Huawei G1000PLUS Bedienungsanleitung
G1000PLUS
GSM Mobile Phone
User Guide
Copyright © Huawei Technologies Co., Ltd. 2011. All
rights reserved.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
i
Contents
Your Phone ..........................................................................1
Keys and Functions...............................................................2
Screen Icons.........................................................................4
Installing the SIM Card and the Battery .................................5
Removing the Battery and the SIM Card................................5
Charging the Battery ............................................................6
Navigating the Main Menu...................................................6
Making a Call.......................................................................7
Answering a Call ..................................................................7
Phone Lock ..........................................................................7
PIN and PUK ........................................................................8
Locking and Unlocking the Keypad .......................................8
Changing the Text Input Mode .............................................8
Entering a Word...................................................................9
Entering a Digit ..................................................................10
Entering a Symbol ..............................................................10
Flashlight (Optional) ...........................................................10
FM Radio (Optional) ...........................................................11
Warnings and Precautions ..................................................12
1
Features marked with “Optional” are optional and may vary
with phone models.
Your Phone
The following figure shows the appearance of your phone.
1 Earpiece 7 Flashlight
2 Screen 8 #key
3 Left soft key 9 Number keys
4 Navigation keys 10 End/Power key
5 Call/Answer key 11 Right soft key
6 * key 12 Charger jack
2
Keys and Functions
Press… To…
Make a call.
Answer a call.
View Dialed calls in standby mode.
Power the phone on or off (press and hold the key
for about 3 seconds).
End or reject a call.
Return to standby mode.
Access Menu in standby mode.
Select the highlighted item.
Access Contacts in standby mode.
Return to the previous menu.
3
Press… To…
Turn the Flashlight on (press and hold for
about 3 seconds or press twice in standby
mode).
Turn the Flashlight off (press ).
Access Alarm clock (press ) in standby
mode.
Access Call Records (press ) in standby mode.
Access Calculator (press ) in standby mode.
Increase the volume (press ) during a call.
Decrease the volume (press ) during a call.
through
Enter numbers, letters, and symbols.
Enter +in standby mode (press and hold the 0key
for about 3 seconds).
Call voicemail in standby mode (press and hold the
1key for about 3 seconds).
Speed-dial phone numbers in standby mode (press
and hold the 2–9keys for about 3 seconds).
Select an option labeled with the corresponding
number.
4
Press… To…
Enter *(press the key) or P (press and hold the key)
in standby mode.
Display the symbol list in editing mode.
Enter #.
Lock the keypad in standby mode (press and hold
the key for about 3 seconds).
Switch between text input methods in editing
mode.
Screen Icons
Icon Indicates…
Signal strength.
New text messages.
Roaming.
Call forwarding enabled.
Alarms enabled.
Keypad locked.
Battery level.
Standard profile activated.
Conference profile activated.
Outdoor profile activated.
5
Mute profile activated.
Customize profile activated.
Frequency modulation (FM) radio turned on.
Missed calls.
Installing the SIM Card and the Battery
Before installing the subscriber identity module (SIM) card, ensure
that your phone is powered off.
When installing the SIM card, ensure that the gold contact area faces
down, and that the beveled edge of the SIM card aligns with that of
the SIM card slot.
Removing the Battery and the SIM Card
Before removing the battery and the SIM card, ensure that your
phone is powered off.
6
If your phone does not work properly or if crashes occur,
press the battery reset button on the right of the SIM card
slot, and then press and hold for about 3 seconds
until the phone is powered on again.
Charging the Battery
1. Connect the small end of the universal serial bus (USB) cable to
the phone's charger jack and the larger end to the charger.
2. Connect the charger to a power socket.
3. Wait until the battery is completely charged.
While the battery is charging, the charging icon blinks. When the
charging icon stops blinking, the battery is fully charged.
4. Unplug the charger from the power socket and the USB cable
from the phone.
Navigating the Main Menu
1. In standby mode, press (Menu).
2. Press to scroll to the desired application and press
(Select) to access the application.
3. Press the number key labeled with the serial number of the
desired option, or press or to scroll to the
desired option, and then press (Select) to access the
option.
4. Press (Back) to return to the previous menu.
To return to the standby mode, press .
7
Making a Call
1. In standby mode, enter the phone number.
To make an international call, press and hold to enter the
plus sign (+). Then enter the country or region code, area code,
and phone number.
To call an extension number, enter the phone number, press and
hold to enter P, and enter the extension number.
2. Press to dial the number.
3. Press to end the call.
You can also make a call from the call log, contacts, or
messaging screen.
During a call, you can press or to adjust the
volume.
Answering a Call
When there is an incoming call, you can:
Press to answer the call.
Press (Options) and select Accept to answer the call.
Press (Reject) or to reject the call.
If the Any key answer function is enabled, you can press any key
except and to answer a call.
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. Once the phone lock is enabled,
