Huawei G1000PLUS Bedienungsanleitung

G1000PLUS

GSM Mobile Phone

User Guide

rights reserved.

Trademarks and Permissions

, , and are trademarks or registered

trademarks of Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned

are the property of their respective owners.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT

AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY

KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED

TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE

ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO

CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY

SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,

OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR

ANTICIPATED SAVINGS.

Contents

Your Phone ..........................................................................1

Keys and Functions...............................................................2

Screen Icons.........................................................................4

Installing the SIM Card and the Battery .................................5

Removing the Battery and the SIM Card................................5

Charging the Battery ............................................................6

Navigating the Main Menu...................................................6

Making a Call.......................................................................7

Answering a Call ..................................................................7

Phone Lock ..........................................................................7

PIN and PUK ........................................................................8

Locking and Unlocking the Keypad .......................................8

Changing the Text Input Mode .............................................8

Entering a Word...................................................................9

Entering a Digit ..................................................................10

Entering a Symbol ..............................................................10

Flashlight (Optional) ...........................................................10

FM Radio (Optional) ...........................................................11

Warnings and Precautions ..................................................12

Features marked with “Optional” are optional and may vary

with phone models.

Your Phone

The following figure shows the appearance of your phone.

1 Earpiece 7 Flashlight

2 Screen 8 #key

3 Left soft key 9 Number keys

4 Navigation keys 10 End/Power key

5 Call/Answer key 11 Right soft key

6 * key 12 Charger jack

Keys and Functions

Press… To…

Make a call.

Answer a call.

View Dialed calls in standby mode.

Power the phone on or off (press and hold the key

for about 3 seconds).

End or reject a call.

Return to standby mode.

Access Menu in standby mode.

Select the highlighted item.

Access Contacts in standby mode.

Return to the previous menu.

Press… To…

Turn the Flashlight on (press and hold for

about 3 seconds or press twice in standby

mode).

Turn the Flashlight off (press ).

Access Alarm clock (press ) in standby

mode.

Access Call Records (press ) in standby mode.

Access Calculator (press ) in standby mode.

Increase the volume (press ) during a call.

Decrease the volume (press ) during a call.

through

Enter numbers, letters, and symbols.

Enter +in standby mode (press and hold the 0key

for about 3 seconds).

Call voicemail in standby mode (press and hold the

1key for about 3 seconds).

Speed-dial phone numbers in standby mode (press

and hold the 2–9keys for about 3 seconds).

Select an option labeled with the corresponding

number.

Press… To…

Enter *(press the key) or P (press and hold the key)

in standby mode.

Display the symbol list in editing mode.

Enter #.

Lock the keypad in standby mode (press and hold

the key for about 3 seconds).

Switch between text input methods in editing

mode.

Screen Icons

Icon Indicates…

Signal strength.

New text messages.

Roaming.

Call forwarding enabled.

Alarms enabled.

Keypad locked.

Battery level.

Standard profile activated.

Conference profile activated.

Outdoor profile activated.

Mute profile activated.

Customize profile activated.

Frequency modulation (FM) radio turned on.

Missed calls.

Installing the SIM Card and the Battery

Before installing the subscriber identity module (SIM) card, ensure

that your phone is powered off.

When installing the SIM card, ensure that the gold contact area faces

down, and that the beveled edge of the SIM card aligns with that of

the SIM card slot.

Removing the Battery and the SIM Card

Before removing the battery and the SIM card, ensure that your

phone is powered off.

If your phone does not work properly or if crashes occur,

press the battery reset button on the right of the SIM card

slot, and then press and hold for about 3 seconds

until the phone is powered on again.

Charging the Battery

1. Connect the small end of the universal serial bus (USB) cable to

the phone's charger jack and the larger end to the charger.

2. Connect the charger to a power socket.

3. Wait until the battery is completely charged.

While the battery is charging, the charging icon blinks. When the

charging icon stops blinking, the battery is fully charged.

4. Unplug the charger from the power socket and the USB cable

from the phone.

Navigating the Main Menu

1. In standby mode, press (Menu).

2. Press to scroll to the desired application and press

(Select) to access the application.

3. Press the number key labeled with the serial number of the

desired option, or press or to scroll to the

desired option, and then press (Select) to access the

option.

4. Press (Back) to return to the previous menu.

To return to the standby mode, press .

Making a Call

1. In standby mode, enter the phone number.

To make an international call, press and hold to enter the

plus sign (+). Then enter the country or region code, area code,

and phone number.

To call an extension number, enter the phone number, press and

hold to enter P, and enter the extension number.

2. Press to dial the number.

3. Press to end the call.

You can also make a call from the call log, contacts, or

messaging screen.

During a call, you can press or to adjust the

volume.

Answering a Call

When there is an incoming call, you can:

Press to answer the call.

Press (Options) and select Accept to answer the call.

Press (Reject) or to reject the call.

If the Any key answer function is enabled, you can press any key

except and to answer a call.

Phone Lock

The phone lock protects your phone from unauthorized use. By

default, the phone lock is disabled. Once the phone lock is enabled,
