doorbell button, all zones will hear the door sound le for that door station.

Note that Lync V3 controllers can be customized using the HTD Lync app to only ring into specic zones,

leaving other zones undisturbed. The rst zone to answer the ring by pressing the Talk button will be placed

in one-to-one communication with the door station. Releasing the Talk button allows you to hear what is

occurring at the door, i.e. the visitor cannot press anything to talk into the house. Press “End Call” to end

communication with the door.

Front Door and Back Door are also displayed as an option in the list of available zones. You can initiate a

call to either the front door or back door by simply selecting it from the list. Similarly, you can monitor what

is occurring at the door by selecting it and then pressing the Talk button for approximately one second and

releasing.

Customize zone and source names with the HTD Lync app

Zone names will default to Zone 1, Zone 2, etc. and Source names will default to Source 1, Source 2, etc.,

but can easily be changed to match your zones and sources using the free HTD Lync app which is available

for iOS and Android. Edit the elds for KEYPAD ZONE NAME and KEYPAD SOURCE NAME to customize

what appears (max 10 characters) on LyncTouch.

Twist-apart spacers

On the rare occasion that you are installing into an existing

junction box where the hole was cut with an opening taller

than the height of our custom metal bracket, you can use

these bright green “spacers” to ensure that the metal bracket

is secure and ush with the wall (or slightly recessed into the

wall). Install 1 to 4 of these spacers as needed for both the

top and bottom screws to ll the space between the metal

bracket and the wall surface.

For LyncTouch to install properly, the metal bracket can

be recessed up to 1/4 inch behind the surface of the

drywall and should never protrude beyond the surface

of the wall. The spacer strip can be twisted apart where

needed and folded and snapped together in a similar fashion

as Legos. Visit this webpage for more details: https://www.

gardnerbender.com/en/p/GSP-24/Spacers-Twist-apart-4-

inch

Wall

Junction

Box

Spacers

Wall

Metal

Ring

Home Theater Direct, Inc.

www.htd.com

Expert Support

M-F 8am-6pm CST

Toll free: 866-HTD-AUDIO (483-2834)

[email protected]

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HTD Controller Handbücher

HTD

HTD MC-66 Multi-Zone Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
