Huawei G2802S Bedienungsanleitung
G2802S
GSM Mobile Phone
User Guide
Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
No part of this document may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd. and possible
licensors. Customers shall not in any manner reproduce,
distribute, modify, decompile, disassemble, decrypt, extract,
reverse engineer, lease, assign, or sublicense the said software,
unless such restrictions are prohibited by applicable laws or
such actions are approved by respective copyright holders
under licenses.
Trademarks and Permissions
, HUAWEI, and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, products, services, and company names
mentioned are the property of their respective owners.
Notice
Some features of the product and its accessories described
herein rely on the software installed, capacities and settings of
the local network, and may not be activated or may be limited
by local network operators or network service providers. Thus,
the descriptions herein may not exactly match the product or
its accessories you purchase.
Huawei Technologies Co., Ltd. reserves the right to change or
modify any information or specifications contained in this
manual without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import
laws and regulations and will obtain all necessary governmental
permits and licenses in order to export, re-export or import the
product mentioned in this manual including the software and
technical data therein.
i
Table of Contents
1 Getting to Know Your Phone................................................1
Your Phone ........................................................................................... 1
Keys and Functions ........................................................................... 2
Screen Icons......................................................................................... 4
2 Getting Started .......................................................................5
Installing the SIM Cards and the Battery................................. 5
Installing a microSD Card............................................................... 6
Charging the Battery........................................................................ 6
Phone Lock........................................................................................... 7
PIN and PUK ........................................................................................ 7
Locking and Unlocking the Keypad........................................... 7
3 Voice Services .........................................................................8
Making a Call....................................................................................... 8
Answering a Call................................................................................. 9
4 Text Input ............................................................................. 10
Changing the Text Input Mode..................................................10
Entering a Letter...............................................................................11
Entering a Digit.................................................................................11
Entering a Symbol ...........................................................................11
5 Messaging ............................................................................ 11
Sending a Text Message ............................................................... 11
ii
6 Phonebook ........................................................................... 12
Creating a Contact ..........................................................................12
Searching for a Contact ................................................................12
7 Audio Player......................................................................... 12
8 FM Radio............................................................................... 13
9 Warnings and Precautions ................................................. 14
1
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone and
is provided for your reference only.
9
10
11
12
1
2
3
4
5
6
7
8
2
1 Earpiece 7 Microphone
2 Charger/Headset interface 8 Torch
3 Screen 9 Number keys
4 Navigation keys 10 End/Power key
5 Left soft key 11 Right soft key
6 Call/Answer key 12 Confirm key
Keys and Functions
Press … To …
zMake a call.
zAnswer an incoming call.
zView call logs in standby mode.
zPower the phone on or off (press and hold the
key for about 3 seconds).
zEnd or reject a call.
zReturn to standby mode.
Select the option displayed in the lower left corner
of the screen.
Select the option displayed in the lower right
corner of the screen.
zAccess the main menu in standby mode.
zConfirm a selection.
3
Press … To …
Access the functions assigned to the navigation
keys in standby mode.
To customize the functions assigned to the
navigation keys, select Menu > Settings > Phone
settings >Shortcuts > Dedicated key.
–
zEnter numbers, letters, and symbols.
zCall voicemail in standby mode (press and hold
the 1key for about 3 seconds).
zSpeed-dial phone numbers in standby mode
(press and hold the 2–9keys for about 3
seconds).
zSelect an option labeled with the corresponding
number.
zEnter * (press the key once), + (press the key
twice), P (press the key three times), and W
(press the key four times) in standby mode.
zDisplay the symbol list in editing mode.
zTurn the torch on or off in standby mode (press
and hold the key for about 3 seconds).
zEnter #.
zSwitch between text input methods in editing
mode.
zLock the keypad in standby mode (press and
hold the key for about 3 seconds).
4
Screen Icons
Icon Indicates …
Signal strength.
The alert type is Ring.
The alert type is Vibrate only.
The alert type is Vibrate and ring.
The alert type is Vibrate then ring
The alert type is Silent.
Headset profile activated.
Missed calls.
Call forwarding enabled.
New text messages.
Alarms activated.
Keypad locked.
Battery level.
5
2 Getting Started
Installing the SIM Card and the Battery
When installing a SIM card, ensure that the gold contact area
faces down, and that the beveled edge of the SIM card aligns
with that of the SIM card slot.
Before removing the battery and the SIM card, ensure that your
phone is powered off.
