Huawei G2802 Bedienungsanleitung
G2802
GSM Mobile Phone
User Guide
Copyright © Huawei Technologies Co., Ltd. 2012.
All rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
1
Features marked with "optional" are optional. These
features may vary according to service providers. For
details, contact your service provider.
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone and
is provided for your reference only.
1
2
3
8
5
4
11
12
79
10
6
2
1 Earpiece 7 Microphone
2 Charger/Headset 8 Torch
3 Screen 9 Number keys
4 Navigation keys 10 End/Power key
5 Left soft key 11 Right soft key
6 Call
/
Answer key 12 Confirm key
Keys and Functions
Press … To …
zMake a call.
zAnswer an incoming call.
zView call logs in standby mode.
zPower the phone on or off (press and hold the
key for about 3 seconds).
zEnd or reject a call.
zReturn to standby mode.
Select the option displayed in the lower left corner
of the screen.
Select the option displayed in the lower right
corner of the screen.
zAccess the main menu in standby mode.
zConfirm a selection.
3
Press … To …
zAccess the functions assigned to the navigation
keys in standby mode.
zCustomize the functions assigned to the
navigation keys, select Menu > Settings >
Phone settings > Direction key setup.
–
zEnter numbers, letters, and symbols.
zCall voicemail in standby mode (press and hold
the 1key for about 3 seconds).
zSpeed-dial phone numbers in standby mode
(press and hold the 2–9keys for about 3
seconds).
zSelect an option labeled with the corresponding
number.
zEnter * (press the key once), + (press the key
twice), P (press the key three times), and W
(press the key four times) in standby mode.
zDisplay the symbol list in editing mode.
zTurn the torch on or off in standby mode (press
and hold the key for about 3 seconds).
zEnter #.
zSwitch between text input methods in editing
mode.
zLock the keypad in standby mode (press and
hold the key for about 3 seconds).
4
Screen Icons
Icon Indicates …
Signal strength.
General Packet Radio Service (GPRS) signal.
The alert type is Ring only.
The alert type is Vib. only.
The alert type is Vib. and ring.
The alert type is Vib. then ring
The alert type is Silence.
The earphone is plugged (Optional).
Missed calls.
Call forwarding enabled.
New text messages.
New multimedia messages.
Alarms activated.
Keypad locked.
Battery level.
5
2 Getting Started
Installing the SIM Card and the Battery
When installing a SIM card, ensure that the gold contact area
faces down, and that the beveled edge of the SIM card aligns
with that of the SIM card slot.
Before removing the battery and the SIM card, ensure that your
phone is powered off.
Installing a microSD Card
6
Charging the Battery
1. Connect the charger to an AC power socket.
2. Connect the charger to the phone's charger jack.
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon blinks. When
the charging icon stops blinking, the battery is fully charged.
When you charge a completely exhausted battery, the
charging icon may appear several minutes later.
4. Disconnect the charger from the phone.
5. Disconnect the charger from the AC power socket.
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. You can change the preset
phone unlock code (1234) to any number of four to eight
digits.
If you forget the phone unlock code, contact your service
provider.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use. The PIN unblocking key (PUK)
unlocks a blocked PIN. Both the PIN and the PUK are provided
with the SIM card. For details, contact your service provider.
If you enter the incorrect PIN a specified number of times, the
phone prompts you to enter the PUK.
7
If you enter the incorrect PUK a specified number of times, the
SIM card will become permanently invalid. If this occurs,
contact your service provider for a new SIM card.
Locking and Unlocking the Keypad
To lock the keypad, press and hold for about 3 seconds
in standby mode. To unlock the keypad, press
(Unlock) then in quick succession.
If the Auto keypad lock function is enabled, the phone will
lock the keypad automatically after being idle in standby mode
for a pre-defined period.
When the keypad is locked, you can press to
answer a call or make an emergency call.
3 Voice Services
Making a Call
1. In standby mode, enter a phone number.
zTo make an international call, press twice to enter
the plus sign (+). Then enter the country code or region
code, area code, and phone number.
8
zTo call an extension, enter the phone number, press
three times to enter P, and enter the extension number.
2. Press to dial the number.
3. Press to end the call.
zYou can also make a call from call logs, contacts, and
messages.
zDuring a call, you can press or to
adjust the in-call volume.
Answering a Call
When there is an incoming call:
zPress to answer the call.
zPress to reject the call.
zPress (Mute) to mute the speaker, and then press
(Reject) to reject the call.
If the Any key answer function is enabled, you can press any
key except and to answer a call.
